Connections (Optional)
English
Connecting a VCR or
Cable/Satellite Box
AUDIO
OUT
S-VIDEO
IN
VIDEO IN
SCART IN
1
~ AC MAINS
VCR or Cable/
Satellite Box
FM/MW ANTENNA
L
L
R
R
2
4
3
Viewing and listening to the
Using the VCR for recording DVD
playback
playback
1 Connect the VCR or Cable/Satellite Box
Some DVDs are copy-protected. You
to the TV as shown.
cannot record or dub protected discs
using a VCR.
2 Connect the DVD system’s AUX IN
(R/L) jacks to the AUDIO OUT jacks on
3 Connect the DVD system’s S-VIDEO
the VCR or cable/satellite box.
jack to the S-VIDEO IN jack on the VCR.
Before starting operation, press AUX/DI
4 Connect the DVD system’s LINE OUT
on the remote to select “AUX” in order
(R/L) jacks to the AUDIO IN jacks on
to activate the input source.
the VCR.
This will allow you to make analogue
stereo (two channel, right and left)
recordings.
To view DVD playback while
recording,
you must connect the DVD system to
your TV using SCART (as shown above)
connection.
12
3139 115 22871
001-041-LX39-22-Eng1 12/12/2003, 10:20 AM12
Connections (Optional)
Connecting digital audio
equipment
English
(for example)
CD Recorder
L
L
R
R
Listening to the playback
● Connect the DVD system’s DIGITAL
IN jack to the DIGITAL OUT jack on a
digital audio device.
Before starting operation, press AUX/DI
on the remote to select “DI” in order to
activate the input source.
Helpful Hints:
– Some DVDs are copy-protected. You
cannot record the disc through a VCR or
digital recording device.
–You cannot hear or record the SACD or
MP3-CD playback if you use the digital
connection.
–For your playback through DIGITAL IN
connection, set the digital output of that
player to PCM format.
– Always refer to the owner’s manual of the
other equipment for complete connection
and use details.
