1

Please read and comply with

these original instructions prior

to the initial operation of your appliance and

store them for later use or subsequent own-

ers.

Before first start-up it is definitely neces-

sary to read the safety indications no.

5.956-250!

The machine has been approved for use on

surfaces with gradients of up to 18%.

Your sales outlet should be informed about

any transit damage noted when unpacking

the product.



Please read the operating instructions

for your machine before using it, and

pay particular attention to the following

safety instructions.

–

Warning and information plates on the

machine provide important directions

for safe operation.

–

In addition to the information contained

in the operating instructions, all statuto-

ry safety and accident prevention regu-

lations must be observed.



Danger

Risk of injury!

Danger of tipping if gradient is too high.

–

The gradient in the direction of travel

should not exceed 18%.

Danger of tipping when driving round

bends at high speed.

–

Drive slowly when cornering.

Danger of tipping on unstable ground.

–

Only use the machine on sound surfac-

es.

Danger of tipping with excessive sideways

tilt.

–

The gradient perpendicular to the direc-

tion of travel should not exceed 18%.

–

It is important to follow all safety instruc-

tions, rules and regulations applicable

for driving motor vehicles.

–

The operator must use the appliance

properly. He must consider the local

conditions and must pay attention to

third parties, in particular children, when

working with the appliance.

–

The appliance may only be used by per-

sons who have been instructed in han-

dling the appliance or have proven

qualification and expertise in operating

the appliance or have been explicitly

assigned the task of handling the appli-

ance.

–

Before using the device, practice using

the device in a non-public area.

–

The appliance must not be operated by

children, young persons or persons

who have not been instructed accord-

ingly.

–

It is strictly prohibited to take co-pas-

sengers.



Please remove the ignition key, when

not in use, to avoid unauthorised use of

the appliance.



Never leave the machine unattended

so long as the engine is running. The

operator may leave the appliance only

when the engine has come to a stand-

still, the appliance has been protected

against accidental movement by apply-

ing the immobilization brake and the ig-

nition key has been removed.



Danger

Risk of injury!

–

Do not close the exhaust.

–

Do not bend over the exhaust or touch

it (risk of burns).

–

Do not touch the drive motor (risk of

burns).

–

Exhaust gases are poisonous and haz-

ardous to health, do not inhale them.

–

The engine requires approx. 3-4 sec-

onds to come to a standstill once it has

been switched off. During this time, stay

well clear of the working area.

–

The petrol cans mounted on the appli-

ance must be closed tightly.

–

Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and trouble free.

Danger of crushing. While closing, hold the

device hood only at the handles.

Risk of injury on account of rotating roller

brush. Open the appliance hood only when

the engine has come to a halt.

Risk of fire. Do not vacuum up any burning

or glowing objects.

Risk of burns on account of hot surfaces!

Allow the exhaust to cool down sufficiently

before starting work on the machine.

Petrol is highly prone to fire hazards and is

explosive. Before tanking up, switch off the

engine and allow it to cool down.

The engine exhaust contains the poison-

ous carbon monoxide.  Do not run the en-

gine in closed areas.



Danger

Immediate danger that can cause severe

injury or even death.

몇

Warning

Possible hazardous situation that could

lead to severe injury or even death.

Caution

Possible hazardous situation that could

lead to mild injury to persons or damage to

property.

Contents

Safety instructions  . . . . . . . . .  EN  . .  1

Environmental protection  . . . .  EN  . .  2

Proper use  . . . . . . . . . . . . . . .  EN  . .  2

Operating and Functional Ele-

ments  . . . . . . . . . . . . . . . . . . .  EN  . .  3

Before Startup. . . . . . . . . . . . .  EN  . .  3

Start up . . . . . . . . . . . . . . . . . .  EN  . .  4

Operation  . . . . . . . . . . . . . . . .  EN  . .  4

Shutdown . . . . . . . . . . . . . . . .  EN  . .  6

Maintenance and care  . . . . . .  EN  . .  6

Troubleshooting  . . . . . . . . . . .  EN  . .  9

Technical specifications  . . . . .  EN  .  10

EC Declaration of Conformity .  EN  .  11

Warranty . . . . . . . . . . . . . . . . .  EN  .  11

Accessories and Spare Parts .  EN  .  11

Safety instructions

General notes

Drive mode

Appliances with combustion engine

Symbols on the machine

Symbols in the operating

instructions
