Karcher Autolaveuse BD 80-120 W Bp Pack: Accessories

     -

8

– Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and troublefree.

– At the end of the operating instructions

you will find a selected list of spare

parts that are often required.

– For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

The warranty terms published by the rele-

vant sales company are applicable in each

country. We will repair potential failures of

your appliance within the warranty period

free of charge, provided that such failure is

caused by faulty material or defects in man-

ufacturing. In the event of a warranty claim

please contact your dealer or the nearest

authorized Customer Service centre.

Please submit the proof of purchase.

Accessories

Description

Part no.:

Description

Piece

Machine

requires

piece

Disk brush, white

8.600-032.0

For polishing floors.

1

2

Disk brush, red (medium, standard)

8.600-030.0

For cleaning slightly dirtied or sensitive floors.

1

2

Disk brush, black

8.600-034.0

For cleaning heavily dirtied floors.

1

2

Specifications

Power

Nominal voltage

V

36

Battery capacity (Pack model)

Ah (5h)

200

Average power consumption

W

2160

Drive motor output (rated output)

W

560

Suction engine output

W

560

Brush engine output

W

2x560

Type of protection

IP X4

Vacuuming

Cleaning power, air quantity

l/s

31,4

Cleaning power, negative pressure

kPa

15

Cleaning brushes

Working width

mm

810

Brush diameter

mm

410

Brush speed

1/min

200

Dimensions and weights

Drive speed (max.)

km/h

5,2

Climbing capability (max.)

%

2

Theoretical surface cleaning performance

m²/h

3300

Fresh/dirt water reservoir volume

l

120/120

Max. water temperature

°C

60

Permissible overall weight

kg

694

Transport weight

kg

574

Surface load

kPa

441

Length

mm

1800

Width

mm

990

Height

mm

1170

Values determined as per EN 60335-2-72

Vibration total value on arms

m/s

2

<2,5

Uncertainty K

m/s

2

0,5

Sound pressure level L

pA

dB(A)

75

Uncertainty K

pA

dB(A)

3

Sound power level L

WA

 + Uncertainty K

WA

dB(A)

93

Spare parts Warranty

19 EN
