Karcher Autolaveuse BR 55-40 RS Bp Pack: Accessories

-

9

Faults

Fault

Remedy

By whom

Appliance cannot be started

Insert the battery plug on the device.

Operator

Swivel the top of the appliance down and close the lock.

Operator

Release emergency-stop button by turning.

Operator

Check battery cable for correct sitting.

Operator

Check battery cable for corrosion; clean, if required.

Operator

Battery capacity exhausted; recharge battery.

Operator

Remove the power plug from the charger and hook the holder into the appliance (model

Bp Pack only).

Operator

Device does not drive or drives

only slowly

Release accelerator pedal, turn the key switch to "0", turn the key switch to "1", press

the accelerator pedal.

Operator

Reset fuse of control system.

Operator

Set the unlock lever to "drive".

Operator

Charge battery.

Operator

Motor or control overheated; switch off the appliance and let it cool down for 5 minutes. Operator

Remove obstacles from the wheels or push the appliance away from the obstacle.

Operator

Device does not brake

Park brake deactivated; pull the unlock lever down to activate.

Operator

No or inadequate suction power Empty the dirt water reservoir.

Operator

Reset fuse of suction turbine.

Operator

Foam generated in dirt water reservoir? Use less or a different detergent. Use defoam-

er.

Operator

Clean the seals between dirt water reservoir and top of the appliance and check for

leaks, replace if required.

Operator

Clean the vacuum lips on the

vacuum bar, turn or replace if

required.

Operator

Check suction hose for blockages; clean if required.

Operator

Check connection between suction hose and suction bar and suction hose and waste-

water tank.

Operator

Check the suction hose for tightness; replace if required.

Operator

Check if the cover on the dirt water discharge hose is closed

Operator

Clean the floater in the dirt water tank.

Operator

The battery indicator blinks

Charge battery.

Operator

See "Faults with display".

Operator

Insufficient cleaning result

Select a more intensive cleaning program.

Operator

Check the brushes for wear, replace if required.

Operator

Check brush for contamination and clean it.

Operator

Check whether the detergent and the brush are suitable for the cleaning task.

Operator

Charge battery.

Operator

Brushes do not turn

Reset fuse of brush drive.

Operator

Check the brush for blockage by foreign objects; remove the foreign objects.

Operator

Charge battery.

Operator

No or very little detergent solu-

tion gets added

Check level of detergent solution in the fresh water tank; refill, if required.

Operator

Open fresh water valve.

Operator

Select a more intensive cleaning program.

Operator

Check fresh water sieve; clean if required.

Operator

The cleaning head is not low-

ered.

Reset fuse of control system.

Operator

The suction bar is not lowered.

Unhook the ropes from the suction bar.

Operator

Accessories

Description

Part no.:

Description

Piece

Machine

requires

piece

Battery *

6.654-093.0 12V/70 Ah, maintenance-free (gel),

1

3

Dosing station

2.641-811.0 To fill the appliance with water and detergent.

1

1

* Only suited for appliances with maintenance-free batteries (gel).

23 EN

     -

10

Accessories BR 55/40 RS

Description

Part no.:

Description

Piece

Machine

requires

piece

Brush roller, white (soft)

4.762-409.0 For cleaning slightly dirtied or sensitive floors.

1

2

Brush roller, red (medium, standard) 4.762-393.0 For all floors.

1

2

Brush roller, hard (green)

4.762-411.0 Hard, for severe contamination and basic cleaning;

only suitable for insensitive floor coverings.

1

2

Brush roller, black (very hard)

4.777-412.0 Very hard, for extreme contamination and basic

cleaning; only suitable for insensitive floor cover-

ings.

1

2

Brush roller, high/low (medium hard-

ness)

4.762-410.0 Medium hardness, to clean structrued floors and

deeper grouts.

1

2

Pad roller shaft

4.762-415.0 For intake of roller pads.

1

2

Pad, soft, yellow

6.369-732.0 For polishing floors.

1

2

Pad, medium soft, red

6.369-734.0 For cleaning slightly dirtied floors.

1

2

Pad, hard, green

6.369-733.0 For cleaning normal to heavily dirtied floors.

1

2

Rubber lips of vacuum bar

6.273-294.0

1 set

1 set

Accessories BD 50/40 RS

Description

Part no.:

Description

Piece

Machine

requires

piece

Disk brush, blue (medium, standard) 8.600-042.0 For cleaning slightly dirtied or sensitive floors.

1

1

Disk brush, grey (hard)

8.600-043.0 For cleaning heavily dirtied floors.

1

1

Driver plate

8.600-041.0 For intake of pads.

1

1

Rubber lips of vacuum bar

8.634-020.0

1 set

1 set

24 EN
