Karcher Injecteur-extracteur BRC 45-45 C: Start up

8

English

1

Fuse for suction turbine

2

Fuse of roller brush drive

3

Spray mode, interval spraying

4

RM application with vacuuming|

5

Normal operation

6

Operation with hand nozzle

7

Power switch

8

RM application without vacuuming|

9

Selection of processing

10 Spray mode, continuous spraying

11 Spray mode

Î

Open the fill opening of the fresh water

tank or attach the fill hose to a water tap.

Î

Fill the fresh water tank with hot water

(max. 60°C, capacity 38 liters).

Î

Pour in detergent.

Î

Close the fill opening of the fresh water

tank or pull the fill hose off of the water

tap and slide it back into the appliance.

If you require further information please re-

quest the product information sheet and the

DIN safety data sheet for the respective

cleaning agent.

몇

Warning

Health risk, risk of damage. Observe all in-

dications on the detergent used.

For considerate treatment of the environ-

ment use detergent economically.

1

Push handle

2

Lock of pushing handle

A Push handle position, backup drive

B Push handle position, forward drive

The appliance can be pushed forward or

pulled backwards during operation.

Î

Vacuum loose dirt with a vacuum clean-

er prior to cleaning.

Î

Insert the mains plug into the socket.

몇

Warning

Risk of damage!

Check the object to be cleaned prior to us-

ing the appliance in an inconspicuous place

for colour fastness and water resistance.

Î

Pull the push handle lock out and swivel

the push handle into position A.

Î

Set the spray mode key to interval

spraying.

Î

Set the key selection of process to RM

application with vacuuming.

Î

Set the appliance switch to normal oper-

ation.

Î

Run across the surface to be cleaned in

overlapping paths. Pull the appliance

backwards during this procedure (do

not push).

Î

To spray on the detergent solution,

three keys must be pressed on the push

handle for interval spraying during oper-

ation.

Î

Pull the push handle lock out and swivel

the push handle into position B.

Î

To spray on the detergent solution, set

the spray mode key to continuous

spray.

Î

Set the key selection of process to RM

application with vacuuming.

Î

Set the appliance switch to normal oper-

ation.

Î

Run across the surface to be cleaned in

overlapping paths.

Pretreat heavily soiled carpets prior to

cleaning.

Î

Pull out the lock of the push handle on

the handle and swivel the push handle

in position A or B, depending on the size

of the area to be cleaned.

Î

To spray detergent solution, set the key

for the spray mode to interval spraying

or continuous spray, depending on the

size of the area to be cleaned.

Î

Set the key selection of process to RM

application without vacuuming.

Î

Run across the surface to be cleaned in

overlapping paths.

Î

Let the detergent solution soak for 5 to

10 minutes.

Î

Set the key selection of process to RM

application with vacuuming.

Î

Run across the surface to be cleaned in

overlapping paths.

Î

If the waste water reservoir is full, switch

the appliance switch to "OFF".

Î

Move the appliance to an appropriate

drain.

Î

Hold the drain hose for waste water into

the drain, remove the cover and empty

the waste water reservoir.

몇

Warning

Please observe the local provisions regard-

ing the wastewater treatment.

Î

Connect the provided adapter to the de-

tergent hose of the accessory tools.

1

Detergent hose coupling

2

Coupling for accessory tools

3

Suction hose for accessory tools

Î

Pull the suction hose out of the dome.

Î

Insert the suction hose of the accessory

tool into the dome instead of the suction

hose.

Î

Connect the coupling of the detergent

hose on the appliance to the detergent

hose of the accessory tool.

Î

Set the appliance switch to operation

with manual nozzle - the suction turbine

will start.

Î

Use the lever on the accessory tool to

spray on detergent solution.

Important

When unplugging the accessory tools, the

adapter must be removed from the appli-

ance, so that the water output on the appli-

ance is closed.

Recommendation: Leave the adapter on

the hose of the accessory tool.

Operating field

Start up

Deep carpet clean-

ing

RM 764 liquid

Intermediate carpet

cleaning

RM 768 iCapsol

Operation

Cleaning small areas

Cleaning large areas

Pretreatment for heavily soiled are-

as

Emptying the Dirt Water Reservoir

Operation with accessory tools
