Karcher HD 8-19-4 Cage IN: Operation

Water flowing through a system separator

Select spray type

is considered non-drinkable.

 Close the hand spray gun.

몇 Warning

 Unscrew the nozzle screw connection

Observe regulations of water supplier.

and attach the desired nozzle on the

For connection values refer to technical

spray lance.

specifications

 Connect the supply hose (minimum

Note

length 7.5 m, minimum diameter 1“) to

2 nozzles are included with the appliances

the water connection point of the appli-

1.524-212.0 and 1.524-213.0:

ance (such as the tap).

– 25° spray angle: for heavy contamina-

tions.

Note

– 40° spray angle: for large areas of dirt.

The supply hose is not included.

1 nozzle is included with the appliances

 Open the water supply.

1.524-214.0 and 1.524-215.0:

Drawing in water from open reservoirs

– 25° spray angle: for heavy contamina-

 Install the suction hose (order no.

tions.

4.440-270.0) to the water connection.

 Danger

 Deaerate the appliance:

With short spray lances, there is a risk of in-

Unscrew the nozzle.

jury, as a hand can accidentally come in

Switch on the appliance and let it run

contact with the high pressure jet. If the

until the water exiting is bubble-free.

spray lance is shorter than 75 cm, you must

At the end let the appliance run for ap-

not use a point spray nozzle or a rotor noz-

prox. 10 seconds - then switch off. Re-

zle.

peat the procedure for a couple of

times.

High pressure operation

 Switch off the appliance and fit the noz-

 Set the appliance switch to "I".

zle again.

The high-pressure pump starts and

works in circuit operation.

Operation

 Unlock the hand-spray gun and pull the

 Danger

lever of the gun.

If the appliance is used in hazardous areas

Operation with detergent*

(e.g. filling stations) the corresponding

safety provisions must be observed.

* only with detergent valve mounting kit.

The jet must not be directed at other per-

몇 Warning

sons or directed by the user at him/herself

Unsuitable detergents can cause damage

to clean clothing or footwear.

to the appliance and to the object to be

몇 Warning

cleaned. Use only those detergents that

Clean engines only at places with corre-

have been approved by Kärcher. Observe

sponding oil separators (environmental

the dosage and other instructions provided

safety).

with these detergents. For considerate

Risk of blocking. Place the nozzles in the

treatment of the environment use detergent

accessory compartment with their joint

economically.

pointing upward.

Kärcher detergents ensure smooth func-

tioning. Please consult us or ask for our cat-

alogue or our detergent information sheets.

 Suspend end of suction hose in a con-

tainer filled with detergent.

16 EN

– 4
