Karcher HD 8-19-4 Cage IN: Device elements

Device elements

Electrical connection

see cover page

몇 Warning

1 Nozzle

The appliance may only be connected to al-

2 Nozzle screws

ternating current.

3 Adapter

The appliance may only be connected to an

electrical supply which has been installed in

4 Hand blowing gun

accordance with IEC 60364.

5 Safety lever

The voltage indicated on the type plate

6 Lever for hand spray gun

must correspond to the voltage of the elec-

7 High pressure hose

trical source.

8 Power switch

The minimum fuse rating required at the

9 High pressure connection

socket outlet is (see technical specifica-

10 Water connection

tions).

11 Filter

The appliance should always be connected

12 Output thermal valve

to the electrical mains using a plug. It is for-

13 Oil level indicator

bidden to permanently connect the appli-

14 Oil tank

ance to the power supply. The plug is only

for mains separation.

15 Spray lance

Check the power cord with mains plug for

Colour coding

damage before every use. If the power cord

is damaged, please arrange immediately

– The operating elements for the cleaning

for the exchange by an authorized custom-

process are yellow.

er service or a skilled electrician.

– The controls for the maintenance and

The plug and coupling of the extension ca-

service are light gray.

ble used must be watertight.

Start up

Use the extension cord that has an ade-

quate cross-section (see "Technical Data")

Check oil level

and unwind it fully from the cable drum.

Unsuitable extension cables can be haz-

 Read the oil level display when the de-

ardous. Only use extension cables out-

vice is not running. The oil level must be

doors which have been approved for this

above the two pointers.

purpose and labelled with a sufficient cable

Activate deaeration of oil container

cross section:

 Cut off tip of oil container cover

For connection values, see type plate/tech-

Attaching the Accessories

nical data.

 Install nozzle with nozzle screw on the

Water connection

spray pipe/nozzle adapter.

Connection to the water supply

 Connect the spray lance/nozzle adapter

According to the applicable regu-

to the hand spray gun.

lations, the appliance must never

 Fasten the high pressure hose to the

be used on the drinking water net

high pressure connection.

without a system separator. Use a

suitable system separator manufactured by

Kärcher; or, as an alternative, a system

separator as per EN 12729 Type BA.

– 3

15EN
