Karcher KM 100/100 R D: Contents

-

1

Please read and comply with

these original instructions prior

to the initial operation of your appliance and

store them for later use or subsequent own-

ers.

Before first start-up it is definitely neces-

sary to read the safety indications Nr.

5.956-250!

Your sales outlet should be informed about

any transit damage noted when unpacking

the product.

– Warning and information plates on the

machine provide important directions

for safe operation.

– In addition to the information contained

in the operating instructions, all statuto-

ry safety and accident prevention regu-

lations must be observed.



Danger

Risk of injury!

Danger of tipping if gradient is too high.

–

The gradient in the direction of travel should

not exceed 18%.

Danger of tipping when driving round bends at

high speed.

–

Drive slowly when cornering.

Danger of tipping on unstable ground.

–

Only use the machine on sound surfaces.

Danger of tipping with excessive sideways tilt.

–

The gradient perpendicular to the direction

of travel should not exceed 15%.

– It is important to follow all safety instruc-

tions, rules and regulations applicable for

driving motor vehicles.

– The operator must use the appliance prop-

erly. He must consider the local conditions

and must pay attention to third parties, in

particular children, when working with the

appliance.

– The appliance may only be used by per-

sons who have been instructed in handling

the appliance or have proven qualification

and expertise in operating the appliance or

have been explicitly assigned the task of

handling the appliance.

– The appliance must not be operated by chil-

dren, young persons or persons who have

not been instructed accordingly.

– It is strictly prohibited to take co-passen-

gers.

– Ride-on appliances may only be started af-

ter the operator has occupied the driver's

seat.

Î

Please remove the key, when not in use, to

avoid unauthorised use of the appliance.

Î

Never leave the machine unattended so

long as the engine is running. The operator

may leave the appliance only when the en-

gine has come to a standstill, the appliance

has been protected against accidental

movement, and the key has been removed.



Danger

To avoid risks, all repairs and replacement

of spare parts may only be carried out by

authorized customer service personnel.

– Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and troublefree.

– At the end of the operating instructions

you will find a selected list of spare

parts that are often required.

– For additional information about spare

parts, please go to the Service section

at www.kaercher.com.



Danger

Immediate danger that can cause severe

injury or even death.

몇

Warning

Possible hazardous situation that could

lead to severe injury or even death.

Caution

Possible hazardous situation that could

lead to mild injury to persons or damage to

property.

The sweeper operates using the overthrow

principle.

– The side brushes (3) clean the corners

and edges of the surface, moving dirt

and debris into the path of the roller

brush.

– The rotating roller brush (4) moves the

dirt and debris directly into the waste

container (5).

– The dust raised in the container is sep-

arated by the dust filter (2) and the fil-

tered clean air is drawn off by the

suction fan (1).

Contents

Safety instructions

EN -

1

Function

EN -

1

Proper use

EN -

2

Environmental protection

EN -

2

Operating and Functional Ele-

ments

EN -

3

Before Startup

EN -

4

Start up

EN -

4

Operation

EN -

4

Shutdown

EN -

6

Maintenance and care

EN -

6

Accessories

EN -

10

Troubleshooting

EN -

11

Technical specifications

EN -

12

CE Declaration

EN -

13

Warranty

EN -

13

Safety instructions

General notes

Drive mode

Accessories and Spare Parts

Symbols on the machine

Please do not sweep away

any burning substances

such as cigarettes, match

sticks or similar objects.

Risk of being squeezed or

hurt at the belts, side-

brushes, containers, ma-

chine cover.

Symbols in the operating instruc-

tions

Function
