Karcher BR 40/10C ADV: Accessories

-

7

We hereby declare that the machine de-

scribed below complies with the relevant

basic safety and health requirements of the

EU Directives, both in its basic design and

construction as well as in the version put

into circulation by us. This declaration shall

cease to be valid if the machine is modified

without our prior approval.

The undersigned act on behalf and under

the power of attorney of the company man-

agement.

Authorised Documentation Representative

S. Reiser

Alfred Kärcher GmbH Co. KG

Alfred-Kärcher-Str. 28 - 40

71364 Winnenden (Germany)

Phone: +49 7195 14-0

Fax: +49 7195 14-2212

Winnenden, 2012/12/01

The warranty terms published by our com-

petent sales company are applicable in

each country. We will repair potential fail-

ures of your accessory within the warranty

period free of charge, provided that such

failure is caused by faulty material or de-

fects in fabrication. In the event of a warran-

ty claim please contact your dealer or the

nearest authorized Customer Service cent-

er. Please submit the proof of purchase.

–

Only use accessories and spare parts

which have been approved by the man-

ufacturer. The exclusive use of original

accessories and original spare parts

ensures that the appliance can be oper-

ated safely and trouble free.

–

At the end of the operating instructions

you will find a selected list of spare

parts that are often required.

–

For additional information about spare

parts, please go to the Service section

at www.kaercher.com.

Accessories

Order No.

Piece

Machine requires piece

Brush roller, red (medium, stand-

ard)

For cleaning slightly dirtied or sensitive floors.

4.762-249.0

1

2

Brush roller, green (grit)

For cleaning heavily dirtied floors.

4.762-252.0

1

2

Brush roller, orange (high/ low)

For scrubbing structured floors (safety tiles, etc.).

4.762-251.0

1

2

Brush roller, white (soft)

For polishing floors.

4.762-250.0

1

2

Pad roller shaft

For intake of roller pads.

4.762-228.0

1

2

Pad, very soft, white

For cleaning and polishing sensitive floorings.

6.369-727.0

1

2

Pad, soft, yellow

For polishing floors.

6.369-724.0

1

2

Pad, medium soft, red

For cleaning slightly dirtied floors.

6.369-726.0

1

2

Pad, hard, green

For cleaning normal to heavily dirtied floors.

6.369-725.0

1

2

Microfibre roller

To remove grey tint

4.114-004.0

1

2

Vacuum bar, standard

4.777-323.0

1

2

Vacuum bar, oil-resistant

4.777-322.0

1

2

Extension cable

20 m

6.647-022.0

1

1

Attachment kit transport wheels

for BR 40/10 C Classic

2.783-013.0

1

1

EC Declaration of Conformity

Product:

Floor cleaner

Type:

1.783-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)

2004/108/EC

Applied harmonized standards

EN 55014–1: 2006+A1: 2009+A2: 2011

EN 55014–2: 1997+A1: 2001+A2: 2008

EN 60335–1

EN 60335–2–72

EN 61000–3–2: 2006+A1: 2009+A2: 2009

EN 61000–3–3: 2008

EN 62233: 2008

Applied national standards

-

CEO

Head of Approbation

Warranty Spare parts

16 EN
