Karcher K 7 Premium Car: Technical specifications EC Declaration of Conformity

Technical specifications

EC Declaration of Conformity

We hereby declare that the machine de-

Electrical connection

scribed below complies with the relevant

Voltage 230

V

basic safety and health requirements of the

1~50

Hz

EU Directives, both in its basic design and

Connected load 3,0 kW

construction as well as in the version put

Protection class IP X5

into circulation by us. This declaration shall

Protective class I

cease to be valid if the machine is modified

without our prior approval.

Mains fuse (slow-blow) 16 A

Product: High pressure cleaner

Water connection

Type: 1.168-xxx

Max. feed pressure 0,6 MPa

Relevant EU Directives

Max. feed temperature 60 °C

2000/14/EC

Min. feed volume 12 I/min

2004/108/EC

2006/42/EC (+2009/127/EC)

Max. Suction height 0,5 m

2011/65/EU

Performance data

Applied harmonized standards

Working pressure 15 MPa

EN 50581

Max. permissible pressure 16 MPa

EN 55014–1: 2006+A1: 2009+A2: 2011

Water flow rate 9,2 I/min

EN 55014–2: 1997+A1: 2001+A2: 2008

EN 60335–1

Max. flow rate 10,0 I/min

EN 60335–2–79

Detergent flow rate 0-0,3 I/min

EN 61000–3–2: 2006+A1: 2009+A2: 2009

Recoil force of trigger gun 23 N

EN 61000–3–3: 2008

Dimensions and weights

EN 62233: 2008

Applied conformity evaluation method

Length 404 mm

2000/14/EC: Appendix V

Width 461 mm

Sound power level dB(A)

Height 968 mm

Measured: 92

Weight, ready to operate with

22,0 kg

Guaranteed: 95

accessories

The undersigned act on behalf and under

Values determined as per

the power of attorney of the company man-

EN 60335-2-79

agement.

2

Hand-arm vibration value

<2,5

m/s

2

Uncertainty K

0,3

m/s

Sound pressure level L

pA

77

dB(A)

Uncertainty K

pA

3

dB(A)

CEO

Head of Approbation

Sound power level L

WA

+ Un-

95 dB(A)

Authorised Documentation Representative

certainty K

WA

S. Reiser

Subject to technical changes.

Alfred Kärcher GmbH Co. KG

Alfred-Kärcher-Str. 28 - 40

71364 Winnenden (Germany)

Phone: +49 7195 14-0

Fax: +49 7195 14-2212

Winnenden, 2013/12/01

– 13

23EN
