Karcher KM 75/40 W Bp: Start up



-

5

Fault display:



Open the device hood.



Insert the charging cable of the charger

in the charger box of the sweeper



Plug in mains connector and switch on

charger.



KM 75/40 W Bp Pack



Disconnect the mains plug.



Wrap the mains cord around the cable

holder of the charger.



Close cover.



KM 75/40 W Bp



Switch off the charger and remove the

plug from the socket.



Hang out the charging cable out of the

machine.



Close cover.



Open the device hood.



Disconnect pole terminal to negative

pole (-).



Unscrew the connection wires from the

batteries.



Disconnect pole terminal to positive

pole (-).



Loosen the holding strap.



Remove the battery.



Dispose of the used battery according

to the local provisions.

Batteries and chargers are available in spe-

cialised stores.

Always use 2 batteries of the same type!



DANGER

Risk of injury! Switch off the appliance prior

to removing the waste container.

Note:

 Start the appliance only when the

hood is closed.



Park the sweeper on an even surface.



Switch off engine.



Lock parking brake.



Check charging status of battery.



Check side brush.



Check roller brush.



Shake off dust filter.



Empty waste container.

Note:

 For description, see section on Care

and maintenance.



Release parking brake.

Start the motor.



Turn the main switch to position “1”.

Note:

 The roller brush and the side brush

will rotate.



Pull the lever for forward drive.

Note:

 The drive speed for forward drive

can be adjusted steplessly depending on

the position of the lever.



Release the lever for forward drive. De-

vice comes to a halt.

Driving over fixed obstacles which are 30

mm high or less:



Raise bulk waste flap.



Drive forwards slowly and carefully.

Driving over fixed obstacles which are

more than 30 mm high:



Only drive over these obstacles using a

suitable ramp.



Danger

Risk of injury! If the bulk waste flap is open,

stones or gravel may be flung forwards by

the roller brush. Make sure that this does

not endanger persons, animals or objects.

CAUTION

Do not sweep up packing strips, wire or

similar objects as this may damage the

sweeping mechanism.

Note:

 To achieve an optimum cleaning re-

sult, the driving speed should be adjusted

to take specific situations into account.

Note:

 To sweep up larger items up to a

height of 50 mm, e.g. cigarette packs, the

bulk waste flap must be raised briefly.

Raising bulk waste flap:



Pull the lever for raising the bulk waste

flap.

Lowering the bulk waste flap:



Release the lever for raising the bulk

waste flap.

Note:

 An optimum cleaning result can only

be achieved if the bulk waste flap has been

lowered completely.



Move the lever to lower the side brush

to the front. The side brush will be low-

ered.

Note:

 During operation, the waste contain-

er should be emptied at regular intervals.

Note:

 During operation, the dust filter

should be shaken off and cleaned at regu-

lar intervals.



Close wet/dry flap



Open wet/dry flap.

Note:

 This protects the filter from moisture.

The battery display shows the charging sta-

tus of the batteries during operation:



Pull the handle of the filter clean-off out

several times and reinsert it.



DANGER

Risk of injury! Switch off the appliance prior

to removing the waste container.

Note:

 Make sure the seal strip is not dam-

aged while emptying the waste container.

Note:

 The max. load of the waste container

is 40 kg.



Shake off dust filter.



Pull lock bow of the waste container up-

ward.



Pull out the waste container.



Empty waste container.



Push in the waste container.



Push lock bow of the waste container

downward.

Switch off engine.



Turn the main switch to position “0”.



The side-brushes lift up.



Lock parking brake.



Turn the main switch using "0" position

and pull it out.

Charger or motor control

malfunction

glows red

Charging process - KM 75/40 W Bp

After charging

Remove the battery

Recommended batteries, chargers

Order number

Battery 60 Ah

6.654-226.0

Charger

6.654-225.0

Maximum battery dimensions

Length

Width

Height

267 mm

177 mm

190 mm

Start up

General notes

Inspection and maintenance work

Operation

Starting the machine

Drive the machine

Drive forward

Dry run

Driving over obstacles

Sweeping mode

Sweeping with bulk waste flap raised

Sweeping with side brushes

Sweeping dry floors

Sweeping damp or wet floors

Battery display

full

glows green

30% capacity remaining glows yellow

10% capacity remaining blinks red

Protection against total

discharge; the appliance

is switched off

glows red

Cleaning the dust filter

Emptying waste container

Turn off the appliance

16 EN
