Karcher Полотер BRS 40-1000C: Specifications
Specifications: Karcher Полотер BRS 40-1000C

-
5
Faults
Fault
Remedy
Appliance cannot be started
Check if the mains plug is connected.
Socket fuse rating too low, look for proper socket.
Insufficient water quantity
Check fresh water level, refill tank if necessary.
Clean the ball valve in the fresh water reservoir.
Check and ensure that the fresh water reservoir is seated properly on the appliance.
Filter in the fresh water reservoir is plugged, clean filter.
Pull out the water distribution bars above the brushes and flush with water.
Check hoses for blockages; clean if required.
Insufficient cleaning result
Check the brushes for wear, replace if required.
Use brush rollers suited for the type of dirt and floor covering.
Brushes do not turn
Check if foreign matters block the brushes; remove foreign matter if required.
Overcurrent protective switch was triggered. The overcurrent protective switch will allow the op-
eration after max. one minute.
Appliance vibrates.
Brush rollers are out of balance, replace the brush rollers.
Specifications
1.783-320.0
1.783-320.0
1.783-321.0
Power
Nominal voltage
V/Hz
220...240 / 1~50
230 / 1~60
Average power consumption
W
1300
Brush engine output
W
2100
Maximum allowed net impedance
Ohm
0.396+j0.248
Type of protection
IPX4
Working width
mm
400
Brush diameter
mm
96
Brush speed
1/min
1100
Dimensions and weights
Theoretical surface cleaning performance
m²/h
400
Volume, fresh water reservoir
l
10
Length (without pushing handle)
mm
490
Width
mm
460
Height (without pushing handle)
mm
250
Weight (without tank content, without brushes)
kg
38
Values determined as per EN 60335-2-67
Vibration total value on arms
m/s
2
<2,5
Uncertainty K
m/s
2
0,2
Sound pressure level L
pA
dB(A)
73
Uncertainty K
pA
dB(A)
1
13 EN
