ENGLISH 21

tains flammable gases: the appli-

1.7 Environment Protection

ance shall be disposed according

This appliance does not contain

to the applicable regulations to

gasses which could damage the

obtain from your local authorities.

ozone layer, in either its refrigerant

Avoid damaging the cooling unit,

circuit or insulation materials. The

especially at the rear near the heat

appliance shall not be discarded

exchanger. The materials used on

together with the urban refuse and

this appliance marked by the sym-

rubbish. The insulation foam con-

bol

are recyclable.

2. CONTROL PANEL

1

234567

1

Display

6

Freezer Compartment button

2

Drink Chill button and Appliance ON/

7

Mode button

OFF button

It is possible to change predefined sound

Temperature colder button

of buttons to a loudly one by pressing to-

3

gether Mode button and Temperature

4

Temperature warmer button

colder button for some seconds. Change

5

Fridge Compartment button

is reversible.

2.1 Display

A DCB E F G H I

K J

A)

Fridge temperature indicator

I)

Freezer temperature indicator

B)

Fridge OFF indicator

J)

DrinksChill mode

C)

HolidayMode

K)

FreeStore mode

D)

Fridge EcoMode

After selection of the fridge or

E)

ShoppingMode

freezer compartment the anima-

F)

Alarm indicator

tion

starts.

G)

Freezer EcoMode

After selection of the temperature

the animation flashes for a few mi-

H)

FastFreeze mode

nutes.

22

www.electrolux.com

After a power failure the set tem-

2.2 Switching on the appliance

perature remains stored.

To switch on the appliance do these

steps:

2.7 HolidayMode

1.

Connect the mains plug to the power

socket.

This function allows you to keep the re-

frigerator closed and empty during a long

2.

The temperature indicators show the

holiday period without the formation of a

set default temperature.

bad smell.

If DEMO appears on the Display, the ap-

pliance is in demonstration mode: refer to

The fridge compartment must be

“WHAT TO DO IF....” paragraph.

empty with holiday function on.

To select a different set temperature refer

to "Temperature regulation".

To switch on the function:

1.

Press the Mode button until the cor-

2.3 Switching off the fridge

responding icon appears.

The Holiday indicator flashes for few

To switch off the fridge:

seconds.

1.

Press the Fridge Compartment button

The fridge temperature indicator

for few seconds.

shows the set temperature.

2.

The fridge OFF indicator is shown.

To switch off the function:

1.

Press the Mode button until the Holi-

2.4 Switching on the fridge

day indicator flashes.

To switch on the fridge:

2.

The Holiday indicator goes off.

1.

Press the Fridge Compartment but-

The function switches off by se-

ton.

lecting a different fridge set tem-

The fridge OFF indicator goes off.

perature.

To select a different set temperature refer

to "Temperature regulation".

2.8 EcoMode for Fridge and

Freezer Compartment

2.5 Switching off

For optimal food storage select the Eco-

To switch off the appliance do these

Mode .

steps:

To switch on the function:

1.

Press the Appliance ON/OFF button

1.

Select the fridge/freezer compart-

for 3 seconds.

ment.

2.

The display switches off.

2.

Press the Mode button until the cor-

3.

To disconnect the appliance from the

responding icon appears.

power disconnect the mains plug

The EcoMode indicator flashes for

from the power socket.

few seconds.

The temperature indicator shows the

2.6 Temperature regulation

set temperature:

– for the fridge: +4°C

Select the fridge or freezer compartment.

Press the temperature button to set the

– for the freezer: -18°C

temperature.

3.

The EcoMode indicator is shown.

Set default temperature:

To switch off the function:

• +4°C for the fridge

1.

Select the fridge/freezer compart-

• -18°C for the freezer

ment.

The temperature indicators show the set

2.

Press the Mode button until the Eco-

temperature.

Mode indicator flashes.

The set temperature will be reached with-

3.

The EcoMode indicator goes off.

in 24 hours.

ENGLISH 23

The function switches off by se-

useful for example when a recipe requires

lecting a different set temperature.

to cool down a mixture for a certain peri-

od of time, or when a reminder is needed

in order not to forget the bottles placed in

2.9 ShoppingMode

the freezer for fast cooling.

If you need to insert a large amount of

To switch on the function:

warm food, for example after doing the

1.

Press the DrinkChill button.

grocery shopping, we suggest activating

The DrinksChill indicator appears.

the ShoppingMode to chill the products

The Timer shows the set value (30 mi-

more rapidly and to avoid warming the

nutes).

other food which is already in the refriger-

ator.

2.

Press the Temperature colder button

To switch on the function:

and Temperature warmer button to

1.

change the Timer set value from 1 to

Press the Mode button until the cor-

90 minutes.

responding icon appears.

3.

The Timer start to flash (min).

The ShoppingMode indicator flashes

At the end of the countdown the Drinks-

for few seconds.

Chill indicator flashes and an audible

The ShoppingMode shuts off automatical-

alarm sounds:

ly after approximately 6 hours.

To switch off the function before its auto-

1.

Remove any drinks contained in the

matic end:

freezer compartment.

1.

Press the Mode button until the

2.

Press the DrinkChill button to switch

ShoppingMode indicator flashes.

off the sound and terminate the func-

tion.

2.

The ShoppingMode indicator goes

It is possible to deactivate the function at

off.

any time during the countdown:

The function switches off by se-

1.

Press the DrinkChill button.

lecting a different fridge set tem-

2.

The DrinksChill indicator goes off.

perature.

It is possible to change the time during

the countdown and at the end by press-

2.10 FastFreeze mode

ing the Temperature colder button and

the Temperature warmer button.

To switch on the function:

1.

Select the freezer compartment.

2.12 High temperature alarm

2.

Press the Mode button until the cor-

responding icon appears.

An increase in the temperature in the

freezer compartment (for example due to

The FastFreeze indicator flashes for

an earlier power failure) is indicated by:

few seconds.

This function stops automatically after 52

• flashing the alarm and freezer tempera-

hours.

ture indicators

To switch off the function before its auto-

• sounding of buzzer.

matic end:

To reset the alarm:

1.

Select the freezer compartment.

1.

Press any button.

2.

Press the Mode button until the Fast-

2.

The buzzer switches off.

Freeze indicator flashes.

3.

The freezer temperature indicator

3.

The FastFreeze indicator goes off.

shows the highest temperature

reached for a few seconds. Then

The function switches off by se-

show again the set temperature.

lecting a different freezer set tem-

4.

perature.

The alarm indicator continue to flash

until the normal conditions are re-

stored.

2.11 DrinksChill mode

When the alarm has returned the alarm in-

dicator goes off.

The DrinksChill mode is to be used to set

an acoustic alarm at the preferred time,
