Additional information12

Video

Symptom Remedy

No image is output when an

• Check the video connections of the source component (see page 29).

input is selected.

• For HDMI, or when digital video conversion is set to OFF and a TV and another

component are connected with different cords (in Setting the Video options on

page 71), you must connect your TV to this receiver using the same type of video

cable as you used to connect your video component.

• Make sure the input assignment is correct for components connected using

component video or HDMI cables (see The Input Setup menu on page 42).

• Check the video output settings of the source component.

• Check that the video input you selected on your TV is correct.

• Some components (such as video game units) have resolutions that may not

be converted. If adjusting this receiver’s Resolution setting (in Setting the Video

options on page 71) and/or the resolution settings on your component or

display doesn’t work, try switching Digital Video Conversion (in Setting the Video

options on page 71) to OFF.

Can’t record video. • Check that the source is not copy-protected.

• The video converter is not available when making recordings. Check that the

same type of video cable is used for connecting both the recorder and the video

source (the one you want to record) to this receiver.

Noisy, intermittent, or

• Sometimes a video deck may output a noisy video signal (during scanning,

distorted picture.

for example), or the video quality may just be poor (with some video game units,

for example). The picture quality may also depend on the settings, etc. of your

display device. Switch off the video converter and reconnect the source and

display device using the same type of connection (component or composite),

then start playback again.

Video signals are not output

• When a monitor only compatible with resolutions of 480i is connected to the

from the component

component terminal and another monitor is connected to the HDMI terminal,

terminal.

the video signals may not be output to the monitor connected to the component

terminal. If this happens, do the following:

– Turn off the power of the monitor connected to the HDMI terminal.

– Change the VIDEO PARAMETER menu RES setting (page 71).

– Video signals from the HDMI terminal cannot be output to the component

terminals. Input the video signals from the player or other source to the

composite or component terminals. When using the component terminal,

assign it at Input Setup.
