Pioneer VSX-1025-K: Switching the speaker terminals Using the MULTI-ZONE controls

Using other functions 08

English

Switching the speaker terminals

Using the MULTI-ZONE controls

If you selected Speaker B at Speaker system

The following steps use the front panel

setting on page 101, you can switch between

controls to adjust the sub zone volume and

speakers using the SPEAKERS button. If you

select sources. See MULTI-ZONE remote

selected Normal(SB/FH), Normal(SB/FW),

controls on page 74.

Deutsch

Front Bi-Amp or ZONE 2, the button will

1Press

MULTI-ZONE ON/OFF

on the front

simply switch your main speaker terminals on

panel.

or off. The options below are for the Speaker B

1

Each press selects a MULTI-ZONE option:

setting only.

• ZONE 2 ON – Switches the MULTI-ZONE

•Use

SPEAKERS

on the front panel to

feature on

Français

select a speaker terminal setting.

• MULTI ZONE OFF – Switches the MULTI-

As mentioned above, if you have selected

ZONE feature off

Normal(SB/FH) or Normal(SB/FW), the

button will simply switch your main speaker

The MULTI-ZONE indicator lights when the

terminals (A) on or off.

MULTI-ZONE control has been switched ON.

Press repeatedly to choose a speaker terminal

2Press

MULTI-ZONE CONTROL

on the

Italiano

option:

front panel.

2

• SPA – Sound is output from the A-

• When the receiver is on,

make sure that

speaker terminals (up to 7 channels

any operations for the sub zone are done

(including surround back channels),

while ZONE 2 shows in the display. If this

depending on the source).

is not showing, the front panel controls

Nederlands

affect the main zone only.

• SPB – Sound is output from the two

speakers connected to the B-speaker

3Use the

INPUT SELECTOR

dial to select

terminals. Multichannel sources will not be

the source for the sub zone.

heard.

For example, ZONE 2 CD-R sends the source

• SPAB – Sound is output from the A-

connected to the CD-R inputs to the sub room

speaker terminals (up to 5 channels,

Español

(ZONE 2).

depending on the source), the two

•If you select TUNER, you can use the tuner

speakers connected to the B-speaker

controls to select a preset station (see

terminal, and the subwoofer. The sound

Saving station presets on page 51 if you’re

from B-speaker terminals will be the same

3

unsure how to do this).

as the sound from the A-speaker terminals

(multichannel sources will be downmixed

• VSX-920 model only: iPod/USB and

to 2 channels).

INTERNET RADIO function cannot be

selected for the MULTI-ZONE feature.

• SP (off) – No sound is output from the

speakers.

73

En

VSX-1020_SYXCN.book 73 ページ ２０１０年３月１２日　金曜日　午前９時１０分

1 • The subwoofer output depends on the settings you made in Manual speaker setup on page 100. However, if SPB

is selected above, no sound is heard from the subwoofer (the LFE channel is not downmixed).

• All speaker systems (except Speaker B connections) are switched off when headphones are connected.

2 If the receiver is in standby, the display is dimmed, and ZONE 2 DVD for example shows in the display.

3 The tuner cannot be tuned to more than one station at a time. Therefore, changing the station in one zone also

changes the station in the other zone. Please be careful not to change stations when recording a radio broadcast.
