Pioneer VSX-1025-K: Setting What it does Option(s)

VSX-1020_SYXCN.book 72 ページ ２０１０年３月１２日　金曜日　午前９時１０分

Using other functions08

Setting What it does Option(s)

c

Specifies the aspect ratio when analog video input signals are

THROUGH

ASP

(Aspect)

output at the HDMI output. Make your desired settings while

NORMAL

checking each setting on your display (if the image doesn’t match

your monitor type, cropping or black bands appear).

d,e,f

This setting optimizes the picture for film material when the video

AUTO

PCINEMA

output is set to progressive. Usually set to AUTO; but try

(PureCinema)

ON

switching to OFF if the picture appears unnatural.

OFF

Additionally, certain PAL movie videos (576i, 25 frames/second

STB video output or DVD disc playback, etc.) that contain film

progressive material cannot be recognized as such by this

receiver. In such instances, if you choose ON, PureCinema mode

is activated.

d,f

Adjusts the motion and still picture quality when video output is

–4 to +4

P.MOTION

(Progressive Motion)

set to progressive.

Default: 0

d

Adjusts the amount of noise reduction (NR) applied to the Y

0 to +8

YNR

(brightness) component.

Default: 0

d

Adjusts how sharp edges appear. –4 to +4

DETAIL

Default: 0

d,g

Adjusts the sharpness of the high-frequency (detailed) elements

–4 to +4

SHARP

in the picture.

(Sharpness)

Default: 0

d

Adjusts the overall brightness. –6 to +6

BRIGHT

(Brightness)

Default: 0

d

Adjusts the contrast between light and dark. –6 to +6

CONTRAST

Default: 0

d,h

Adjusts the red/green balance. –6 to +6

HUE

Default: 0

d

Adjusts saturation from dull to bright. –6 to +6

CHROMA

(Chroma Level)

Default: 0

a.If the video picture deteriorates when this settings is switched ON, switch it OFF.

b.• When set to a resolution with which the TV (monitor) is not compatible, no picture is output. Also, in some cases

no picture will be output due to copyright protection signals. In this case, change the setting.

• When AUTO is selected, the resolution is selected automatically according to the capacity of the TV (monitor)

connected by HDMI. When PURE is selected, the signals are output with the same resolution as when input (see

About the video converter on page 24).

• When a display is connected by HDMI, if this is set to something other than PURE and 480i/576i analog signals are

input, 480p/576p signals are output from the component output terminals.

• The AUTO setting is not displayed for HDMI inputs.

c.• If the image doesn’t match your monitor type, adjust the aspect ratio on the source component or on the monitor.

• This cannot be set when the resolution is set to PURE.

• The NORMAL setting is only displayed when 480i/p or 576i/p analog video signals are being input.

d.This setting is only displayed when 480i or 576i analog video signals are being input.

e.If the picture does not display properly when ON is selected, select AUTO or OFF.

f. This setting is valid for component outputs and HDMI output.

g.This setting is not valid for HDMI output.

h.This setting is not displayed for component inputs.
