Pioneer KRL-37V: instruction

Class: Household, kitchen appliances, electronics and equipment

Type: Home Theater System

Manual for Pioneer KRL-37V

<TINS-D642WJZZ>

Printed in Spain

Imprimé en Espagne

Published by Pioneer Corporation.

Publication de Pioneer Corporation.

Tous droits de reproduction et de traduction réservés.

PIONEER CORPORATION

4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

Корпорация Пайонир

4-1, Мегуро 1-Чоме, Мегуро-ку, Токио 153-8654, Япония

PIONEER ELECTRONICS (USA) INC.

P.O. BOX 1540, Long Beach, California 90801-1540, U.S.A. TEL: (800) 421-1404

PIONEER ELECTRONICS OF CANADA, INC.

300 Allstate Parkway, Markham, Ontario L3R 0P2, Canada TEL: 1-877-283-5901, 905-479-4411

PIONEER EUROPE NV

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 03/570.05.11

PIONEER ELECTRONICS ASIACENTRE PTE. LTD.

253 Alexandra Road, #04-01, Singapore 159936 TEL: 65-6472-7555

PIONEER ELECTRONICS AUSTRALIA PTY. LTD.

178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: (03) 9586-6300

PIONEER ELECTRONICS DE MEXICO S.A. DE C.V.

Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270

K002_Ru

Discover the benefits of registering your product online at

http://www.pioneer.co.uk

(or http://www.pioneer.eu).

Découvrez les nombreux avantages offerts en enregistrant votre produit en ligne

maintenant sur

http://www.pioneer.fr

(ou

http://www.pioneer.eu).

Bitte nutzen Sie die Möglichkeit zur Registrierung Ihres Produktes unter

http://www.pioneer.de

(oder

http://www.pioneer.eu)

Registra il tuo prodotto su

http://www.pioneer.it

http://www.pioneer.eu) e

scopri subito quali vantaggi puoi ottenere!

Ontdek nu de voordelen van online registratie! Registreer uw Pioneer product via

http://www.pioneer.nl - http://www.pioneer.be

(of

http://www.pioneer.eu)

Registre su producto en

http://www.pioneer.es

(o en

http://www.pioneer.eu)

Descubra los beneficios de registrarse on-line:

Зарегистрируйте Baшe изделие на

http://www.pioneer-rus.ru

(или

http://www.pioneer.eu

). Oзнакомьтесь с преимуществами регистрации в Интернет

Примечание:

В соответствии со статьей 5 Закона Российской Федерации “О защите прав потребителя” и

Указанием Правительства Российской Федерации № 720 от 16 июня 1997 года, корпорация

Pioneer Europe NV устанавливает условие на следующую продолжительность срока

службы официально поставляемых на Российский рынок товаров.

Аудио и видеооборудование: 7 лет

Переносное аудиооборудование: 6 лет

Другое оборудование (наушники, микрофон и т.д.): 5 лет

Автомобильная электроника: 6 лет

D3-7-10-6_A_Ru

(130.0

)

(130,0

)

[156.7

]

[156,7

]

300.0

300,0

300.0

300,0

( 776.0 ) / [ 898.0 ]

( 776,0 ) / [ 898,0 ]

( 95.9 ) / [ 96.4 ]

( 95,9 ) / [ 96,4 ]

(55.0

)

(55,0

)

[57.0

]

[57,0

]

(517.0

[581.0

]

(517,0

[581,0

]

(572.0

[638.0

]

(572,0

[638,0

]

101.9

101,9

281.0

281,0

451.5

451,5

( 701.5 ) / [ 824.4 ]

( 701,5 ) / [ 824,4 ]

(395.9

[463.8

]

(395,9

[463,8

]

(332.0

[369.0

]

(332,0

[369,0

]

15°

( ) : KRL-32V

[ ] : KRL-37V

KRL-32V

KRL-37V

: KRL-32V

: KRL-37V

OPERATION MANUAL

Contents ............................................................................. 1

Introduction ........................................................................ 2

Dear Pioneer customer ................................................. 2

Important Safety Precautions ........................................ 2

Remote control unit....................................................... 3

Controlling other equipment using the supplied

remote control unit ................................................ 4

Trademarks ................................................................... 8

TV (Front view) .............................................................. 9

TV (Rear view) ............................................................... 9

Preparation ...................................................................... 10

Supplied accessories .................................................. 10

Attaching the stand unit .............................................. 10

Inserting the batteries .................................................. 11

Using the remote control unit ...................................... 11

Cautions regarding the remote control unit ............. 11

Installation precautions .......................................... 12

Quick guide ...................................................................... 13

Initial installation overview ............................................ 13

Before turning on the power........................................ 14

Bundling the cables ............................................... 14

Initial auto installation .................................................. 15

Checking signal strength and channel strength ...... 15

Watching TV ..................................................................... 16

Daily operation ............................................................ 16

Switching on/off ..................................................... 16

Switching between analogue and

digital broadcasts ................................................ 16

Changing channels ................................................ 16

Selecting an external video source ......................... 16

Selecting a sound mode ........................................ 16

EPG (Electronic Programme Guide) ............................. 17

EPG Overview ............................................................. 17

Useful settings for using EPG ...................................... 17

Selecting a programme using EPG.............................. 18

Timer recording using EPG ......................................... 19

Cancelling the timer recording ..................................... 19

Teletext ....................................................................... 20

Using the MHEG-5 application (UK only) ..................... 20

Connecting external devices .......................................... 21

Introduction to connections ......................................... 21

HDMI connection ................................................... 22

Component connection ......................................... 22

S-VIDEO/VIDEO connection .................................. 22

SCART connection ................................................ 23

Controlling devices with SCART using i/o link.A ..... 23

Speaker/amplifier connection ................................. 24

Inserting a smart card ................................................. 25

HDMI CONTROL .............................................................. 26

Controlling HDMI devices using HDMI CONTROL ....... 26

HDMI CONTROL connection ...................................... 27

HDMI CONTROL Setup .............................................. 27

Operating an HDMI CONTROL device ........................ 28

Menu operation................................................................ 29

What is the HOME MENU? ......................................... 29

Common operations .............................................. 29

Basic adjustment ............................................................. 30

Picture Settings ........................................................... 30

AV SELECTION ...................................................... 31

Sound Settings ........................................................... 31

Power Save Settings ................................................... 31

Channel Settings ......................................................... 32

Auto Installation ..................................................... 32

Digital channel settings .......................................... 32

Analogue channel settings ..................................... 33

Password/Parental lock settings ............................ 34

Language Settings (language, subtitle, multi audio) ..... 34

Useful Viewing functions ................................................ 35

Selecting the picture size ............................................ 35

Selecting the WSS (Wide Screen Signalling)

picture size automatically ..................................... 35

Selecting the WSS (Wide Screen Signalling)

picture size manually ........................................... 35

Selecting the picture size manually ......................... 35

Selecting the recording picture size manually ......... 36

Selecting the HDMI picture size automatically ........ 36

Other picture and audio settings ................................. 36

Adjusting image position ........................................ 36

Reducing noise on the screen ................................ 36

Automatic volume adjustment ................................ 36

Emphasising dialogue ............................................ 36

Outputting audio only ............................................. 36

Display Settings .......................................................... 37

Channel display ..................................................... 37

Time and Title display ............................................ 37

Other useful features ...................................................... 38

Setting when using external devices ........................... 38

Input source settings ............................................. 38

Skipping specified inputs ....................................... 38

Colour system settings .......................................... 38

Additional features ...................................................... 38

Connecting a PC .............................................................. 39

Connecting a PC ........................................................ 39

Displaying a PC image on the screen .......................... 39

Selecting the picture size ....................................... 39

Adjusting the PC image automatically .................... 40

Adjusting the PC image manually ........................... 40

Selecting input resolution ............................................ 40

RS-232C port specifications ....................................... 41

PC compatibility chart ................................................. 42

RS-232C command list............................................... 42

Appendix .......................................................................... 43

Troubleshooting .......................................................... 43

Updating your TV via DVB-T ....................................... 44

Reset .......................................................................... 44

Identification................................................................ 44

Specifications ............................................................. 45

End of life disposal ...................................................... 46

ENGLISH

The illustrations and the OSD (On-Screen Display) in this operation manual are for explanation purposes and may vary slightly

from the actual operations.

The examples used throughout this manual are based on the KRL-37V model.

•

Contents

ENGLISH

KRL3237V_GB.indd 1

2008/06/13 14:49:19

Cleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product.

Do not use liquid cleaners or aerosol cleaners.

Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,

swimming pool and in a wet basement.

Do not place vases or any other water-filled containers on this product. The water may spill onto the

product causing fire or electric shock.

Stand—Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the

product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart,

stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When

mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting

hardware recommended by the manufacturer.

When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops,

excessive force and uneven floor surface can cause the product to fall from the cart.

Ventilation—The vents and other openings in the cabinet are designed for ventilation. Do not cover or

block these vents and openings since insufficient ventilation can cause overheating and/or shorten the

life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they

can block ventilation openings. This product is not designed for built-in installation; do not place the

product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the

manufacturer’s instructions are followed.

The LCD panel used in this product is made of glass. Therefore, it can break when the product is

dropped or impact applied. If the LCD panel is broken, be careful not to be injured by broken glass.

Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating

products (including amplifiers).

To prevent fire, never place any type of candle or naked flames on the top or near the TV set.

To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.

Do not display a still picture for a long time, as this could cause an afterimage to remain.

There is power consumption always if main plug is connected.

Servicing—Do not attempt to service the product yourself. Removing covers can expose you to high

voltage and other dangerous conditions. Request a qualified person to perform servicing.

The LCD panel is a very high technology product, giving you fine picture details.

Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fixed point of

blue, green or red. This is within product specifications and does not constitute a fault.

Precautions when transporting the TV

When transporting the TV, never carry it by holding onto the speakers. Be sure to always carry the TV by two people holding

it with two hands—one hand on each side of the TV.

•

Introduction

Dear Pioneer customer

Thank you for your purchase of the Pioneer Flat screen TV. To ensure safety and many years of trouble-free

operation of your product, please read the Important Safety Precautions carefully before using this product.

Important Safety Precautions

KRL3237V_GB.indd 2

2008/06/13 14:49:20

Introduction

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

(TV) (Standby/On)

(Page 16)

INPUT1–8

Select an input source (Page 16).

Buttons for mode switch

Press to access conventional

analogue TV mode.

DTV

Press to access digital TV mode.

RADIO

DTV: Switch between Radio and

Data mode.

When only data broadcasting (no

radio broadcasting) is transmitted

by DVB, the radio broadcasting

will be skipped.

0–9 numeric buttons

Set the channel.

Enter desired numbers.

Set the page in teletext mode.

When the five Nordic countries

(Sweden, Norway, Finland,

Denmark, or Iceland) are selected

in the country setting from “Auto

Installation” (page 32), DTV

services are four digits. When

another country is selected, DTV

services are three digits.

(INFO)

Press to display the station

information (channel number, signal,

etc.) in the upper right corner of the

screen (Page 37).

CH RETURN

Press to return to the previously

selected channel or external input.

(

)

Select the TV channel.

Select the page in teletext mode.

(Mute)

TV sound on/off.

(EXIT)

Exit the “HOME MENU” screen.

(Cursor)

Select a desired item on the setting

screen.

ENTER

Execute a command within the

“HOME MENU” screen.

ATV/DTV: Display the programme

list when no other “HOME MENU”

screen is running.

(HOME MENU)

“HOME MENU” screen on/off.

•

Buttons for useful operations

(Subpage)

(Page 20)

[

(Subtitle)

Switch subtitle languages on/off

(Pages 20 and 34).

(Reveal hidden Teletext)

(Page 20)

(Freeze/Hold)

Press to freeze a moving image on

the screen.

Teletext: Stop updating teletext

pages automatically or release the

hold mode.

(Teletext)

ATV: Display analogue teletext (Page

20).

DTV: Select MHEG-5 and teletext for

DTV (Page 20).

P. INFO

Press to display programme

information which is transmitted

through digital video broadcasting in

the upper left corner of the screen

(DTV only).

(Volume)

Increase/decrease TV volume.

EPG

DTV: Display the EPG screen (Pages

17–19).

(RETURN)

Return to the previous “HOME

MENU” screen.

Buttons for HDMI CONTROL

If external equipment is connected

via HDMI cables and is HDMI

CONTROL compatible, you can use

these HDMI CONTROL buttons. See

pages 26 and 28 for details.

Buttons for picture adjustments

SCREEN SIZE

Select a screen size (Pages 35 and

39).

AV SELECTION

Select a video setting (Page 31).

SELECT

Switch the selection among

STB

DVD/DVR

, and

VCR

, so that

you can control other connected

equipment, using the supplied

remote control unit (Page 4–7).

(Sound mode)

Select a sound multiplex mode

(Page 16).

Remote control unit

Colour (Red/Green/Yellow/Blue)

buttons

The coloured buttons are

correspondingly used to select the

coloured items on the screen (e.g.

EPG, MHEG-5, Teletext).

(SOURCE)

(Pages 6–7)

NOTE

Press and hold both

and

on the remote control unit to show “100Hz” demonstration in a dual screen.

•

KRL3237V_GB.indd 3

2008/06/13 14:49:23

Introduction

Controlling other equipment using

the supplied remote control unit

Using the supplied remote control unit, you can control

other equipment in connection: a set-top box (STB),

DVD player, DVD/HDD recorder (DVR), BD player or

VCR.

Before using this function, you need to preset the

supplied remote control unit with the manufacture

code of the equipment to be controlled. When you

then want to control the equipment, press

SELECT

on the remote control unit to select an appropriate

mode depending on the equipment; the selection is

switched among

STB

DVD/DVR

, and

VCR

. The

corresponding mode indicators on the remote control

unit show the currently selected mode.

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

NOTE

When you control a BD player, select the DVD/DVR

mode.

Presetting manufacture codes

Press

SELECT

on the remote control unit

to select the STB, DVD/DVR, or VCR mode

depending on the equipment.

After confirming that the indicator of the

previously selected mode goes off, press and

hold

SELECT

, and then press

on the remote

control unit.

The corresponding mode indicator flashes.

Press

–

to enter a three-digit manufacture

code.

See the manufacture code list to identify an

appropriate code. The mode indicator lights up

for approximately one second and then goes off;

presetting the manufacture code is completed.

EXIT

DVD TOPMENU/

GUIDE

EPG

4 5 6

7 8 9

P.INFO

1 2 3

INFO

SOURCE

STB DVR VCR

DVD

SELECT

CTRL

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

•

NOTE

If you perform no operation for approximately one

minute while a mode indicator is flashing, the code

presetting procedure is quitted.

If you enter a code not listed in the table, a mode

indicator flashes quickly for approximately one

second and then flashes as before.

To quit the code presetting procedure halfway

while a mode indicator is flashing, you may press

SELECT

on the remote control unit.

The factory default manufacture codes for the STB,

DVD/DVR, and VCR modes are “000”, “100”, and

“500” respectively.

Manufacture codes

You may not be able to control some equipment

in the tables partially or entirely with the supplied

remote control unit.

STB

000

PIONEER 1 (factory default)

001

PIONEER 2

002

CANAL SATELLITE

003

HUMAX

004

PACE 1

005

PACE 2

006

QUALI-TV

007

SKY DIGITAL

DVD

100

PIONEER 1 (factory default)

101

PIONEER 2

102

AKAI

103

DENON

104

HITACHI

105

JVC

106

KENWOOD 1

107

KENWOOD 2

108

PANASONIC 1

109

PANASONIC 2

110

PHILIPS 1

111

PHILIPS 2

112

SAMSUNG

113

SHARP

114

SONY 1

115

SONY 2

116

SONY 3

117

THOMSON

118

TOSHIBA

119

YAMAHA

•

KRL3237V_GB.indd 4

2008/06/13 14:49:23

Introduction

DVR

200

PIONEER 1

201

PIONEER 2

202

PIONEER 3

203

PANASONIC

204

PHILIPS 1

205

PHILIPS 2

206

SHARP

207

SONY

208

TOSHIBA

300

PIONEER

301

302

PANASONIC

303

SAMSUNG

304

SONY

305

TOSHIBA

VCR

500

PIONEER 1 (factory default)

501

PIONEER 2

502

AIWA 1

503

AIWA 2

504

AKAI 1

505

AKAI 2

506

AKAI 3

507

DAEWOO

508

GRUNDIG 1

509

GRUNDIG 2

510

GRUNDIG 3

511

GRUNDIG 4

512

HITACHI 1

513

HITACHI 2

514

HITACHI 3

515

JVC 1

516

JVC 2

517

JVC 3

518

JVC 4

519

JVC 5

520

LOEWE 1

521

LOEWE 2

522

MATSUI

523

ORION

524

PANASONIC 1

525

PANASONIC 2

526

PHILIPS 1

VCR

527

PHILIPS 2

528

PHILIPS 3

529

SANYO

530

SAMSUNG 1

531

SAMSUNG 2

532

SAMSUNG 3

533

SAMSUNG 4

534

SHARP

535

SONY 1

536

SONY 2

537

SONY 3

538

SONY 4

539

SONY 5

540

SONY 6

541

SONY 7

542

THOMSON

543

TOSHIBA

KRL3237V_GB.indd 5

2008/06/13 14:49:25

Introduction

Using with other equipment (STB)

DTV

RADIO

P.INFO

INFO

CH RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

SOURCE

STB DVR VCR

DVD

SELECT

DTV

RADIO

P.INFO

CH RETURN

DVR VCR

DVD

SELECT

Using with other equipment (VCR)

DTV

RADIO

P.INFO

INFO

CH RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

DTV

RADIO

P.INFO

INFO

CH RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

STB DVR

DVD

SELECT

STB (set-top box) control buttons

When in the STB mode, the buttons on the remote

control unit function as below.

0–9

Function as the numeric buttons.

INFO

Press to display information on the current broadcasting.

Press to tune in a higher or lower channel.

EXIT

Press to exit the broadcasting menu screen or the

broadcasting guide screen.

ENTER

Press to activate the selected function.

Press to select items on the broadcasting menu screen

or the broadcasting guide screen.

Press to display the broadcasting menu screen.

SOURCE

Turns the set-top box on and off.

GUIDE

Press to display the broadcasting guide screen.

RETURN

When the broadcasting menu screen is in display, press

to restore the immediately previous screen.

VCR control buttons

When in the VCR mode, the buttons on the remote

control unit function as below.

0–9

Function as the numeric buttons.

Press to select channels of the TV tuner on the VCR.

(PAUSE/STILL)

Set pauses and still pictures.

(REC)

Start recording.

SOURCE

Turn the power of the VCR on and off.

(REW)

Rewind the tape and allows picture search.

(PLAY)

Start playback.

(FF)

Fast-forward the tape and allows picture search.

(STOP)

Stop playback.

KRL3237V_GB.indd 6

2008/06/13 14:49:25

Introduction

Using with other equipment (DVD/DVR)

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

EXIT

CTRL

HDMI

REC STOP

CM SKIP

STB

VCR

SELECT

DVD/DVR control buttons

When in the DVD/DVR mode, the buttons on the

remote control unit function as below.

0–9

Function as the numeric buttons.

(DVD/HDD recorder (DVR) only)

Press to change the channel of the tuner built in the

DVD/HDD recorder (DVR).

ENTER

Press to activate the selected function.

Press to select items on the DVD menu screen.

Press to display the DVD menu.

(PAUSE/STILL)

Set pauses and still pictures.

(REC) (DVD/HDD recorder (DVR) only)

Start recording.

TOOLS (Pioneer BD player only)

Press to display the “TOOLS” menu.

SOURCE

Turn on and off the power of the DVD player or DVD/HDD

recorder (DVR).

DVD TOP MENU

When this button is pressed, the DVD top menu will

appear.

RETURN

When the DVD menu is in display, press to restore the

immediately previous screen.

(CHAPTER SEARCH)

Each time you press, you move back to the start of the

previous chapter.

(CHAPTER SEARCH)

Each time you press, you move ahead to the start of the

next chapter.

(SCAN)

Press to go backward.

(PLAY)

Start playback.

(SCAN)

Press for fast forward.

(STOP)

Press to stop playback or recording. With some DVD

players or DVD/HDD recorders (DVRs), pressing the

button twice may open the disc tray.

REC STOP (DVD/HDD recorder (DVR) only)

Press

and

at the same time to stop recording. This

operation is available for only Pioneer and Sony DVD/

HDD recorders (DVRs).

HDD (DVD/HDD recorder (DVR) only)

Press to select the hard disk (HDD) for playback or

recording.

DVD (DVD/HDD recorder (DVR) only)

Press to select the DVD for playback or recording.

NOTE

You can control a BD player in the DVD/DVR mode.

The DVD player, DVD/HDD recorder (DVR) or BD

player cannot be selected at the same time.

•

KRL3237V_GB.indd 7

2008/06/13 14:49:28

Trademarks

“HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC.”

•

Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

•

TruSurround XT, SRS and

symbol are trademarks of SRS Labs, Inc.

TruSurround XT technology is incorporated under license from SRS Labs, Inc.

•

The “HD ready 1080P” Logo is a trademark of EICTA.

•

The DVB logo is the registered trademark of the Digital Video Broadcasting—

DVB—project.

•

“x.v.Colour” and

are trademarks of Sony Corporation.

•

Introduction

KRL3237V_GB.indd 8

2008/06/13 14:49:29

Introduction

INPUT4 (HDMI) terminal

INPUT5 (HDMI) terminal

INPUT7 (ANALOGUE RGB/AUDIO)

terminals

DIGITAL AUDIO OUTPUT terminal

OUTPUT (AUDIO) terminals

ANT (antenna) terminal

TV (Front view)

TV (Rear view)

INPUT6 (HDMI/AUDIO) terminals

RS-232C terminal

INPUT8 (COMPONENT/AUDIO)

terminals

INPUT2 (RGB) terminal

INPUT1 (RGB) terminal

INPUT3 terminals

PHONES (Headphones)

SERVICE socket

COMMON INTERFACE slot

AC INPUT terminal

RLS*

WARNING:

Excessive sound pressure from

earphones and headphones can cause

hearing loss.

RLS = Room Light Sensor

Remote control

sensor

indicator

SLEEP

indicator

STANDBY

indicator

HOME MENU

button

(Power) button

Volume

buttons

Programme

(channel) buttons

(Input source) button

KRL3237V_GB.indd 9

2008/06/13 14:49:31

Confirm that there are ten screws with the stand

unit.

Attach the supporting post for the stand unit

onto the base using the six screws with the

screw driver (supplied) as shown.

Preparation

Inserting the stand.

Insert the stand into the openings on the

bottom of the TV (Hold the stand so it will

not drop from the edge of the base area).

Insert and tighten the four short screws into

the four holes on the rear of the TV.

NOTE

To detach the stand unit, perform the steps in reverse

order.

•

Supplied accessories

Attaching the stand unit

Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.

Before performing work, spread cushioning over the surface on which you will be laying the TV. This will prevent

it from being damaged.

CAUTION

Attach the stand in the correct direction.

Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

•

Remote control unit

(

AC cord (

Stand unit (

Cable clamp (

Pages 3 and 11

Page 10

Page 14

Operation manual (This publication)

Warranty card

•

“AA” size alkaline battery (

2) ... Page 11

•

SOURCE

STB DVR VCR

DVD

SELECT

HOME

RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

P.INFO

INFO

CH RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

DTV

RADIO

INPUT

ENTER

Supporting

post

Soft

cushion

KRL3237V_GB.indd 10

2008/06/13 14:49:35

Preparation

Inserting the batteries

Before using the TV for the first time, insert two supplied “AA” size alkaline batteries. When the batteries become

depleted and the remote control unit fails to operate, replace the batteries with new “AA” size batteries.

Open the battery cover.

Insert two supplied “AA” size alkaline batteries.

Place batteries with their terminals corresponding to the

(

) and (

) indications in the battery compartment.

Close the battery cover.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

Do not mix batteries of different types. Different types of batteries have different characteristics.

Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause

chemical leakage in old batteries.

Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you

find any chemical leakage, wipe thoroughly with a cloth.

The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

If you will not be using the remote control unit for an extended period of time, remove the batteries from it.

When replacing the batteries, use alkaline batteries instead of zinc-carbon ones.

•

Cautions regarding the remote control unit

Do not expose the remote control unit to shock. In addition, do not expose the

remote control unit to liquids, and do not place in an area with high humidity.

Do not install or place the remote control unit under direct sunlight. The heat may

cause deformation of the unit.

The remote control unit may not work properly if the remote control sensor of the

TV is under direct sunlight or strong lighting. In such cases, change the angle of the

lighting or the TV, or operate the remote control unit closer to the remote control

sensor.

•

SOURCE

STB DVR VCR

DVD

SELECT

HOME

RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

P.INFO

INFO

CH RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

DTV

RADIO

INPUT

ENTER

30°

Using the remote control unit

Use the remote control unit by pointing it towards the remote control sensor. Objects between the remote control

unit and sensor may prevent proper operation.

5 m

Remote control sensor

KRL3237V_GB.indd 11

2008/06/13 14:49:38

Installation precautions

Observe the following precautions when installing with

any items such as the optional stand.

When using other stands, brackets or equivalent

items

Consult your dealer.

The following mounting holes can be used for the

installation.

Rear view

(KRL-37V)

(KRL-32V)

NOTE

The mounting holes can be used after removing the

black seals and the screws.

CAUTION

Use M6 screws, which go 12 mm to 15 mm in

depth from the mounting surface of the flat screen

TV. See the side view shown to the right.

Be careful not to block the ventilation opening at the

rear of the flat screen TV.

Be sure to install the flat screen TV on a flat surface

because the LCD panel used in this product is made

of glass.

The screw holes other than the illustrations above

are to be used only for the specified products. Never

use them for mounting non-specified products.

NOTE

Pioneer shall not be liable for any personal injury

or product damage that results from the use of

mounting items.

•

Mounting

holes

Mounting

holes

Mounting

holes

Mounting

holes

Preparation

Side view

Flat

screen

Mounting surface

Mounting bracket

(or equivalent item)

M6 screw

12 mm to 15 mm

KRL3237V_GB.indd 12

2008/06/13 14:49:40

Quick guide

1 2 3

Initial installation overview

Follow the steps below one by one when using the TV for the first time. Some steps may not be necessary

depending on your TV installation and connection.

Connect an antenna cable to

the antenna terminal (Page

14).

If necessary, insert a smart

card into the Common

Interface slot to watch

scrambled broadcasts (Pages

14 and 25).

Connect the AC cord to the TV

(Page 14).

Turn on the power using

the TV (Page 16).

Run the initial auto installation

(Page 15).

Language setting

English

Italiano

Svenska

Country setting

Austria A B/G

Finland FIN B/G

Greece GR

B/G

Channel search setting

Analogue Search

Digital Search

✔

Congratulations!

Now you can watch TV.

If necessary, adjust the

antenna to attain maximum

signal reception (Page 15).

Preparation

Power on and

run the auto

installation

Watch TV

Connect

external devices

Connect external

devices such as a

DVD player/recorder

as instructed (Pages

21–23).

Connect external

audio devices such as

speakers/amplifier as

instructed (Pages 21

and 24).

Start searching

channels

KRL3237V_GB.indd 13

2008/06/13 14:49:41

Quick guide

Supplying power to the antenna

You must supply power to the antenna in order

to receive digitally/terrestrially broadcast stations

after connecting the antenna cable to the antenna

terminal on the rear of the TV.

Press

and the “HOME MENU” screen displays.

Press

to select “Setup”.

Press

to select “Antenna Setup-DIGITAL”, and

then press

ENTER

Press

to select “Supply Voltage”, and then press

ENTER

Press

to select “On”, and then press

ENTER

Before turning on the power

Bundling the cables

(For U.K. and Eire)

Carefully insert the

CA Module in the

Common Interface

slot with the contact

side forward.

The logo on the CA

Module must be

facing forward from

the rear of the TV.

Cable clamp

Bundle the cables with

the clamp.

AC cord

Place the TV close

to the AC outlet, and

keep the power plug

within reach.

Standard DIN45325 plug (IEC 169-2) 75

coaxial cable

(For Europe, except

U.K. and Eire)

KRL3237V_GB.indd 14

2008/06/13 14:49:45

Quick guide

Initial auto installation

When the TV is powered on for the first time after

purchase, the initial auto installation wizard appears.

Follow the menus and make the necessary settings

one after another.

Press

on the TV.

The initial auto installation wizard appears.

Setting the OSD language.

English

Italiano

Svenska

Press

to select the desired language,

and then press

ENTER

Setting the country (Location of the TV).

Austria A B/G

Finland FIN B/G

Greece GR

B/G

Press

to select your country or area,

and then press

ENTER

This setting screen only appears during the first

installation.

Starting channel search.

Analogue Search

Digital Search

Press

to select “Digital Search” or

“Analogue Search”, and then press

ENTER

If you want to search for more broadcasts, execute

“Additional Search” from the “Programme Setup”

menu (Pages 32 and 33).

To watch both analogue broadcasts and digital

broadcasts, you should perform the channel search

setting for each format.

EXAMPLE

If you execute “Digital Search” in the initial auto

installation wizard, you should perform “Analogue

Search” from “Auto Installation” under the “Setup”

menu.

•

The TV searches for, sorts and stores all the

receivable TV stations according to their settings

and the connected antenna.

To abort the initial auto installation in progress, press

(RETURN)

NOTE

If you turn off the power on the TV after performing step 4,

the initial auto installation wizard does not appear. The auto

installation function allows you to execute the installation

again from the “Setup” menu (Page 32).

The initial auto installation wizard will go off if you leave

the TV unattended for 30 minutes before searching for

channels in step 5.

Checking signal strength and

channel strength

If you install a DVB-T antenna for the first time or

relocate it, you should adjust the alignment of the

antenna to receive a good reception while checking

the antenna setup screen.

Press

and the “HOME MENU” screen

displays.

Press

to select “Setup”.

Press

to select “Antenna Setup-DIGITAL”,

and then press

ENTER

Checking signal strength

Press

to select “Signal Strength”.

Signal Strength

Supply Voltage

Channel Strength

Signal Strength

Quality

Current

Max.

CH No.

Current

Max.

Checking channel strength

Press

to select “Channel Strength”, and

then press

ENTER

You can input a specified frequency band using the

–

numeric buttons.

Signal Strength

Supply Voltage

Channel Strength

Signal Strength

Quality

Current

Max.

CH No.

Current

Max.

MHz

Position and align the antenna so that the

maximum possible values for “Signal Strength”

and “Quality” are obtained.

NOTE

The values of “Signal Strength” and “Quality” indicate when

to check the appropriate alignment of the antenna.

•

Confirm the following before turning

on the power

Is the antenna cable connected?

Is the AC cord plugged in?

KRL3237V_GB.indd 15

2008/06/13 14:49:48

Watching TV

Selecting a sound mode

DTV mode:

If multi sound modes are received, each time you

press

the mode switches as follows.

Audio (ENG) : STEREO

L/R

Audio (ENG) : CH A

CH A

CH B

CH AB

Audio (ENG) : MONO

Press

to select L or R sound when the STEREO

or DUAL MONO screen is displayed.

Audio (ENG) : STEREO

L/R

NOTE

The sound mode screen disappears in six seconds.

Selectable items vary depending on the received broadcasts.

ATV mode:

Each time you press

, the mode switches as

shown in the following tables.

NICAM TV broadcasts selection

Signal

Selectable items

Stereo

NICAM STEREO, MONO

Bilingual

NICAM CH A, NICAM CH B, NICAM CH AB, MONO

Monaural

NICAM MONO, MONO

A2 TV broadcasts selection

Signal

Selectable items

Stereo

STEREO, MONO

Bilingual

CH A, CH B, CH AB

Monaural

MONO

NOTE

When no signal is input, the sound mode will display “MONO”.

•

Watching analogue

broadcasts

Watching digital

broadcasts

DTV

RADIO

DTV

RADIO

P.INFO

INFO

Daily operation

Switching on/off

Turning on/off the power

Press

on the TV.

Switch it off by pressing

on the TV.

Standby mode

To standby mode

If the TV is switched on, you can switch it to standby

by pressing

(TV)

on the remote control unit.

Switching on from standby

From standby, press

(TV)

on the remote control unit.

INPUT

TV indicator status

TV indicator

Status

ON (Blue)

Power on

STANDBY (Red)

Standby

SLEEP (Orange)

Sleep timer is on

NOTE

If you are not going to use this TV for a long period of time, be sure

to remove the AC cord from the AC outlet.

A small amount of electric power is still consumed even when

turned off.

•

Switching between analogue and

digital broadcasts

Changing channels

With 0–9:

With P

Selecting an external video source

Once the connection is made, press

INPUT1–8

on the

remote control unit or

on the TV to switch over to

the appropriate external source.

NOTE

When turning off the power using

on the TV, EPG data (Electronic

programme guide) will be lost, and

programmed timer recordings will

not be performed by the TV.

•

KRL3237V_GB.indd 16

2008/06/13 14:49:50

Watching TV

Useful functions

Common Operation

Press

and the “HOME MENU” screen

displays.

Press

to select “Digital Setup”.

Press

to select “EPG Setup”, and then

press

ENTER

REC Picture Size

Download Setup

EPG Setup

Subtitle

CI Menu

[Yes]

[16:9 TV]

Press

to select the desired item, and then

press

ENTER

(Example: “EPG Setup”, “Display

Range Setup”, etc.).

Yes

EPG Setup

Display Range Setup

Genre Icon Setup

Press

to select or adjust the desired

item, and then press

ENTER

(Example: “Yes”,

“No”, etc.).

EPG (Electronic Programme Guide)

EPG (Electronic Programme Guide) is a programme list that is displayed on the screen. With the EPG, you can

check the schedule of DTV/RADIO/DATA, view detailed information about them, tune to an event currently on-air

and set a timer for future events.

EPG Overview

Basic functions

Useful settings for using EPG

EPG display settings

EPG Setup (setting for receiving EPG

data)

If you want to use the EPG for digital stations, select

“Yes”. The EPG data must be automatically captured

while the TV is in standby mode. After setting to “Yes”,

it may take some time to turn off the power using the

remote control unit due to the process of the data

capture.

NOTE

If the TV main power is switched off, the EPG data will not

be captured.

Display Range Setup

The “Display Range Setup” allows you to select three

types of time spans for display on the screen.

•

Genre Icon Setup

You can grey out or place a mark on desired genres

and smoothly search for programmes you frequently

watch.

Genre Icon List

Icon

Genre

Icon

Genre

Movie/Drama

Music/Ballet/Dance

News/Current affairs

Arts/Culture (without

music)

Show/Game show

Social/Political

Issues/Economics

Sports

Education/Science/

Factual Topics

Children’s/Youth

programmes

Leisure hobbies

Select a programme using EPG (Page 18)

Check programme information (Page 18)

Search for a programme by category (Page 18)

Search for a programme by date and time

(Page 18)

Timer recording using EPG (Page 19)

Mode1:

Displays six hours of programme information.

Mode2:

Displays three hours of programme information.

Mode3:

Changes to the EPG display format with a

vertical time span.

Item

KRL3237V_GB.indd 17

2008/06/13 14:49:54

Check programme information

Press

to select the programme you

want to check.

Press

Red

button.

040

10 : 00AM - 1 : 00 AM

BBC News 24

BBC News

Programme Info.

Back to EPG

The BBC’s rolling news service with headlines every 15 minutes.

10 AM

0 PM

BBC TWO

002

BBC THREE

007

BBC FOUR

010

BBC FIVE

012

CBBC Channel

030

BBC

061

BB22

062

BBC NEWS 24

340

BBCi

351

This is BBC THREE

BBC NEWS

BBCi

This is BBC THREE

Press

ENTER

to tune to the selected programme.

Search a programme in a category

Press

Green

button.

Press

to select the desired genre, and

then press

ENTER

Press

to select a programme you want to

watch, and then press

ENTER

10 : 50 AM - 11 : 05 AM

Mon 19/05

CBBC Cahnnel

030

time

10 : 50 AM - 11 : 10 AM

Mon 19/05

BBC TWO

002

School is Lock

11 : 05 AM - 11 : 20 AM

Mon 19/05

CBBC Cahnnel

030

Words and Pictures

Movie/Drama

News/Current affairs

Show/Game show

Sports

Children’s/Youth programmes

Music/Ballet/Dance

Arts/Culture (without music)

Social/Political Issues/Economics

Education/Science/Factual Topics

Leisure hobbies

[Today] 0-12

[Today] 12-0

[Tue] 20 0-12

[Tue] 20 12-0

Refer to page 17 for the genre setting.

•

Search for a programme by date/time

Press

Yellow

button.

Press

to select the desired time span, and

then press

ENTER

Search by Time

10 AM

11 0

1 2 3

BBC TWO

002

BBC THREE

007

BBC FOUR

010

BBC FIVE

012

CBBC Channel

030

BBC 1

061

BB22

062

BBC NEWS 24

340

This is BBC THREE

BBC NEWS

This is BBC THREE

Back to EPG

SIT 1

994

: Select Time

Enter

+1 Week

: Enter

0 AM -

6 AM

6 AM -

0 PM

0 PM -

6 PM

6 PM -

0 AM

Today

Press

to select the desired programme,

and then press

ENTER

NOTE

When you select a programme outside of the current time

span, the timer setting screen is displayed (Page 19).

•

Select a programme

Select the time span

Press

to select the time span you want to search.

Continue to press

to display programmes in the next time span.

Select the desired programme

Press

to select the desired programme.

are displayed on the left of the services, continue to press

to display next or previous screen.

•

Watching TV

Selecting a programme using EPG

Basic Operation

The illustrations on this page are explained using three digit services.

Display/Close the EPG screen

Press

EPG

Selecting a programme

EPG

[Mon]16/04 10:57 AM

[DTV-TV]

Today (Tue)20

(Wed)21

(Thu)22

(Fri)23 (Sat)24

(Sun)25

(Mon)26

040

10 : 00AM - 1 : 00 AM

BBC News 24

BBC News

10 AM

0 PM

BBC TWO

002

BBC THREE

007

BBC FOUR

010

BBC FIVE

012

CBBC Channel

030

BBC

061

BB22

062

BBC NEWS 24

340

BBCi

351

SIT

996

BBC ONE

999

SIT

994

SIT

995

SIT

998

SIT

997

This is BBC THREE

BBC NEWS

This is BBC THREE

BBCi

This is BBC THREE

: Select

: Enter

: Back

: Exit

Programme info.

Search By Genre

Search By Date

Timer List

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

EXIT

HOME

RETURN

Programme Information

Search by Time

Back to EPG

: Select Time

Enter +1

Week

: Enter

0 - 6

6 -12

12 - 18

18 - 0

Today

Programme Info.

Back to EPG

The BBC’s rolling news service with headlines every 15 minutes.

Movie/Drama

News/Current affairs

Show/Game show

Sports

Children’s/Youth programmes

Music/Ballet/Dance

Arts/Culture (without music)

Social/Political Issues/Economics

Education/Science/Factual Topics

Leisure hobbies

Genre

Date/Time

KRL3237V_GB.indd 18

2008/06/13 14:49:55

Watching TV

Timer recording using EPG

You can record TV programmes using data from the

EPG.

Press

EPG

Press

to select the programme you

want to record, and then press

ENTER

Press

to select the preferred timer setting,

and then press

ENTER

Watch

Record

If you select “No”, the TV returns to the EPG screen.

Watching a programme at a set time

Press

to select “Watch”, and then press

ENTER

Press

to select “Yes”, and then press

ENTER

The selected TV programme is marked with an icon.

Recording a programme at a set time

Press

to select “Record”, and then press

ENTER

Press

to select the preferred timer

recording type, and then press

ENTER

•

Press

to select “Yes”, and then press

ENTER

The selected TV programme is marked with an icon.

NOTE

Refer to pages 21–23 for connecting external devices.

•

Cancelling the timer recording

Press

EPG

Press

to select the programme on

timer setup, and then press

ENTER

Press

to select “Cancel”, and then press

ENTER

Press

to select “Yes”, and then press

ENTER

Cancelling using the Blue button on the

remote control unit

Press

EPG

Press

Blue

button to display the timer recording

screen.

Press

to select a programme with a set

timer recording you want to change, and then

press

ENTER

Press

to select “Cancel” and then press

ENTER

Press

to select “Yes”, and then press

ENTER

i/o link.A:

Records a programme at a set time when a

device compatible with i/o link.A is connected.

VHS tape:

Records a programme at a set time when a

device compatible with VHS tape is connected.

Item

KRL3237V_GB.indd 19

2008/06/13 14:49:59

Buttons for teletext operations

Buttons

Description

(

)

Increase or decrease the page number.

Colour (Red/

Green/Yellow/

Blue)

Select a group or block of pages

displayed in the coloured brackets at

the bottom of the screen by pressing

the corresponding

Colour (Red/Green/

Yellow/Blue)

buttons on the remote

control unit.

0–9

Directly select any page from 100 to 899

by using the

–

numeric buttons.

(Reveal

hidden

Teletext)

Reveal or hide hidden information such

as an answer to a quiz.

(Freeze/

Hold)

Stop updating teletext pages

automatically or release the hold mode.

[

(Subtitle

for Teletext)

Display the subtitle or exit the subtitle

screen.

Subtitles will not be displayed when

the service does not contain subtitle

information.

•

(Subpage)

Reveal or hide subpages.

Red

button: Move to the previous

subpage.

Green

button: Move to the following

subpage.

These two buttons are shown on the

screen by the symbols “

”

and “

”.

•

Using the MHEG-5 application (UK

only)

Some services bring you programmes with the MHEG

(Multimedia and Hypermedia Expert Group) application

encoded, letting you experience DTV interactively.

If provided, the MHEG-5 application will start when you

press

Sample MHEG-5 screen

Watching TV

Teletext

What is Teletext?

Teletext broadcasts pages of information and

entertainment to specially equipped TV. Your TV

receives teletext signals broadcast by a TV network,

and decodes them into graphical format for viewing.

News, weather and sports information, stock

exchange prices and programme previews are among

the many services available.

Turning Teletext on/off

Select a TV channel or external source providing

a teletext programme.

Press

to display the Teletext.

Many stations use the TOP operating system, while

some use FLOF (e.g. CNN). Your TV supports both

these systems. The pages are divided into topic

groups and topics. After switching on the teletext, up

to 2,000 pages are stored for fast access.

Each time you press

, the screen switches as

shown below.

Press

again to display the teletext on the right

screen and the normal image on the left screen.

If you select a programme with no teletext signal, “No

Teletext available” displays.

The same message displays during other modes if no

teletext signal is available.

•

NOTE

Teletext will not work if the selected signal type is

RGB (Page 38).

•

TELETEXT

KRL3237V_GB.indd 20

2008/06/13 14:50:00

Connecting external devices

Before connecting ...

Be sure to turn off the TV and any devices before making any connections.

Firmly connect a cable to a terminal or terminals.

Carefully read the operation manual of each external device for possible connection types. This also helps you

get the best possible audiovisual quality to maximise the potential of the TV and the connected device.

Refer to page 39 for connecting a PC to the TV.

Introduction to connections

The TV is equipped with the terminals as shown below. Find the cable corresponding the TV’s terminal and

connect the device.

NOTE

The cables illustrated in pages 21–24 are commercially available items.

•

When using an S-video cable, you also need to connect an audio cable (R/L).

HDMI device (Page 22)

Game console or

camcorder (Page 22)

Audio device (Page 24)

HDMI-certified cable

DVI/HDMI Cable

ø 3.5 mm stereo minijack cable

S-video cable

AV cable

Audio cable

Optical audio cable

SCART cable

Component cable

Audio cable

Video recording device

(Pages 22 and 23)

KRL3237V_GB.indd 21

2008/06/13 14:50:01

Connecting external devices

HDMI connection

The HDMI connections (High Definition Multimedia

Interface) permit digital video and audio transmission

via a connection cable from a player/recorder. The

digital picture and sound data are transmitted without

data compression and therefore lose none of their

quality. Analogue/digital conversion is no longer

necessary in the connected devices, which also would

result in quality losses.

DVI/HDMI conversion

Using an DVI/HDMI adapter cable, the digital video

signals of a DVD can also be played via the compatible

HDMI connection. The sound must be fed in additionally.

When connecting a DVI/HDMI conversion adapter/cable to the

HDMI terminal, the image may not come in clearly.

Both HDMI and DVI use the same HDCP copy

protection method.

NOTE

If a connected HDMI device is HDMI CONTROL compatible,

you can take advantage of versatile functions (Pages 26–28).

Video noise may occur depending on the type of HDMI cable used.

Make sure to use a certified HDMI cable.

When playing the HDMI image, the best possible format for the

picture will be detected and set automatically.

Supported video signal:

576i, 576p, 480i, 480p, 1080i, 720p, 1080p

See page 42 for PC signal compatibility.

•

Component connection

You will enjoy accurate colour reproduction and high

quality images through the INPUT8 terminal when

connecting a DVD player/recorder or other device.

(

CB)

(

CR)

COMPONENT

AUDIO

S-VIDEO/VIDEO connection

You can use the INPUT3 terminal when connecting to

a game console, camcorder, a DVD player/recorder or

other device.

NOTE

When using an S-video cable, you also need to connect an

audio cable (R/L).

INPUT3: The S-VIDEO terminal has priority over the VIDEO terminal.

•

DVI/HDMI

cable

ø 3.5 mm stereo

minijack cable

HDMI-certified

cable

Audio cable

Component

cable

AV cable

S-video cable

Example of connectable devices

DVD player/recorder

Blu-ray player/recorder

After connecting

HDMI Audio Select

After connecting, you must set the audio signal

compatible with the cable you use for the HDMI

device.

Go to “HOME MENU” > “Option” > “HDMI

Audio Select”.

Select “Digital” for audio signals via the

HDMI terminal. Select “Analogue” for audio

signals via the AUDIO jack (INPUT6).

Example of connectable devices

VCR

DVD player/recorder

Blu-ray player/recorder

Example of connectable devices

VCR

DVD player/recorder

Blu-ray player/recorder

Game console

Camcorder

(

KRL3237V_GB.indd 22

2008/06/13 14:50:05

Connecting external devices

NOTE

In cases when the decoder needs to receive a signal from the TV, make sure to select the appropriate input terminal to which

the decoder is connected in “Manual Adjust” in the “Analogue Setting” menu (Page 33).

TV-VCR advanced AV Link systems may not be compatible with some external sources.

You cannot connect the VCR with Decoder using a fully wired SCART cable when selecting “Y/C” under “INPUT2” in the

“Input Select” menu.

Controlling devices with SCART using i/o link.A

This TV incorporates four typical i/o link.A functions for smooth connections between the TV and other audiovisual

equipment.

One Touch Play

While the TV is in standby mode, it automatically turns on and plays back the image from the audiovisual source

(e.g. VCR, DVD player/recorder).

TV Standby

When the TV enters standby mode, the connected audiovisual equipment (e.g. VCR, DVD player/recorder) enters

standby mode as well.

WYSIWYR (What You See Is What You Record)

When the remote control unit of the connected VCR has the WYSIWYR button, you can automatically start

recording by pressing the WYSIWYR button.

Preset Download

Automatically transfers the channel preset information from the tuner on the TV to the one on the connected

audiovisual equipment (e.g. VCR) via the INPUT2 terminal.

NOTE

Refer to the operation manuals of external equipment for details.

The i/o link.A function works only when audiovisual equipment is connected to the INPUT2 terminal with a fully wired SCART

cable.

The use of the i/o link.A function is only possible if the TV has enforced a complete auto installation with the connected

audiovisual equipment (Page 15, Initial auto installation).

The availability of the i/o link.A function depends on the audiovisual equipment used. Depending on the manufacturer and type

of equipment used, it is possible that the described functions may be completely or partially unusable.

•

SCART connection

Example of connectable devices

Decoder

When using the INPUT2 (SCART) terminal

If your VCR supports TV-VCR advanced AV Link

systems, you can connect the VCR using a fully wired

SCART cable.

Example of connectable devices

VCR

DVD player/recorder

SCART cable

Decoder

SCART cable

Decoder

VCR

KRL3237V_GB.indd 23

2008/06/13 14:50:07

Connecting external devices

DIGITAL AUDIO IN

AUX1 IN

AUX OUT

Connecting an amplifier with analogue

audio input

Connecting an amplifier with digital audio

input

Speaker/amplifier connection

Connect an amplifier with external speakers as shown below.

After connecting

Digital audio output setting

After connecting an amplifier with digital audio

input and external speakers as shown, you should

set an audio output format compatible with

the programme you are watching or the device

connected.

Go to “HOME MENU” > “Option” > “Digital

Audio Output” > select “PCM” or “Dolby

Digital”.

Optical audio cable

Audio cable

Amplifier with

analogue audio input

Amplifier with

digital audio input

KRL3237V_GB.indd 24

2008/06/13 14:50:09

Connecting external devices

Inserting a smart card

In order to receive coded digital stations, a Common

Interface Module (CA Module) and a smart card must

be inserted in the Common Interface slot of the TV

(Page 14).

The CA Module and the smart card are not supplied

accessories. They are usually available from your

dealers.

Inserting the smart card into the CA Module

With the side with the gold coloured contact

chip facing the side of the CA Module marked

with the provider’s logo, push the smart card

into the CA Module as far as it will go. Note the

direction of the arrow printed on the smart card.

Inserting the CA Module in the Common

Interface slot

Carefully insert the CA

Module in the Common

Interface slot with the

contact side forward. The

logo on the CA Module

must be facing forward

from the rear of the TV.

Do not use excessive

force. Make sure the

module is not bent in the

process.

Checking CA Module information

NOTE

Make sure that the CA Module is properly inserted.

This menu is only available for digital stations.

Press

and the “HOME MENU” screen

displays.

Press

to select “Digital Setup”.

The content of this menu depends on the provider of

the CA Module.

Press

to select “CI Menu”, and then press

ENTER

Removing the CA Module

Remove the cover from the rear of

the TV.

Remove the module from the TV.

Replace the cover.

•

Module

General information on CA Module displays.

Adjustment parameters of each smart card

displays.

Enquiry

You can input numerical values such as passwords

here.

NOTE

The content of each screen depends on the provider of

the CA Module.

•

KRL3237V_GB.indd 25

2008/06/13 14:50:10

HDMI CONTROL

Controlling HDMI devices using HDMI CONTROL

What is HDMI CONTROL?

Using the HDMI CEC (Consumer Electronics Control) protocol, with HDMI CONTROL

you can interactively operate compatible system devices (AV amplifier, DVD player/

recorder, Blu-ray player/recorder) using a single remote control unit.

What you can do with HDMI CONTROL

One Touch Recording

You do not have to search for the remote control unit of your recording device. Press the

or the

REC STOP

buttons to start/stop recording what you see on the recorder.

One Touch Play

When the TV is in standby mode, it will automatically turn on and play back the image

from the HDMI source.

Single remote control operation

HDMI CONTROL automatically recognises the connected HDMI device and you can

control the TV and the devices as if using a universal remote control unit.

Operating Title list of external devices

In addition to displaying the TV’s own Timer list (Page 18), you can also call up the

external player’s Top menu or Pioneer BD Player’s/Pioneer Recorder’s Title list provided

that the devices support HDMI CONTROL.

Multiple control of HDMI devices

You can select which HDMI device to operate using the

HDMI CTRL

button.

NOTE

When you use HDMI CONTROL, make sure to use a certified HDMI cable.

Point the remote control unit toward the TV, not to the connected HDMI device.

Video noise may occur depending on the type of HDMI cable used. Make sure to use a certified

HDMI cable.

Up to three HDMI recording devices, one AV amplifier and two players can be connected using

this system.

These operations affect the HDMI device selected as the current external source. If the device

does not operate, turn on the device and select the appropriate external source using

INPUT1–8

on the remore control unit or

on the TV.

After unplugging connection cables or changing the connection pattern, turn on all connected

HDMI devices before turning on the TV. Confirm that picture and audio are correctly output by

selecting “INPUT4”, “INPUT5” or “INPUT6” using

INPUT1–8

on the remore control unit or

on the TV.

The KURO LINK function name used on the web and in catalogues is referred to as HDMI

CONTROL in the operating instructions and on the product.

✔

•

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

KRL3237V_GB.indd 26

2008/06/13 14:50:14

HDMI-certified

cable

HDMI CONTROL

HDMI CONTROL connection

First connect the Pioneer AV Sound system or a Pioneer BD Player/Pioneer Recorder that supports the HDMI

CEC protocol.

NOTE

Refer to the operation manual of the device to be connected for further details.

After unplugging connection cables or changing the connection pattern, turn on the power of the TV after all relevant devices’

power have been turned on. Change the external input source by pressing

INPUT1–8

, select the appropriate external source

and verify the audiovisual output.

The cables illustrated in the following explanation are commercially available items.

•

HDMI CONTROL

Set to “On” to enable HDMI CEC functions. When

turning on the power while “HDMI CONTROL” is set

to “On”, the connected HDMI devises’ power will be

turned on in conjunction with the TV.

Press

and the “HOME MENU” screen displays.

Press

to select “Option”.

Press

to select “HDMI CONTROL Setup”,

and then press

ENTER

Press

to select “HDMI CONTROL”, and

then press

ENTER

Press

to select “On”, and then press

ENTER

Auto Power On

If this is activated, the One Touch Play function

is enabled. While the TV is in standby mode, it

automatically turns on and plays back the image from

the HDMI source.

HDMI CONTROL Setup

Repeat steps 1 to 3 in

HDMI CONTROL

Press

to select “Auto Power On”, and then

press

ENTER

Press

to select “On”, and then press

ENTER

NOTE

The factory default for this item is “Off”.

Selecting recorder

Here, you can select a recorder for the recording from

several connected recorders.

Repeat steps 1 to 3 in

HDMI CONTROL

Press

to select “Selecting Recorder”, and

then press

ENTER

Select the recorder, and then press

ENTER

NOTE

If you have connected the Pioneer AV Sound system

between the TV and a Pioneer Recorder, the external

source’s indication changes (e.g. from “INPUT5” to

“INPUT5 (Sub)”).

•

Connecting a Pioneer BD

Player/Pioneer Recorder only

Connecting a Pioneer BD Player/Pioneer Recorder via

the Pioneer AV Sound system

HDMI-certified cable

Pioneer AV Sound

system

HDMI-certified cable

Pioneer BD Player/

Pioneer Recorder

Optical audio

cable

Pioneer BD Player/

Pioneer Recorder

KRL3237V_GB.indd 27

2008/06/13 14:50:14

HDMI CONTROL

Operating an HDMI CONTROL

device

HDMI CONTROL allows you to operate the HDMI-

connected device with a single remote control unit.

Press

to start playback of a title.

See below, the section “

Playback of titles using

HDMI CONTROL

” if you want to start playback using

the list of the titles of the Pioneer BD Player/Pioneer

Recorder.

Press

to fast forward.

Press

to reverse.

Press

to stop.

Press

(TV)

to turn the HDMI-connected

device on/off.

Recording via the Pioneer Recorder EPG

(only for recorders)

You can call up the CEC-compatible recorder’s EPG and

preset timer recordings using the TV’s remote control unit.

Press

HDMI CTRL

HDMI CONTROL Menu

Recorder EPG

Top Menu/Title List

Media change

Switch to AV Sound

Switch to TV Sound

Sound mode change

Setup Menu

Model select

Press

to select “Recorder EPG”, and then

press

ENTER

The external input source switches and the recorder’s

EPG is displayed.

Select the programme to record.

Refer to the operation manual of the recorder for details.

Playback of titles using HDMI CONTROL

This section explains how to play back a title in the

Pioneer BD Player/Pioneer Recorder.

Press

HDMI CTRL

Press

to select “Top Menu/Title List”, and

then press

ENTER

The linked recorder now powers on and the TV

automatically selects the appropriate external input source.

The title list data from the connected Pioneer BD

Player/Pioneer Recorder displays.

Select the title with

, and then press

Selecting media type for CEC-compatible

recorder

If your recorder has multiple storage media, select the

media type here.

Press

HDMI CTRL

Press

to select “Media change”, and then

press

ENTER

•

Select the desired medium, such as DVD

recorder or HDD. The media type changes every

time you press

ENTER

NOTE

This function may not work depending on the connected

recording devices.

Listening with the Pioneer AV Sound system

You can choose to listen to the TV sound only from the

Pioneer AV Sound system.

Press

HDMI CTRL

Press

to select “Switch to AV Sound”, and

then press

ENTER

The sound from the TV speaker and headphone

terminal is silenced and only the sound from the

Pioneer AV Sound system is audible.

Listening with the TV Sound system

You can choose to listen to the TV sound only from the

TV Sound system.

Press

HDMI CTRL

Press

to select “Switch to TV Sound”, and

then press

ENTER

Manually changing the Pioneer AV Sound

system’s sound mode

Press

HDMI CTRL

Press

to select “Sound mode change”.

The sound mode changes every time you press

ENTER

Refer to the operation manual of the Pioneer AV

Sound system for details.

Calling up the menu of an external device

connected with the TV via HDMI

You can call up the menu of an HDMI CEC-compatible

external device (player, recorder, decoder, etc.) using

the “Setup Menu” function.

Press

HDMI CTRL

Press

to select “Setup Menu”, and then

press

ENTER

NOTE

If a connected device does not have this function or the

device is in a status where the menu cannot be displayed

(recording, entering standby, etc.), this function may not be

available.

HDMI device selection

If multiple HDMI devices are connected in a daisy

chain, you can specify which device to control here.

Press

HDMI CTRL

Press

to select “Model select”, and then

press

ENTER

. The HDMI device changes every

time you press

ENTER

•

KRL3237V_GB.indd 28

2008/06/13 14:50:17

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

EXIT

DVD TOPMENU/

GUIDE

EPG

ENTER

HOME

RETURN

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

DTV

RADIO

INPUT

P.INFO

INFO

CH RETURN

DVD TOPMENU/

GUIDE

EPG

CTRL

HDMI

REC STOP

HDD

SELECTION

CM SKIP

DVD

TOOLS

SCREEN

SIZE

SOURCE

STB DVR VCR

DVD

SELECT

Menu operation

1


Sound

Power Control

Setup

Option

Digital Setup

Information

No Signal Off

No Operation Off

Ecology

Sleep Timer

[Disable]

Analogue Search

Digital Search

3 2

NOTE

“HOME MENU” options differ in the selected input modes, but the operating procedures are the same.

The screens in the operation manual are for explanation purposes (some are enlarged, others cropped) and may vary slightly from the actual screens.

Items with

cannot be selected for various reasons.

•

What is the HOME MENU?

You need to call up the OSD to perform settings for the TV. The OSD for the settings is called “HOME MENU”.

The “HOME MENU” enables various settings and adjustments.

The “HOME MENU” can be operated with the remote control unit.

Common operations

•

Operation without a remote control unit

This function is useful when there is no remote control

unit within your reach.

Press

HOME MENU

and the

“HOME MENU” screen displays.

Press

instead of

select the item.

Press

to complete the setting.

NOTE

The “HOME MENU” screen will disappear if left unattended

for several seconds.

•

About the Guide Display

The Guide Display at the bottom of the screen shows

operations with the OSD.

: Select

: Enter

: End

: Back

The bar above is an operational guide for the remote

control unit. The bar will change in accordance with

each menu setting screen.

ENTER

Display the HOME

MENU Screen

Exit the HOME

MENU screen

Select an item

Press

and the “HOME MENU”

screen displays.

The operation will exit the “HOME

MENU” screen if you press

(EXIT)

before it is completed.

Press

to select/adjust

the desired menu, and adjust the

item to the desired level, and then

press

ENTER

Press

to return to the previous

“HOME MENU” page.

ENTER

Selecting in the menu

Selecting options

KRL3237V_GB.indd 29

2008/06/13 14:50:18

Basic adjustment

NOTE

When set to “On”, the TV senses the surrounding light and

automatically adjusts the backlight brightness. Make sure no

object obstructs the RLS, which could affect its ability to sense

surrounding light.

•

This TV provides various advanced functions for

optimising the picture quality.

Colour Temp.

100Hz

PureCinema

Active Contrast

3D-Y/C

Monochrome

Range of RLS

High

Mid-High

Middle

Mid-Low

Low

Colour Temp.

Adjusts the colour temperature to give the best white image.

NOTE

“3D-Y/C” may not operate depending on the input signal type or

when the input signal is noisy.

“3D-Y/C” has even more effect on composite video signals (CVBS).

•

Picture Settings

Contrast

RLS

[Off]

Brightness

Colour

Tint

Sharpness

Pro Adjust

Reset

[+30]

[0]

–30

–10

+40

+30

+10

Backlight [+14]

–16

+16

DYNAMIC

100Hz

“100Hz” technology provides superior solutions for

digital display picture quality removing motion blur.

NOTE

Press and hold both

and

on the remote control unit to show

“100Hz” demonstration in a dual screen format.

This effect is greater on fast moving images.

“100Hz” will have no effect in the following cases;

1) The type of signal received is a PC signal.

2) An OSD is being displayed.

3) Teletext is activated.

If images appear blurred, set the “PureCinema” to “Off”.

PureCinema

Automatically detects a film-based source (originally

encoded at 24 or 25 frames per second, depending on

the vertical frequency), analyses it and then recreates

each still film frame for high-definition picture quality.

Active Contrast

Automatically adjusts the contrast of an image according to the scene.

3D-Y/C

Provides high quality images with minimal dot crawl and

cross colour noise by detecting changes in the image.

•

Off:

The brightness is fixed at the value set in “Backlight”.

On:

Automatically adjusts.

On:Display:

Displays the RLS effect on the screen while

adjusting the brightness of the screen.

RLS


Automatically adjusts the brightness of the screen.

Adjusts the picture to your preference with the

following picture settings.

Adjustment items

Selectable

items

button

Backlight

The screen dims

The screen brightens

Contrast

For less contrast

For more contrast

Brightness

For less brightness

For more brightness

Colour

For less colour

intensity

For more colour

intensity

Tint

Skin tones become

purplish

Skin tones become

greenish

Sharpness

For less sharpness

For more sharpness

Pro Adjust


High:

White with bluish tone.

Mid-High:

Intermediate tone between “High” and “Middle”.

Middle:

Natural tone.

Mid-Low:

Intermediate tone between “Middle” and “Low”.

Low:

White with reddish tone.

Standard:

Normal adjustment.

Fast:

Sets the optimum image quality for fast-moving images.

Slow:

Sets the optimum image quality for slow-moving images.

Off:

No detecting.

Picture adjustments


Item

KRL3237V_GB.indd 30

2008/06/13 14:50:22

Basic adjustment

NOTE

The item marked with * is available only when selecting

“INPUT4”, “INPUT5”, “INPUT6” or “INPUT7” using

INPUT1–8

on the remore control unit or

on the TV.

The item marked with ** is available only when accepting

an “x.v.Colour” signal through an HDMI terminal.

•

Monochrome

For viewing a colour video in black & white.

Range of RLS

The brightness level range of the RLS’s automatic

adjustments can be set according to your preferences.

The adjustment range of the RLS can be set to a

maximum of

16 and a minimum of

16.

Selectable

items

Description

Max.

16 through

Min.

16 through

NOTE

This function is available only when the “RLS” setting is set

to “On” or “On:Display”.

The maximum setting cannot be set to a smaller number

than the minimum setting.

The minimum setting cannot be set to a bigger number

than the maximum setting.

The maximum and minimum settings cannot be set to the

same number.

Depending on the brightness of the surrounding light, the

RLS might not operate if the adjustment range is small.

AV SELECTION

gives you several viewing options to

choose from to best match the system environment,

which can vary due to factors like room-brightness,

type of programme watched or the type of image input

from external equipment.

Press

AV SELECTION

Each time you press

AV SELECTION

, the mode

changes.

You can also switch the mode on the “Picture” and

“Sound” menu screen by pressing

AV SELECTION

•

Sound Settings

Balance

Treble

Surround

Reset

[ 0]

–15

+15

[Off]

Bass

[ 0]

–15

+15

DYNAMIC

STANDARD:

For a highly defined image in a normally

bright room.

MOVIE:

For viewing a movie in a darkened room.

GAME:

For playing of video games.

PC*:

For PC.

x.v.Colour**:

Produce realistic colour on the TV screen

unlike any other signal.

USER:

Allows you to customise settings as desired. You

can set the mode for each input source.

DYNAMIC (Fixed):

For a clear-cut image emphasising

high contrast for sports viewing (The “Picture” and

“Sound” settings cannot be adjusted).

DYNAMIC:

For a clear-cut image emphasising high

contrast for sports viewing.

Sound adjustment

Sound

Surround

Sound

No Signal Off

Power Control

When set to “Enable”, the TV will automatically enter

standby mode if there is no signal input for 15 minutes.

Five minutes before the TV enters standby mode, the

remaining time displays every minute.

NOTE

Even if a TV programme finishes, this function may not

operate because of interference from other TV stations or

other signals.

•

This function allows you to enjoy realistic live sound.

Power Save Settings

No Signal Off

No Operation Off

Ecology

Sleep Timer

[Disable]

You can adjust the sound quality to your preference

with the following settings.

Selectable

items

button

Treble

For weaker treble

For stronger treble

Bass

For weaker bass

For stronger bass

Balance

Decrease audio from

the right speaker

Decrease audio from

the left speaker

Item

KRL3237V_GB.indd 31

2008/06/13 14:50:23

The TV will automatically enter standby mode if no

operations are performed during the time span you set

(“30min.” or “3hr.”).

Five minutes before the TV enters standby mode, the

remaining time displays every minute in the lower-left

corner of the screen.

•

When set to “Yes”, the TV activates the following

power saving mode.

“RLS” set to “On” (Page 30).

“Standby Mode” set to “Mode2” (Page 38).

“No Signal Off” set to “Enable” (Page 31).

“No Operation Off” set to “3hr.” (Page 32).

•

Allows you to set a time when the TV automatically

enters standby mode.

NOTE

Select “Off” to cancel the sleep timer.

When the time has been set, countdown automatically

starts.

Five minutes before the preset of time expires, the

remaining time displays each minute in the lower-left corner

of the screen.

Channel Settings

Auto Installation

•

No Operation Off

Power Control

Ecology

Power Control

Sleep Timer

Power Control

Basic adjustment

Auto Installation

Setup

The TV automatically detects and stores all available

services in your area. This function also allows you to

perform the channel setting for digital and analogue

individually and reconfigure the settings after the initial

auto installation has been completed.

After selecting “Yes” on the screen, you can set

language and channel search the same as in the

initial auto installation. Follow steps 2, 4 and 5

on page 15.

NOTE

You cannot set the country setting in “Auto Installation” in

the “Setup” menu. If you want to reconfigure the country

setting, automatically execute initial auto installation after

executing “Reset” from the “Setup” menu.

The current country setting is displayed on the screen.

•

Programme Setup

Setup

Digital Setting

You can reconfigure the DTV service settings

automatically or manually.

Additional Search

Use this menu to add new services automatically after

auto installation has been completed.

Manual Search

Add new services within a specified frequency band.

Enter the frequency using

–

numeric buttons.

You can perform “Manual Search” with a service number

only when the five Nordic countries have been selected in

the country setting.

Manual Adjust

Configure various settings for each service using the

Colour (Red/Green/Yellow/Blue)

buttons.

DTV 993

Service

No.

Old

LCN

EPG

Skip

Lock

Service

Name

SIT 3

DTV 994

✔ ✔

SIT 2

DTV 995

✔

SIT 1

DTV

999

HD Monosco

: Lock

: CH Skip

: EPG Skip

: Sort

Press

to select the desired service.

Press the colour button on the remote control unit

corresponding with the item you want to reconfigure.

The

✔

mark indicates the operation is set to on. Each

time the colour button is pressed, you can switch the

corresponding operation on/off.

•

Digital channel settings

Buttons for Manual Adjust operation

Lock: Press Red button.

When the service is locked, you must enter your PIN

whenever you tune to the service.

CH Skip: Press Green button.

Services with a

✔

mark are passed over when pressing

on the TV or remote control unit.

EPG Skip: Press Yellow button.

Services with a

✔

mark are passed over in the Electronic

Programme Guide (EPG).

Sort: Press Blue button.

The item position of services can be sorted.

Press

to select the service whose item

position you want to move, and then press

ENTER

DTV 994

✔ ✔

SIT 2

DTV 995

✔

SIT 1

Press

to move it to the desired position,

and then press

ENTER

DTV

994

✔

SIT 1

DTV

995

✔

SIT 2

Repeat steps 1 and 2 until all desired service

items are sorted.

KRL3237V_GB.indd 32

2008/06/13 14:50:25

Basic adjustment

Channels with “Skip” set to “On” are passed over

when using

even if selected while watching the

image from the TV.

When connecting a decoder to the TV, you need to

select “INPUT1” or “INPUT2”.

NOTE

The factory preset value is “Off”.

•

You can block the viewing of any channel.

NOTE

See “Child Lock” for setting a PIN.

When “Lock” is set to “On” for a channel, “Child lock has

been activated” displays, and the image and sound of the

channel are blocked.

When pressing

while “Child lock has been activated”

displays, the PIN input window will display. Inputting the

correct PIN unlocks the “Child Lock” temporarily until the

power is turned off.

Sort

Channel positions can be sorted freely.

Press

to select “Yes”, and then press

ENTER

Press

to select the channel you

want to move, and then press

ENTER

Press

to move it to the desired

position, and then press

ENTER

Repeat steps 2 and 3 until all desired channels

are sorted.

Erase Programme

Channels can be erased individually.

Press

to select “Yes”, and then press

ENTER

Press

to select the channel you

want to erase, and then press

ENTER

A message window pops up.

Press

to select “Yes”, and then press

ENTER

to erase the selected channel. All the

subsequent channels move up.

Repeat steps 2 and 3 until all desired channels

are erased.

•

Programme Setup

Setup

Analogue Setting

You can reconfigure the analogue TV channels settings

automatically or manually.

Additional Search

Use this menu to add new channels automatically after

auto installation has been made.

Start searching channels after selecting the colour system

and sound system.

Manual Adjust

Use this menu to set up analogue TV channels

manually.

After selecting “Yes” on the screen, press

to select the channel you want to set and

then press

ENTER

•

You can adjust the frequency to the desired position.

NOTE

Adjust while checking the background picture as a

reference.

Instead of pressing

to adjust the frequency, you

can set by directly entering the frequency number of the

channel with

–

numeric buttons.

EXAMPLE

179.25 MHz: Press

49.25 MHz: Press

ENTER

•

Select the optimum colour system to receive (“Auto”,

“PAL”, “SECAM”).

Select the optimum sound systems (Broadcasting

systems) to receive (“B/G”, “D/K”, “I”, “L/L’”).

When a TV channel sends its Network Name, the

“Auto Installation” detects the information and assigns

a name to it. However, you can change channel names

individually.

Press

to select each character of

the new name for the channel, and then press

ENTER

Repeat step 1 above until the name is fully spelt

out.

NOTE

The name can be five characters or less.

If a channel name is less than five characters, select “END”

to set the channel name.

•

Analogue channel settings

Fine

Colour sys.

Sound sys. (Broadcasting systems)

Label

Skip

Decoder

Lock

KRL3237V_GB.indd 33

2008/06/13 14:50:26

Basic adjustment

Child Lock

Setup

Allows you to use a PIN to protect certain settings

from being accidentally changed.

Change PIN

“Child Lock” function.

Enter the four-digit number as a PIN using

–

numeric buttons.

Enter the same four-digit number as in step 1 to

confirm.

“The system PIN has been changed successfully” displays.

NOTE

To view a locked channel, you must enter the PIN (See pages 32

and 33 for locking channels from viewing in DTV and ATV mode).

When you select a locked channel, a PIN prompt message pops

up. Press

to display the PIN input window.

Cancel PIN

Allows you to reset your PIN.

NOTE

As a precautionary measure, make a note of your PIN on the

back of this operation manual, cut it out and keep it in a safe

place that children cannot reach.

Parental rating

This function allows DTV services to be restricted.

It prevents children from watching violent or sexual

scenes that may be harmful.

NOTE

“Universal viewing” and “Parental approval pref.” are ratings used

exclusively in France.

Refer to page 46 for details about ratings.

•

Language

Setup

You can select a OSD language from the “Setup”

menu. Select from among 22 languages (Czech,

Danish, Dutch, English, Estonian, Finnish, French,

German, Greek, Hungarian, Italian, Latvian, Lithuanian,

Norwegian, Polish, Portuguese, Russian, Slovak,

Slovene, Spanish, Swedish, Turkish).

Subtitle

Digital Setup

Set up to two preferred subtitle languages (including

subtitles for the hearing impaired) to display if subtitles

are available.

NOTE

Subtitles will not be displayed when the service does not contain

subtitle information.

•

Digital Audio Language

Option

Set up to three preferred multi audio languages to

display if the audio languages are available.

Switching the multi audio languages

Each time you press

on the remote control unit,

the audio language switches.

Key Lock

Option

This function allows you to lock the buttons on the TV

or remote control unit in order to prohibit children from

changing the channel or volume.

NOTE

You cannot set both “RC Control Lock” and “Button Control Lock”

at the same time.

Cancelling the lock

Press the

HOME MENU

button on the TV and set to

“Off” to cancel the “RC Control Lock”. Press the

button on the remote control unit and set to “Off” to

cancel the “Button Control Lock”.

Refer to page 29 for menu operation using the

button on the TV.

•

1st Language

2nd Language

For hearing impaired

Switching subtitle languages

Each time you press

[

on the remote control unit, the

subtitle switches.

Password/Parental lock settings

Off:

Unlocks the buttons.

RC Control Lock:

Locks all buttons on the remote control unit.

Button Control Lock:

Locks the buttons on the TV except the

power switch.

Language Settings (language,

subtitle, multi audio)

1st Language

Off

2nd Language

• • • • • •

1st Language

(For hearing impaired)

Set “For hearing impaired” to “Yes”

Subtitles for the hearing impaired have priority over

each of the subtitle language settings (Example: “1st

Language”, “2nd Language”, etc.).

EXAMPLE

Item

Selectable items

KRL3237V_GB.indd 34

2008/06/13 14:50:27

Useful Viewing functions

WSS

Setup

WSS signal 4:3 screen

4:3 Mode

Setup

The “WSS” signal has 4:3 auto-switching that allows

you to select between “4:3” and “WIDE”.

4:3 mode “WIDE”

4:3 mode “4:3”

The “WSS” allows the TV to switch automatically

among the different picture size.

NOTE

Use

SCREEN SIZE

if an image does not switch to the

appropriate picture size. When the broadcast signal

contains no “WSS” information, the function will not work

even if enabled.

Selecting the WSS (Wide Screen

Signalling) picture size manually

•

Selecting the picture size

Selecting the WSS (Wide Screen

Signalling) picture size automatically

4:3:

Normal range keeping 4:3 or 16:9 aspect ratio.

WIDE:

Wide image without side bars.

Selecting the picture size manually

You can select the picture size. Selectable picture size

varies with the type of signal received.

4:3:

Keeps the original aspect ratio in a full screen display.

CINEMA 14:9:

For 14:9 letterbox pictures. A thin side bar

appears on each side, and you may also see bars on

the top and bottom with some programmes.

WIDE:

In this mode, the picture is stretched toward each

side of the screen.

FULL:

For 16:9 squeeze pictures.

ZOOM:

For 16:9 letterbox pictures. Bars may appear on

the top and bottom with some programmes.

CINEMA:

For 14:9 letterbox pictures. Bars may appear

on the top and bottom with some programmes.

FULL:

Displays with an Overscan image. Crops all sides

of screen.

Underscan:

Displays with an Underscan image only

when receiving a 720p signal. Displays with the High-

Definition image adjusted optimally. Noise may appear

on the edge of the screen with some programmes.

Dot by Dot:

Displays an image with the same number

of pixels on the screen when receiving 1080i/1080p

signals only.

NOTE

Some items do not appear depending on the type of

received signal.

Press

SCREEN SIZE

The

SCREEN SIZE

menu displays.

The menu lists the

SCREEN SIZE

options selectable

for the type of video signal currently received.

Press

SCREEN SIZE

while the

SCREEN SIZE

menu displays on the screen.

As you toggle the options, each is immediately

reflected on the screen. There is no need to press

ENTER

Basically, if you set “WSS” to “On” in the “Setup”

menu, the optimum

SCREEN SIZE

is automatically

chosen for every broadcast, VCR or DVD player/

recorder.

NOTE

Even if you select your desired

SCREEN SIZE

manually,

the TV may automatically switch to the optimum

SCREEN

SIZE

depending on the signal received when “WSS” is set

to “On”.

•

Item

Item (for SD [Standard-Definition] signals)

Item (for HD [High-Definition] signals)

KRL3237V_GB.indd 35

2008/06/13 14:50:28

You can use this menu to set the appropriate picture

size for viewing a 16:9 format TV programme on a 4:3

TV.

REC Picture Size

Digital Setup

Setting to “4:3 TV”

Setting to “16:9 TV”

This function allows you to automatically change to the

appropriate picture size when viewing an HDMI signal

using the INPUT4, 5 and 6 terminals.

Other picture and audio settings

Adjusting image position

HDMI Auto View

Setup

NOTE

This function must be set before recording.

Selecting the HDMI picture size

automatically

•

Position

Setup

For adjusting a picture’s horizontal and vertical

position.

NOTE

Adjustments are stored separately for each input source.

Depending on the input signal type or

SCREEN SIZE

setting, a position setting may not be available.

•

DNR

Option

“DNR” (Digital Noise Reduction) produces a clearer

image (“Off”, “High”, “Low”).

Automatic volume adjustment

Auto Volume

Option

Different sound sources sometimes do not have the

same volume level, such as a programme and its

commercial breaks. The Automatic Volume Control

(Auto Volume) reduces this problem by equalizing

levels.

Emphasising dialogue

Clear Voice

Option

This function emphasises speech against background

noise for greater clarity. It is not recommended for

music sources.

Outputting audio only

Audio Only

Option

When listening to music from a music programme, you

can set the TV off and enjoy audio only.

Useful Viewing functions

Selecting the recording picture

size manually

H-Pos.:

Centres the image by moving it to the left or

right.

V-Pos.:

Centres the image by moving it up or down.

Reducing noise on the screen

Off:

Both screen images and audio are output.

On:

Audio is output without a screen image.

Item

KRL3237V_GB.indd 36

2008/06/13 14:50:29

Useful Viewing functions

Time Display

Option

Time Format

You can select the time format (either “24HR” or “AM/

PM”) for the clock time.

Game Play Time

Option

This function allows you to display the elapsed time on

the screen when

AV SELECTION

is set to “GAME”.

Programme Title Display

Option

This function allows you to display programme

information such as the title and airtime by tuning a

channel.

NOTE

This function is available only when the DTV mode is

selected.

•

Time Display

This function allows you to display the clock time in the

lower-right corner of the screen.

Four digit numbers (e.g. 0001) are displayed after

selecting the five Nordic countries in the country

setting.

Time display in channel information

You can display the time information included in DTV

and teletext broadcasts.

NOTE

Skip step 1 if receiving DTV broadcasts.

Select a TV channel (The time information is

automatically captured).

Press

. The channel display will appear on

the TV.

Press

again within the several seconds

that the channel display is on the screen. Time

information will be shown in the lower-right

corner of the screen for several seconds.

Even when you change the TV channel, you can

display the time information with steps 2 and 3

above.

NOTE

If acquired successfully, the time information will appear in

the upper-right corner of the screen by pressing

•

Subtitle ENG

1/3

New Information

Audio (ENG)

STEREO

Video

1080i

DTV

001

BBC2

Subtitle

Teletext Off

New Information

PAL

NICAM

STEREO

ATV

BBC1

DTV Mode

ATV Mode

Display Settings

Channel display

You can display the channel information by pressing

on the remote control unit.

Time and Title display

On:

Displays the clock time.

On (half-hourly):

Displays the clock time in 30-minute

increments.

Off:

Hides the clock time.

On:

Under connecting a game console to the TV, the

elapsed time is displayed in 30-minute increments

in the lower-left corner of the screen after

SELECTION

is set to “GAME”.

Off:

Hides the time.

Item

KRL3237V_GB.indd 37

2008/06/13 14:50:29

Other useful features

Input Select

Option

For setting the signal type of external equipment.

NOTE

If no (colour) image displays, try changing to another

signal type.

Check the operation manual of the external equipment for

the signal type.

When the signal type is set to “Auto”, the input terminal

where a cable is connected is automatically selected.

•

Input Label

Setup

You can label each input source with a custom

description.

Press

INPUT1–8

on the remote control unit or

on the TV to select the desired input source.

Go to “HOME MENU” > “Setup” > “Input Label”.

Press

to select each character of

the new name for the input source, and then

press

ENTER

BACK

CLEAR

END

DVD

–

Repeat until the label is fully spelt out.

NOTE

The label can be six characters or less.

When you want to set an input source label of less than six

characters, select “END” to set the name.

You cannot change labels if the input source is “TV”.

•

Input Skip

Setup

This setting allows you to skip the SCART, HDMI or

RGB input on the Input Source Selection operation.

INPUT1 (SCART)

INPUT2 (SCART)

INPUT4 (HDMI)

INPUT5 (HDMI)

INPUT6 (HDMI)

INPUT7 (RGB)

Y es

Colour system settings

You can change the colour system to one that is

compatible with the image on the screen.

NOTE

The factory preset value is “Auto”.

If “Auto” is selected, the colour system for each channel

is automatically set. If an image does not display clearly,

select another colour system (e.g. “PAL”, “SECAM”).

Additional features

•

Standby Mode

Setup

You can reduce the TV’s start-up time after turning on

the power with the remote control unit.

Colour System

Option

Setting when using external

devices

Input source settings

INPUT1:

Y/C, CVBS, RGB

INPUT2:

Y/C, CVBS, RGB

INPUT3:

Auto, S-VIDEO, VIDEO

Skipping specified inputs

Mode1:

The TV quickly starts up from standby. 30 W or

more of power consumption is required during standby.

Mode2:

Power consumption is small during standby.

Item

KRL3237V_GB.indd 38

2008/06/13 14:50:31

Connecting a PC

NOTE

The PC input terminals are DDC1/2B-compatible.

Refer to page 42 for a list of PC signals compatible with

the TV.

A Macintosh adaptor may be required for use for some

Macintosh computers.

When connecting to a PC, the input signal type is

automatically detected except 1,024

768 and 1,360

768 signals. Refer to

Selection input resolution

on page

40.

•

Analogue Connection

NOTE

Refer to page 35 for AV signals (480i/480p/576i/576p/

720p/1080i/1080p). The ANALOGUE RGB (PC) terminal

(INPUT7) is not compatible with 480i/576i/1080p signals.

•

Connecting a PC

HDMI Connection

Displaying a PC image on the

screen

Selecting the picture size

You can select the picture size.

Press

SCREEN SIZE

The

SCREEN SIZE

menu displays.

Press

SCREEN SIZE

to select a

desired item on the menu.

NOTE

Connect the PC before making adjustments.

Selectable picture size may vary with input signal type.

EXAMPLE

•

FULL:

An image fully fills the screen.

CINEMA:

For 14:9 letterbox pictures. Bars may appear

on the top and bottom with some programmes.

4:3:

Keeps the original aspect ratio in a full screen display.

Dot by Dot:

Displays an image with the same number of

pixels on the screen.

ø 3.5 mm stereo minijack cable

INPUT4 or 5

HDMI-certified cable

INPUT6

DVI/HDMI cable

RGB cable

ø 3.5 mm stereo minijack cable

DVI/RGB conversion cable

4:3

FULL

Item

INPUT7

KRL3237V_GB.indd 39

2008/06/13 14:50:32

Connecting a PC

Press

to select the specific adjustment

item.

Press

to adjust the item to the desired

position.

Reset

H-Pos. [

90]

V-Pos.

Clock

Phase

[ 39]

[ 90]

[ 20]

NOTE

You can only select the “Input Signal” on the “Setup” menu

when receiving one of the two input signals listed above.

•

1024 x 768

1360 x 768

(Example)

Fine Sync.

Setup

NOTE

For resetting all adjustment items to the factory preset

values, press

to select “Reset”, and then press

ENTER

“Clock” and “Phase” in the “Fine Sync.” menu can be

adjusted only when inputting analogue signals through the

INPUT7 terminal.

Selecting input resolution

Some input signals may have to be registered

manually to display properly.

The pairs of input signals (resolutions) in the list

below are not distinguishable when received. In such

cases, you have to set the correct signal manually.

After setting once, it will display when the same

signal (resolution) is input again.

•

Input Signal

Setup

30%

NOTE

When “Auto Sync.” is successful, “Auto Sync completed

successfully” displays. If not, “Auto Sync.” failed.

“Auto Sync.” may fail even if “Auto Sync completed

successfully” displays.

“Auto Sync.” may fail if the PC image has low resolution,

has unclear (black) edges, or is moved while executing

“Auto Sync.”.

Be sure to connect the PC to the TV and switch it on

before starting “Auto Sync.”.

“Auto Sync.” can be executed only when inputting

analogue signals through the INPUT7 terminal.

Adjusting the PC image manually

Ordinarily you can easily adjust the picture as

necessary to change image position using “Auto

Sync.”. In some cases, however, manual adjustment is

needed to optimise the image.

•

Auto Sync.

Setup

Adjusting the PC image

automatically

This function enables the screen to be automatically

adjusted to its best possible condition when the

analogue terminals of the TV and PC are connected

with a commercially available DVI/RGB conversion

cable, etc.

H-Pos.:

Centres the image by moving it to the left or

right.

V-Pos.:

Centres the image by moving it up or down.

Clock:

Adjusts when the image flickers with vertical

stripes.

Phase:

Adjusts when characters have low contrast or

when the image flickers.

Item

KRL3237V_GB.indd 40

2008/06/13 14:50:34

Connecting a PC

C1 C2 C3 C4 P1 P2 P3 P4

Communication conditions

Set the RS-232C communications settings on the PC

to match the TV’s communications conditions. The

TV’s communications settings are as follows:

Baud rate:

9,600 bps

Data length:

8 bits

Parity bit:

None

Stop bit:

1 bit

Flow control:

None

Communication procedure

Send the control commands from the PC via the RS-

232C connector.

The TV operates according to the received command

and sends a response message to the PC.

Do not send multiple commands at the same time.

Wait until the PC receives the OK response before

sending the next command.

Make sure to send “A” with the carriage return and

confirm that “ERR” returns before operating.

Command format

–

Response code format

RS-232C port specifications

PC Control of the TV

When a programme is set, the TV can be controlled

from the PC using the RS-232C terminal. The input

signal (PC/video) can be selected, the volume

can be adjusted and various other adjustments

and settings can be made, enabling automatic

programmed playing.

Use an RS-232C serial control cable (cross type)

(commercially available) for the connections.

NOTE

This operation system should be used by a person who is

accustomed to using PCs.

•

Parameter

Input the parameter values, aligning left, and fill with

blank(s) for the remainder (Be sure that four values are

input for the parameter).

When the input parameter is not within an adjustable

range, “ERR” returns (Refer to “Response code

format”).

When “?” is input for some commands, the present

setting value responds.

After sending the return code (0DH), make sure to

send the line feed (0AH) as well.

Command four-digits: Command. The text of four

characters.

Parameter four-digits: Parameter 0–9, blank, ?

RS-232C serial control cable

(cross type)

Eight ASCII codes

Command four-digits

Parameter four-digits

Return code

Normal response

Problem response (communication error or incorrect

command)

Return code (0DH)

KRL3237V_GB.indd 41

2008/06/13 14:50:35

Connecting a PC

NOTE

This TV has only limited PC compatibility, correct operation

can only be guaranteed if the video card conforms exactly

to the VESA 60 Hz standard. Any variations from this

standard will result in picture distortions.

•

CONTROL ITEM

COMMAND

PARAMETER

CONTROL CONTENTS

POWER SETTING

O W R

POWER OFF

INPUT SELECTION A

G D

INPUT SWITCHING (TOGGLE)

TV (CHANNEL FIXED)

DTV (CHANNEL FIXED)

INPUT1–8 (1–8)

CHANNEL

TV DIRECT CHANNEL (1–99)

CHANNEL UP

D W

CHANNEL DOWN

THREE DIGIT DTV DIRECT

CHANNEL (1–999) (Non-Nordic

countries)

FOUR DIGIT DTV DIRECT

CHANNEL (1–9999) (Nordic

countries only)

DTV CHANNEL UP

D W

DTV CHANNEL DOWN

INPUT SELECTION B

INPUT1 (Y/C)

INPUT1 (CVBS)

INPUT1 (RGB)

INPUT2 (Y/C)

INPUT2 (CVBS)

INPUT2 (RGB)

INPUT3

INPUT3 (S-VIDEO)

INPUT3 (VIDEO)

AV SELECTION

V M D

TOGGLE

V M D

STANDARD

V M D

MOVIE

V M D

GAME

V M D

USER

V M D

DYNAMIC (Fixed)

V M D

DYNAMIC

V M D

x.v.Colour

V M D

1–8

VOLUME

VOLUME (0–60)

CONTROL ITEM

COMMAND

PARAMETER

CONTROL CONTENTS

POSITION

H-POSITION (AV/PC)

V-POSITION (AV/PC)

CLOCK (0–180)

PHASE (0–40)

SCREEN SIZE

TOGGLE (AV)

4:3 (AV)

CINEMA 14:9 (AV)

WIDE (AV)

FULL (AV)

ZOOM (AV)

CINEMA (AV)

4:3 (PC)

CINEMA (PC)

FULL (PC)

DOT by DOT (AV/PC)

UNDERSCAN (AV)

MUTE

M U

TOGGLE

M U

MUTE ON

M U

MUTE OFF

SURROUND

SURROUND TOGGLE

SURROUND ON

SURROUND OFF

AUDIO CHANGE

TOGGLE

SLEEP TIMER

OFF

SLEEP TIMER 30 MIN

SLEEP TIMER 1 HOUR

SLEEP TIMER 1 HOUR 30 MIN

SLEEP TIMER 2 HOUR

SLEEP TIMER 2 HOUR 30 MIN

TEXT

TEXT OFF

TEXT ON (TOGGLE)

DIRECT PAGE JUMP (100–899)

PC compatibility chart

Resolution

Horizontal

Frequency

Vertical

Frequency

Analogue (D-

Sub)

Digital (HDMI)

VESA

Standard

VGA

640

480

31.5 kHz

60 Hz

✔

SVGA

800

600

37.9 kHz

60 Hz

✔

XGA

1,024

768

48.4 kHz

60 Hz

✔

WXGA

1,360

768

47.7 kHz

60 Hz

✔

SXGA

1,280

1,024

64.0 kHz

60 Hz

✔

SXGA+

1,400

1,050

65.3 kHz

60 Hz

✔

VGA, SVGA, XGA, WXGA, SXGA and SXGA+ are

registered trademarks of International Business

Machines Corporation.

RS-232C command list

KRL3237V_GB.indd 42

2008/06/13 14:50:36

Appendix

Troubleshooting

Problem

Possible Solution

No power.

•

Check if you pressed

(TV)

on the remote control unit.

If the indicator on the TV lights up red, press

(TV)

Is the AC cord disconnected?

Check if you pressed

on the TV.

•

The TV cannot be operated.

•

External influences such as lightning, static electricity, etc., may cause improper operation. In this

case, operate the TV after first turning off the power, or unplugging the AC cord and re-plugging

it in after one or two minutes.

•

Remote control unit does not operate.

•

Are batteries inserted with polarity (

) aligned?

Are batteries worn out? (Replace with new batteries.)

Are you using it under strong or fluorescent lighting?

Is a fluorescent light illuminating to the remote control sensor?

•

Picture is cut off.

•

Is the image position correct?

Are screen mode adjustments (

SCREEN SIZE

) such as picture size made correctly? (Pages 35

and 39)

•

Strange colour, light colour, or dark

colour, or colour misalignment.

•

Adjust the picture tone.

Is the room too bright? The picture may look dark in a room that is too bright.

Check the “Colour System” setting (Pages 33 and 38).

•

Power is suddenly turned off.

•

The TV’s internal temperature has increased.

Remove any objects blocking the vent or clean.

Is the “Sleep Timer” set? Select “Off” from the “Sleep Timer” menu (Page 32).

Is “No Signal Off” or “Ecology” activated?

•

No picture.

•

Are connections to external equipment correct? (Pages 21–23)

Is the input signal type selected correctly after connection? (Page 38)

Is the correct input source selected? (Page 16)

Is a non-compatible signal being input? (Page 42)

Is the picture adjustment correct? (Pages 30–31)

Is the antenna connected properly? (Page 14)

Is “On” selected in “Audio Only”? (Page 36)

•

No sound.

•

Is the volume too low?

Make sure that headphones are not connected.

Check if you pressed

on the remote control unit.

•

The TV sometimes makes a cracking

sound.

•

This is not a malfunction. This happens when the cabinet slightly expands and contracts

according to changes in temperature. This does not affect the TV’s performance.

•

Cautions regarding use in high and low temperature environments

When the TV is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed.

This is not a malfunction, and the TV will recover when the temperature returns to normal.

Do not leave the TV in a hot or cold location. Also, do not leave the TV in a location exposed to direct sunlight or near a

heater, as this may cause the cabinet to deform and the LCD panel to malfunction.

Storage temperature:

5 °C to

35 °C.

•

Information on the software license for this product

Software composition

The software included in this product is comprised of various software components whose individual copyrights are held by

Pioneer or by third parties.

Software developed by Pioneer and open source software

The copyrights for the software components and various relevant documents included with this product that were developed

or written by Pioneer are owned by Pioneer and are protected by the Copyright Act, international treaties, and other relevant

laws. This product also makes use of freely distributed software and software components whose copyrights are held by

third parties. These include software components covered by a GNU General Public License (hereafter GPL), a GNU Lesser

General Public License (hereafter LGPL) or other license agreement.

Obtaining source code

Some of the open source software licensors require the distributor to provide the source code with the executable software

components. GPL and LGPL include similar requirements. For information on obtaining the source code for the open source

software and for obtaining the GPL, LGPL, and other license agreement information, contact your local Pioneer Customer Service.

We are unable to answer any questions about the source code for the open source software. The source code for the

software components whose copyrights are held by Pioneer is not distributed.

Acknowledgements

The following open source software components are included in this product:

• linux kernel • modutils • glibc • zlib • libpng

KRL3237V_GB.indd 43

2008/06/13 14:50:37

Appendix

Download Setup

Digital Setup

Message List

Information

Go to “HOME MENU” > “Setup” > “Reset”.

Press

to select “Yes”, and then press

ENTER

“Now, TV will restart automatically. OK?” displays on

the screen.

Press

to select “Yes”, and then press

ENTER

“Now initialising...” displays on the screen and blinks.

After the reset has completed, the power shuts

off and then comes back on. The screen will have

returned to its original settings.

Now initialising...

•

Reset

Setup

Identification

Setup

Receiver Report

Information

Display reports regarding failures and changes for

timer settings.

Reset

If complex adjustments are made so that the settings

cannot be restored to normal, you can reset the

settings to the factory preset values.

Searching for updates*

All countries except UK and Sweden are set to “No”

for this function.

The TV automatically determines whether a new

software version is available when the TV is in standby

mode.

Updating your TV via DVB-T

Ensure that your TV software version is always up to

date. From time to time Pioneer will make updated TV

base software and DVB software available.

Yes:

Automatically searches for new software updates

available when the TV is in standby mode.

No:

Does not search for update information.

Now:

Checks if there is new software immediately.

Downloading the software

You can select the method of update.

If the software is updated, the confirmation

message “New download information has been

detected.” appears.

If the TV receives the update service while in standby

mode, a confirmation message displays after turning

on the power.

Follow the screen prompts.

•

Yes:

Starts downloading immediately. It takes

approximately one hour to update. You cannot carry

out other operations while downloading.

Cancels the download by pressing

ENTER

on the

remote control unit when “Discontinue” is displayed on

the screen during the update.

No:

Starts downloading automatically several minutes

after entering standby mode.

•

When new software is detected, you can confirm the

update information and download the software from

“Message List”.

NOTE

When the TV succeeds at downloading new software,

the message is updated in the “Message List” of the

“Information” menu.

The software update will not be carried out if there is no

new software available at the specified download time.

•

Identification

CLEARING THE PIN

Go to “HOME MENU” > “Setup”.

Press

to select “Auto Installation”,

“Programme Setup”, “Child Lock” or “Reset”,

and then press

ENTER

. The PIN input window

will display.

Press and hold both

and

on the TV

simultaneously until the message appears on

the screen.

You can check the TV ID on the screen for reporting to

customer service.

NOTE

The TV must remain in standby mode for download. Do not

turn off the power using

on the TV.

Updating the software may take some time.

•

Item

KRL3237V_GB.indd 44

2008/06/13 14:50:37

Appendix

Specifications

Item

Flat screen TV,

Model: KRL-32V

Flat screen TV,

Model: KRL-37V

LCD panel

Advanced Super View & BLACK TFT LCD

Resolution

2 073 600 pixels (1 920

1 080)

Video Colour System

PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV Function

TV-Standard

Analogue

CCIR (B/G, D/K, I, L/L’)

Digital

DVB-T (OFDM)

Receiving

Channel

VHF/UHF

E2–E12 ch (VHF), E21–E69 ch (UHF), F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: E5–E69 ch)

CATV

Hyper-band, S1–S41 ch

TV-Tuning System

Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort

Audio

Analogue

NICAM/A2

Digital

MPEG AUDIO

Brightness

450 cd/m

Backlight life

60 000 hours (when “Backlight” is set to the default position)

Viewing angles

H: 176°, V: 176°

Audio Power

10 W

Speaker

(100 mm

40 mm)

2, Ø 20 mm

Terminals

Antenna

UHF/VHF 75

Din type (Analogue & Digital)

RS-232C

D-Sub 9 pin male connector

INPUT1

SCART (AV input, Y/C input, RGB input, TV output)

INPUT2

SCART (AV input/monitor output, Y/C input, AV Link, RGB input)

INPUT3

S-VIDEO (Y/C input), RCA pin (AV input)

INPUT4

HDMI

INPUT5

HDMI

INPUT6

HDMI, Ø 3.5 mm jack

INPUT7

15 pin mini D-sub, Ø 3.5 mm jack

INPUT8

COMPONENT IN: Y/P

)/P

), RCA pin (AUDIO R/L)

DIGITAL AUDIO OUTPUT

Optical SPDIF Digital audio output

C. I. (Common Interface)

EN50221, R206001

OUTPUT

RCA pin (AUDIO R/L)

Headphones

Ø 3.5 mm jack (Audio output)

OSD language

Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian,

Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish,

Swedish, Turkish

Power Requirement

AC 220–240 V, 50 Hz

Power Consumption

140 W (0.4 W Standby) (Method IEC62087)

171 W (0.4 W Standby) (Method IEC62087)

Weight

15.0 kg (Without stand), 18.0 kg (With stand)

18.0 kg (Without stand), 21.0 kg (With stand)

Operating temperature

0 °C to

40 °C

As a part of our policy of continuous improvement, Pioneer reserves the right to make design and specification

changes for product improvement without prior notice. The performance specification figures indicated are

nominal values of production units. There may be some deviations from these values in individual units.

NOTE

Refer to the inside back cover for dimensional drawings.

•

KRL3237V_GB.indd 45

2008/06/13 14:50:39

Information for users on collection and disposal of old equipment and used batteries

These symbols on the products, packaging, and/or

accompanying documents mean that used electrical and

electronic products and batteries should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used batteries, please take them to

applicable collection points in accordance with your national legislation.

By disposing of these products and batteries correctly, you will help to save valuable resources and prevent any

potential negative effects on human health and the environment which could otherwise arise from inappropriate waste

handling.

For more information about collection and recycling of old products and batteries, please contact your local

municipality, your waste disposal service or the point of sale where you purchased the items.

These symbols are only valid in the European Union.

For countries outside the European Union:

If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of

disposal.

(Symbol examples for

batteries)

Rating table for Child Lock

AGE

Universal viewing

✔

—

Parental approval pref.

✔

—

X-rated

✔

Universal viewing

Parental approval pref.

X-rated

Universal viewing

—

Parental approval pref.

✔

—

X-rated

✔

—

End of life disposal

(Symbol for equipment)

User-

adjusted rating

Broadcasted

rating

User-

adjusted rating

Broadcasted

rating

KRL3237V_GB.indd 46

2008/06/13 14:50:39

Memo

KRL3237V_GB.indd 47

2008/06/13 14:50:41

Memo

KRL3237V_GB.indd 48

2008/06/13 14:50:41
