Pioneer VSX-1025-K: Setting What it does Option(s)

VSX-1020_SYXCN.book 69 ページ ２０１０年３月１２日　金曜日　午前９時１０分

Using other functions 08

Setting What it does Option(s)

English

c

Adjusts the amount of treble. –6 to +6 (dB)

TREBLE

Default: 0 (dB)

S.RTRV

With the Sound Retriever function, DSP processing is used to

d

OFF

(Sound Retriever)

compensate for the loss of audio data upon compression,

ON

improving the sound’s sense of density and modulation.

Deutsch

DNR

May improve the quality of sound in a noisy source (for example,

OFF

(Digital Noise

video tape with lots of background noise) when switched on.

ON

Reduction)

DIALOG E

Localizes dialog in the center channel to make it stand out from

OFF

(Dialog

other background sounds in a TV or movie soundtrack. By moving

FLAT

Enhancement)

from UP1 through UP2 and UP3 up to UP4, you can make the

Français

e

sound source seem to relocate upwards.

UP1/UP2/UP3/UP4

DUAL

Specifies how dual mono encoded Dolby Digital soundtracks

CH1 – Channel 1 is

(Dual Mono)

should be played. Dual mono is not widely used, but is sometimes

heard only

necessary when two languages need to be sent to separate

CH2 – Channel 2 is

channels.

heard only

Italiano

CH1 CH2

–

Both

channels heard from

front speakers

DRC

Adjusts the level of dynamic range for movie soundtracks

f

AUTO

(Dynamic Range

optimized for Dolby Digital, DTS, Dolby Digital Plus, Dolby

MAX

Nederlands

Control)

TrueHD, DTS-HD and DTS-HD Master Audio (you may need to use

this feature when listening to surround sound at low volumes).

MID

OFF

LFE

Some audio sources include ultra-low bass tones. Set the LFE

0dB/ –5dB/ –10dB/

(LFE Attenuate)

attenuator as necessary to prevent the ultra-low bass tones from

–15dB/ –20dB

distorting the sound from the speakers.

OFF

The LFE is not limited when set to 0 dB, which is the

Español

recommended value. When set to –5 dB, –10 dB, –15 dB or –20

dB, the LFE is limited by the respective degree. When OFF is

selected, no sound is output from the LFE channel.

g

Brings out detail in SACDs by maximizing the dynamic range

0 (dB)

SACD GAIN

(during digital processing).

+6 (dB)

h

Specifies the routing of the HDMI audio signal out of this receiver

AMP

HDMI

(amp) or through to a TV. When THROUGH is selected, no sound

(HDMI Audio)

THROUGH

is output from this receiver.

A. DELAY

This feature automatically corrects the audio-to-video delay

OFF

(Auto delay)

between components connected with an HDMI cable. The audio

ON

delay time is set depending on the operational status of the

display connected with an HDMI cable. The video delay time is

i

automatically adjusted according to the audio delay time.

69

En
