Integrated control section

Specifications

Control (SR) terminal. . .Ø 3.5 Mini-jack (MONO)

Control (IR) terminal . . .Ø 3.5 Mini-jack (MONO)

Audio section

IR signal . . . . . . . High Active (High Level: 2.0 V)

Rated power output

Miscellaneous

Front, Center, Surround, Surround back

. . . . . . . . 140 W per channel (1 kHz, 6 Ω, 1 %)

Power requirements

. . . . . . . . . . . . . . . . . . . . . . 100 W per channel

. . . . . . . . . . . . . . . AC 220 V to 230 V, 50 Hz/60 Hz

(20 Hz to 20 kHz, 8 Ω, 0.09 %)

Power consumption . . . . . . . . . . . . . . . . . .245 W

Total Harmonic Distortion

In standby . . . . . . . . . . . 0.4 W (Control OFF)

. . . . . . . . 0.06 % (20 Hz to 20 kHz, 8 Ω, 95 W/ch)

0.6 W (Control ON)

Guaranteed speaker impedance

Dimensions

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Ω to 16 Ω

. . . . . . .420 mm (W) x 158 mm (H) x 379 mm (D)

Signal-to-Noise Ratio

Weight (without package). . . . . . . . . . . . . 10.2 kg

(IHF, short circuited, A network)

Number of Furnished Parts

LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB

MCACC Setup microphone (APM7008). . . . . . . 1

Frequency Response

Remote control unit (AXD7596) . . . . . . . . . . . . . 1

. . . . . . . . . . . . . . . . . . . 5 Hz to 100 000 Hz dB

AAA/IEC R03 dry cell batteries . . . . . . . . . . . . . . 2

(Pure Direct Mode)

AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1

Input (Sensitivity/Impedance)

FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1

LINE . . . . . . . . . . . . . . . . . . . . . . 300 mV/47 kΩ

iPod cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Output (Level/Impedance)

Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

REC . . . . . . . . . . . . . . . . . . . . . 300 mV/2.2 kΩ

Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

These operating instructions

Video section

Signal level

Composite . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)

Note

Component Video . . . . . . . . Y: 1.0 Vp-p (75 Ω),

• These specifications are applicable when

PB, PR: 0.7 Vp-p (75 Ω)

the power supply is 230 V.

Corresponding maximum resolution

Component Video . . . . . . . . . . . 1080p (1125p)

• Specifications and the design are subject

(Video convert off)

to possible modifications without notice,

due to improvements.

Tuner section

Frequency Range (FM) . . . 87.5 MHz to 108 MHz

Antenna Input (FM) . . . . . . . . .75 Ω unbalanced

Frequency Range (AM). . . . 531 kHz to 1602 kHz

Antenna (AM) . . . . . . . Loop antenna (balanced)

Digital In/Out section

HDMI terminal . . . . . . . . . . . . . .19-pin (Not DVI)

HDMI output type . . . . . . . . . . . . . . . 5 V, 100 mA

USB terminal. . . . . . USB2.0 Full Speed (Type A)

iPod terminal. . . . . USB, and Video (Composite)

ADAPTER PORT terminal. . . . . . . . . 5 V, 100 mA
