Beurer MC 5000: Installation location

23

Warning!

•  Keep packaging material away from children!

There is a choking hazard.

•  Before using the device for the first time, read the

safety notes in the Safety section.

w

 Safety, pages 15 to 16

Caution!

•  The massage chair could damage your flooring.

Place a suitable, non-slip underlay under the

massage chair.

Installation location

•  Install the massage chair on a sturdy and even

surface.

•  Before using the device for the first time, remove all

obstacles in front of and behind the massage chair

so that the back rest can be lowered and the leg

rest raised freely.

5.  Initial use

The massage chair MC5000 is delivered in a

cardboard box.

Caution!

Do not use sharp or pointed tools (Stanley knife) to

remove the packaging.

Unpacking and assembly

Step 1:

>

Open the cardboard box and hold the massage chair at the

designated holding points.

>

Remove the chair from the cardboard box.

Four persons are required for this.

>

Carefully remove all the packaging material

Step 2:

>

Unfold the back rest to the upright position until the locking

mechanism audibly engages.

The back rest now stands at approx. 115°.

24

Step 3:

>

Connect the lower end of the back cushion and the lower end of

the seat cushion using the zip fastening.

>

Lay the seat cushion with the back cushion on the massage chair

over the back rest.

>

Connect the back cushion and the back rest using the

zip fastening.

Step 4:

>

Fold the seat cushion backwards against the back rest.

>

Connect the air hoses behind the seat with the air hoses on the

seat cushion.

Plug the hose marked red into the connection marked red.

Plug the hose marked white into the connection marked white.

>

Replace the seat cushion on the seat.

  Important! Do not pinch the hoses. Ensure that the hoses are not

crossed and or kinked.

Step 5:

>

Plug the mains plug into a socket.

>

Switch on the main switch at the bottom of the rear side.

>

Switch on the massage chair at the on/off button   on the hand

switch.

The massage chair is now ready for operation.
