Indesit IDV-75-(EU): Description of the tumble dryer

7

Description

of the tumble dryer

Front side Rear side

Control panel

Drum

Rating Plate

Air inlet

Serial number

and model

Caution, high

number

Filter

temperature

Connection for

ventilation hose

Control panel

Start

High Heat

button

button

Drying time selector

knob

Drying time selector knob

This is used to set the drying time: turn the knob in a clockwise direction until the indicator is set to the desired drying time (see

Drying settings). Do not attempt to turn the knob anticlockwise.

High Heat button

It can be used to customise the selected programme in accordance with your own requirements.

START button

Press the button to begin drying.

How to carry out a drying cycle

Starting a drying programme

1. Plug the dryer into the power supply socket.

2. Select a suitable drying programme for the type of laundry (see Laundry).

3. Open the door, ensure that the filter is clean and securely placed.

4. Load the machine, making sure that no piece of laundry gets between the door and the door seal. Close the door.

5. Turn the “Drying time selector” knob until the indicator is pointing towards the most suitable drying time for the type of fabric in

that load. Use the table to check the relationship between fabric type and load capacity (see Drying settings), and make sure you

are familiar with the instructions provided for each type of fabric (see Laundry). Do not attempt to turn the knob anticlockwise.

6. If necessary, set the temperature using the HIGH HEAT button.

7. Press the START button to start the drying cycle.

Laundry can be checked while the drying programme runs and any garments already dry can be removed, while drying continues

for the remaining items. After closing the door, press the START button to resume machine operation.

8. The final COOL TUMBLE phase (i.e. the fabrics are cooled) activates during the last few minutes of the drying programme; always

allow this phase to terminate.

9. Open the door, remove the laundry then clean the filter and replace it.

10. Disconnect the dryer from the power supply.
