Manual for Asus HS-W1
HS-W1
USB Wireless Headset
Quick Start Guide
English ...........................................2
Magyar ..........................................42
Français .........................................6
Norwegian ...................................46
Deutsch .........................................10
Polski ..............................................50
Italiano ..........................................14
Português .....................................54
Русский .........................................18
Română .........................................58
Čeština ...........................................22
Slovenščina ..................................62
Dansk .............................................26
Español ..........................................66
Nederlands ..................................30
Svenska .........................................70
Suomi .............................................34
Українська ...................................74
Ελληνικά ........................................38
Türkçe ............................................78
U7446 / Second Edition / May 2012
English
Package contents
• 1 x HS-W1 USB Wireless Headset
• 1 x Mini-USB charging cable
• 1 x USB wireless dongle
• 1 x Quick Start Guide
Getting to know your headset
1
2
5
6
7
3
8
4
1. Adjustable headband
Allows you to adjust the headset for a snug t on your head.
2. Ear cups
Provides you with an enhanced audio experience.
3. Microphone
Use the microphone for a two-way communication.
4. Mini-USB port
Use this port to connect the bundled mini-USB cable to your computer’s
USB port to charge your wireless headset’s battery.
5. Volume up (+)
Press (+) to increase the volume.
6. Status indicators
• Solid red light: Battery is charging. The red light is o when the
battery is fully charged.
• Solid green light: Devices are in the pairing mode.
• Fast ashing green light: Devices are waiting to be paired.
• Slow ashing green light: Devices are not paired.
2
Quick Start Guide
7. Power button
Press this button to turn your wireless headset on/o or to pair it with
your computer.
8. Volume down (-)
Press (-) to decrease the volume.
English
Charging the battery
1
2
To charge the battery:
1. Connect the mini-USB cable in the wireless headset’s mini-USB port.
2. Connect the other end of the mini-USB cable into your computer’s USB
port.
NOTES:
• Charge the battery for six hours before using your wireless
headset for the rst time.
• If the battery is completely used up, charge it for approximately
three hours.
• The battery power will slowly be depleted even if you do not use
the wireless headset.
WARNING: DO NOT attempt to repair the wireless headset or
replace the rechargeable battery. The rechargeable battery should
be replaced only by an authorized service personnel. Please contact
the ASUS Service Center for service information.
ASUS HS-W1 USB Wireless Headset
3
