Yamaha RX-397: TROUBLESHOOTING

TROUBLESHOOTING

30

Refer to the chart below if this unit does not function properly. If the problem you are experiencing is not listed below or

if the instructions below do not help, set this unit to the standby mode, disconnect the power cord, and contact the nearest

authorized YAMAHA dealer or service center.

■

General

TROUBLESHOOTING

Problem

Cause

Remedy

See

page

This unit fails to turn

on.

The power supply cord is not connected or

the plug is not completely inserted.

Connect the power supply cord firmly.

—

The impedance setting is incorrect.

Set the impedance to match your speakers.

10

The protection circuitry has been activated

because of a short circuit, etc.

Check that the speaker wires are not touching each

other and then turn the power of this unit back on.

10

The IMPEDANCE SELECTOR switch on

the rear panel is not set to either end.

Set the IMPEDANCE SELECTOR switch to either

end when the power of this unit is turned off.

10

This unit has been exposed to a strong

external electric shock (such as lightning

or strong static electricity).

Set this unit to the standby mode, disconnect the

power supply cord, plug it back in after 30 seconds,

then use it normally.

—

No sound

Incorrect input or output cable

connections.

Connect the cables properly. If the problem persists,

the cables may be defective.

9

No appropriate input source has been

selected.

Select an appropriate input source with the INPUT

selector on the front panel (or one of the input

selector buttons on the remote control).

15

The TAPE MONITOR function is turned

on.

Turn off the TAPE MONITOR function.

3

The SPEAKERS A/B switches are not set

properly.

Turn on the corresponding SPEAKERS A or

SPEAKERS B.

15

Speaker connections are not secure.

Secure the connections.

10

The sound suddenly

goes off.

The protection circuitry has been activated

because of a short circuit, etc.

Check that the IMPEDANCE SELECTOR setting is

correct.

10

Check that the speaker wires are not touching each

other and then turn the power of this unit back on.

10

Only the speaker on

one side can be

heard.

Incorrect cable connections.

Connect the cables properly. If the problem persists,

the cables may be defective.

9

Incorrect setting for the BALANCE

control.

Set the BALANCE control to the appropriate

position.

16

There is a lack of bass

and no ambience.

The + and – wires are connected in

reverse at the amplifier or the speakers.

Connect the speaker wires to the correct + and –

phase.

10

A “humming” sound

can be heard.

Incorrect cable connections.

Connect the audio plugs firmly. If the problem

persists, the cables may be defective.

9

No connection from the turntable to the

GND terminal.

Make the GND connection between the turntable and

this unit.

9

The volume level is

low while playing a

record.

The record is being played on a turntable

with an MC cartridge.

The turntable should be connected to this unit through

the MC head amplifier.

—

The volume level

cannot be increased,

or the sound is

distorted.

The component connected to the TAPE

OUT or the MD OUT jacks of this unit is

turned off.

Turn on the power of the component.

—

31

TROUBLESHOOTING

ADDITIONA

L

INF

O

RMA

T

IO

N

English

■

Tuner

The sound is

degraded when

listening with the

headphones

connected to the CD

player or the tape

deck connected to

this unit.

The power of this unit is turned off, or this

unit is set to the standby mode.

Turn on the power of this unit.

14

The sound level is

low.

The LOUDNESS control is functioning.

Set the LOUDNESS control to the FLAT position.

16

The INPUT selector

will not function

though it is rotated.

The TAPE MONITOR function is turned

on.

Turn off the TAPE MONITOR function.

3

Using the BASS,

TREBLE, BALANCE

and LOUDNESS

controls does not

affect the tonal

quality.

The PURE DIRECT button is turned on.

The PURE DIRECT button must be turned off to use

those controls.

16

Problem

Cause

Remedy

See

page

FM

FM stereo

reception is

noisy.

The particular characteristics of the FM

stereo broadcasts being received may

cause this problem when the transmitter is

too far away or the antenna input is poor.

Check the antenna connections.

Try using a high-quality directional FM antenna.

11

Try using the manual tuning method.

21

There is

distortion, and

clear reception

cannot be

obtained even

with a good FM

antenna.

There is multipath interference.

Adjust the antenna position to eliminate the multipath

interference.

—

The desired

station cannot

be tuned in

with the

automatic

tuning method.

The signal is too weak.

Try using a high-quality directional FM antenna.

11

Try using the manual tuning method.

21

Previously

preset stations

can no longer

be tuned in.

This unit has been disconnected for a long

period.

Preset the stations again.

21

AM

The desired

station cannot

be tuned in

with the

automatic

tuning method.

The signal is weak or the antenna

connections are loose.

Tighten the AM loop antenna connections and orient

it for the best reception.

—

Try using the manual tuning method.

21

There are

continuous

crackling and

hissing noises.

The noises may result from lightning,

fluorescent lamps, motors, thermostats or

other electrical equipment.

Try using an outdoor antenna and a ground wire.

This will help somewhat, but it is difficult to

eliminate all noise.

—

There are

buzzing and

whining noises.

A TV set is being used nearby.

Move this unit away from the TV set.

—

32

TROUBLESHOOTING

■

Remote control

Problem

Cause

Remedy

See

page

The remote control

does not work nor

function properly.

Wrong distance or angle.

The remote control will function within a maximum

range of 6 m (19.7 ft) and no more than 30 degrees

off-axis from the front panel.

8

Direct sunlight or lighting (from an

inverter type of fluorescent lamp, etc.) is

striking the remote control sensor of this

unit.

Reposition this unit.

—

The batteries are weak.

Replace all batteries.

8
