Yamaha RX-397: ADVANCED SETUP

ADVANCED SETUP

28

■

ADVANCED SETUP menu parameters

Change the initial settings (indicated in bold under each

parameter) to reflect the needs of your listening

environment.

Factory presets

PRESET

Use to reset all parameters to the factory presets.

Choices:

CANCEL

, RESET

• Select CANCEL if you do not want the parameters of

this unit to be initialized when you reset the factory

presets.

• Select RESET if you want all of the parameters of this

unit to be initialized when you reset the factory presets.

• This setting does not affect the parameters in the ADVANCED

SETUP menu.

• The resetting process starts next time you turn on the power of

this unit.

Tuner

TU

(Asia and General models only)

Use to switch the frequency step selection according to the

frequency spacing in your area.

Choices:

AM10/FM100

, AM9/FM50

• North, Central and South America:

AM10/FM100 (kHz)

• Other areas: AM9/FM50 (kHz)

The ADVANCED SETUP menu is displayed in the front

panel display.

y

• During the ADVANCED SETUP procedure, audio output is

muted.

• During the ADVANCED SETUP procedure, only

STANDBY/ON, A/B/C/D/E and the preset station number

buttons (1 and 2) on the front panel are operational.

1

Press STANDBY/ON on the front panel to set

this unit to the standby mode.

2

Press and hold A/B/C/D/E on the front panel

and then press STANDBY/ON.

This unit is turned on, and the ADVANCED SETUP

menu appears in the front panel display.

ADVANCED SETUP

Notes

Changing the ADVANCED SETUP  menu parameters

STANDBY

/ON

INPUT

PHONES

BASS

TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2,4

1,2,5

3

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

STANDBY

/ON

While holding down,

press

A/B/C/D/E

STANDBY

/ON

29

ADVANCED SETUP

OPERA

T

ION

English

3

(Asia and General models only)

Press the preset station number buttons (1

and 2) on the front panel to move through the

menu and select the parameter you want to

adjust.

See page 28 for available parameters.

4

Press A/B/C/D/E on the front panel

repeatedly to toggle between the available

parameters.

5

Press STANDBY/ON to confirm your setting.

The settings you made are reflected next time you turn on this

unit.

Note

1

2

A/B/C/D/E

STANDBY

/ON
