Yamaha RX-397: SPECIFICATIONS

SPECIFICATIONS

33

ADDITIONA

L

INF

O

RMA

T

IO

N

English

AUDIO SECTION

• Minimum RMS Output Power

(8

Ω

 , 20 Hz to 20 kHz, 0.04% THD) ...................... 50 W + 50 W

• Dynamic Power (IHF)

(8/6/4/2

Ω

)  ........................................................... 70/77/89/100 W

• Maximum Output Power [Europe model only]

(1 kHz, 0.7% THD, 4

Ω

)  ...................................................... 55 W

• IEC Output Power [Europe model only]

(1 kHz, 0.04% THD, 8

Ω

)  .................................................... 52 W

• Power Band Width

(0.08% THD, 25 W, 8

Ω

) ..................................... 10 Hz to 50 kHz

• Damping Factor (SPEAKERS A)

20 Hz to 20 kHz, 8

Ω

.................................................  150 or more

• Maximum Output Power (EIAJ)

[Asia and General models only]

(1 kHz, 10% THD, 8

Ω

)  ....................................................... 85 W

• Maximum Input Signal

PHONO (1 kHz, 0.04% THD) ............................  115 mV or more

CD/DVD, etc. (1 kHz, 0.04% THD)  ......................  2.2 V or more

• Frequency Response

CD/DVD, etc. (20 Hz to 20 kHz)  ................................. 0 ± 0.5 dB

CD/DVD, etc. PURE DIRECT ON (10 Hz to 100 kHz)

....................................................................................... 0 ± 1.0 dB

• RIAA Equalization Deviation

PHONO ............................................................................ ± 0.5 dB

• Total Harmonic Distortion

PHONO to OUT (REC)

(20 Hz to 20 kHz, 3 V

)

...........................................  0.02% or less

CD/DVD, etc. to SPEAKERS

(20 Hz to 20 kHz, 25 W, 8

Ω

)

.................................  0.02% or less

• Signal to Noise Ratio (IHF-A Network)

PHONO (5 mV input shorted) ...............................  82 dB or more

CD/DVD, etc. (150 mV input shorted)  ................  108 dB or more

• Residual Noise (IHF-A Network)

PURE DIRECT ON ..........................................................  100 µV

• Input Sensitivity/Input Impedance

PHONO ..................................................................  2.5 mV/47 k

Ω

CD/DVD, etc.  .......................................................  150 mV/47 k

Ω

• Output Level/Output Impedance

OUT (REC)................................................  150 mV/1.2 k

Ω

 or less

• Headphone Output/Impedance

(Input 1 kHz, 150 mV, 8

Ω

, 0.04% THD)

CD/DVD, etc.  .......................................................... 0.47 V/330

Ω

• Channel Separation

CD/DVD, etc. (5.1 k

Ω

 input shorted, 1/10 kHz)

...........................................................................  65/50 dB or more

• Tone Control Characteristics

BASS

Boost/Cut (50 Hz) ........................................................... ±10 dB

Turnover Frequency ........................................................  350 Hz

TREBLE

Boost/Cut (20 kHz) ......................................................... ±10 dB

Turnover Frequency .......................................................  3.5 kHz

• Continuous Loudness Control

Attenuation (1 kHz)  ...........................................................  –30 dB

FM SECTION

• Tuning Range

[U.S.A. and Canada models] ...........................  87.5 to 107.9 MHz

[Asia and General models] ........ 87.5/87.50 to 107.9/108.00 MHz

[Other models]  ............................................  87.50 to 108.00 MHz

• Usable Sensitivity (IHF)........................................ 1.0 µV (11.2 dBf)

• Signal to Noise Ratio (IHF)

Mono/Stereo .............................................................. 76 dB/70 dB

• Harmonic Distortion (1 kHz)

Mono/Stereo ................................................................  0.2%/0.3%

• Stereo Separation (1 kHz)  ....................................................... 45 dB

• Frequency Response ........................... 20 Hz to 15 kHz, +0.5/–2 dB

AM SECTION

• Tuning Range

[U.S.A. and Canada models] ..............................  530 to 1710 kHz

[Asia and General models] .................  530/531 to 1710/1611 kHz

[Other models]  ...................................................  531 to 1611 kHz

• Usable Sensitivity .............................................................  300 µV/m

GENERAL

• Power Supply

[U.S.A. and Canada models] .............................. AC 120 V, 60 Hz

[Asia model] .................................... AC 220/230-240 V, 50/60 Hz

[General model] ................  AC 110/120/220/230-240 V, 50/60 Hz

[Australia model]  ............................................... AC 240 V, 50 Hz

[Europe model] ................................................... AC 230 V, 50 Hz

• Power Consumption  ..............................................................  130 W

• Standby Power Consumption  .................................................  0.1 W

• Maximum Power Consumption [General model only]

(8

Ω

 , 1 kHz, 10% THD) ....................................................  300 W

• AC  Outlets

[Australia model]  ...............................  1 (Total 100 W maximum)

[General model]  ...................................  2 (Total 50 W maximum)

[Other models]  ...................................  2 (Total 100 W maximum)

• Dimensions (W x H x D)  ................................  435 x 151 x 308 mm

(17-1/8” x 5-15/16” x 12-1/8”)

• Weight  .............................................................  7.4 kg (16 lbs. 5 oz.)

* Specifications are subject to change without notice.
