USING USEFUL FUNCTIONS

You can also enjoy the following function.

Setting the sleep timer

• When you start playback of DVD/BD discs other than

CD discs on this unit or display HOME/SETUP menu

You can set the sleep timer by using the remote control.

screen, the input selector of the TV is switched to this

The sleep timer sets this unit to standby mode after the

unit automatically (One Touch Play).

specified time elapses.

*1 When you select this unit to output TV sounds by using the

TV remote control, the unit automatically selects TV as the

input source, and sound can be enjoyed from the speakers

PROGRAM MARKER DIGEST ZOOM

connected to the unit.

SLEEP

SLEEP

Notes

SW

• This unit may be operated by using cursor buttons of TV remote

control for some TVs.

• Even if your TV supports the HDMI control function, some

1 Press SLEEP repeatedly.

functions may not be available. For details, refer to the manual

supplied with your TV.

• HDMI control function may not work properly depending on

the TV.

• Functions other than ones shown above may work depending on

the TV.

Operating this unit by TV remote

• In order to make the HDMI control function available, set up

settings for the HDMI control function on ALL components

control (the HDMI control function)

(this unit, TV, and other components). Certain operation may

also be required.

You can use the TV remote control to operate this unit if

• Each function may be set independently to activate/deactivate

your TV supports the HDMI control function and is

depending on the TV.

connected to this unit’s HDMI terminal.

• Refer to the operation manuals supplied with the TV for details

Remote control of TV (Example)

regarding setup.

■ Setting the HDMI control function

Turns on/off both TV and

1 Turn on all components connected to the TV with

this unit.

HDMI.

2 Check all components connected with HDMI and

enable the HDMI control function on each

component.

For this unit, set [HDMI Control] to [On] (p. 35).

For external components, refer to the manual

supplied with each component.

y

• The default setting of [HDMI Control] is set to [Off] for

this unit.

• The example of TV settings

– From a setup menu on your TV, select “Link setting” =

Controls the volume of

this unit.

“HDMI control setting” (example), then set a setting

such as “HDMI control function” to “ON” (example).

– Setting such as “Speaker priority” should be set to “AV

Select this unit or TV to

output sounds.

*1

amplifier”.

3 Turn off the TV and then turn on it again.

30 En

USING USEFUL FUNCTIONS

■ Registering HDMI components to TV

1 Select this unit as the input source of the TV.

2 Select Disc/USB/Network as the input source of this

unit.

3 Check that the image from this unit is correctly

displayed on the TV.

4 Check that the HDMI control function works (turn on

this unit or adjust the volume level using the TV

remote control).

y

For some HDMI components, you only need to set the HDMI

control function. Registering HDMI components to TV is not

required in this case.

If the HDMI control function is not working

Check the following:

• The TV is connected to the HDMI terminal of this unit.

OPERATIONS

The HDMI control function is set to [On] in SETUP

menu (p. 35).

• The HDMI control function is enabled on the TV. (Also

check the relative settings such as power interlock

function or speaker priority.)

The HDMI control function is not working even

checking the above

• Turn off this unit and the TV, and then turn them back

on again.

• Unplug the AC power supply cable of this unit, the TV

and external components connected to the TV with

HDMI.

Plug them in again after about 30 seconds.

■ Changing the connection method and

connected components

When the connected components and jacks are changed,

reset this unit with following procedures.

1 Turn off the HDMI control function of the TV and

this unit, turn off all connected devices, and change

the connections.

2 Perform the step 1 to 3 of “Setting the HDMI control

function” (p. 30).

English
