Indesit WITL 86: Washing machine description

Washing machine description

Control panel

GB

START/RESET

LID LOCKED

button

LED

FUNCTION

Buttons

START/STOP

button

LEDs

SPIN

TEMPERATURE

PROGRAMME

knob

knob

knob

Detergent dispenser to add detergent and fabric

ON/OFF key to turn the washing machine on and

softener (see page 8).

off.

LEDs to find out which wash cycle phase is under way.

START/RESET key to start the programmes or

If the Delay Timer function has been set, the time left

cancel incorrect settings.

until the programme starts will be indicated (see page 5).

ON-OFF/LID LOCK led, to find out whether the

FUNCTION keys to select the functions available.

washing machine is on (flashing) and if the lid may be

The button corresponding to the function selected will

opened (see page 5).

remain on.

PROGRAMME knob to set the programmes

SPIN SPEED knob to set the spin speed or exclude the

(see page 6).

spin cycle completely (see page 7).

The knob stays still during the cycle.

TEMPERATURE knob to set the temperature or the cold

wash cycle (see page 7).

ON-OFF/LID LOCK led:

If this LED is on, the appliance Lid is locked to prevent it from being opened accidentally; to avoid any

damages, you must wait for the lamp to flash before you open the Lid.

.

 The rapid flashing of the ON-OFF/LID LOCK Led together with the flashing of at least one other LED indicates

there is an abnormality (see page 11).

4

How to open and to close the drum

GB

A) Opening (Fig. 1).

Lift the external lid and open it completely.

B) Opening the drum (Soft opening):

With one finger, push the button indicated in fig. 2

and the drum will open delicately.

Fig. 1

Fig. 2

C) Loading the washing machine. (Fig. 3).

D) Shutting (Fig. 4).

- close the drum fully by first shutting the front door

followed by the rear one;

- then ensure the hooks on the front door are perfectly

housed within the seat of the rear door;

- after the hooks have clicked into position, press both

doors lightly downwards to make sure they do not

come loose;

- finally shut the external lid.

Fig. 3

Fig. 4

Leds

The LEDS provide important information.

Cycle phase under way:

This is what they can tell you:

During the wash cycle, the LEDs gradually illumi-

nate on to indicate the cycle phase under way:

Delay set:

If the Delay Timer function has been enabled (see

Prewash

page. 7), once you have started the programme,

the LED corresponding to the delay set will begin to

Wash

flash:

Rinse

Spin cycle

Note: during draining, the LED corresponding to

the Spin cycle phase will be turned on.

Function buttons

As time passes, the remaining delay will be

The FUNCTION BUTTONS also act like LEDS.

displayed, and the corresponding LED will flash:

When a function is selected, the corresponding

button is illuminated.

If the function selected is incompatible with the

programme set, the button will flash and the function

will not be enabled.

If you set a function that is incompatible with another

function you selected previously, only the last one

ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description

selected will be enabled.

Once the set delay is complete, the flashing LED will

turn off and the programme set will start.

5
