Indesit WITL-1061-(EU): Washing machine description

6

GB

 ON-OFF/LID LOCK led:

If this LED is on, the appliance Lid is locked to prevent it from being opened accidentally; to avoid any damages, you must

wait for the lamp to flash before you open the Lid.

.

!

 The rapid flashing of the ON-OFF/LID LOCK Led together with the flashing of at least one other LED indicates there is an

abnormality.

Control panel

Washing machine description

ON/OFF

button

SPIN

knob

TEMPERATURE

knob

START/RESET

button

FUNCTION

Buttons

PROGRAMME

knob

LEDs

LID LOCKED

LED

Detergent dispenser

to add detergent and fabric softener.

LEDs

to find out which wash cycle phase is under way.

If the Delay Timer function has been set, the time left until the

programme starts will be indicated.

FUNCTION

keys to select the functions available.

The button corresponding to the function selected will

remain on.

SPIN SPEED

knob to set the spin speed or exclude the

spin cycle completely.

TEMPERATURE

knob to set the temperature or the cold

wash cycle.

ON/OFF

key to turn the washing machine on and off.

START/RESET

key to start the programmes or cancel

incorrect settings.

ON-OFF/LID LOCK

led, to find out whether the wash-

ing machine is on (flashing) and if the lid may be opened.

PROGRAMME

knob to set the programmes.

The knob stays still during the cycle.

Standby mode

This washing machine, in compliance with new energy sa-

ving regulations, is fitted with an automatic standby system

which is enabled after about 30 minutes if no activity is

detected. Press the ON/OFF button briefly and wait for the

machine to start up again.

7

GB

Fig. 1

Fig. 2

A) Opening (Fig. 1).

 Lift the external lid and open it completely.

B) Opening the drum (Soft opening):

With one finger, push the button indicated in fig. 2 and the

drum will open delicately.

C)  Loading the washing machine. (Fig. 3).

D)  Shutting (Fig. 4).

- close the drum fully by first shutting the front door

  followed by the  rear one;

- then ensure the hooks on the front door are perfectly

  housed within the seat of the rear door;

- after the hooks have clicked into position, press both

  doors lightly downwards to make sure they do not

  come loose;

- finally shut the external lid.

How to open and to close the drum

Fig. 3

Fig. 4

Cycle phase under way:

During the wash cycle, the LEDs gradually illuminate  on

to indicate the cycle phase under way:

        Prewash

        Wash

        Rinse

        Spin cycle

Note: during draining, the LED corresponding to the Spin

cycle phase will be turned on.

Function buttons

The FUNCTION BUTTONS also act like LEDS.

When a function is selected, the corresponding button is

illuminated.

If the function selected is incompatible with the program-

me set, the button will flash and the function will not be

enabled.

If you set a function that is incompatible with another fun-

ction you selected previously, only the last one selected

will be enabled.

Leds

The LEDS provide important information.

This is what they can tell you:

Delay set:

If the Delay Timer function has been enabled

(see page.

9)

, once you have started the programme, the LED corre-

sponding to the delay set will begin to flash:

As time passes, the remaining delay will be displayed,

and the corresponding LED will flash:

Once the set delay is complete, the flashing LED will turn

off and the programme set will start.
