Using other functions08

Setting What it does Option(s)

j

Provides a better blend of the front speakers by spreading the

0 to 7

C. WIDTH

center channel between the front right and left speakers, making

(Center Width)

Default: 3

it sound wider (higher settings) or narrower (lower settings).

(Applicable only

when using a center

speaker)

j

Adjusts the depth of the surround sound balance from front to

–3 to +3

DIMENSION

back, making the sound more distant (minus settings), or more

Default: 0

forward (positive settings).

j

Extends the front stereo image to include the surround speakers

OFF

PANORAMA

for a ‘wraparound’ effect.

ON

k

Adjusts the center image to create a wider stereo effect with

0 to 10

C. IMAGE

vocals. Adjust the effect from 0 (all center channel sent to front

(Center Image)

Defaults:

right and left speakers) to 10 (center channel sent to the center

(Applicable only

Neo:6 MUSIC: 3

speaker only).

when using a center

Neo:6 CINEMA: 10

speaker)

EFFECT Sets the effect level for the currently selected Advanced Surround

10 to 90

or ALC mode (each mode can be set separately).

Defaults: 50

(90 for EXT.STEREO

only)

H.GAIN

Adjusts the output from the front height speaker when listening in

LOW

(Height Gain)

DOLBY PLIIz HEIGHT mode. If set to HIGH, the sound from the

MID

top will be more emphasized.

HIGH

V.SB

When you’re not using surround back speakers, selecting this

OFF

(Virtual Surround

mode allows you to hear a virtual surround back channel through

ON

Back)

your surround speakers. You can choose to listen to sources with

no surround back channel information, or if the material sounds

better in the format (for example, 5.1) for which it was originally

encoded, you can have the receiver only apply this effect to 6.1

l

encoded sources like Dolby Digital EX or DTS-ES.

V.HEIGHT

When you’re not using front height speakers, selecting this mode

OFF

(Virtual Front

allows you to hear a virtual front height channel through your front

ON

m

Height)

speakers.

a.When EQ OFF is selected, the MCACC indicator does not light.

b.This setting is only displayed when the listening mode is Stereo, Auto surround (STEREO) or SOUND RETRIEVER AIR.

c.The adjustment can be made only when TONE is set to ON.

d.With the iPod/USB, INTERNET RADIO or ADAPTER PORT input function, by default S.RTRV is set to ON.

e.UP1 to UP4 can be selected only when the front height speaker is connected. The presence or absence of effects

depends on the listening mode.

f. The initially set AUTO is only available for Dolby TrueHD signals. Select MAX or MID for signals other than Dolby

TrueHD.

g.You shouldn’t have any problems using this with most SACD discs, but if the sound distorts, it is best to switch the

gain setting back to 0 dB.

h.•The HDMI Audio setting cannot be switched while performing synchronized amp mode operations.

• The synchronized amp mode must be turned on in order to play the receiver’s HDMI audio and video input signals

from the TV with the receiver’s power in the standby mode. See About synchronized operations on page 65.
