Yamaha RX-497: FM/AM TUNING

FM/AM TUNING

20

There are 2 tuning methods; automatic and manual. Select either method according to your preference and the strength of

station signals.

Automatic tuning is effective when station signals are

strong and there is no interference.

1

Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER as

the input source.

2

Press FM/AM on the front panel to select the

reception band (FM or AM).

FM or AM appears in the front panel display.

3

Press TUNING MODE on the front panel so

that the AUTO indicator lights up in the front

panel display.

4

Press TUNING

l

 /

h

 once to begin

automatic tuning.

Press

h

 to tune into a higher frequency.

Press

l

 to tune into a lower frequency.

• When you tune into a station, the frequency of the received

station is shown in the front panel display.

• To search for another station, press TUNING

l

 /

h

 once more.

• If the tuning search does not stop at the desired station because

the station signals are weak, try using the manual tuning

method.

FM/AM TUNING

Automatic tuning

ON/OFF

INPUT

MAIN ZONE

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2 4 3

1

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

INPUT

TUNER

or

Front panel

Remote control

FM/AM

TUNING MODE

AUTO/MAN'L

AUTO

Lights up

Notes

l

 TUNING

h

21

FM/AM TUNING

BA

S

IC

OPE

R

A

T

IO

N

English

Manual tuning is effective when station signals are weak.

1

Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER as

the input source.

2

Press FM/AM on the front panel to select the

reception band (FM or AM).

FM or AM appears in the front panel display.

3

Press TUNING MODE on the front panel so

that the AUTO indicator disappears from the

front panel display.

4

Press TUNING

l

 /

h

 to manually tune into

the desired station.

Hold down the button to continue tuning search.

• When you tune into a station, the frequency of the received

station is shown in the front panel display.

• If you tune into an FM station, it is automatically received in the

monaural mode to increase signal quality.

Manual tuning

ON/OFF

INPUT

MAIN ZONE

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2 4 3

1

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

INPUT

TUNER

or

Front panel

Remote control

FM/AM

TUNING MODE

AUTO/MAN'L

AUTO

Disappears

Notes

l

 TUNING

h

22

FM/AM TUNING

You can use the automatic preset tuning method to

automatically store FM stations. This function enables this

unit to automatically tune into FM stations with strong

signals and store up to 40 (8 stations in each of the 5

groups, A1 to E8) of those received stations in order. You

can then easily recall any preset stations by selecting the

preset station numbers where they are stored.

• Any station data stored under a preset station number is cleared

when you store a new station under that preset station number.

• If the number of received stations does not reach 40 (E8),

automatic preset tuning automatically stops once searching all

available stations are tuned into and stored.

• Only FM stations with sufficient signal strength are stored

automatically by automatic preset tuning. If the station you

want to store is weak in signal strength, try using the manual

preset tuning method.

1

Rotate the INPUT selector (or press TUNER

on the remote control) to select TUNER.

2

Press FM/AM on the front panel to select FM

as the reception band.

FM appears in the front panel display.

3

Press and hold MEMORY on the front panel

for more than 3 seconds.

The preset station group and the MEMORY and

AUTO indicators flash in the front panel display.

4

Press TUNING

l

 /

h

 once to begin

automatic preset tuning.

Press

h

 to tune into higher frequencies.

Press

l

 to tune into lower frequencies.

When automatic preset tuning is complete, the

frequency of the last preset station is shown in the

front panel display.

• If TUNING

l

 /

h

 is not pressed within approximately 5

seconds while the MEMORY and AUTO indicators are

flashing, automatic preset tuning automatically begins from the

currently displayed frequency and proceeds toward higher

frequencies.

• Received stations are sequentially programmed to 8 stations in

each preset station group. If 8 stations are all programmed in a

preset station group, another 8 stations are sequentially

programmed in the next preset station group.

Automatic preset tuning

Notes

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2

1

3 4

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

INPUT

TUNER

or

Front panel

Remote control

Notes

FM/AM

MEMORY

MAN'L/AUTO FM

l

 TUNING

h

23

FM/AM TUNING

BA

S

IC

OPE

R

A

T

IO

N

English

■

Customized automatic preset tuning

You can specify a preset station group and a preset station

number from which this unit stores the FM stations

received by automatic preset tuning.

1

Press and hold MEMORY on the front panel

for more than 3 seconds.

2

Press A/B/C/D/E and then press one of the

preset station number buttons on the front

panel to select the preset station group and

the preset station number where the first

received station will be stored.

For example, if you select C5, the first received

station is automatically programmed to C5 and the

next received stations are sequentially programmed

to C6, C7, etc.

3

Press TUNING

l

 /

h

 on the front panel to

begin automatic preset tuning.

Press

h

 to tune into higher frequencies.

Press

l

 to tune into lower frequencies.

When automatic preset tuning is complete, the

frequency of the last preset station is shown in the

front panel display.

Automatic preset tuning stops when the received stations have all

been stored up to E8.

MEMORY

MAN'L/AUTO FM

A/B/C/D/E

1

2

3

4

5

6

7

8

Note

l

 TUNING

h

24

FM/AM TUNING

You can also manually store up to 40 stations (8 stations in

each of the 5 groups, A1 to E8). You can then easily recall

any preset stations by selecting the preset station numbers

where they are stored.

1

Repeat steps 1 to 4 in “Automatic tuning” or

in “Manual tuning” to tune into a station.

When you tune into a station, the frequency of the

received station is shown in the front panel display.

2

Press MEMORY on the front panel.

The MEMORY indicator flashes in the front panel

display for approximately 5 seconds.

3

Press A/B/C/D/E on the front panel

repeatedly to select a preset station group (A

to E).

The selected preset station group is shown in the front

panel display.

4

Press one of the preset station number

buttons on the front panel to select a preset

station number (1 to 8) where you want to

store the station.

This operation must be done within 5 seconds while the

MEMORY indicator is flashing in the front panel display.

Otherwise, the manual preset tuning process is automatically

canceled.

5

Press MEMORY on the front panel to store

the station.

6

Repeat steps 1 to 5 to store other stations.

• Any station data stored under a preset station number is cleared

when you store a new station under that preset station number.

• The reception mode (stereo or monaural) is stored along with

the station frequency.

Manual preset tuning

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNINGH

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

3

4

2

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

MEMORY

MAN'L/AUTO FM

MEMORY

Flashes

A/B/C/D/E

Note

Notes

1

2

3

4

5

6

7

8

25

FM/AM TUNING

BA

S

IC

OPE

R

A

T

IO

N

English

You can tune into the desired station simply by selecting

the preset station number where it is stored.

1

Press A/B/C/D/E on the front panel

repeatedly (or press A/B/C/D/E

j

 /

i

 on the

remote control) to select a preset station

group (A to E).

The selected preset station group is shown in the front

panel display.

2

Press one of the preset station number

buttons on the front panel (or

PRESET

j

 /

i

 on the remote control) to select

a preset station number (1 to 8).

The preset station number appears in the front panel

display along with the reception band and the

frequency.

You can exchange the assignment of two preset stations

with each other. The following procedure describes an

example where a preset station E1 is exchanged with

another preset station A5.

1

Repeat steps 1 and 2 in “Selecting preset

stations” to select a preset station E1.

2

Press EDIT on the front panel.

E1 and the MEMORY indicator flash in the front

panel display.

3

Repeat steps 1 and 2 in “Selecting preset

stations” to select another preset station A5.

A5 and the MEMORY indicator flash in the front

panel display.

4

Press EDIT on the front panel again.

E1-A5 appears in the front panel display, indicating

that the two preset station assignments have been

exchanged.

Selecting preset stations

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

1

2

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

A/B/C/D/E

A/B/C/D/E

A/B/C/D/E

PRESET/CH

ENTER

Front panel

or

Remote control

1

2

3

4

5

6

7

8

A/B/C/D/E

A/B/C/D/E

PRESET/CH

ENTER

or

Front panel

Remote control

Exchanging preset stations

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2,4

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

EDIT

MEMORY

Flashes

MEMORY

Flashes

EDIT
