JVC KD-DV7402: Listening to the USB device

Listening to the USB device

You can connect a USB mass storage class device such as a USB memory, portable HDD, etc. to the unit.

• You can also connect an Apple iPod to the USB input jack. For details of the operations, see pages 37 – 41.

This unit can play DivX/MPEG Video/MP3/WMA/WAV tracks stored in a USB device.

ENGLISH

All tracks will be played repeatedly until you change the source or detach the USB device.

USB input jack

12

USB memory

Turn on the monitor to watch the playback picture if

You can operate the USB device in the same way you

you play back a DivX/MPEG file. You can also control

operate the files on a disc. (See pages 16 – 25.)

playback by referring to the monitor screen. (See also

• You cannot select “USB” when Dual Zone is in use

pages 22 – 25.)

(see page 27).

• See pages 20 – 25 for operation using the remote

controller.

Cautions:

• See pages 50, 51, and 56 for more settings.

• Avoid using the USB device if it might hinder your

safety driving.

If “ ” appears on the monitor when pressing a

• Do not pull out and attach the USB device repeatedly

button, the unit cannot accept the operation you

while “Reading” is shown on the display.

have tried to do.

• Do not start the car engine if a USB device is

• In some cases, without showing “ ,” operations

connected.

will not be accepted.

• This unit may not be able to play the files depending

on the type of USB device.

If a USB device has been attached...

• Operation and power supply may not work as

Playback starts from where it has

intended for some USB devices.

been stopped previously.

• You cannot connect a computer to the USB input

• If a different USB device is

terminal of the unit.

currently attached, playback starts

• Make sure all important data has been backed up to

from the beginning.

avoid losing the data.

• Do not leave a USB device in the car, expose to direct

To stop play and detach the USB device

sunlight, or high temperature to avoid deformation

Straightly pull it out from the unit.

or cause damages to the device.

• Press SOURCE to listen to another playback source.

• Some USB devices may not work immediately after

you turn on the power.

• For more details about USB operations, see page 56.

26
