Specifications

(Camera

Product type : Digital camera (for recording and playback)

Recording system

Still pictures :

Digital recording, JPEG (in accordance with Design

rule for Camera File system (DCF))

Applicable standards :

Exif 2.2, Digital Print Order Format (DPOF), PRINT Image

Matching III, PictBridge

Sound with still

: Wave format

pictures

Movies : AVI Motion JPEG

Memory : Internal memory

En

xD-Picture Card 16 MB to 2 GB (TypeH/M, Standard)

No. of pictures

: Approx. 200

(when fully charged)

(based on CIPA battery life measurement standards)

No. of effective pixels : 7,110,000 pixels

Image pickup device : 1/2.33" CCD (primary color filter), 7,380,000 (gross)

Lens : Olympus lens 6.5 to 19.5 mm, f3.4 to 5.7

(equivalent to 37 to 111 mm on a 35 mm camera)

Photometric system : Digital ESP metering, spot metering system

Shutter speed : 4 to 1/1000 sec.

Shooting range : 0.6 m (2.0 ft.) to ) (W/T) (normal)

0.2 m (0.7 ft.) to ) (W), 0.5 m (1.6 ft.) to ) (T) (macro mode)

0.08 m (3.2 in.) to 0.6 m (2.0 ft.) (W only) (super macro mode)

Monitor : 2.5" TFT color LCD display, 230,000 pixels

Flash charge time : Approx. 4 sec. (for full flash discharge at room temperature using

a new fully charged battery)

Outer connectors : DC-IN jack, USB connector, A/V OUT jack (multi-connector)

Automatic calendar system : 2000 up to 2099

Water resistance

Type : Equivalent to IEC Standard publication 529 IPX4 (under

OLYMPUS test conditions)

Meaning : Camera is not damaged by water spray from any direction.

Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (operation),

-20°C to 60°C (-4°F to 140°F) (storage)

Humidity : 30% to 90% (operation)/10% to 90% (storage)

Power supply : One Olympus lithium ion battery (LI-42B/LI-40B) or Olympus AC

adapter

Dimensions : 99 mm (W) × 54 mm (H) × 24.4 mm (D) (3.9 × 2.1 × 1.0 in.)

(excluding protrusions)

Weight : 120 g (4.2 oz) (excluding battery and card)

20

d4328_basic_e_00.book Page 21 Wednesday, December 13, 2006 10:29 AM

(Lithium ion battery (LI-42B)

Product type : Lithium ion rechargeable battery

Standard voltage : DC 3.7 V

Standard capacity : 740 mAh

Battery life : Approx. 300 full charges (varies on usage)

Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (charging)/

-10°C to 60°C (14°F to 140°F) (operation)/

-20°C to 35°C (-4°F to 95°F) (storage)

Dimensions : 31.5 × 39.5 × 6 mm (1.2 × 1.5 × 0.2 in.)

Weight : Approx. 15 g (0.5 oz)

(Battery charger (LI-40C)

Power requirements : AC 100 to 240 V (50 to 60 Hz)

En

3.2 VA (100 V) to 5.0 VA (240 V)

Output : DC 4.2 V, 200 mA

Charging time : Approx. 300 min.

Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (operation)/

-20°C to 60°C (-4°F to 140°F) (storage)

Dimensions : 62 × 23 × 90 mm (2.4 × 0.9 × 3.5 in.)

Weight : Approx. 65 g (2.2 oz)

Design and specifications subject to change without notice.
