Dell™ PowerEdge™ 840 Systems

Getting Started

With Your System

Začínáme se systémem

Guide de mise en route

Erste Schritte mit dem System

Τα πρώτα βήµατα Με το σύστηµά σας

Rozpoczęcie pracy z systemem

Начало работы с системой

Procedimientos iniciales con el sistema

Model MVT01

www.dell.com | support.dell.com

Dell™ PowerEdge™ 840 Systems

Getting Started

With Your System

www.dell.com | support.dell.com

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid

the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

____________________

Information in this document is subject to change without notice.

© 2006 Dell Inc. All rights reserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, PowerEdge, and OpenManage are trademarks of Dell Inc.; Intel, Pentium, and Celeron

are registered trademarks and Core is a trademark of Intel Corporation; Microsoft, Windows, and Windows Server are registered trademarks

of Microsoft Corporation; Red Hat is a registered trademark of Red Hat, Inc.; SUSE is a registered trademark of Novell, Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Model MVT01

May 2006 P/N HJ031 Rev. A00

System Features

This section describes the major hardware and software features of your system. It also provides

information about other documents you may need when setting up your system and how to obtain

technical assistance.

Major hardware and software features of your system include:

• One of the following processors:

®

– One Intel

Core™ 2 Duo

®

– One Intel Celeron

D, 300 sequence

®

– One Intel Pentium

4, 600 sequence

NOTE: Use the System Setup program to view processor information. See "Using the System Setup

Program" in your Hardware Owner’s Manual.

• A minimum of 512 MB of 533- or 667-MHz DDRII SDRAM memory, upgradable to a maximum

of 8 GB by installing combinations of 512-MB, 1-GB, or 2-GB unbuffered ECC memory modules

in four memory module sockets on the system board, single or dual rank.

• The following expansion slots:

– One PCIe x1 (3.3-V) slot

– One PCIe x8 (3.3-V) slot

– One 32-bit, 33-MHz PCI (5-V) slot

– Two 64-bit, 133-MHz PCI-X (3.3-V) slots

• An integrated Gigabit Ethernet NIC, capable of supporting 10-Mbps, 100-Mbps, or 1000-Mbps

data rates, with support for IPMI 1.5 and Wake-on-LAN.

• Four USB 2.0-compliant connectors (two on the front and two on the back) capable of supporting

a diskette drive, CD-ROM drive, keyboard, mouse, or USB flash drive.

• An integrated ATI ES1000 SVGA video controller supporting True-color graphics in the following

resolutions: 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, and 1600 x 1200.

• Systems management circuitry that monitors critical system voltages and fan speeds. The systems

management circuitry works in conjunction with the systems management software.

• Standard baseboard management controller with serial access.

• Back-panel connectors include PS/2 mouse and keyboard, serial, video, two USB connectors,

and one NIC connector.

Getting Started With Your System 3

• One 3.5-inch CD, DVD, or combination CD-RW/DVD in a peripheral drive bay.

NOTE: DVD devices are data only.

• Support for the following internal hard-drive configurations:

– Up to four internal, 1-inch, SATA hard drives with integrated drive controllers.

– Up to four internal, 1-inch, Serial-Attached SCSI (SAS) hard drives with an optional SAS

controller card or backplane.

NOTE: Hot-plug capability is supported only when SATA or SAS drives are connected to the optional SAS

controller card or backplane.

• Optional remote access controller (DRAC 4) for remote systems management. This option requires

a dedicated PCI slot.

• One 420-W power supply.

For more information about specific features, see "Technical Specifications."

The following software is included with your system:

• A System Setup program for quickly viewing and changing system configuration information. For more

information on this program, see "Using the System Setup Program" in the

Hardware Owner’s Manual

.

• Enhanced security features, including a system password and a setup password, available through

the System Setup program.

• System diagnostics for evaluating system components and devices. For information about using

the system diagnostics, see "Running the System Diagnostics" in your

Hardware Owner’s Manual

.

• Video drivers for displaying many popular application programs in high-resolution modes.

• SATA or SAS device drivers that allow the operating system to communicate with devices attached

to the integrated SATA or SAS subsystem. For more information about these drivers, see "Installing

Drives" in your

Hardware Owner’s Manual

.

• Systems management software and documentation CDs.

Supported Operating Systems

Your system supports the following operating systems:

• Microsoft Windows Server

™

2003, Standard Edition and Web Edition

• Microsoft Windows Server 2003, Standard Edition 64-Bit

®

•Red Hat

Enterprise Linux ES (version 3) for Intel x86

• Red Hat Enterprise Linux ES (version 4) for Intel x86

• Red Hat Enterprise Linux ES (version 4) for Intel Extended Memory 64 Technology (Intel EM64T)

®

•SUSE

Linux Enterprise Server 9 (Service Pack 2 or later) for Intel EM64T

• SUSE Linux Enterprise Server 10 for Intel EM64T

4 Getting Started With Your System

Other Information You May Need

CAUTION: The Product Information Guide provides important safety and regulatory information. Warranty

information may be included within this document or as a separate document.

• The

Hardware Owner’s Manual

provides information about system features and describes how to

troubleshoot the system and install or replace system components. The

Hardware Owner’s Manual

is available on the CDs that came with your system or on

support.dell.com

.

• CDs included with your system provide documentation and tools for configuring and managing

your system.

• Systems management software documentation describes the features, requirements, installation,

and basic operation of the software.

• Operating system documentation describes how to install (if necessary), configure, and use

the operating system software.

• Documentation for any components you purchased separately provides information necessary

to configure and install these options.

• Updates are sometimes included with the system to describe changes to the system, software,

and/or documentation.

NOTE: Always check for updates on support.dell.com and read the updates first because they often

supersede information in other documents.

• Release notes or readme files may be included to provide last-minute updates to the system

or documentation or advanced technical reference material intended for experienced users or

technicians.

Obtaining Technical Assistance

If you do not understand a procedure in this guide or if the system does not perform as expected,

see your Hardware Owner’s Manual.

Dell Enterprise Training and Certification is available; see www.dell.com/training for more information.

This service may not be offered in all locations.

Getting Started With Your System 5

Installation and Configuration

CAUTION: Before performing the following procedure, read and follow the safety instructions and important

regulatory information in your Product Information Guide.

This section describes the steps to set up your system for the first time.

CAUTION: Installing the feet on a stand-alone tower system is necessary to provide a stable foundation for the

system. Failure to install the feet poses the risk of having the system tip over, possibly causing bodily injury or

damage to the system.

CAUTION: Whenever you need to lift the system, get others to assist you. To avoid injury, do not attempt to lift the

system by yourself.

Unpacking the System

Unpack your system and identify each item.

Keep all shipping materials in case you need them later.

See the documentation included with your system on installing the system stabilizer feet.

6 Getting Started With Your System

Connecting the Keyboard, Mouse, and Monitor

Connect the keyboard, mouse, and monitor (optional).

The connectors on the back of your system have icons indicating which cable to plug into each

connector. Be sure to tighten the screws (if any) on the monitor's cable connector.

Connecting the Power

Connect the system’s power cable(s) to the system.

Plug the other end of the cable into a grounded electrical outlet or a separate power source

such as an uninterrupted power supply (UPS) or a power distribution unit (PDU).

Getting Started With Your System 7
