M4A785TD-V EVO specications summary

®

®

CPU AMD

Socket AM3 for AMD

Phenom™ II / Athlon™ II /

Sempron™ 100 series processors

Supports 45nm CPU

AMD Cool ‘n’ Quiet™ Technology

®

* Refer to www.asus.com for the AMD

CPU support list

®

Chipset AMD

785G / SB710

Front side bus Up to 5200MT/s HyperTransport™ 3.0 interface

Memory Dual-channel memory architecture

4 x 240-pin DIMM slots support maximum 16GB unbuffered

ECC and non-ECC DDR3 1800 (O.C.) / 1600 (O.C.) /

1333 / 1066 MHz memory modules

* Refer to www.asus.com for the latest Memory QVL

(Qualied Vendors List).

** When you install a total memory of 4GB or more,

®

Windows

32-bit operating system may only recognize

less than 3GB. We recommend a maximum of 3GB

®

system memory if you are using a Windows

32-bit

operating system.

VGA Integrated ATI Radeon™ HD 4200 GPU

SidePort Memory - onboard 128MB DDR3 1333 memory

- Supports HDMI™ technology with max. resolution up

to 1920 x 1200 (1080p)

- Supports Dual-link DVI with max. resolution up to

2560 x 1600 @60Hz

- Supports D-Sub with max. resolution up to

2048 x 1536 @85Hz

- Supports Hybrid CrossFireX™ technology (for

®

Windows

Vista only)

- Supports dual independent displays with HDMI/DVI

and D-Sub

®

- Supports Microsoft

DirectX 10.1, OpenGL 2.0, Shader

Model 4.1

- Supports Hardware Decode Acceleration for H.264,

VC-1, and MPEG-2

- Maximum shared memory of 512MB

Expansion slots 2 x PCIe 2.0 x16 slots (blue @ x16 mode, gray @ x4 mode)

1 x PCIe x1 slot

3 x PCI slots

®

Storage / RAID AMD

SB710 southbridge:

- 1 x Ultra DMA 133/100/66 connector for up to 2 PATA

devices

- 5 x Serial ATA 3Gb/s connectors support RAID 0,

RAID 1, RAID 0+1, and JBOD congurations

- 1 x eSATA 3Gb/s port

LAN RTL8112L Gigabit LAN controller featuring AI NET2

(continued on the next page)
