Инструкция к Сетевому оборудованию Asus PL-X31M PL-X32M
EC Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTek COMPUTER INC.
Address, City:
No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C.
Country:
TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City: HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name : HomePLUG AV Ethernet adapter
Model name : PL-X31M, PL-X32M
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
EN 55022:2006+A1:2007
EN 61000-3-2:2006
EN 61000-3-3:2008
EN 50412-2-1:2005
IEC 61000-4-2:2008
IEC 61000-4-3:2006+A1:2007
IEC 61000-4-4:2004
IEC 61000-4-5:2005
IEC 61000-4-6:2008
IEC 61000-4-11:2004
1999/5/EC-R &TTE Directive
EN 300 328 V1.7.1(2006-05)
EN 301 489-1 V1.8.1(2008-04)
EN 300 440-1 V1.4.1(2008-05)
EN 301 489-3 V1.4.1(2002-08)
EN 300 440-2 V1.2.1(2008-03)
EN 301 489-4 V1.3.1(2002-08)
EN 301 511 V9.0.2(2003-03)
EN 301 489-7 V1.3.1(2005-11)
EN 301 908-1 V3.2.1(2007-05)
EN 301 489-9 V1.4.1(2007-11)
EN 301 908-2 V3.2.1(2007-05)
EN 301 489-17 V2.1.1(2009-05)
EN 301 893 V1.4.1(2005-03)
EN 301 489-24 V1.4.1(2007-09)
EN 302 544-2 V1.1.1(2009-01)
EN 302 326-2 V1.2.2(2007-06)
EN 50360:2001
EN 302 326-3 V1.3.1(2007-09)
2006/95/EC-LVD Directive
EN 60950-1:2006
EN 60065:2002+A1:2006+A11:2008
EN 60950-1:2006+A11:2009
2009/125/EC-ErP Directive
Regulation (EC) No. 1275/2008
Regulation (EC) No. 278/2009
EN 62301:2005
EN 62301:2005
Regulation (EC) No. 642/2009
EN 62301:2005
Ver. 110101
CE marking
Position : CEO
Name : Jerry Shen
Declaration Date: Jan. 28, 2011
Year to begin affixing CE marking:2011
Signature : __________
(
EC conformit
y
markin
g)
Index
1 English .............................................................................................. 1
2 Nederlands ........................................................................................5
3 Français
.............................................................................................9
4 Deutsch
............................................................................................13
5 Italiano
.............................................................................................17
6 Português
........................................................................................21
7 Pусский
..............................................................................................25
8 Español
............................................................................................29
9 繁體中文
...........................................................................................33
10 Türkçe
..............................................................................................37
11 Български
..........................................................................................41
12 Česky
...............................................................................................45
13 Eesti
.................................................................................................49
14 Suomi
...............................................................................................53
15 Ελληνικά
..........................................................................................57
16 Magyar
.............................................................................................61
17 Bahasa Indonesia ...........................................................................65
18 한국어
...............................................................................................69
19 Latviski
............................................................................................73
20 Lietuvių
............................................................................................77
21 Polski
...............................................................................................81
22 Română
............................................................................................85
23 Slovensky
........................................................................................89
24 ไทย
...................................................................................................93
25 Українська
.........................................................................................97
Q4044_PL-X31.indb 1 8/14/08 2:15:17 PM
PL-X31M_X32M 200Mbps HomePlug AV Ethernet Adapter Quick Start Guide
1. Package contents
English
1
• PL-X31M HomePlug AV Ethernet Adapter x 1(x 2 for PL-X32M)
• LAN cable x 1 (x 2 for PL-X32M)
• Quick Start Guide x 1
• CD x 1
2.Specicationsummary
Port
1 x 10/100 Mbps Ethernet port
PowerSupply
AC 100-240V/50-60Hz
Dimension
88(W) X 52(D) X 32(H) mm
Powerline Speeds
Up to 200 Mbps
Connection
RJ45
LED Indicator
Encryption
128-bit AES Encryption
Coverage
Up to 5000 square foot home
Communication Distance
Approx 300M (Varies depending on the electrical
environment)
o
Temperature&Humidity
• Operating temperature: 0-40
C
• Operating relative humidity: 10% to 85% non-
condensing
o
• Storage Temperature: 0-60
C
• Storage Humidity: 10% to 85% non-condensing
3.SystemRequirements
Check that the following requirements are met:
• Your Ethernet network is set up and an Ethernet port is available on your
network.
Power
Ethernet Link
Data
