DF 700 EQ

17

GB

11 Accessories

The order numbers of the accessories and tools can

be found in the Festool catalogue or on the Internet

under "www.festool.com".

Festool provides comprehensive accessories which

allow you to use your machine effectively and for di-

verse applications, e.g.:

• Handrail fence RA-DF 500/700

• Cross stop QA-DF 500/700

• Stopper LA-DF 500/700

Assembly instructions are included at the end of

the operating manual.

12 Environment

Do not throw the power tool in your household

waste! Dispose of machines, accessories and pack-

aging at an environmentally responsible recycling

centre. Observe the valid national regulations.

EU only:

European Directive 2002/96/EC stipulates

that used electric power tools must be collected

separately and disposed of at an environmentally

responsible recycling centre.

Information on REACh:

www.festool.com/reach

13 EU Declaration of Conformity

We declare under sole responsibility that this prod-

uct complies with the following directives and stan-

dards:

2006/42/EG, 2004/108/EG, 2011/65/EU, EN 60745-

1, EN 60745-2-19, EN 55014-1, EN 55014-2, EN

61000-3-2, EN 61000-3-3.

Festool Group GmbH & Co. KG

Wertstr. 20, D-73240 Wendlingen, Germany

Dr. Martin Zimmer

Head of Research, Development and Technical

Documentation

21.02.2013

Tool cannot be loosened during

tool change

Spindle lock not functioning

Twist spindle against the tool using

an open-ended spanner. If this

occurs several times contact the

after-sales service department.

The positions of the dowel holes

which are created with one of the

left and one of the right stop pins

do not match precisely.

The stop pins are selected differ-

ent on the right and left.

Select the same stop pins on the

left and the right.

DOMINO joining machine oper-

ates irregularly, jerks

a. No dust extractor connected

b. Rubber buffer

[1-1]

 worn

a. Connect dust extractor

b. Replace rubber buffer (spare

part)

Fault

Cause

Solution

Dowel jointer

Serial no.

DF 700 EQ

499247

Year of CE mark: 2011
