JVC KW-AV70BT: REFERENCE

Searching for an item directly

Various disc operations

Tuner frequency

Using the disc menu

1 Press DIRECT while holding SHIFT to enter the

• DVD-Video/DVD-VR

search mode.

1 For DVD Video, press TOP M or MENU.

2 Press number buttons while holding SHIFT to enter

ENGLISH

For DVD-VR, press...

a frequency.

TOP M: To display Original Program

• To erase a misentry, press CLR (clear) while

MENU: To display Playlist

holding SHIFT.

2 Press % / fi/@ / # to select an item you want to

3 Press ENT to confirm the entry.

play.

3 Press ENT to confirm the selection.

DVD-Video/DVD-VR/DivX/MPEG1/MPEG2/JPEG/

MP3/WMA/WAV/VCD/CD

• VCD

1 Press DIRECT while holding SHIFT to enter the

During PBC playback...

search mode.

1 Press DIRECT while holding SHIFT to enter the

• Each time you press DIRECT, the item to search

search mode.

for changes.

2 Press a number button while holding SHIFT to

2 Press a number button while holding SHIFT to

select the item you want to play.

select a desired item.

3 Press ENT to confirm the selection.

• To erase a misentry, press CLR (clear) while

holding SHIFT.

• To return to the previous screen, press RETURN.

3 Press ENT to confirm the selection.

To cancel PBC playback

1 Press 7 to stop PBC playback.

2 Press DIRECT while holding SHIFT.

3 Press a number button while holding SHIFT to

select a desired track.

4 Press ENT to confirm the selection.

• To resume PBC, press TOP M or MENU.

64

EN_KW-AV70EU.indb 64EN_KW-AV70EU.indb 64 11/12/13 16:3911/12/13 16:39

Maintenance

Caution on cleaning the unit

To keep discs clean

Do not use any

A dirty disc may not play correctly.

solvent (for

If a disc does become dirty, wipe it with a

ENGLISH

example, thinner,

soft cloth in a straight line from center to

benzine, etc.),

edge.

detergent, or

• Do not use any solvents (for example, conventional

insecticide. This may damage the monitor or the unit.

record cleaner, spray, thinner, benzine, etc.) to clean

Recommended cleaning method:

discs.

Gently wipe the panel with a soft, dry cloth.

To play new discs

How to clean the connector

New discs may have some rough spots

Frequent detachment will

around the inner and outer edges. If

deteriorate the connectors.

such a disc is used, this unit may reject

To minimize this

the disc.

possibility, periodically

To remove these rough spots, rub the edges with a

wipe the connectors with

pencil or ball-point pen, etc.

a cotton swab or cloth

Connectors

moistened with alcohol,

being careful not to damage the connectors.

Do not use the following discs:

8 cm CD Warped disc

Moisture condensation

Moisture may condense on the lens inside the unit in

the following cases:

• After starting the heater in the car.

Sticker and sticker

• If it becomes very humid inside the car.

residue Stick-on label

Should this occur, the unit may malfunction. In this

case, eject the disc and leave the unit turned on for a

few hours until the moisture evaporates.

How to handle discs

C-thru Disc (semi-

When removing a disc from

Unusual shape

transparent disc)

Center holder

its case, press down the center

holder of the case and lift the

disc out, holding it by the edges.

• Always hold the disc by the

Transparent or semi-

edges. Do not touch its recording surface.

transparent parts on its

When storing a disc in its case, gently insert the

recording area

disc around the center holder (with the printed surface

facing up).

• Make sure to store discs in their cases after use.

65

EN_KW-AV70EU.indb 65EN_KW-AV70EU.indb 65 11/12/13 16:3911/12/13 16:39

More about this unit

File playback

Playing MP3/WMA/WAV files

• This unit can play back files with the extension code

Playing DivX files (for discs only)

<.mp3>, <.wma>, or <.wav> (regardless of the

ENGLISH

• This unit can play back DivX files with the extension

letter case—upper/lower).

code <.divx>, <.div>, or <.avi> (regardless of the

• This unit can play back the files meeting the

letter case—upper/lower).

conditions below:

• Audio stream should conform to MP3 or Dolby

– Bit rate:

Digital.

MP3/WMA: 32 kbps — 320 kbps

• The file encoded in the interlaced scanning mode

– Sampling frequency:

may not be played back correctly.

48 kHz, 44.1 kHz, 32 kHz (for MPEG1)

• The maximum bit rate for video signals (average) is

24 kHz, 22.05 kHz, 16 kHz (for MPEG2)

4 Mbps.

48 kHz, 44.1 kHz, 32 kHz, 22.05 kHz (for WMA)

44.1 kHz (for WAV)

Playing MPEG1/MPEG2 files

• This unit can show ID3 Tag Version

• This unit can play back MPEG1/MPEG2 files with the

1.0/1.1/2.2/2.3/2.4 (for MP3).

extension code <.mpg>, <.mpeg>, or <.mod>.

• This unit can also show WAV/WMA Tag.

• The stream format should conform to MPEG system/

• This unit can play back files recorded in VBR (variable

program stream.

bit rate).

The file format should be MP@ML (Main Profile at

• Files recorded in VBR have a discrepancy in elapsed

Main Level)/SP@ML (Simple Profile at Main Level)/

time indication.

MP@LL (Main Profile at Low Level).

• This unit cannot play back the following files:

• Audio streams should conform to MPEG1 Audio

– MP3 files encoded with MP3i and MP3 PRO

Layer-2 or Dolby Digital.

format.

• The maximum bit rate for video signals (average) is

– MP3 files encoded with Layer 1/2.

4 Mbps.

– WMA files encoded with lossless, professional, and

voice format.

Playing JPEG files

– WMA files which are not based upon Windows

• This unit can play back JPEG files with the extension

Media® Audio.

code <.jpg>, or <.jpeg>.

– WMA files copy-protected with DRM.

• This unit can play back JPEG files that are at 32 x 32 to

• This unit can display the jacket picture meeting the

8 192 x 7 680 resolution.

conditions below:

It may take time to display the file depending on its

– Picture size: 32 x 32 to 1 232 x 672 resolution

resolution.

– Data size: less than 650 KB.

• This unit can play back baseline JPEG files.

− File type: JPEG

Progressive JPEG files or lossless JPEG files cannot be

played.

We bear no responsibility for any loss of data

in an iPod/iPhone and USB mass storage

class device while using this unit.

66

EN_KW-AV70EU.indb 66EN_KW-AV70EU.indb 66 11/12/13 16:3911/12/13 16:39

Sound signals emitted through the rear terminals

Through the analog terminals (Speaker out/REAR OUT/FRONT OUT)

2-channel signal is emitted. When playing multi-channel encoded disc, multi-channel signals are downmixed.

Language codes (for DVD/DVD-VR/DivX language selection)

ENGLISH

Code Language Code Language Code Language Code Language

AA Afar GL Galician MI Maori SO Somali

AB Abkhazian GN Guarani MK Macedonian SQ Albanian

AF Afrikaans GU Gujarati ML Malayalam SR Serbian

AM Ameharic HA Hausa MN Mongolian SS Siswati

AR Arabic HI Hindi MO Moldavian ST Sesotho

AS Assamese HR Croatian MR Marathi SU Sundanese

AY Aymara HU Hungarian MS Malay (MAY) SW Swahili

AZ Azerbaijani HY Armenian MT Maltese TA Tamil

BA Bashkir IA Interlingua MY Burmese TE Telugu

BE Byelorussian IE Interlingue NA Nauru TG Tajik

BG Bulgarian IK Inupiak NE Nepali TH Thai

BH Bihari IN Indonesian NO Norwegian TI Tigrinya

BI Bislama IS Icelandic OC Occitan TK Turkmen

BN Bengali, Bangla IW Hebrew OM (Afan) Oromo TL Tagalog

BO Tibetan JA Japanese OR Oriya TN Setswana

BR Breton JI Yiddish PA Panjabi TO Tonga

CA Catalan JW Javanese PL Polish TR Turkish

CO Corsican KA Georgian PS Pashto, Pushto TS Tsonga

CS Czech KK Kazakh QU Quechua TT Tatar

CY Welsh KL Greenlandic RM Rhaeto-Romance TW Twi

DZ Bhutani KM Cambodian RN Kirundi UK Ukrainian

EL Greek KN Kannada RO Rumanian UR Urdu

EO Esperanto KO Korean (KOR) RW Kinyarwanda UZ Uzbek

ET Estonian KS Kashmiri SA Sanskrit VI Vietnamese

EU Basque KU Kurdish SD Sindhi VO Volapuk

FA Persian KY Kirghiz SG Sangho WO Wolof

FI Finnish LA Latin SH Serbo-Croatian XH Xhosa

FJ Fiji LN Lingala SI Singhalese YO Yoruba

FO Faroese LO Laothian SK Slovak ZU Zulu

FY Frisian LT Lithuanian SL Slovenian

GA Irish LV Latvian, Lettish SM Samoan

GD Scots Gaelic MG Malagasy SN Shona

67

EN_KW-AV70EU.indb 67EN_KW-AV70EU.indb 67 11/12/13 16:3911/12/13 16:39

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

• “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other

countries.

• DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used

ENGLISH

under license.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is

an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to

convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX

Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device

setup menu. Go to vod.divx.com for more information on how to complete your registration.

• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the

United States and/or other countries.

• “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to connect

specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance

standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory

standards. Please note that the use of this accessory with iPod, or iPhone may affect wireless performance.

iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other

countries.

• This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property

rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

• Font for this product is designed by Ricoh.

Only for KW-AV70BT

• SDHC Logo is a trademark of SD-3C, LLC.

•

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by

JVCKENWOODCorporation is under license. Other trademarks and trade names are those of their respective owners.

SAFETY INSTRUCTIONS

Use of the iPhone Navigation App is only permitted if the traffic conditions are suitable and you are absolutely

sure that no risk, obstruction or injury will be incurred to you, your passengers or other road users. The

requirements of the Road Traffic Regulations must always be followed and may vary by state. The destination

must not be entered while the vehicle is in motion.

iPhone Navigation guidance may not be applicable to the current situation because of changes in traffic

conditions (e.g. changes in tollroads, principal roads, one-way traffic, or other traffic regulations). In this case,

observe the current traffic signs or regulations.

• Traffic signs should be observed carefully while driving using the iPhone Navigation App. iPhone Navigation

App is only an aid. Driver must always decide whether or not to heed the information provided. We do not

accept liability for erroneous data provided by the iPhone Navigation App.

• Do not operate the unit while driving.

68

EN_KW-AV70EU.indb 68EN_KW-AV70EU.indb 68 11/12/13 16:3911/12/13 16:39

Troubleshooting

What appears to be trouble is not always serious. Check the following points before calling a service center.

• For operations with the external components, refer also to the instructions supplied with the adapters used for the

connections (as well as the instructions supplied with the external components).

• Messages (enclosed in “ ”) in the tables below are shown in the language selected on <Language> (☞page 48 ).

ENGLISH

If the following messages appear

Message Remedy/Cause

“No Signal” • Start the playback on the external component connected to VIDEO IN jack.

• Check the cords and connections.

• Signal input is too weak.

“MISWIRING Check wiring

A speaker cord has shorted or it has come in to contact with the car chassis.

connection then reset unit”

Wire or insulate the speaker cord as appropriate, then reset the unit

“WARNING Check wiring

(☞page3 ). See also the Installation/Connection Manual.

connection then reset unit”

“Parking Brake” No playback picture is shown when the parking brake is not engaged.

“Eject Error” / “Loading Error”

Eject the disc forcibly. (☞ page 3 )

“Restricted Device”

Check whether the connected iPod/iPhone is compatible with this unit. (☞

page 29)

“USB Device Error” • The USB power voltage is abnormal.

• Turn off and turn on the unit.

• Connect another USB device.

“No BT Dongle”* Bluetooth adapter (KS-UBT1) is removed.

“Connection Error”* The device is registered but the connection has failed. Connect the registered

device. (☞ page 53)

“Please Wait...”*

The unit is preparing to use the Bluetooth function. If the message does not

disappear, turn off and turn on the unit, then connect the device again (or reset

the unit).

“No Voice Device”* The connected mobile phone does not have the voice recognition system.

“No Data”* No phone book data is contained in the connected Bluetooth phone.

“Initialize Error”* The unit has failed to initialize the Bluetooth module. Try the operation again.

“Dial Error”* Dialing has failed. Try the operation again.

“Hung Up Error”* The call has not ended yet. Park your car, and use the connected mobile phone

to end the call.

“Pick Up Error”* The unit has failed to receive a call.

“Pairing Error”* Pairing between the unit and Bluetooth device has failed. Register the device

again. (☞ page 52)

* Only for KW-AV70BT .

69

EN_KW-AV70EU.indb 69EN_KW-AV70EU.indb 69 11/12/13 16:3911/12/13 16:39

If there seems to be a problem

Symptom Remedy/Cause

No sound comes out of the speakers. • Adjust the volume to the optimum level.

• Check the cords and connections.

ENGLISH

No picture is displayed on the screen.

Turn on the screen. (☞ page 8 )

The unit does not work at all.

Reset the unit. (☞ page 3 )

<Display Sensor> does not work properly. The display sensor may malfunction when an object exists

close to the motion sensor. In this case, select <High> for

<Motion Sensitiv.>. (☞ page 11)

General

The remote controller does not work.

• Deactivate the rear source. (☞ page 38) (While the rear

source is activated, the remote controller only functions

for operating the DVD/CD player.)

• Replace the battery.

Desired source button (“

Bluetooth

”*

, “

AV -

Select appropriate setting for <AV Input>. (☞ page 47 )

IN

”, or “

Apps

”) is not displayed on <AV

Menu> screen.

SSM automatic presetting does not work.

Store stations manually. (☞ page 15 )

TUNER

Static noise while listening to the radio. Connect the aerial firmly.

Disc can be neither recognized nor played

Eject the disc forcibly. (☞ page 3 )

back.

Disc cannot be ejected.

Unlock the disc. (☞ page 18)

• Recordable/Rewritable discs cannot be

• Insert a finalized disc.

played back.

• Finalize the discs with the component which you used

• Tracks on the Recordable/Rewritable discs

for recording.

cannot be skipped.

Disc in general

Playback does not start. The format of files is not supported by the unit.

No picture appears on the external monitor. • Connect the video cord correctly.

• Select the correct input on the external monitor.

Disc cannot be played back. • Record the tracks using a compliant application on the

appropriate discs. (☞ page 19)

• Add appropriate extension codes to the file names.

Tracks are not played back as you have

Playback order may differ from the one played back using

DivX/MPEG1/MPEG2/

intended them to play.

other players.

JPEG/MP3/WMA/WAV

* Only for KW-AV70 .

70

EN_KW-AV70EU.indb 70EN_KW-AV70EU.indb 70 11/12/13 16:3911/12/13 16:39

Symptom Remedy/Cause

“Now Reading...” keeps flashing on the

Turn off the power and on again.

screen.

While playing a track, sound is sometimes

The tracks are not properly copied into the USB device or

USB/SD*

ENGLISH

interrupted.

the SD card. Copy tracks again, and try again.

No sound comes out of the speakers. • Disconnect the iPod, then connect it again.

• Select another source, then reselect “

iPod

”.

The iPod/iPhone does not turn on or does

• Check the connecting cable and its connection.

not work.

• Update the firmware version.

• Charge the battery.

• Check whether the iPod control mode is correctly

selected. (☞ page 30)

• Reset the iPod/iPhone.

Sound is distorted. Deactivate the equalizer either on this unit or the iPod/

iPhone.

iPod/iPhone

A lot of noise is generated. Turn off (uncheck) “VoiceOver” of the iPod. For details, visit

<http://www.apple.com>.

No operations are available when playing

Operate the unit after the Artwork is loaded. (☞ page 31)

back a track containing Artwork.

Sound does not synchronize with the video.

Select <iPod> for <AV Input>. (☞ page 47 )

• Videos cannot be played.

• Connect with USB Audio and Video cable JVC KS-U30.

• No sound of videos come out.

Other cables cannot be used.

• Select <iPod> for <AV Input>. (☞ page 47 )

No picture appears on the screen. • Turn on the video component if it is not on.

AV-IN

• Connect the video component correctly.

* Only for KW-AV70BT.

71

EN_KW-AV70EU.indb 71EN_KW-AV70EU.indb 71 11/12/13 16:3911/12/13 16:39

Symptom Remedy/Cause

Phone sound quality is poor. • Reduce the distance between the unit and the

Bluetooth mobile phone.

• Move the car to place where you can get a better signal

reception.

ENGLISH

The sound is interrupted or skipped while

• Reduce the distance between the unit and the

using a Bluetooth audio player.

Bluetooth audio player.

• Disconnect the device connected for Bluetooth phone.

• Turn off, then turn on the unit.

• (When the sound is not yet restored) connect the player

again.

The connected audio player cannot be

Check whether the connected audio player supports AVRCP

controlled.

(Audio Video Remote Control Profile).

Bluetooth device does not detect the unit. • Check whether the Bluetooth adapter (KS-UBT1) is

inserted correctly.

• Search from the Bluetooth device again.

• When “Waiting for connection...” appears on the screen,

press [Cancel] then connect a Bluetooth device.

Bluetooth (only for KW-AV70BT)

The unit does not make pairing with the

Enter the same PIN code for both the unit and target

Bluetooth device.

device. If the PIN code of the device is not indicated on its

instructions, try “0000” or “1234.”

Echo or noise occurs. • Adjust the microphone unit position.

• Make sure that NR/EC (Noise reduction/Echo cancel)

function is activated. (☞ page 55)

The unit does not respond when you try to

You may have tried to copy the same entries (as stored)

copy the phone book to the unit.

to the unit.

72

EN_KW-AV70EU.indb 72EN_KW-AV70EU.indb 72 11/12/13 16:3911/12/13 16:39

Specifications

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output

Front/Rear 20 W per channel into 4 Ω, 40 Hz to 20 000

(RMS)

Hz at no more than 0.8% total harmonic

ENGLISH

distortion

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range Frequencies Low: 60Hz, 80Hz, 100Hz, 150Hz

Mid: 500Hz, 1kHz, 1.5kHz, 2kHz

High: 10kHz, 12.5kHz, 15kHz, 17.5kHz

Level ±10 dB

AMPLIFIER

Signal-to-Noise Ratio 70 dB

Audio Output Level

Line-Out Level/Impedance 4 V/20 kΩ load (full scale)

LINE OUT (FRONT/REAR),

Output Impedance 1 kΩ

SUBWOOFER

Other Terminals Input LINE IN, VIDEO IN, CAMERA IN, USB input, MIC

IN*, Aerial input

Output 2nd AUDIO OUT

Others OE REMOTE, RGB input

Frequency Range FM 87.5 MHz to 108.0 MHz

AM (MW) 531 kHz to 1 611 kHz

(LW) 153 kHz to 279 kHz

FM Tuner Usable Sensitivity 9.3 dBf (0.8 μV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8 μV/75 Ω)

Alternate Channel Selectivity

65 dB

(400 kHz)

FM/AM TUNER

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 40 dB

MW Tuner Sensitivity/Selectivity 20 μV/40 dB

LW Tuner Sensitivity 50 μV

* Only for KW-AV70BT.

73

EN_KW-AV70EU.indb 73EN_KW-AV70EU.indb 73 11/12/13 16:3911/12/13 16:39
