Activating/deactivating TA/News Standby Reception

TA Standby Reception

News Standby Reception

TP indicator

1

ENGLISH

2

TP indicator TA Standby Reception

Lights up The unit will temporarily switch

to Traffic Announcement (TA) if

available.

Flashes Not yet activated. Tune in to another

station providing the Radio Data

System signals.

NEWS indicator News Standby Reception

Goes off Deactivated.

Lights up The unit will temporarily switch to

• The volume adjustment for Traffic Announcement

News Program if available.

is automatically memorized. The next time the unit

Flashes Not yet activated. Tune in to

switches to Traffic Announcement, the volume is set

another station providing the

to the previous level.

Radio Data System signals.

Goes off Deactivated.

• The volume adjustment while receiving News is

automatically memorized. The next time the unit

switches to News, the volume is set to the previous

level.

16

EN_KW-AV70EU.indb 16EN_KW-AV70EU.indb 16 11/12/13 16:3911/12/13 16:39

Tracing the same program

Automatic station selection—

—Network-Tracking Reception

Program Search

When driving in an area where FM reception is not

Usually when you select preset stations, the preset

sufficient enough, this unit automatically tunes in to

station is tuned in.

another FM Radio Data System station of the same

If the signals from the preset FM Radio Data System

ENGLISH

network, possibly broadcasting the same program with

station are not sufficient for good reception, this

stronger signals.

unit, using the AF data, tunes in to another station

broadcasting the same program as the original preset

station is broadcasting.

Program A broadcasting on different frequency

areas (01 – 05)

To activate Program Search

1

2

When shipped from the factory, Network-Tracking

Reception is activated.

To change the Network-Tracking

Reception setting

1

• The unit takes some time to tune in to another

station using program search.

2

To deactivate, select <Off>.

AF Switches to another station. The program

may differ from the one currently received

(the AF indicator lights up).

AF Reg. Switches to another station broadcasting

the same program (the AF indicator

lights up).

Off Cancels.

17

EN_KW-AV70EU.indb 17EN_KW-AV70EU.indb 17 11/12/13 16:3911/12/13 16:39

Disc operations

Playing a disc

• If a disc does not have any disc menu, all tracks on it will be played repeatedly until you change the source or eject

the disc.

ENGLISH

Inserting a disc

To eject a disc

1 Open the monitor panel.

1 On the source control screen:

On the source control screen:

2 Press [ Eject].

• You can eject a disc when playing another AV source.

• If the ejected disc is not removed within 15 seconds,

the disc is automatically inserted again into the

loading slot to protect it from dust.

• If the disc cannot be ejected, ☞ page 3 .

2

Label side

When removing a disc, pull it horizontally.

To prohibit disc ejection

On the source control screen, press and /

MENU at the same time.

The source changes to “

DISC

” and playback starts.

• The DISC IN (

) indicator lights up while a

disc is inserted.

• If “

” appears on the screen, the unit cannot

accept the operation you have tried to do.

– In some cases, without showing “

,”

operations will not be accepted.

• When playing back a multi-channel encoded

disc, the multi-channel signals are downmixed

To cancel the prohibition, repeat the same procedure

to stereo.

to select <Eject OK?>.

18

EN_KW-AV70EU.indb 18EN_KW-AV70EU.indb 18 11/12/13 16:3911/12/13 16:39

Playable disc types

Disc type Recording format, file type, etc. Playable

1

DVD

DVD-Video *

• DTS sound cannot be

Region Code: 2

ENGLISH

reproduced or emitted from

DVD-Audio/DVD-ROM

this unit.

DVD Recordable/Rewritable

DVD-Video

2

3

(DVD-R/-RW *

, +R/+RW *

)

4

DVD-VR *

• DVD Video: UDF bridge

DivX

/MPEG1/MPEG2

• DVD-VR

• DivX

/MPEG1/MPEG2/JPEG/

JPEG

MP3/WMA/WAV : ISO 9660 level

MP3/WMA/WAV

1, level 2, Romeo, Joliet

MPEG4/AAC/DVD+VR/DVD-RAM

Dual Disc DVD side

Non-DVD side

CD/VCD Audio CD/CD Text (CD-DA)

VCD (Video CD)

DTS-CD/SVCD (Super Video CD)/CD-ROM/CD-I(CD-I Ready)

CD Recordable/Rewritable

CD-DA

(CD-R/-RW)

VCD (Video CD)

• ISO 9660 level 1, level 2,

DivX

/MPEG1/MPEG2

Romeo, Joliet

JPEG

MP3/WMA/WAV

MPEG4/AAC

1

*

If you insert a DVD Video disc of an incorrect Region Code, “Region Code Error” appears on the screen.

2

*

DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not

playable.

3

*

It is possible to play back finalized +R/+RW (Video format only) discs. “DVD” is selected as its disc type when a

+R/+RW disc is loaded. +RW double layer discs are not playable.

4

*

This unit cannot play back contents protected with CPRM (Content Protection for Recordable Media).

Caution for DualDisc playback

The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use

of Non-DVD side of a DualDisc on this product may not be recommended.

19

EN_KW-AV70EU.indb 19EN_KW-AV70EU.indb 19 11/12/13 16:3911/12/13 16:39

Playback operations

To select the method to display the source control screen, ☞ page 11.

• The operation buttons disappear when no operation is done for about 10seconds.

ENGLISH

For DVD/DVD-VR/VCD/DivX/MPEG1/MPEG2/JPEG

Audio format

Playback mode

Playing time

Media type

(☞page 23)

DISC IN indicator

☞ page 9

Video format/

video playback

Playback status

mode—VIDEO/

(3: play / 8: pause / 7: stop)

VR-PRG (program)/

VR-PLAY (playlist)/

• DVD Video: Title no./

DivX/MPEG/PBC

Chapter no.

• DVD-VR: Program no. (or

1

Playlist no.)/Chapter no.*

• DivX/MPEG1/MPEG2:

Folder no./Track no.

• JPEG: Folder no./File no.

• VCD: Track no.

2

5

[7]*

Stops playback.

[4] [¢]*

• Selects chapter/track.

3

[

]*

Displays folder/track list. (☞

(Press)

6

page 21)

• Reverse/forward search.*

4

(Hold)

[

] [ ]*

Selects playback mode. (☞

page 23)

[

] [–] [+]

Adjusts the volume.

7

[6] Starts/pauses playback.

[Mode]*

Changes the settings for disc

playback. (☞ page 24)

[AV MENU] Displays <AV Menu> screen.

1

*

To display the Original Program/Playlist screen, ☞page22.

2

*

Appears only for DVD/DVD-VR/VCD.

3

*

Does not appear for DVD/DVD-VR/VCD.

4

*

Does not appear for DVD/DVD-VR/JPEG.

5

*

The icon displayed between the buttons varies depending on the type of disc or file.

6

*

Search speed varies depending on the type of disc or file.

7

*

Does not appear for VCD.

20

EN_KW-AV70EU.indb 20EN_KW-AV70EU.indb 20 11/12/13 16:3911/12/13 16:39

For CD/MP3/WMA/WAV

Playback mode (☞ page 23)

Playing time

Playback status

Audio format

DISC IN indicator

(3: play / 8: pause )

ENGLISH

Media type

☞

page 9

• MP3/WMA/WAV: Folder

no./Track no.

• CD: Track no.

While playing, the jacket picture is

Track/file information

shown if the file has the tag data

• Touching an information bar scrolls the text if not all of the

including the jacket picture.

text is shown.

1

Displays folder/track list.

[4] [¢] • Selects track. (Press)

[ ]*

2

(☞below)

• Reverse/forward search.*

[

] [ ]

Selects playback mode.

(Hold)

(☞page23)

[

] [–] [+]

Adjusts the volume.

[6] Starts/pauses playback.

1

[Mode]*

Changes the settings for disc

playback. (☞ page 24)

[AV MENU] Displays <AV Menu> screen.

1

*

Does not appear for CD.

2

*

Search speed varies depending on the type of disc or file.

Selecting folder/track on the list

Changes the page

Plays tracks/files in the folder

Playing Recordable/Rewritable discs

• This unit can recognize a total of 5 000 files and

250 folders (a maximum of 999 files per folder).

• Use only “finalized” discs.

• This unit can play back multi-session discs;

however, unclosed sessions will be skipped

while playing.

• Some discs or files may not be played back due

Returns to the root folder

to their characteristics or recording conditions.

Returns to the upper layer

21

EN_KW-AV70EU.indb 21EN_KW-AV70EU.indb 21 11/12/13 16:3911/12/13 16:39

Video menu operations

[ ] Selects the subtitle type.

You can display the video menu screen while watching

[ ]

Selects view angle.

the playback pictures on the screen.

[Menu] Displays the disc menu (DVD)/playlist

• Available items on the screen differ depending on the

(DVD-VR).

types of the loaded disc and playback files.

[Top Menu] Displays the disc menu (DVD)/original

ENGLISH

• The operation buttons disappear when no operation

program (DVD-VR).

is done for about 10 seconds.

[

]

Displays the menu/playlist/original

Touch any position of the screen other than

program/scene selecting screen.

operation buttons.

(☞ below)

[

]

Switches to the direct menu selection

mode. Touch the target item to select.

• To exit from the menu selecting

screen, press [

].

• Touching any position other than operation buttons

displays the source control screen.

Using menu/playlist/original program/

scene selecting screen

• The screen for MPEG1/MPEG2 differs from the above.

[5] [∞]

Selects an item.

[2] [3]

[Enter] Confirms the selection.

[Return] Returns to the menu screen of the

previous layer.

[

]

Displays the menu screen of the top

layer when several menu screens exist

on the disc.

[Zoom] Displays the picture size selecting

screen. (☞ page 44)

• For DivX only

[Aspect]

Selects aspect ratio. (☞ page 44)

[2] [3] Skips back or forward by about 5

[Adjust] Displays picture adjustment screen.

minutes.

(☞ page 43)

[Return] Returns to the previous screen.

[

] Selects the audio type.

[

]

Exits from the scene selecting screen.

• For DVD-VR: Selects the audio

channel (ST: stereo, L: left, R: right).

22

EN_KW-AV70EU.indb 22EN_KW-AV70EU.indb 22 11/12/13 16:3911/12/13 16:39

Only for VCD

• To deactivate the PBC function, press [7] then the

direct selecting buttons to select a track number.

1

Selecting playback mode

For DVD/DVD-VR

ENGLISH

2

Selects Repeat playback mode

For VCD (without PBC)/CD/DivX/MPEG1/MPEG2/MP3/

WMA/WAV

Selects Random

Selects Repeat

playback mode*

playback mode*

Direct selecting buttons (☞ below)

* You cannot activate the repeat mode and the random

[Zoom] Displays the picture size selecting

mode at the same time.

screen. (☞ page 44)

[Aspect]

Selects aspect ratio. (☞ page 44)

• Each time you press the button, the playback mode

[Adjust] Displays picture adjustment screen.

changes. (The corresponding indicator lights up.)

(☞ page 43)

– Available items differ depending on the types of

loaded disc and playback file.

[

] Selects the audio channel (ST: stereo,

L: left, R: right).

Indicator Playback mode

[Return] Displays the previous screen or the

CHAPTER

Repeats current chapter.

menu.

TITLE

Repeats current title.

[Menu] Displays the disc menu.

Repeats current program (not

[ ]

Displays/hides the direct selecting

PROGRAM

available for Playlist playback).

buttons. (☞ below)

SONGS

Repeats current track.

• To select a track directly

FOLDER

Repeats all tracks of the current

folder.

FOLDER

Randomly plays all tracks of

current folder, then tracks of next

folders.

ALL

Randomly plays all tracks.

To cancel, press the button repeatedly until the

– To switch between chapter/track entry and title/

indicator disappears.

folder entry, press [Direct/CLR].

– When you enter a wrong number, press [Direct/

CLR] to delete the last entry.

23

EN_KW-AV70EU.indb 23EN_KW-AV70EU.indb 23 11/12/13 16:3911/12/13 16:39

Settings for disc playback

ENGLISH

Disc Setup items Selectable setting/item Initial: Underlined

Menu Language

Select the initial disc menu language; Initial English (☞ page 67).

Audio Language

Select the initial audio language; Initial English (☞ page 67).

Subtitle

Select the initial subtitle language or erase the subtitle (Off) ; Initial English (☞

page 67).

Down Mix When playing back a multi-channel disc, this setting affects the signals reproduced

through the FRONT OUT/REAR OUT jacks.

♦ Dolby Surround : Select this to enjoy multi-channel surround audio by

connecting an amplifier compatible with Dolby Surround.

♦ Stereo : Normally select this.

For DVD/DVD-VR/DivX

D. (Dynamic)

You can change the dynamic range while playing Dolby Digital software.

Range Compres.

♦ Off : Select this to enjoy a powerful sound at a low volume

(Compression)

level with its full dynamic range.

♦ On : Select this to reduce the dynamic range a little.

♦ Dialog : Select this to reproduce the movie dialog more clearly.

Monitor Type Select the monitor type to watch a wide screen picture on the external monitor.

♦ 16:9

♦ 4:3 LB (Letterbox)

♦ 4:3 PS (PanScan)

VCD/CD

For discs except

File Type Select the playback file type when a disc contains different types of files.

♦ Audio

: Plays back audio files.

♦ Still Picture

: Plays back JPEG files.

♦ Video

: Plays back DivX/MPEG1/MPEG2 files.

♦ Audio&Video

: Plays back audio files and DivX/MPEG1/MPEG2 files.

• For playable file types, ☞ page 19.

video/picture files

• If the disc contains no files of the selected type, the existing files are played in the

For discs containing audio/

following priority: audio, video, then still picture.

24

EN_KW-AV70EU.indb 24EN_KW-AV70EU.indb 24 11/12/13 16:3911/12/13 16:39

SD operations (only for KW-AV70BT)

Playing files in an SD card

• This unit can play JPEG/MPEG1/MPEG2 */MP3/WMA/

3 Close the monitor panel.

WAV files stored in an SD card.

ENGLISH

• This unit can recognize a total of 5 000 files and 250

folders (a maximum of 999 files per folder).

• Make sure all important data has been backed up to

avoid losing the data.

* Except for MPEG2 files recorded by JVC Everio

camcorder (extension code <.mod>).

Inserting an SD card

To eject the SD card

1 Open the monitor panel.

On the source control screen:

1 Open the monitor panel.

2 Push the SD card gently.

• Do not release your finger quickly; otherwise,

the SD card may pop out from the loading slot.

3 Close the monitor panel.

2

Push in the SD card until you hear a clicking sound.

The source changes to “

SD

” and playback starts.

• All tracks in the SD card will be played

repeatedly until you change the source.

25

EN_KW-AV70EU.indb 25EN_KW-AV70EU.indb 25 11/12/13 16:3911/12/13 16:39

Selecting a track/video from menu

iPod/iPhone playback

on the iPod/iPhone

operations for <iPod Out>

1

mode

• Connect the iPod touch/iPhone using KS-U30

ENGLISH

(separately purchased). (☞ Installation/Connection

Manual)

2 Select the menu (Music or Video) (1), a

• Select <iPod> for <AV Input> setting. (☞page 29)

category (2), then a desired item (3).

• Make sure to select <iPod Out> for <iPod

• Select the item in the selected layer until a

Control>. (☞ page 30)

desired track starts playing.

• Select “

iPod

” as the source. (☞ page 12)

Music menu:

Selecting a track from the menu on

Switches between Music ( ) and Video

the iPod/iPhone

( )

*

[5] [∞] Selects a category.

Returns to the top layer

Returns to the

previous layer

[Select/6] Confirms the selection.

[iPod Menu] Returns to the previous layer.

Plays all items in the layer

Operations during playback

Video menu:

Switches between Music ( ) and Video

( )

[2] [3] Skips to the previous/next track.

[Select/6] Starts/pauses playback.

[iPod Menu] Displays the menu.

• Available categories differ depending on the type of

your iPod/iPhone.

* You can switch to the top of the category by pressing

the corresponding tab: Playlist (

), Artist ( ),

Albums (

) or Songs( ).

32

EN_KW-AV70EU.indb 32EN_KW-AV70EU.indb 32 11/12/13 16:3911/12/13 16:39

Using an App of iPod touch/iPhone

You can use an App of the connected iPod touch/iPhone on this unit.

• You can operate some functions of an App on the touch panel.

Preparation

ENGLISH

• Connect the iPod touch/iPhone using KS-U30 (separately purchased). (☞ Installation/Connection Manual)

• Select <iPod> for <AV Input> setting. (☞page 29)

• For Apps you can use on this unit, visit < http://www3.jvckenwood.com/english/car/>.

• When you use an App of the iPod touch or iPhone,

1 Start App on your iPod touch/iPhone.

see also page 68 for safety instructions.

2 Select “

Apps

” as the source.

On <AV Menu> screen:

Displaying the screen of App while

listening to other source

You can switch the display to screen of App from

connected iPod touch/iPhone while listening to other

source.

• You can also play back the audio/video using iPod/

Activating input of iPod touch/iPhone to

iPhone itself instead of the unit.

show buttons for switching display

– You can operate for basic playback on the touch

• Make sure that “

AV Off

” is selected as the rear

panel.

source. (☞ page 38)

Audio

1 Turn off the AV source.

On <AV Menu> screen:

2 Display <Input> setting screen.

Video

33

EN_KW-AV70EU.indb 33EN_KW-AV70EU.indb 33 11/12/15 17:5611/12/15 17:56

3 Select <iPhone> for <Input> setting

To view the screen of App

on <Navigation Input> screen.

On <AV Menu> screen:

ENGLISH

or

On source control screen:

• When <Input> is set to <iPhone>, [Apps] button

is shown on the <AV Menu> screen, and [

]

button is shown on the source control screen. You can

To cancel the screen of App

display the screen of App by pressing either button.

(☞below)

• When <Input> is set to <iPhone>, <AV Input>

setting is automatically changed and fixed to

<iPod>.

To deactivate, select <Off> for <Input>.

34

EN_KW-AV70EU.indb 34EN_KW-AV70EU.indb 34 11/12/13 16:3911/12/13 16:39

Using other external components

To select the method to display the source control screen, ☞ page 11.

• The operation buttons disappear when no operation is done for about 10seconds.

• To change settings for video playback, ☞ page 43.

ENGLISH

AV-IN name ( ☞ below)

[ ] [–] [+]

Adjusts the volume.

[Mode] Changes the AV-IN name.

• Press [2] or [3] to select an AV-IN name.

[AV MENU] Displays <AV Menu> screen.

AV-IN

You can connect an external component to the LINE IN/

1 Select “

AV-IN

” as the source. (☞ page 12)

VIDEO IN jacks. (☞ Installation/Connection Manual)

2 Turn on the connected component and

start playing the source.

Preparation:

Select <AV-IN> for <AV Input> setting. (☞ page 47)

• <AV Input> setting can be changed only when

<Input> setting in <Navigation Input> is set to

<RGB> or <Off>.

35

EN_KW-AV70EU.indb 35EN_KW-AV70EU.indb 35 11/12/13 16:3911/12/13 16:39

Using the external navigation unit

You can connect a navigation unit (not supplied) to the RGB input terminal so that you can view the navigation

screen. (☞ the Installation/Connection Manual)

• Please contact your dealer to inquire about compatible navigation units.

ENGLISH

Activating navigation

3 Select <RGB> for <Input> setting on

<Navigation Input> screen.

1 Turn off the AV source.

On <AV Menu> screen:

2 Display <Input> setting screen.

• When <Input> is set to <RGB>, [Navi] button is

shown on the <AV Menu> screen, and [

] button

is shown on the source control screen. You can display

the navigation screen by pressing either button.

(☞page 37)

To deactivate, select <Off> for <Input>.

36

EN_KW-AV70EU.indb 36EN_KW-AV70EU.indb 36 11/12/13 16:3911/12/13 16:39

To view the navigation screen

Settings for navigation unit

On <AV Menu> screen:

1 On <AV Menu>:

ENGLISH

2

or

On source control screen:

3

• While the navigation screen is displayed, the touch

panel operations are available only for navigation.

• The aspect ratio of the navigation screen is fixed to

<Full> regardless of the <Aspect> setting (☞

page 44).

• You can select the source “

AV-IN

” for listening to an

audio source connected to the LINE IN jacks.

Input

☞ page 36

Output Select front speakers used for the

To cancel the navigation screen

navigation guidance.

Volume Adjust the volume of the navigation

guidance. (0 to 35)

Navigation

Select <On> to attenuate the

Mute

sound coming through speakers

other than the front speakers during

navigation guidance.


Adjust the brightness and blackness.

Adjust

(☞ page 43)

37

EN_KW-AV70EU.indb 37EN_KW-AV70EU.indb 37 11/12/13 16:3911/12/13 16:39

Rear source operations

You can enjoy the rear source playback on the external monitor connected to the VIDEO OUT and 2nd AUDIO OUT

jacks, while listening to any source.

Displaying rear source images on

• When you press [Same as Front] while listening to

ENGLISH

music, the track list appears.

the external monitor

• If the selected source is other than “

DISC

”, “

SD

”*,

1 On <AV Menu> screen:

“

USB

”, or “

iPod

” or “

AV-IN

”, nothing appears on

the rear monitor.

* “

SD

” is available only for KW-AV70BT.

2 Select the rear source.

Operations on the external monitor

Selects the rear source

(from the remote controller only)

Selecting a folder or track on the control

screen

For DivX/MPEG1/MPEG2/JPEG/MP3/WMA/WAV/

CD/iPod

• DivX/MPEG1/MPEG2/JPEG: While playback is

stopped.

• CD/iPod: Skip step 1.

• If “

DISC

”, “

SD

”*, “

USB

”, or “

iPod

” is selected

1 Press @ / # to select “Folder” column or “Track”

as the front source, only the buttons of “

AV -

column.

IN

”, “

AV Off

”, and the one selected as the front

2 Press % / fi to select a Folder or Track.

source can be selected.

• You cannot select “

DISC

”, “

SD

”*, “

USB

”, or

Using the list screen

“

iPod

” as the rear source when you select

For DivX/MPEG1/MPEG2/JPEG/MP3/WMA/WAV

“

Apps

” as the front source.

While playback is stopped.

1 Press TOP M or MENU to display the list screen.

While activating rear source...

2 Press % / fi / @ / # to select a folder/track on

• To view a front source image on the rear monitor,

the list.

press [Same as Front].

• To go back to the folder list, press RETURN.

– To select a source other than the front source as

3 Press ENT to confirm the selection.

the rear source, press [Select] on <AV Menu>

screen.

38

EN_KW-AV70EU.indb 38EN_KW-AV70EU.indb 38 11/12/13 16:3911/12/13 16:39

Sound adjustment

Using the sound equalization

• The adjustment is memorized for each source until you adjust the sound again. If the source is a disc, the

adjustment is stored for each of the following categories.

ENGLISH

– DVD/DVD-VR/ VCD

– CD

– DivX/MPEG1/MPEG2/MP3/WMA/WAV

• You cannot adjust the sound when the AV source is turned off.

Selecting a preset sound mode

Storing your own adjustment

1 On <AV Menu> screen:

Customizing preset sound mode

1 Select a sound mode. (☞ “Selecting a preset

sound mode”)

2 Adjust the level of each band (1), then

select the subwoofer level (2).

or

On the source control screen:

The adjustments are stored and <User> is

activated.

• To finish the procedure, press [

].

• To make precise adjustments, ☞

page 40.

2 Select a sound mode.

Changes the page

39

EN_KW-AV70EU.indb 39EN_KW-AV70EU.indb 39 11/12/13 16:3911/12/13 16:39

Adjusting the sound precisely

Adjusting the crossover

1 Perform steps 1 and 2 of “Selecting a

frequency

preset sound mode,” then...

1 On <AV Menu> screen:

ENGLISH

2 Select a band.

2

3 Adjust the sound.

3 Select the item to adjust, then make

adjustments.

Adjusts the crossover for front or rear speakers

(high pass filter).

Reset Changes level of Low/Mid/

High to 0.

Freq Selects frequency.

Q Adjusts the width of the

1

frequency.*

2

Bass Activates/deactivates bass.*

SW Level Adjusts subwoofer level.

Adjusts the crossover for subwoofer (low pass filter).

The adjustments are overwritten if <User>

setting has been made (☞ page 39), and <User>

is activated.

• The adjustments are memorized until you

adjust sound again.

• To make adjustment for other bands, repeat

steps

2 and 3.

1

*

Fixed for “High” band.

Adjusts the crossover frequency.

2

*

Only for “Low” band.

Selects the phase for the subwoofer.*

Adjusts the subwoofer level.

* Not selectable when <Freq> is set to <Through>.

40

EN_KW-AV70EU.indb 40EN_KW-AV70EU.indb 40 11/12/13 16:3911/12/13 16:39

Changing display design

You can change the background, the color of text and touch panel buttons .

1 On <AV Menu> screen:

2

Select/

adjust the color

ENGLISH

2

Color palette

Dimmer setting: You can make selections for each

dimmer setting—< > (Dimmer On) or < >

(Dimmer Off)

User color adjuster: You can make your own

color adjustment and store it to <User>

Text/Buttons

Select/adjust the color. (For details, ☞ above.)

3 Select an item (<Backgrnd>, <Text> or

• On the button color selecting screen, you can

<Buttons>), then change the setting.

select a color for touch panel buttons.

Background

1

Select a background

Basic image (default)

You can select a color on the color

palette or adjust the color on the user

color adjuster (☞ the right column)

For setting your favorite scene as the background,

☞ page 42

41

EN_KW-AV70EU.indb 41EN_KW-AV70EU.indb 41 11/12/13 16:3911/12/13 16:39

Menu item Selectable setting/item Initial: Underlined

Camera Input ♦ On

: Displays the picture from the rear view camera when

you shift the gear to the reverse (R) position.

♦ Off

: Cancels.

Navigation Input Change the settings for displaying the screen of App from connected iPod

ENGLISH

Input

touch/iPhone/external navigation unit. (☞ pages 33 and 37)

• When <Input> is set to <iPhone>, <Navigation Mute> does not

work.

Language Select the text language used for on-screen information.

♦ English /Español/Français/Deutsch/Italiano/Nederlands/Svenska/

Dansk/Руccĸий /Português/

/ / /

Türkçe/

/ /

• “Please Power Off” appears when the setting is changed. Turn off the

power, then turn on to enable the change.

♦ GUI

: Select a language (<English> or <Local>: the

Language

language selected above) used for displaying operation

buttons and menu items.

Time Set

Adjust the clock time. (☞ page 7)

Beep

♦ On

: Activates the key-touch tone.

♦ Off

: Cancels.

User Profile

You can memorize, recall, or clear the settings you have made. (☞ page 49)

Touch Panel Adjust

Adjust the touch position of the buttons on the screen. (☞ page 50)

System

Initialize Initialize all settings you have made. Hold [Enter] to initialize the settings.

• After initializing the settings, adjust the settings on the <Initial

Settings> screen. (☞ page 6)

Serial Number Displays the serial number.

DivX® VOD

This unit has its own Registration Code. Once you have played back a file

with which the Registration Code recorded, this unit’s Registration Code is

overwritten for copyright protection.

• Press [Enter] to display the information.

• To return to the previous screen, press [OK].

System Information Displays the version information on the software. You can update the

software. (☞ page 50)

Steering Remote Learning This setting is not used.

48

EN_KW-AV70EU.indb 48EN_KW-AV70EU.indb 48 11/12/13 16:3911/12/13 16:39

Memorizing/recalling the settings

You can memorize the following settings:

• Settings on <Settings> screen: Fader/Balance, Equalizer, Loudness, Crossover (HPF/LPF/SW Level

settings), Volume Adjust, Speaker Select, Dimmer, Display Design, Display Sensor, AV Input, Camera

Input, Navigation

ENGLISH

• Settings for “

AV-IN

”: AV-IN Name

Memorizing your settings

Recalling your settings

• Turn off the AV source by pressing [AV Off] on <AV

1 On <Settings> screen:

Menu> and select “

AV Off

” as the rear source

beforehand.

1 On <User Profile> screen (☞ step 2 on the left

column):

A confirmation message appears. Press [Yes].

2 Finish the procedure.

2

Clearing your settings

1 On <User Profile> screen (☞ step 2 on the left

column):

3 Select an item (<User1>, <User2> or

<User3>) to memorize the settings.

2

Clears all settings memorized in <User1>,

<User2> and < User3>

A confirmation message appears. Press [Yes].

4 Finish the procedure.

A confirmation message appears. Press [Yes].

3 Finish the procedure.

49

EN_KW-AV70EU.indb 49EN_KW-AV70EU.indb 49 11/12/13 16:3911/12/13 16:39

Updating the system

Adjusting the touch position

You can update the system by connecting a USB device

You can adjust the touch position on the touch panel if

containing an update file.

the position touched and the operation performed do

not match.

1 Create an update file, copy it to a USB

ENGLISH

device, and connect it to the unit.

1 On <Settings> screen:

• To connect a USB device, ☞ page 27.

2 On <Settings> screen:

2 Touch the center of the marks at the

lower left and at the upper right as

instructed.

3

It may take a while.

If the update has been completed successfully,

• To cancel the current operation, press [Cancel].

“Update Completed” appears. Reset the unit.

• To reset to the initial setting, press [Reset].

• If the update has failed, turn the power off and then

on, and retry the update.

• Even if you have turned off the power during the

update, you can restart the update after the power

is turned on. The update will be performed from the

beginning.

50

EN_KW-AV70EU.indb 50EN_KW-AV70EU.indb 50 11/12/13 16:3911/12/13 16:39
