Avoid touching the drilled core that is automati-

cally ejected by the centering pin when the work-

ing procedure is finished.

Contact with the core

when it is hot, or if it falls, can cause personal

injuries.

Operate the power tool only from earthing contact

sockets that comply with the specifications. Do

not use any connection cables that are damaged;

use extension cables with an earthing contact that

are checked at regular intervals.

A earth conduc-

tor without continuity can cause an electric

shock.

Do not rivet or screw any name-plates or signs

onto the power tool.

If the insulation is damaged,

protection against an electric shock will be inef-

fective. Adhesive labels are recommended.

Wear personal protective equipment. Depending

on the application, use a face shield, safety gog-

gles or safety glasses. Wear ear protection.

The

safety glasses must be capable of protecting

against flying particles generated by the various

different operations. Prolonged exposure to

high intensity noise may cause loss of hearing.

Do not use accessories which are not specifically

designed and recommended by the power tool

manufacturer.

 Safe operation is not ensured

merely because an accessory fits your power

tool.

Clean the ventilation openings on the power tool at

regular intervals using non-metal tools.

 The

blower of the motor draws dust into the hous-

ing. An excessive accumulation of metallic dust

can cause an electrical hazard.

The guard protecting against chippings and acci-

dental contact must always be mounted during

operation.

 Hot, sharp chippings can cause per-

sonal injuries.

The motor must not be able to descend on its own

accord while the tool is inserted.

 If necessary,

tighten the hexagon nuts (790).

Before adjusting, pull the plug from the socket

and remove the cover (950). Please pay special

attention to the sensitive electronics underneath

the cover!

See exploded drawing.

At a glance.

The following numbering used for the

operating elements relates to the figures

at the beginning of this Instruction Manual.

1 Lever for setting the stroke range

For setting the variable stroke range of the

motor.

2 Motor switch

For starting and stopping the motor.

3 Capstan handle

For moving the drill motor up and down.

4 Depth scale

1 segment represents an upward or down-

ward movement of the drill motor of 1 mm.

5 Main switch

For switching the magnet ON and OFF.

6 Magnetic foot

For fastening the core drill to a magnetizable

base.

7 Guard protecting against chippings and acci-

dental contact

For preventing accidental contact with the

rotating parts.

Hook for locking (7a).

8 Slit for the clamping strap

Secure the core drill using the clamping

strap.

9 Coolant connection

For connecting to the coolant container

using the coolant hose.

10 Tool holder (Quick IN)

For clamping the tool.

11 Adapter for geared drill chuck with core drill

thread (M 18x6/P 1.5)

For clamping the twist drill and core drill bits.

12 Standard accessories

Adapter (M 18x6/P 1.5) (12b),

Geared drill chuck (1.5–13 mm) with drill-

chuck wrench (12c),

Long centering pin (119 mm) (12d),

Short centering pin (104 mm) (12e),

Chip hook (12f),

Clamping strap (12g),
