Beurer BY 99: ENGLISH

ENGLISH

Read these instructions for use carefully and

keep them for later use, be sure to make them

accessible to other users and observe the

information they contain.

Table of contents

1. Getting to know your device .......................21

9.3.2 Setting the notification sensitivity ........30

9.4 General settings .....................................31

2. Signs and symbols .......................................22

10. Operating the camera via the app ............31

3. Intended use .................................................22

10.1 Switching on the camera ......................31

4. Notes .............................................................22

10.2 Adding another camera ........................31

5. How the app works ......................................24

10.3 Removing a camera ..............................31

6. Unit description ............................................25

10.4 Account settings / signing out ..............32

6.1 “Baby” HD camera ...................................25

10.5 Infrared night vision function ................32

6.2 “Monitor” parent unit ...............................25

10.6 Functions during live transmission in

6.3 Display description ..................................26

the app .................................................32

7. Initial use of parent unit ...............................26

10.6.1 Intercom function ..............................32

7.1 Initial use of camera .................................26

10.6.2 Photo function / Video memory

7.2 Initial use of parent unit with battery ........26

function ..............................................32

7.3 Initial use of parent unit with mains part

10.6.3 Lullabies ............................................33

plug ..........................................................27

10.6.4 Temperature display ..........................33

8. Operating the parent unit ............................27

10.7 Using the camera for other end

8.1 Infrared night vision .................................27

devices .................................................33

8.2 Set the volume .........................................27

10.8 Access to the user account via the

8.3 Set the brightness ....................................27

web portal (PC) ....................................33

8.4 Intercom function .....................................27

11. Useful information about the baby

8.5 Settings menu .........................................27

monitor ..........................................................33

9. Initial use via smartphone/tablet ................30

12. Maintenance and cleaning ........................33

9.1 Setting up the camera using an

13. What if there are problems? ......................34

Android™ device .....................................30

14. Disposal ......................................................36

®

9.2 Setting up the camera on your iPhone

/

®

15. Technical data .............................................36

iPad

........................................................30

9.3 Camera settings .......................................30

9.3.1 Allocating a camera name / menu

image ....................................................30

Included in delivery

•

1x WLAN camera

•

2x mains part plugs

•

1x parent unit

•

1x lithium-ion battery for parent unit

•

1x these instructions for use

20

Dear customer,

Thank you for choosing one of our products. Our brand stands for well-engineered, quality made

products; driven by innovation and safety. Our product range encompasses a wealth of products

for health and well-being in the heat, gentle therapy, blood pressure/diagnosis, weight, massage,

beauty, air and babycare sectors. Read these instructions for use carefully and keep them for later

use, be sure to make them accessible to other users and observe the information they contain.

With kind regards,

Your Beurer team.

1. Getting to know your device

This Video Baby Monitor enables you to see your baby via your parent unit, smartphone or

tablet at all times whilst you pursue activities in other rooms or in the garden. It is also possible

to display the transmission image simultaneously on the parent unit and a mobile end device

(smartphone/tablet) (this requires a WLAN network, smartphone/tablet and the free Beurer

CareCam app powered by Hubble).

It is therefore possible to keep an eye on everything whenever and wherever.

The Video Baby Monitor is also suitable for caring for the elderly or for home surveillance.

Functions of the device

The device has the following functions:

•

Video surveillance

•

Infrared night vision function

•

ECO+ mode / energy-saving mode

•

Range control with acoustic signal

•

Range of up to 300 m with a clear view

•

Infrared night vision function

•

Temperature sensor

•

Microphone / loudspeaker

•

Wall-mounting fixture (camera)

Using the app provides you with the following functions:

•

Video monitoring via WLAN with the Beurer CareCam app powered by Hubble

•

Timeline function (events are displayed chronologically in the app)

•

Range control with acoustic signal

•

Push notifications for movements / noises / temperature

•

Intercom function

•

5 lullabies

System requirement (for using the app)

App:

®

- Android™ from version 4.0 / iOS

from version 6.0

Web portal:

®

- Windows

System, 7 or 8 (Java Version from 7)

®

- MacOS

version 10.7 or higher

21

®

- Internet Explorer

version 8.0 or higher

®

- Firefox

version 11.0 or higher

®

- Chrome

version 18.0 or higher

®

- Safari

version 5.1 or higher

Camera:

- 802.11 b/g/n (2.4 - 2.4835 GHz) WLAN

- Protected by at least WEP

2. Signs and symbols

The following symbols appear in these instructions for use:

WARNING

Warning instruction indicating a risk of injury or damage to health

IMPORTANT

Safety note indicating possible damage to the device/accessory

Note

Note on important information

3. Intended use

WARNING

•

Only use the Video Baby Monitor when you cannot mind your baby directly. It is not a sub-

stitute for your own personal, responsible supervision!

•

You can also use the Video Baby Monitor as a room monitor.

•

Improper use can be dangerous.

•

The Video Baby Monitor is only intended for domestic/private use, not for commercial use.

•

Respect the personal rights of others. All persons in the monitored room or who may

be in the monitored room should be informed that there is a camera filming the room.

4. Notes

WARNING

Safety notes

•

Always position the camera and power cord out of the reach of children. The power

cord may cause strangulation or injury to children.

•

Keep small parts out of reach of children.

•

Keep packaging material away from children (risk of suocation).

•

Never place the camera in the cot or within reach of your child.

22

•

Place the camera 2 m away from your baby, in order to minimise the possibility of electros-

mog pollution and noise pollution.

•

Make sure that cables are not accessible to your child.

•

Always make sure that the Video Baby Monitor is fully functioning before use and check

that the battery in the parent unit is suciently charged when operating the device with

the battery.

•

Never submerge the camera and the parent unit in water. Never rinse it in running water.

•

Never use the camera and the parent unit in proximity to moisture.

•

Do not cover the camera and the parent unit with a towel or cover.

•

Only use the mains part plugs included in delivery.

•

Do not use the cable to pull the mains part plug out of the socket.

•

This device may be used by children over the age of eight and by people with reduced

physical, sensory or mental skills or a lack of experience or knowledge, provided that they

are supervised or have been instructed on how to use the device safely, and are fully aware

of the consequent risks of use.

•

Children must not play with the device.

•

Cleaning and user maintenance must not be performed by children unless supervised.

•

Do not pull, twist or bend the mains cable.

•

Pull the mains part plug out in the case of operational faults before the cleaning process,

after charging and when the device is not in use.

•

The camera, the parent unit and the mains part plugs should not come into contact with hot

surfaces or sharp-edged objects.

•

Do not use any additional parts that are not recommended by the manufacturer or oered

as accessories.

Note

•

Before making a claim, please check the battery in the parent unit and replace it if necessary.

•

Repairs must only be carried out by Customer Services or authorised suppliers. Under no

circumstances should you open or repair the camera or parent unit yourself, as faultless

functionality could no longer be guaranteed thereafter. Failure to comply will result in void-

ing of the warranty.

•

If you should have any questions about using the Video Baby Monitor, please contact either

your retailer or Customer Services.

WARNING

Safety notes on handling batteries

•

If a battery has leaked, put on protective gloves and clean the battery compartment with

a dry cloth.

•

If your skin or eyes come into contact with fluid from the battery cell, flush out the aected

areas with water and seek medical assistance.

•

Risk of explosion! Never throw batteries into a fire.

•

Do not disassemble, split or crush the batteries.

23

•

Batteries must be charged correctly prior to use. The instructions from the manufacturer

and the specifications in these instructions for use regarding correct charging must be ob-

served at all times.

5. How the app works

BY 99

Smartphone, Tablet, PCWLAN-Router

24

Local

Internet

Note

If there is an active internet connection, the camera sends all recordings via the Hubble server.

This is of vital importance when setting up the camera. Not all functions are available if there

is no active internet connection (limited functionality)

.

•

You can increase the range of the camera by placing it as high as possible near a door or

a window.

•

Other radio waves may possibly interfere with the transmission of the baby monitor. There-

fore, do not position the baby monitor near devices such as microwaves, etc.

•

The following other factors can interfere with the baby monitor’s transmission or shorten its

range: furniture, walls, houses, trees, environmental factors (such as fog, rain).

Note

On the Hubble homepage (http://beurer.hubbleconnected.com), you can activate the record-

ing function at an additional charge. When the recording function is activated, events trig-

gered by movements are automatically recorded and saved onto the Hubble server so that

they can be viewed later.

6. Unit description

6.1 “Baby” HD camera

2

8

1

3

4

PAIR

5

6

7

1. Brightness sensor (night vision function) 5. ON/OFF button

2. Camera lens 6. Pair button

3. Function light 7. Connection for “Baby” mains part plug

4. Microphone 8. Temperature sensor

*Function light status

Function light lights up blue = Camera warm-up phase ~ 1 minute

Function light flashes red = Camera is not connected

Function light flashes red and blue = Camera is ready to connect

Function light flashes blue = Camera is connected

6.2 “Monitor” parent unit

1

1. LED sound level indicator

2. Bottom direction arrow / Reduce brightness

3. Right direction arrow / Increase volume

4. Intercom function

9

2

5. OK button

8

3

6. Menu button

7. ON/OFF button

7

4

8. Left direction arrow / Reduce volume

6

9. Top direction arrow / Increase brightness

5

25

Note

In doing so, all events on this camera are irrevocably deleted.

10.4 Account settings / signing out

In the account settings you can, amongst other things, change your password, view your app

version or log out.

1.

When you see the current transmission image, tap the Beurer CareCam logo on the top left.

You are taken to the camera menu.

2. Now tap “Account” on the top right.

3. In order to change your password, tap “Change password” and follow the instructions. If

you would like to log out of your account, tap “Log out” and confirm.

10.5 Infrared night vision function

To ensure that clear transmission images can be seen on the screen even when it is dark, the

camera automatically activates the infrared night vision function (black and white image display).

10.6 Functions during live transmission in the app

Note

When you tap the transmission image, the following

menu interface appears. After approx. 10seconds, the

menu interface disappears again.

These functions are only available in the app.

1 Intercom function 3 Lullabies

2 Photo function /

video memory function (Android only

™

)

4 Temperature display

10.6.1 Intercom function

1. T

ap the microphone symbol ( ) on the far left.

2.

The first time you do this, the message “Allow Beurer CareCam access to the microphone?”

appears. Tap “Yes”.

3. To activate the intercom function, tap the push-to-talk button. The words you have spoken

can now be heard on the camera. To deactivate the intercom function, tap the push-to-talk

button again.

10.6.2 Photo function / Video memory function

1. Tap the camera symbol ( ).

2.

To take a photo of the current transmission image, tap the camera button. The image is

saved in the image folder of your smartphone/tablet.

Note

If you have an Android™ end device, you can also record videos locally. To do this, tap the

video symbol (

).

32

10.6.3 Lullabies

You can activate one of five lullabies that will then be played over the camera:

1. Tap the note symbol (

).

2.

Tap to choose your required lullaby. The lullaby now plays on the camera. To deactivate

the lullaby, tap it again.

10.6.4 Temperature display

Tap the thermometer symbol ( ). The current ambient temperature of the camera appears.

When you tap again on the thermometer symbol (

), you can change the temperature dis-

play between °C and °F.

10.7 Using the camera for other end devices

To use the camera with other end devices, you must log in with the same username + pass-

word as your user account.

10.8 Access to the user account via the web portal (PC)

It is possible to access your user account via the web portal.

You will have received a link to the web portal automatically via e-mail after setting up the camera.

Note

The transmission image and the timeline can only be displayed via the web portal. Other func-

tions/settings options (such as the intercom function) are not available.

11. Useful information about the baby monitor

•

If you operate the parent unit with the battery, this minimises electrosmog from electrical

and magnetic alternating fields.

•

You can increase the range of the baby monitor by positioning the camera as high up as

possible near a door or window and ensuring that the battery is not too weak.

•

Other radio waves may possibly interfere with the transmission of the baby monitor. There-

fore, do not position the baby monitor near devices such as microwaves, WLAN, etc.

•

The following other factors can interfere with the baby monitor’s transmission or shorten its

range: furniture, walls, houses, trees, environmental factors (such as fog, rain).

12. Maintenance and cleaning

The service life of the camera and the parent unit depend on careful handling.

IMPORTANT

•

Remove the battery from the parent unit if the Video Baby Monitor is not in use for an ex-

tended period.

•

You will get the maximum capacity from your battery if you run down the battery at least

once every six months. To do this, disconnect the parent unit from the mains and run the

battery down through normal use. Then fully charge the battery up again.

33

•

The maximum battery capacity can only be reached after it has been charged several

times and is dependent on many factors (battery state, ambient temperature, means and

frequency of charging, etc.).

•

Protect the camera and the parent unit from knocks, damp, dust, chemicals, drastic changes

in temperature, electromagnetic fields and nearby sources of heat (ovens, heaters).

•

Clean the camera/parent unit with a soft, dry cloth. Do not use any abrasive cleaning prod-

ucts.

13. What if there are problems?

IMPORTANT Forgotten password

If you have forgotten your password, tap “Forgotten password” in the app and enter your e-

mail address. A new password will be sent to your e-mail address.

Problem Solution

The parent unit will not switch on. Check whether

•

the “Monitor” mains part plug is properly

plugged in,

•

the battery is correctly inserted,

•

the battery is full, needs charging or is damaged.

An acoustic signal sounds from the parent

Check whether

unit.

•

t

he maximum range has been exceeded,

•

t

he mains part plug for the camera (“Baby”) is

correctly connected,

•

t

he camera is switched on,

•

t

he parent unit’s battery needs charging.

The parent unit is switched on, but is not

To set your desired volume on the parent unit,

making any noise.

press the right or left direction arrows during op-

eration.

The parent unit switches itself o.

•

Recharge the parent unit’s battery.

•

It could be that the parent unit is in energy-

saving mode. Check whether the power-saving

mode has been selected in the menu and de-

activate it where necessary.

The signal is weak, the connection keeps

•

If another technical device such as a microwave

breaking up or there is interference.

is in the area between the camera and the parent

unit, remove the technical device or switch it o.

•

Check whether other factors, such as trees or

anything else, are in the area between the cam-

era and the parent unit, and change the posi-

tion of the devices until the parent unit signals

a connection.

•

Check whether the camera and parent unit are

inside the maximum receiving range.

34

Problem Solution

If no transmission is possible, you have the

1. Switch on the camera and parent unit.

option to retune the device signals digitally =

2. Delete the camera in the menu of the parent unit

pairing.

and then set up the camera again as described

in the “Add camera” section (see Chapter 8.5).

No connection can be established to the cam-

Switch your WLAN router o and back on again.

era.

Go through the registration again.

No connection can be made to the camera.

Check that the camera is within range of the WLAN

router. If the function light flashes, place the cam-

era closer to the WLAN router for better reception.

There is no alarm warning sound on the smart-

Check whether your alarm settings have been ac

-

phone/tablet.

tivated.

Videos cannot be recorded on the end device.

Videos can only be saved on Android™ devices.

I cannot log into my user account after reg-

Check that the user name and password are cor

-

istration.

rect.

I receive the error message “Your e-mail ID is

Make sure that you have registered with us. First

not registered”.

tap “Create user account”.

What should I do if I have forgotten my pass

-

In the app tap “Forgotten password” and enter your

word?

e-mail address. A new password will be sent to

your e-mail address.

I have not received an e-mail, even though I

•

The e-mail may be in the spam folder of your

have used the “Forgotten password” function.

e-mail account. Check the spam folder for the

e-mail.

•

The e-mail may not have arrived yet. Check your

e-mail account again after a few minutes.

If I try to add a new camera to my user ac-

Press the “PAIR” button on the camera for 5 sec

-

count, no available cameras appear.

onds and try again.

During the set-up process, no camera ap-

Switch the camera o and back on again. Press

pears in the last step. The set-up process is

the “PAIR” button until there is a beep. Wait for a

interrupted.

minute until the indicator lamp flashes. The cam

-

era is now ready for the set-up process. Start the

set-up process for the camera again.

If I try to view the transmission image, I re-

Conduct a Firmware update. We update the app

ceive the message that I should update my

from time to time to constantly improve the cam-

Firmware.

era function.

35

14. Disposal

Batteries must be disposed of through specially designated collection boxes, recycling points

or electronics retailers. You are legally required to dispose of the batteries.

For environmental reasons, do not dispose of the device in the household waste

at the end of its useful life.

Dispose of the unit at a suitable local collection or recycling point. Dispose of the

device in accordance with EC Directive – WEEE (Waste Electrical and Electronic

Equipment).

If you have any questions, please contact the local authorities responsible for waste disposal.

15. Technical data

•

23 channels

•

Frequency 2.4 - 2.483 GHz

•

Digital receiver

•

2.4" TFT display

•

Infrared technology

•

ECO mode (parent unit)

•

Camera dimensions: 9 x 6.5 x 5.8 cm

Parent unit dimensions: 11.5 x 6.9 x 2.4 cm

•

Weight: camera 95 g; parent unit 80 g; battery 38 g

•

Range up to 300 m with a clear view

Operation Mains parts provided:

Parent unit (5V USB/600mA)

HD camera (5V USB/1000mA)

Li-Ion battery (2100 mA)

Battery life (dependent on bat-

Parent unit: 12 hours

tery state, ambient temperature,

means and frequency of charg-

ing, etc.)

We hereby guarantee that this product complies with the European R&TTE Directive 1999/5/

EC. Please contact the specified service address to obtain further information, such as the

CE Declaration of Conformity.

36
