51
GB
Additional Information
FM tuner section
Tuning range
87.5 - 108.0 MHz
Antenna terminals
75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/
75 ohms
Stereo: 38.3 dBf, 22.5
µV/75 ohms
Usable sensitivity
11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation
45 dB at 1 kHz
Frequency response
30 Hz - 15 kHz +0.5/–2
dB
Selectivity
60 dB at 400 kHz
AM tuner section
Tuning range
531 - 1602 kHz
Antenna
Loop antenna
Usable sensitivity
50 dB/m (at 999 kHz)
S/N
54 dB (at 50 mV/m)
Harmonic distortion
0.5 % (50 mV/m, 400
kHz)
Selectivity
At 9 kHz: 35 dB
Video section
Inputs
Video: 1 Vp-p 75 ohms
S-video*:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
Outputs
Video: 1 Vp-p 75 ohms
S-video*:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
* STR-DE545 and STR-SE501 only.
General
System
Tuner section:
PLL quartz-locked
digital synthesizer
system
Preamplifier section:
Low-noise NF type
equalizer
Power amplifier section:
Pure-complementary
SEPP
Power requirements
230 V AC, 50/60 Hz
Power consumption
STR-DE545/SE501:
220 W
STR-DE445: 160 W
AC outlets (STR-DE545 and STR-SE501
only)
1 switched, max 100 W
Dimensions
430
×
303
×
157 mm
including projecting
parts and controls
Mass (Approx.)
STR-DE545: 7.9 kg
STR-DE445: 7.7 kg
STR-SE501: 8.2 kg
Supplied accessories
See page 4.
Design and specifications are subject to
change without notice.
