Sony CPD-E215E: instruction

4-080-479-13 (1)

â

Trinitron Color

Computer Display

GB

Operating Instructions

FR

Mode d’emploi

DE

Bedienungsanleitung

ES

Manual de instrucciones

IT

Istruzioni per l’uso

RU

Инструкция по эксплуатации

SESE

Bruksanvisning

NL

Gebruiksaanwijzing

CPD-E215E

© 2000 Sony Corporation

Owner’s Record

NOTICE

This notice is applicable for USA/Canada only.

The model and serial numbers are located at the rear of the unit.

If shipped to USA/Canada, install only a UL LISTED/CSA

Record these numbers in the spaces provided below. Refer to them

LABELLED power supply cord meeting the following

whenever you call upon your dealer regarding this product.

specifications:

Model No.

Serial No.

SPECIFICATIONS

Plug Type Nema-Plug 5-15p

Cord Type SVT or SJT, minimum 3

× 18 AWG

WARNING

Length Maximum 15 feet

Rating Minimum 7 A, 125 V

To prevent fire or shock hazard, do not expose the

unit to rain or moisture.

NOTICE

Cette notice s’applique aux Etats-Unis et au Canada

Dangerously high voltages are present inside the

uniquement.

unit. Do not open the cabinet. Refer servicing to

Si cet appareil est export* aux Etats-Unis ou au Canada, utiliser

le cordon d’alimentation portant la mention UL LISTED/CSA

qualified personnel only.

LABELLED et remplissant les conditions suivantes:

FCC Notice

SPECIFICATIONS

This equipment has been tested and found to comply with the limits

Type de fiche Fiche Nema 5-15 broches

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

Cordon Type SVT ou SJT, minimum 3

× 18 AWG

These limits are designed to provide reasonable protection against

Longueur Maximum 15 pieds

harmful interference in a residential installation. This equipment

Tension Minimum 7 A, 125 V

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

As an

ENERGY STAR Partner, Sony

– Reorient or relocate the receiving antenna.

Corporation has determined that this

– Increase the separation between the equipment and receiver.

product meets the

ENERGY STAR

– Connect the equipment into an outlet on a circuit different from

guidelines for energy efficiency.

that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly

approved in this manual could void your authority to operate this

equipment.

EN 55022 Compliance (Czech Republic Only)

This monitor complies with the

This device belongs to category B devices as described in EN

TCO’99 guidelines.

55022, unless it is specifically stated that it is a category A

device on the specification label. The following applies to

devices in category A of EN 55022 (radius of protection up to

30 meters). The user of the device is obliged to take all steps

necessary to remove sources of interference to

telecommunication or other devices.

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669)

or write to:

Sony Customer Information Center

1 Sony Drive, Mail Drop #T1-11, Park Ridge, NJ 07656

Declaration of Conformity

INFORMATION

This product complies with Swedish National Council for Metrology

Trade Name: SONY

(MPR) standards issued in December 1990 (MPR II) for very low

Model No.: CPD-E215E

frequency (VLF) and extremely low frequency (ELF).

Responsible Party: Sony Electronics Inc.

INFORMATION

Address: 1 Sony Drive, Park Ridge, NJ 07656 USA

Ce produit est conforme aux normes du Swedish National Council

Telephone No.: 201-930-6972

for Metrology de décembre 1990 (MPR II) en ce qui concerne les

fréquences très basses (VLF) et extrêmement basses (ELF).

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

INFORMACIÓN

cause harmful interference, and (2) this device must accept any

Este producto cumple las normas del Consejo Nacional Sueco para

interference received, including interference that may cause

Metrología (MPR) emitidas en diciembre de 1990 (MPR II) para

undesired operation.

frecuencias muy bajas (VLF) y frecuencias extremadamente bajas (ELF).

2

Table of Contents

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Identifying parts and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Step 1:

Connect your monitor to your computer . . . . . . . . . . . . . . . 6

Step 2:

Connect the power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Step 3:

Turn on the monitor and computer . . . . . . . . . . . . . . . . . . . 7

Selecting the on-screen menu language (LANGUAGE/

INFORMATION) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Customizing Your Monitor . . . . . . . . . . . . . . . . . . . . . . . .8

Navigating the menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Adjusting the brightness and contrast. . . . . . . . . . . . . . . . . . . . . . . . 9

Adjusting the centering of the picture (CENTER). . . . . . . . . . . . . . . 9

Adjusting the size of the picture (SIZE) . . . . . . . . . . . . . . . . . . . . . . 9

Enlarging or reducing the picture (ZOOM) . . . . . . . . . . . . . . . . . . . 10

Adjusting the shape of the picture (GEOMETRY) . . . . . . . . . . . . . 10

GB

Adjusting the color of the picture (COLOR) . . . . . . . . . . . . . . . . . . 10

Additional settings (SCREEN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Resetting the adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Technical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Preset and user modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Power saving function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

If thin lines appear on your screen (damper wires). . . . . . . . . . . . . 12

On-screen messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12



• Trinitron

is a registered trademark of

Trouble symptoms and remedies . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Sony Corporation.

• Macintosh is a trademark licensed to

Self-diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Apple Computer, Inc., registered in the

U.S.A. and other countries.



• Windows

and MS-DOS are registered

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

trademarks of Microsoft Corporation in

the United States and other countries.

• IBM PC/AT and VGA are registered

Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

trademarks of IBM Corporation of the

U.S.A.

Preset mode timing table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i



• VESA and DDC

are trademarks of the

TCO’99 Eco-document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

Video Electronics Standard

Association.

•

E

NERGY

S

TAR is a U.S. registered

mark.

• All other product names mentioned

herein may be the trademarks or

registered trademarks of their respective

companies.

• Furthermore, “



” and “



” are not

mentioned in each case in this manual.

3

Use of the tilt-swivel

Precautions

This monitor can be adjusted within the angles shown below. To

find the center of the monitor’s turning radius, align the center of

Warning on power connections

the monitor’s screen with the centering dots on the stand.

• Use the supplied power cord. If you use a different power cord,

Hold the monitor at the bottom with both hands when you turn it

be sure that it is compatible with your local power supply.

horizontally or vertically. Be careful not to pinch your fingers at

For the customers in the UK

the back of the monitor when you tilt the monitor up vertically.

If you use the monitor in the UK, be sure to use the supplied UK

power cable.

Example of plug types

for 100 to 120 V AC for 200 to 240 V AC for 240 V AC only

• Before disconnecting the power cord, wait at least 30 seconds

after turning off the power to allow the static electricity on the

screen’s surface to discharge.

• After the power is turned on, the screen is demagnetized

(degaussed) for about 5 seconds. This generates a strong

magnetic field around the screen which may affect data stored

on magnetic tapes and disks placed near the monitor. Be sure to

keep magnetic recording equipment, tapes, and disks away

from the monitor.

The equipment should be installed near an easily accessible

outlet.

Installation

Do not install the monitor in the following places:

• on surfaces (rugs, blankets, etc.) or near materials (curtains,

draperies, etc.) that may block the ventilation holes

• near heat sources such as radiators or air ducts, or in a place

subject to direct sunlight

• in a place subject to severe temperature changes

• in a place subject to mechanical vibration or shock

• on an unstable surface

• near equipment which generates magnetism, such as a

transformer or high voltage power lines

• near or on an electrically charged metal surface

Maintenance

• Clean the screen with a soft cloth. If you use a glass cleaning

liquid, do not use any type of cleaner containing an anti-static

solution or similar additive as this may scratch the screen’s

coating.

• Do not rub, touch, or tap the surface of the screen with sharp or

abrasive items such as a ballpoint pen or screwdriver. This type

of contact may result in a scratched picture tube.

• Clean the cabinet, panel and controls with a soft cloth lightly

moistened with a mild detergent solution. Do not use any type

of abrasive pad, scouring powder or solvent, such as alcohol or

benzene.

Transportation

When you transport this monitor for repair or shipment, use the

original carton and packing materials.

4

Identifying parts and controls

See the pages in parentheses for further details.

RearFront

MENU

RESET

AC IN

MENU

RESET

1 RESET button (page 11)

4 AC IN connector (page 6)

This button resets the adjustments to the factory settings.

This connector provides AC power to the monitor.

2 Control button (page 9)

5 Video input connector (HD15) (page 6)

The control button is used to display the menu and make

This connector inputs RGB video signals (0.700 Vp-p,

GB

adjustments to the monitor, including brightness and contrast

positive) and sync signals.

adjustments.

3 ! (power) switch and indicator (pages 7, 12, 15)

This button turns the monitor on and off. The power indicator

lights up in green when the monitor is turned on, and either

flashes in green and orange, or lights up in orange when the

monitor is in power saving mode.

Pin No. Signal

1Red

2 Green

3Blue

4 ID (Ground)

5 DDC Ground*

6 Red Ground

7 Green Ground

8 Blue Ground

9 DDC + 5V*

10 Ground

11 ID (Ground)

12 Bi-Directional Data (SDA)*

13 H. Sync

14 V. Sync

15 Data Clock (SCL)*

* DDC (Display Data Channel) is a standard of VESA.

5
