Sony Grand Wega KF-50SX100K: instruction

4-078-836-31(1)

R

GB

Instruction Manual

CZ

Návod k obsluze

PL

Instrukcja obsługi

HU

Kezelési útmutató

RU

Инструкция пo эксплyатации

BG

Инструкции за експлоатация

KF-50SX100K

©2000 by Sony Corporation

Introduction

Thank you for choosing this Sony “Grand Wega” model.

Before operating the set, please read this manual thoroughly and retain it for future reference.

• Symbols used in the manual:

MENU

• Informs you of possible hazards.

• Shaded buttons on the remote control show the

K

• Important information.

buttons you have to press to follow the sequence

of instructions.

• Information on a feature.

• 1,2... Sequence of instructions.

• Informs you of the result of the instructions.

Safety Information

All TV’s operate on extremely high voltages. To prevent fire or electric shock, please follow the safety guidelines indicated in the

blue sheet supplied.

•

When moving the set two persons are needed. DO NOT push speaker nets placed on the both side of the screen to prevent

these parts from deformation and do not grasp the front panels to prevent these parts from breaking off. Support screen

bottom with one hand while grasping the top part with the other hand.

•Do not block or cover the ventilation opening placed on the left bottom rear side of the set. For ventilation, leave a space of at least

10 cm from the wall.

•After transporting the set directly from a cold to a warm location, or if the room temperature has changed suddenly, pictures may

be blurred or show poor colour over portions of the picture. This is because moisture has condensed on the mirrors or lenses inside

the set. Let the moisture evaporate before using the set.

•To obtain a clear picture, do not expose the screen to direct illumination or direct sunlight. If possible, use spot lighting directed

down from the ceiling.

•The screen of this set has an anti-reflection screen coating. To avoid screen degradation, follow the mentioned below:

•To remove dust from the screen surface, wipe with the suplied cleaning cloth or a soft cloth.

•Clean the screen and cabinet with a soft dampened cloth. Do not use any abrasive cleaners. As a safety precaution, unplug the

set before cleaning it.

•Avoid touching the screen, and take care not to scratch the surface with hard objects.

Table of Contents

GB

Introduction ...................................................................................................................................................................................................................... 3

Safety Information............................................................................................................................................................................................................ 3

Overview

Checking the Accessories Supplied.................................................................................................................................................................. 4

Overview of TV Buttons .................................................................................................................................................................................... 4

Overview of Remote Control Buttons.............................................................................................................................................................. 5

Installation

Inserting Batteries into the Remote Control.................................................................................................................................................... 6

Connecting the Aerial and VCR ....................................................................................................................................................................... 6

Stabilizing the set................................................................................................................................................................................................ 6

First Time Operation

Switching on the set and Automatically Tuning............................................................................................................................................ 7

Menu System

Changing the Screen Format............................................................................................................................................................................. 9

Introducing the Menu System........................................................................................................................................................................... 9

On Screen display Menus Guide.................................................................................................................................................................... 10

Using the Menu System:

Adjusting the Picture..................................................................................................................................................................................... 11

Adjusting the Sound...................................................................................................................................................................................... 12

Using the Features menu............................................................................................................................................................................... 14

Manually Tuning the TV............................................................................................................................................................................... 15

Labelling a channel ........................................................................................................................................................................................ 16

Skipping programme positions.................................................................................................................................................................... 17

Using the “Further Programme Preset” function...................................................................................................................................... 18

Inputting your personal ID........................................................................................................................................................................... 19

Using the Demo Mode................................................................................................................................................................................... 20

Adjusting the H Centre picture for an RGB source................................................................................................................................... 21

Labelling and Selecting the screen format of Input Sources.................................................................................................................... 22

Using Multi PIP (Picture In Picture)............................................................................................................................................................ 23

Using PAP (Picture And Picture)................................................................................................................................................................. 23

Teletext...................................................................................................................................................................................................................... 24

NexTView................................................................................................................................................................................................................. 26

Optional Connections

Connecting Optional Equipment.................................................................................................................................................................... 28

Using Optional Equipment.............................................................................................................................................................................. 29

Smartlink............................................................................................................................................................................................................ 30

Remote Control of other Sony Equipment.................................................................................................................................................... 30

Additional Information

Optimum Viewing Area .................................................................................................................................................................................. 31

Replacing the Lamp.......................................................................................................................................................................................... 32

Specifications..................................................................................................................................................................................................... 33

Troubleshooting................................................................................................................................................................................................ 34

3

Overview

Checking the Accessories Supplied

Two batteries (R6 type)

One Remote Control

(RM-903)

Overview of TV Buttons

Lamp

indicator (see

page 32)

On/Off

Switch

Standby indicator:

(conectores lado izquierdo)

• By pressing the

switch off button of

the Remote Control,

standby indicator

lights up in red

colour.

• By pressing the main

switch off on the set,

the standby indicator

Headphone

lights up in amber

jack

colour.

S Video

Input jack

Video Input

jack

Volume control

Programme up

Audio Input

Selecting

buttons

or down buttons

jacks

input source

(selects TV channels)

4

s

1 Wrench2 Brackets

2 Screws

1 Cleaning cloth

Overview

Overview

Overview of Remote Control Buttons

Resetting to factory set levels

Press not only to return picture and sound

settings to factory-set levels, but also to re-

install the set as the first time it was switched

on.

After the "Language/Country" menu

Displaying the time

appeared on the screen, proceed in the same

Press to switch the time on or off

way as described in the section "Switching on

VIDEO TV

(available only when teletext is

the set and automatically Tuning" of this

broadcast).

instruction manual.

VCR operation

VT

R 1 2 3 4 DVD

For more details, please refer to the

section "Remote Control of other

CH

Sony Equipment".

VCR on/off

Press to switch your VCR on or off.

Muting the Sound

Press to mute TV sound.

To Temporarily Switch Off

Press again to restore the sound.

VIDEO TV

Press to temporarily switch off TV (the standby

indicator

on the set lights up in red). Press

Selecting TV mode

again to switch on TV from standby mode.

GB

Press to switch off Teletext or video input.

After 15-30 minutes without a signal and

without any button being pressed, the set

switches automatically into standby mode.

PAP (Picture And Picture)

For more details, please refer to the section

Displaying On Screen Information

"Using PAP (Picture And Picture)".

Press to display all on-screen indications.

Press again to cancel.

Selecting Teletext

Selecting Input source

Press to switch on Teletext.

Press repeatedly until the desired input symbol of

1

2

3

the source appears on the screen.

Displaying EPG

Press to display the Electronic Programme

4

5

6

Back to the channel last watched

Guide (EPG). Press again to switch off EPG.

Press to watch the last channel selected (watched for

7

8

9

at least 5 seconds).

Freezing the picture

Selecting Screen format

0

Press to freeze the picture. Press again to

Press repeteadly to change the format of the screen

return to the normal picture.

(for more details, please refer to the section

“Changing the Screen format”).

Selecting channels

Displaying Multi PIP (Picture In Picture)

Press to select channels.

K

Press to display Multi PIP mode. Press again to

cancel.

For double-digit programme numbers, e.g.

23, press -/-- first, then the buttons 2 and 3.

PROGR

Joystick for menu selection

If you enter an incorrect first digit, this

• When MENU is switched on:

MENU

should be corrected by entering another digit

4 Scroll Up

$ Scroll Down

(0-9) and then selecting -/-- button again to

Z Previous menu or selection

enter the programme number of your choice.

z Next menu or selection

RM

903

OK Confirms your selection

Selecting Sound mode

• When MENU is switched off:

Press repeatedly to change the sound mode.

Z Return to the last menu screen.

S

OK Shows a channel overview

Selecting Picture mode

Press repeatedly to change the picture mode.

Selecting channels

Press to select the next or previous channel.

Adjusting TV Volume

Displaying the menu system

Press to adjust the volume of the TV.

Press to display the menu on the screen. Press again

to remove the menu display from the screen.

Besides TV functions, all coloured buttons as well as green

symbols are also used for Teletext operation. For more details,

please refer to the "Teletext" section of this instruction manual.

Overview

5

Installation

Inserting Batteries into the Remote Control

Make sure you insert the batteries using the correct

polarities.

Always remember to dispose of used batteries in an

environmental friendly way.

Connecting the Aerial and VCR

Connecting cables are not supplied.

or

VCR

6

OUT IN

Stabilizing the set the set

After setting up, secure the set to a wall, etc., with the supplied brackets, for safety purposes.

1 Mount the two supplied brackets with the screws to the upper rear side of the set.

Do not block or cover this ventilation opening. For

ventilation, leave a space of at least 10 cm from the wall.

2 Pass a strong cord or a chain through each bracket mounted in 1, and then secure to a wall or a pillar, etc.

Installation

First Time Operation

Switching on the set and Automatically Tuning

The first time you switch on your TV, a sequence of menu screen appear on the TV enabling you to 1) choose the language

of the menu screen, 2) choose the country in which you wish to operate the set, 3) search and stores all

available channels (TV Broadcast) and 4) change the order in which the channels (TV Broadcast) appear on the screen.

However, if you need to change the language menu, change the country, change or repeat the tuning (e.g. when you move

house) or rearrange again the order of the channels afterwards, you can do that by selecting the appropriate menu in

the (Set Up)

.

1 Connect the set plug to the mains socket (220-240V AC, 50 Hz). Press

the

on/off button on your set to switch on. The first time you press

this button the Language/Country menu displays automatically on

the screen.

2 Push the joystick on the remote control to $ or 4 to select the

language, then press OK to confirm your selection. From now on all

the menus will appear in the selected language.

GB

3 Push the joystick to $ or 4 to select the country in which you will

operate the set, then press OK to confirm your selection.

Select "Off" instead of a country if you do not want your

channels (TV Broadcasts) stored in a given channel sequence

starting from programme position 1.

4 The Auto Tuning menu appears on the screen in the selected

language, then press the OK button on the remote control to select

Yes.

5 A new menu appears automatically on the screen asking you to

check that the aerial is connected. Confirm that the aerial is connected

and then press the OK button to start the automatic tuning.

• The TV starts to automatically search and store all available

channels (TV Broadcast) for you.

• If you have selected “Off” option in the Country menu and

you make a new autotuning afterwards, the TV Broadcasts

will be stored from the selected programme number.

This procedure could take some minutes. Please, be patient and

do not press any button. Otherwise the automatic tuning will

not be completed.

continued...

First Time Operation

7

Language/Country

4 Italiano

Français

Español

English

Deutsch

Language

Dansk

Country

Čeština

Select Language: Confirm: OK

Language/Country

4

Finland

Denmark

Czech Rep.

Bulgaria

Language

Belgium

Austria

Country

Off

Select Country:

Confirm: OK

V

I

D

E

O

TV

Do you want to start

automatic tuning?

Yes: OK No:

Please confirm that

aerial is connected!

1

2

3

Yes: OK No:

4

5

6

7

8

9

0

1

CO2

2

CO3

3

CO4

4

CO7

5

CO8

Searching...

PROGR

MENU

RM

903

S

First Time Operation

6 After all available channels are captured and stored, the

V

I

D

E

O

TV

Programme Sorting menu appears automatically on the screen

enabling you to change the order in which the channels appear

on the screen.

a) If you do not wish to change the channel order, go to step 7.

Programme Sorting

b) If you wish to change the channel order:

PROG CH LABEL

1

C03

TV 5

1Push the joystick on the remote control to $ or 4 to select the

2

C05

PRO 7

3

C07

EU-SP

4

C08

SWF

5

C09

RTL

programme number with the channel (TV Broadcast) you wish to

6

C11

SAT

7

C12

MDR

8

C13

DDI

rearrange, then push to z.

9

C14

DSF

10

C15

RTL 2

11

C16

KAB 1

1

2

3

Select Prog: Confirm:

2 Push the joystick to $ or 4 to select the new programme number

4

5

6

position for your selected channel (TV Broadcast), then press OK.

7

8

9

Programme Sorting

PROG CH LABEL

The selected channel now moves to its new programme

1

C03

TV 5

C03 TV 5

2

C05

PRO 7

3

C07

EU-SP

0

position and the other channels move accordingly.

4

C08

SWF

5

C09

RTL

6

C11

SAT

7

C12

MDR

8

C13

DDI

9

C14

DSF

10

C15

RTL 2

3Repeat steps b1) and b2) if you wish to change the order of the

11

C16

KAB 1

Select Position: Move: OK

other channels.

7 Press the MENU button to exit and return to the normal TV screen.

PROGR

MENU

The set is now ready for use.

RM

903

S

8

First Time Operation

First Time Operation - Menu System

Changing the Screen Format

This feature allows you to change the size of the TV picture.

1 Press the button on the remote control repeatedly to select one

of the following formats.

Smart: imitation of wide screen effect for 4:3 broadcast.

4:3: conventional 4:3 picture size, full picture information.

14:9: compromise between 4:3 and 16:9 picture size.

Zoom: widescreen format for letterbox movies.

Wide: for 16:9 broadcast.

In Smart, Zoom and 14:9 modes parts of the top and bottom of the

screen are cut off. Press $ or 4 to adjust the position of the image on

screen (eg to read subtitles).

2 Press the OK button to confirm your selection.

GB

Introducing the Menu system

Your set uses an on-screen menu system to guide you through the operations. Use the following buttons on the

Remote Control to operate the menu system:

1 Press the MENU button to switch the first level menu on.

2 •To higlight the desired menu or option, push the joystick to

4 or $.

•To enter to the selected menu or option, push to z

•To return to the last menu or option, push to Z.

push to $/4/Z or z

•To alter settings of your selected option, push to $/4/Z or z.

•To confirm and store your selection, press OK.

OK

press OK

3 Press the MENU button to remove the menu from the screen.

9

V

I

D

E

O

TV

1

2

3

4

5

6

7

8

9

0

PROGR

MENU

RM

903

S

First Time Operation - Menu System

V

I

D

E

O

TV

1

2

3

4

5

6

7

8

9

0

PROGR

MENU

RM

903

S

Menu System

On Screen display Menus Guide

Picture Adjustment

Picture Adjustment

Picture Mode

Personal

Picture Mode

Personal

Contrast

Contrast

Brightness

Brightness

Colour

Colour

Sharpness

Refer to the section

Sharpness

Reset

Reset

AI

On

AI

On

"Adjusting the Picture”

Noise Reduction

Off

Noise Reduction

Off

Colour Tone

Normal

Colour Tone

Normal

Select: Enter Menu:

Select: Enter:

Audio Adjustment

Audio Adjustment

Equaliser Mode

Personal

Equaliser Mode

Personal

Equaliser

Equaliser

Adjustment

0

.

Adjustment

Balance

0

.

Loudness

Off

Balance

Off

Space

Off

Loudness

Refer to the section

Auto Vol. Control

Off

Space

Off

Dual Sound

0

Mono

Auto Vol. Control

Off

"Adjusting the Sound”

Volume

Dual Sound

0

Mono

Dual Sound

0

Mono

Volume

Mono

Select: Enter Menu:

Dual Sound

0

Select: Enter:

Features

Features

Speaker

Main

Speaker

Main

Normal

Refer to the section

Auto Format

Normal

Auto Format

Format Correction

On

Format Correction

On

Sleep Timer

Off

Off

"Using the features

Sleep Timer

Parental Lock

Off

Parental Lock

Off

AV2 Output

AV2 Output

TV

menu”

TV

Select: Enter Menu:

Select: Enter:

Set Up

Set Up

Set Up

Set Up

Auto Tuning

Auto Tuning

Auto Tuning

Auto Tuning

Start

Do you want to start

Refer to the section

Programme Sorting

Programme Sorting

Programme Sorting

Programme Sorting

Select NexTView

Select NexTView

Select NexTView

- - - - - - -

Select NexTView

- - - - - - -

automatic tuning?

"Switching on the set

AV Preset

AV Preset

AV Preset

AV Preset

Manual Set Up

Manual Set Up

Manual Set Up

Manual Set Up

and Automatically

Yes: OK No:

Tuning"

Select:

Select:

Select:

Enter Menu:

Enter Menu:

Enter Menu:

Select:

Start Auto Tuning

Set Up

Programme Sorting

PROG CH LABEL

Auto Tuning

1

Programme Sorting

2

C03

C05

TV 5

PRO 7

Refer to the section

Select NexTView

- - - - - - -

3

4

C07

EU-SP

AV Preset

5

C08

C09

SWF

6

C11

RTL

SAT

"Switching on the set

Manual Set Up

7

8

C12

MDR

9

C13

and Automatically

10

C14

DDI

11

C15

DSF

C16

RTL 2

KAB 1

Select:

Enter:

Tuning"

Select Prog: Confirm:

Set Up

Auto Tuning

Programme Sorting

Select NexTView

- - - - - - -

Refer to the

AV Preset

Manual Set Up

section

“NexTView”

Select:

Enter:

Manual Set Up

Language/Country

Manual Programme Preset

Refer to the section

Further Programme Preset

Set Up

Refer to the

RGB Set Up

- - - - - - -

"Switching on the set

Personal ID

Auto Tuning

section

Demo

Programme Sorting

and Automatically

Select NexTView

- - - - - - -

"Labelling and

Tuning"

AV Preset

Manual Set Up

Select: Enter:

selecting the

Select:

Enter:

screen format

Manual Set Up

of Input

Language/Country

Refer to the sections

Sources”

Manual Programme Preset

Further Programme Preset

"Manually Tuning the

Set Up

RGB Set Up

Auto Tuning

Personal ID

- - - - - - -

TV", "Labelling a

Programme Sorting

Demo

channel" and "Skipping

Select NexTView

- - - - - - -

AV Preset

programme positions"

Manual Set Up

Select: Enter:

Select:

Enter:

Manual Set Up

Language/Country

Manual Programme Preset

Refer to the section

Further Programme Preset

RGB Set Up

"Using the Further

Personal ID

- - - - - - -

Demo

Programme Preset

function"

Select: Enter:

Manual Set Up

Language/Country

Manual Programme Preset

Further Programme Preset

Refer to the section

RGB Set Up

Personal ID

- - - - - - -

"Adjusting the H centre

Demo

picture for an RGB

source"

Select: Enter:

Manual Set Up

Language/Country

Manual Programme Preset

Further Programme Preset

RGB Set Up

Refer to the section

Personal ID

- - - - - - -

Demo

"Inputting your

personal ID"

Select: Enter:

Teletext

Manual Set Up

Language/Country

Top / Bottom / Full

Manual Programme Preset

Refer to the section

Text Clear

Further Programme Preset

Reveal

Refer to the

RGB Set Up

"Using the Demo

Time Page

Personal ID

- - - - - - -

section "Teletext"

Demo Start

Page Overview

Mode"

Select: Enter:

Select: Enter:

10

Menu System

Menu System

Skipping Programme positions

You can programme this set to skip any unwanted programme numbers when they are selected with the PROGR +/-

buttons. To cancel this function afterwards, proceed in the same way as described below by selecting Off instead of On in step 6.

1 Press the MENU button on the remote control to display the menu

V

I

D

E

O

TV

on the screen.

2 Push the joystick to $ to select the symbol, then push to z to

enter the Set Up menu.

1

2

3

4

5

6

3 Push the joystick to $ or 4 to select Manual Set Up, then push

7

8

9

to z.

0

GB

4 Push the joystick to $ or 4 to select Manual Programme Preset,

then push to z.

PROGR

MENU

5 Push the joystick to $ or 4 to select the programme position you

want to skip, then push to z to enter the SKIP column.

RM

903

S

6 Push the joystick to $ to select On, then press the OK button to

store.

7 Repeat steps 5 and 6 to skip other unused programme positions.

8 Press the MENU button to exit and return to the normal TV screen.

When changing channels (TV Broadcasts) with the PROGR +/- buttons,

the skipped programme positions do not appear. You can, however, still

select them using the number buttons.

Menu System

17

Manual Programme Preset

PROG CHSYSSKIP LABEL

1

Off

B/G

C09

ARD

2

Off

B/G

C10

BBC

3

Off

4

Off

5

Off

6

Off

7

Off

8

Off

9

Off

10

Off

11

Off

Select: Enter:

Menu System

Using the "Further Programme Preset" function

With this feature you can:

a) Individually attenuate the strength of a channel signal in case of a strong local aerial signal (striped picture).

b) Individually adjust the volume level of each channel.

c) Even normally the automatic fine tuning (AFT) is operating, however you can manually fine-tune the TV to obtain a better picture

reception if the picture is distorted.

d) Preset the AV output for the programme positions of channels with scrambled signals (eg from a pay TV decoder). In this way

a connected VCR records the unscrambled signal.

Picture Adjustment

1 Press the MENU button on the remote control to display the menu

Picture Mode

Personal

V

I

D

E

O

TV

on the screen.

Contrast

Brightness

Colour

Sharpness

Reset

AI

2 Push the joystick to $ to select the symbol, then push to z to

On

Noise Reduction

Off

Colour Tone

Normal

enter the Set Up menu.

Select: Enter Menu:

Set Up

3 Push the joystick to $ or 4 to select Manual Set Up then push to z

Auto Tuning

Start

Programme Sorting

to enter.

Select NexTView

- - - - - - -

AV Preset

Manual Set Up

1

2

3

4 Push the joystick to $ or 4 to select Further Programme Preset,

Select:

Start Auto Tuning

then push to z.

4

5

6

Set Up

Auto Tuning

Programme Sorting

7

8

9

Select NexTView

- - - - - - -

5 Push the joystick to $ or 4 to select the relevant programme

AV Preset

Manual Set Up

0

number, then push to z repeatedly to select:

Select:

Enter:

a) ATT (RF attenuator)

Manual Set Up

b) VOL (Volume Offset)

Language/Country

Manual Programme Preset

c) AFT (Automatic Fine Tuning) or

Further Programme Preset

RGB Set Up

Personal ID

- - - - - - -

d) DECODER

Demo

PROGR

The selected item changes colour.

Select: Enter:

MENU

Further Programme Preset

6 a) ATT

PROG AFTVOLATT DECODER

1

Off

0

On

Off

2

Off

0

On

Off

Push the joystick to $ to select On, then press the OK button.

3

Off

0

On

Off

4

5

6

7

RM

903

Repeat steps 5 and 6 a) to attenuate other channels.

8

9

10

11

b) VOL

Select: Enter:

S

Push the joystick to $ or 4 to adjust the volume level of the channel

over a range of -7 to +7, then press the OK button. Repeat steps 5

PROG AFTVOLATT DECODER

and 6b) to adjust the volume level of the other channels.

1

Off

On

c) AFT

PROG AFTVOLATT DECODER

Push the joystick to $ or 4 to fine tune the channel frequency over

1On

- 5

a range of -15 to +15, then press the OK button. Repeat steps 5 and

6c) if you wish to fine tune other channels.

PROG AFTVOLATT DECODER

1 On -5

2

d) DECODER

Push the joystick to $ or 4 to select AV1 (for a decoder connected

PROG AFTVOLATT DECODER

to the Scart :1/ ) or AV2 (for a decoder connected to the Scart

1 On -5 2

Off

:2/q 2 (SMARTLINK)), then press the OK button.

AV1

AV2

Repeat steps 5 and 6d) to select the AV1 or AV2 output for other

programme positions.

The picture from the decoder connected to the Scart connector

:1/ or :2/q 2 (SMARTLINK) on the back of the

set will appear on this programme number.

7 Press the MENU button to exit and return to the normal TV screen.

The set is now ready for use.

18

Menu System

Menu System

Inputting Your Personal ID

You can programme this set with a personal code, using up to eleven characters (letters and numbers). Then using

this fuction it will be possible to identify your set if it was ever stolen.

This code can only be input once!

Make sure to write it down in this instruction manual.

1 Press the MENU button on the remote control to display the menu

Picture Adjustment

V

I

D

E

O

TV

Picture Mode

Personal

on the screen.

Contrast

Brightness

Colour

Sharpness

Reset

AI

On

Noise Reduction

Off

Colour Tone

Normal

Select: Enter Menu:

Set Up

2 Push the joystick to $ to select the symbol, then push to z to

Auto Tuning

Start

Programme Sorting

enter the Set Up menu.

Select NexTView

- - - - - - -

AV Preset

Manual Set Up

1

2

3

Select:

Start Auto Tuning

4

5

6

Set Up

3 Push the joystick to $ or 4 to select Manual Set Up, then push to z.

Auto Tuning

Programme Sorting

7

8

9

Select NexTView

- - - - - - -

AV Preset

Manual Set Up

GB

0

Select:

Enter:

Manual Set Up

4 Push to $ or 4 to select Personal ID, then push to z.

Language/Country

Manual Programme Preset

Further Programme Preset

RGB Set Up

Personal ID

- - - - - - -

Demo

PROGR

Select: Enter:

MENU

Manual Set Up

5 Push the joystick to $ or 4 to select a letter, number, + or a blank;

Language/Country

Manual Programme Preset

then push to z to confirm this character. Select the other ten

Further Programme Preset

RGB Set Up

characters in the same way.

Personal ID

A----------

RM

903

Demo

Select A-Z, 0-9: Store: OK

S

6 After selecting all the characters, press the OK button. A new menu

Are you sure?

appears automatically on the screen asking you to be sure that you

Save: OK Cancel:

want to save this ID.

7 a) If you do not wish to store this ID, push the joystick to Z and

repeat steps 4 to 6 to enter a new ID.

b) If you wish to store this ID, press the OK button.

Remember that this code can only be input once.

8 Press the MENU button to return to the normal TV screen.

When you enter the Manual Set Up menu, in the "Personal ID" option the

code you entered above will be displayed. You will not be able to select and

change this option.

Menu System

19
