3-867-659-11 (1)



Trinitron Color

Computer Display

GB

Operating Instructions

FR

Mode d’emploi

DE

Bedienungsanleitung

ES

Manual de instrucciones

IT

Istruzioni per l’uso

RU

Инструкция по эксплуатации

CPD-E100E

© 1999 by Sony Corporation

3-867-659-11 (1)

CPD-E100E

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB02GET-AEP.fm

masterpage:Left

Owner’s Record

Hinweise

• Aus ergonomischen Gründen wird empfohlen, die

The model and serial numbers are located at the rear of the unit.

Grundfarbe Blau nicht auf dunklem Untergrund zu verwenden

Record these numbers in the spaces provided below. Refer to them

(schlechte Erkennbarkeit, Augenbelastung bei zu geringem

whenever you call upon your dealer regarding this product.

Zeichenkontrast).

Model No.

Serial No.

• Aus ergonomischen Gründen (flimmern) sollten nur

Darstellungen bei Vertikalfrequenzen ab 70 Hz (ohne

Zeilensprung) verwendet werden.

WARNING

• Die Konvergenz des Bildes kann sich auf Grund des

Magnetfeldes am Ort der Aufstellung aus der korrekten

To prevent fire or shock hazard, do not expose the

Grundeinstellung verändern. Zur Korrektur empfiehlt es sich

unit to rain or moisture.

deshalb, die Regler an der Frontseite für Konvergenz so

Dangerously high voltages are present inside the

einzustellen, daß die getrennt sichtbaren Farblinien für Rot,

unit. Do not open the cabinet. Refer servicing to

Grün und Blau bei z.B. der Darstellung eines Buchstabens

zur Deckung (Konvergenz) gelangen.

qualified personnel only.

Siehe hierzu auch die Erklärungen zu Konvergenz.

FCC Notice

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

NOTICE

These limits are designed to provide reasonable protection against

This notice is applicable for USA/Canada only.

harmful interference in a residential installation. This equipment

If shipped to USA/Canada, install only a UL LISTED/CSA

generates, uses, and can radiate radio frequency energy and, if not

LABELLED power supply cord meeting the following

installed and used in accordance with the instructions, may cause

specifications:

harmful interference to radio communications. However, there is no

SPECIFICATIONS

guarantee that interference will not occur in a particular installation.

Plug Type Nema-Plug 5-15p

If this equipment does cause harmful interference to radio or

Cord Type SVT or SJT, minimum 3

×

18 AWG

television reception, which can be determined by turning the

Length Maximum 15 feet

equipment off and on, the user is encouraged to try to correct the

Rating Minimum 7 A, 125 V

interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

NOTICE

– Increase the separation between the equipment and receiver.

Cette notice s’applique aux Etats-Unis et au Canada

– Connect the equipment into an outlet on a circuit different from

uniquement.

that to which the receiver is connected.

Si cet appareil est export* aux Etats-Unis ou au Canada, utiliser

– Consult the dealer or an experienced radio/TV technician for help.

le cordon d’alimentation portant la mention UL LISTED/CSA

LABELLED et remplissant les conditions suivantes:

You are cautioned that any changes or modifications not expressly

SPECIFICATIONS

approved in this manual could void your authority to operate this

equipment.

Type de fiche Fiche Nema 5-15 broches

Cordon Type SVT ou SJT, minimum 3

×

18 AWG

EN 55022 Compliance (Czech Republic Only)

Longueur Maximum 15 pieds

Tension Minimum 7 A, 125 V

This device belongs to category B devices as described in EN

55022, unless it is specifically stated that it is a category A

device on the specification label. The following applies to

devices in category A of EN 55022 (radius of protection up to

30 meters). The user of the device is obliged to take all steps

necessary to remove sources of interference to

telecommunication or other devices.

As an

E

NERGY

S

TAR Partner, Sony

Corporation has determined that this

product meets the

E

NERGY

S

TAR

guidelines for energy efficiency.

INFORMATION

This product complies with Swedish National Council for Metrology

(MPR) standards issued in December 1990 (MPR II) for very low

frequency (VLF) and extremely low frequency (ELF).

This monitor complies with the

INFORMATION

TCO’99 guidelines.

Ce produit est conforme aux normes du Swedish National Council

for Metrology de décembre 1990 (MPR II) en ce qui concerne les

fréquences très basses (VLF) et extrêmement basses (ELF).

Hinweis

Dieses Gerät erfüllt bezüglich tieffrequenter (very low frequency)

und tiefstfrequenter (extremely low frequency) Strahlung die

Declaration of Conformity

Vorschriften des „Swedish National Council for Metrology (MPR)“

vom Dezember 1990 (MPR II).

Trade Name: Sony

INFORMACIÓN

Model No.: CPD-E100E

Este producto cumple las normas del Consejo Nacional Sueco para

Responsible Party: Sony Electronics Inc.

Metrología (MPR) emitidas en diciembre de 1990 (MPR II) para

Address: 1 Sony Drive, Park Ridge, NJ. 07656 USA

frecuencias muy bajas (VLF) y frecuencias extremadamente bajas (ELF).

Telephone No.: 201-930-6970

Dieses Garät entspricht den folgenden europäischen EMV-

Vorschriften für Betrieb in Wohngebieten, gewerblicher Gebleten

This device complies with Part 15 of the FCC Rules. Operation is

und Leichtindustriegebieten.

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

EN55022/1994 Klasse B

interference received, including interference that may cause

EN50082-1/1997

undesired operation.

EN61000-3-2/1995

2

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB01COV-AEPTOC.fm

masterpage:Toc.master

Table of Contents

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Identifying parts and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Step 1:

Connect your monitor to your computer . . . . . . . . . . . . . . . 6

Step 2:

Connect the power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Step 3:

Turn on the monitor and computer . . . . . . . . . . . . . . . . . . . 7

Selecting the on-screen menu language (LANGUAGE/

INFORMATION) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Customizing Your Monitor . . . . . . . . . . . . . . . . . . . . . . . .8

Navigating the menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Adjusting the brightness and contrast. . . . . . . . . . . . . . . . . . . . . . . . 9

Adjusting the horizontal size or centering of the picture (H-SIZE/

CENTER) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Adjusting the vertical size or centering of the picture (V-SIZE/

CENTER) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

GB

Adjusting the curvature of the picture’s sides (PIN/PIN BALANCE)10

Adjusting the angle of the picture’s sides (KEY/KEY BALANCE). . 10

Adjusting the picture’s rotation (ROTATION) . . . . . . . . . . . . . . . . . 11

Enlarging or reducing the picture (ZOOM) . . . . . . . . . . . . . . . . . . . 11

Adjusting the color of the picture (COLOR) . . . . . . . . . . . . . . . . . . 11

Additional settings (DEGAUSS/CANCEL MOIRE). . . . . . . . . . . . . 12

Resetting the adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Technical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Preset and user modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Power saving function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13



• Trinitron

is a registered trademark of

Sony Corporation.

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

• Macintosh is a trademark licensed to

Apple Computer, Inc., registered in the

If thin line appears on your screen (damper wire) . . . . . . . . . . . . . 13

U.S.A. and other countries.

On-screen messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13



• Windows

and MS-DOS are registered

Trouble symptoms and remedies . . . . . . . . . . . . . . . . . . . . . . . . . . 14

trademarks of Microsoft Corporation in

the United States and other countries.

Self-diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

• IBM PC/AT and VGA are registered

trademarks of IBM Corporation of the

U.S.A.

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16



• VESA and DDC

are trademarks of the

Video Electronics Standard

Association.

Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

•

E

NERGY

S

TAR is a U.S. registered

mark.

Preset mode timing table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

• All other product names mentioned

TCO’99 Eco-document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

herein may be the trademarks or

registered trademarks of their respective

companies.

• Furthermore, “



” and “



” are not

mentioned in each case in this manual.

3

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Left

Use of the tilt-swivel

Precautions

This monitor can be adjusted within the angles shown below. To

find the center of the monitor’s turning radius, align the center of

Warning on power connections

the monitor’s screen with the centering dots on the stand.

• Use the supplied power cord. If you use a different power cord,

Hold the monitor at the bottom with both hands when you turn it

be sure that it is compatible with your local power supply.

horizontally or vertically. Be careful not to pinch your fingers at

For the customers in the UK

the back of the monitor when you tilt the monitor up vertically.

If you use the monitor in the UK, be sure to use the supplied UK

power cable.

Example of plug types

for 100 to 120 V AC for 200 to 240 V AC for 240 V AC only

• Before disconnecting the power cord, wait at least 30 seconds

after turning off the power to allow the static electricity on the

screen’s surface to discharge.

• After the power is turned on, the screen is demagnetized

(degaussed) for about 5 seconds. This generates a strong

magnetic field around the screen which may affect data stored

on magnetic tapes and disks placed near the monitor. Be sure to

keep magnetic recording equipment, tapes, and disks away

from the monitor.

The equipment should be installed near an easily accessible

outlet.

Installation

Do not install the monitor in the following places:

• on surfaces (rugs, blankets, etc.) or near materials (curtains,

draperies, etc.) that may block the ventilation holes

• near heat sources such as radiators or air ducts, or in a place

subject to direct sunlight

• in a place subject to severe temperature changes

• in a place subject to mechanical vibration or shock

• on an unstable surface

• near equipment which generates magnetism, such as a

transformer or high voltage power lines

• near or on an electrically charged metal surface

Maintenance

• Clean the screen with a soft cloth. If you use a glass cleaning

liquid, do not use any type of cleaner containing an anti-static

solution or similar additive as this may scratch the screen’s

coating.

• Do not rub, touch, or tap the surface of the screen with sharp or

abrasive items such as a ballpoint pen or screwdriver. This type

of contact may result in a scratched picture tube.

• Clean the cabinet, panel and controls with a soft cloth lightly

moistened with a mild detergent solution. Do not use any type

of abrasive pad, scouring powder or solvent, such as alcohol or

benzene.

Transportation

When you transport this monitor for repair or shipment, use the

original carton and packing materials.

4

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Right

Identifying parts and controls

See the pages in parentheses for further details.

RearFront

MENU

RESET

AC IN

MENU

RESET

1 RESET button (page 12)

4 AC IN connector (page 6)

This button resets the adjustments to the factory settings.

This connector provides AC power to the monitor.

2 Control button (page 9)

5 Video input connector (HD15) (page 6)

The control button is used to display the menu and make

This connector inputs RGB video signals (0.700 Vp-p,

GB

adjustments to the monitor, including brightness and contrast

positive) and sync signals.

adjustments.

3 1 (power) switch and indicator (pages 7, 13, 16)

This button turns the monitor on and off. The power indicator

lights up in green when the monitor is turned on, and either

flashes in green and orange, or lights up in orange when the

monitor is in power saving mode.

Pin No. Signal

1Red

2 Green

(Sync on Green)

3Blue

4 ID (Ground)

5 DDC Ground*

6 Red Ground

7 Green Ground

8 Blue Ground

9–

10 Ground

11 ID (Ground)

12 Bi-Directional Data (SDA)*

13 H. Sync

14 V. Sync

15 Data Clock (SCL)*

* DDC (Display Data Channel) is a standard of VESA.

5

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Left

x

Connecting to a Macintosh or compatible

computer

Setup

Before using your monitor, check that the following accessories

are included in your carton:

• Power cord (1)

• Windows Monitor Information Disk (1)

• Warranty card (1)

• Notes on cleaning the screen’s surface (1)

• This instruction manual (1)

Step 1:Connect your monitor to

your computer

Turn off the monitor and computer before connecting.

Note

Do not touch the pins of the video cable connector as this might bend the

pins.

x

Connecting to an IBM PC/AT or compatible

computer

AC IN

Step 2:Connect the power cord

With the monitor and computer switched off, first connect the

power cord to the monitor, then connect it to a power outlet.

to video output

IBM PC/AT or

compatible computer

6

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Right

Step 3:Turn on the monitor and

Selecting the on-screen menu

computer

language (LANGUAGE/

INFORMATION)

First turn on the monitor, then turn on the computer.

English, French, German, Italian, Spanish, Russian and Japanese

versions of the on-screen menus are available. The default setting

is English.

1

Press the center of the control button.

The installation of your monitor is complete.

See page 9 for more information on using the control button.

If necessary, use the monitor’s controls to adjust the picture.

If no picture appears on your screen

MENU

MENU

EXI T

H-SIZE/CENTER

• Check that the monitor is correctly connected to the computer.

V-SIZE/CENTER

• If NO INPUT SIGNAL appears on the screen, confirm that

PIN/PIN BALANCE

KEY/ KEY BALANCE

your computer’s graphic board is completely seated in the

ROTATION

ZOOM

correct bus slot.

COLOR

LANGUAGE / I NFORMAT NOI

• If you are replacing an old monitor with this model and OUT

DEGAUSS /CANCEL MO ERI

OF SCAN RANGE appears on the screen, reconnect the old

SELECT

monitor. Then adjust the computer’s graphic board so that the

horizontal frequency is between 30 – 70 kHz, and the vertical

2

Move the control button

m

/

M

to highlight

frequency is between 48 – 120 Hz.

LANGUAGE/INFORMATION and press the center of

the control button again.

For more information about the on-screen messages, see “Trouble

MENU

symptoms and remedies” on page 14.

LANGUAGE / INFORMAT ION

GB

ENGL ISH FRANÇAI S

DEUTSCH I TAL IANO

For customers using Windows 95/98

ESPAÑOL

To maximize the potential of your monitor, install the new model

information file from the supplied Windows Monitor Information Disk

SELECT EXI T

onto your PC.

This monitor complies with the “VESA DDC” Plug & Play standard. If

your PC/graphics board complies with DDC, select “Plug & Play Monitor

(VESA DDC)” or this monitor’s model name as the monitor type in the

3

Move the control button

m

/

M

to select

“Control Panel” of Windows 95/98. If your PC/graphics board has

(LANGUAGE) and move

<

/

,

to select a language.

difficulty communicating with this monitor, load the Windows Monitor

• ENGLISH

Information Disk and select this monitor’s model name as the monitor

• FRANÇAIS: French

type.

• DEUTSCH: German

• ITALIANO: Italian

• ESPAÑOL: Spanish

For customers using Windows NT4.0

• : Russian

Monitor setup in Windows NT4.0 is different from Windows 95/98 and

does not involve the selection of monitor type. Refer to the Windows

• : Japanese

NT4.0 instruction manual for further details on adjusting the resolution,

refresh rate, and number of colors.

To close the menu

Press the center of the control button once to return to the main MENU,

and press again selecting EXIT to return to normal viewing. If no buttons

Adjusting the monitor’s resolution and color number

are pressed, the menu closes automatically after about 30 seconds.

Adjust the monitor’s resolution and color number by referring to your

computer’s instruction manual. The color number may vary according to

To reset to English

your computer or video board. The color palette setting and the actual

Press the RESET button while the (LANGUAGE) menu is displayed

number of colors are as follows:

on the screen.

• High Color (16 bit) t 65,536 colors

• True Color (24 bit) t about 16.77 million colors

In true color mode (24 bit), speed may be slower.

7

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Left

8

COLOR (page 11)

COLOR

Select the COLOR menu to adjust

USER

5000 6500 9300

KKK

Customizing Your Monitor

R50

the picture’s color temperature.

G50

B50

You can make numerous adjustments to your monitor using the

You can use this to match the

SELECT EXI T

on-screen menu.

monitor’s colors to a printed

picture’s colors.

Navigating the menu

9

LANGUAGE/INFORMATION

LANGUAGE / INFORMAT ION

(page 7, 15)

Press the center of the control button to display the main MENU

Select the LANGUAGE/

ENGL ISH FRANÇAI S

DEUTSCH I TAL IANO

on your screen. See page 9 for more information on using the

INFORMATION menu to choose

ESPAÑOL

control button.

the on-screen menu’s language

SELECT EXI T

and display this monitor’s

MENU

information box.

EXI T

H-SIZE/CENTER

V-SIZE/CENTER

PIN/PIN BALANCE

q;

DEGAUSS/CANCEL MOIRE

DEGAUSS /CANCEL MOI RE

KEY/ KEY BALANCE

ROTATION

(page 12)

DEGAUSS

ZOOM

Select the DEGAUSS/CANCEL

COLOR

ON

LANGUAGE / I NFORMAT NOI

MOIRE menu to degauss the

DEGAUSS /CANCEL MO ERI

SELECT EXI T

SELECT

screen and adjust the moire

cancellation level.

Use the control button to select one of the following menus.

1

EXIT

Select EXIT to close the menu.

2

H-SIZE/CENTER (page 10)

H-SI ZE/CENTER

Select the H-SIZE/CENTER

H-SIZE

menu to adjust the picture’s

26

horizontal size and centering.

SELECT EXI T

3

V-SIZE/CENTER (page 10)

V-SIZE/CENTER

Select the V-SIZE/CENTER

V-SIZE

menu to adjust the picture’s

26

vertical size and centering.

SELECT EXI T

4

PIN/PIN BALANCE (page 10)

PIN/PIN BALANCE

Select the PIN/PIN BALANCE

PIN

menu to adjust the curvature

26

picture’s sides.

SELECT EXI T

5

KEY/KEY BALANCE

KEY/ KEY BALANCE

(page 10)

KEY

Select the KEY/KEY BALANCE

26

menu to adjust the angle of the

SELECT EXI T

picture’s sides.

6

ROTATION (page 11)

ROTAT ION

Select the ROTATION menu to

ROTAT ION

adjust the picture’s rotation.

26

EXI T

7

ZOOM (page 11)

ZOOM

Select the ZOOM menu to enlarge

ZOOM

or reduce the picture.

26

EXI T

8

3-867-659-

CPD-E100E

11

(1)

C:\WIN95-E\DESKTOP\CPD E100\386765911CPDE100EAEP\01GB03BAS-AEP.fm

masterpage:Right

x

Using the control button

Adjusting the brightness and

1

Display the main MENU.

contrast

Press the center of the control button to display the main

MENU on your screen.

Brightness and contrast adjustments are made using a separate

BRIGHTNESS/CONTRAST menu.

MENU

These settings are stored in memory for all input signals.

1

Move the control button in any direction.

The BRIGHTNESS/CONTRAST menu appears on the

screen.

BRIGHTNESS/CONTRAST

2

Select the menu you want to adjust.

Highlight the desired menu by moving the control button

26 26

towards the rear to go up (M), towards the front to go down

the horizontal

the resolution

68.7kHz/85.0Hz

and vertical

(m), and left (<) or right (,) to move sideways.

1024X768

of the current

frequencies of

input signal

the current

FRONT

input signal

MENU MENU

The horizontal and vertical frequencies of the current input

signal are displayed in the BRIGHTNESS/CONTRAST

menu. If the signal matches one of this monitor’s factory

preset modes, the resolution is also displayed.

2

Move the control button m/M to adjust the

REAR

brightness ( ), and </, to adjust the contrast

(6).

GB

The menu automatically disappears after about 3 seconds.

3

Adjust the menu.

Move the control button left (<) or right (,) to make the

adjustment.

MENU

4

Close the menu.

Press the center of the control button once to return to the

main MENU, and press again selecting EXIT to return to

normal viewing. If no buttons are pressed, the menu closes

automatically after about 30 seconds.

MENU

x

Resetting the adjustments

Press the RESET button. See page 12 for more information on

resetting the adjustments.

RESET

9

3-867-659-

CPD-E100E

11

(1)
