Sony MDX-M690 RU: instruction

3-230-448-21 (1)

FM

/

MW

/

LW

Compact Disc Player

CDX-M770 CDX-M670

FM/MW/LW

FM/MW/LW Compact-/Mini- Disc Player

Mini Disc Player

MDX-M690

GB

Operating Instructions

ES

Manual de instrucciones

SE

Bruksanvisning

PT

Manual de instruções

GR

Oδηγίες Λειτουργίας

RU

Инструкция по эксплуатации

For installation and connections, see the supplied installation/connections manual.

Para obtener información sobre la instalación y las conexiones, consulte el manual de

instalación/conexiones suministrado.

Vi hänvisar till det medföljande häftet angående montering/anslutningar.

Para a instalação e as ligações, consulte o manual de instalação/ligações fornecido.

Για την εγκατάσταση και τις συνδέσεις, δείτε το συνοδευτικ εγχειρίδιο

Εγκατάσταση/Συνδέσεις.

Перед установкой и подсоединениями прочитайте прилагаемую инструкцию по

установке и подсоединению.

© 2001 Sony Corporation

Welcome !

Thank you for purchasing this Sony Compact

Disc Player/Mini Disc Player. You can enjoy its

various features even more with:

1

• Display language*

choice from English,

German, French, Italian, Dutch, Spanish,

Portuguese, Swedish, Polish, Czech, or

Turkish.

• Optional CD/MD units (both changers and

2

players)*

.

• MDLP (MiniDisc Long Play) playback.

(MDX-M690 only)

• Optional DAB tuner.

• CD TEXT information (displayed when a CD

3

TEXT disc*

is played).

• Supplied controller accessory

Card remote commander RM-X111

Wireless rotary commander RM-X5S (CDX-

M770)

• Optional controller accessories

Wireless rotary commander RM-X5S (CDX-

M670, MDX-M690)

Wired rotary commander RM-X4S (CDX-

M670, MDX-M690)

*1 Some display indications do not appear in the

language you select.

*2 This unit works with Sony products only.

*3 A CD TEXT disc is an audio CD that includes

information such as the disc name, artist name,

and track names. This information is recorded on

the disc.

This label is located on the bottom of the chassis.

CAUTION INVISIBLE

LASER RADIATION WHEN OPEN

DO NOT STARE INTO BEAM OR

VIEW DIRECTLY WITH OPTICAL INSTRUMENTS

This label is located on the drive unit’s internal

chassis.

2

Table of Contents

Location of controls. . . . . . . . . . . . . . . . . . . . 4

DAB (optional)

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Overview of DAB. . . . . . . . . . . . . . . . . . . . 21

Notes on CDs. . . . . . . . . . . . . . . . . . . . . . . . . 7

Basic operations of DAB . . . . . . . . . . . . . . 22

Notes on MDs . . . . . . . . . . . . . . . . . . . . . . . . 8

Presetting DAB services automatically

— BTM . . . . . . . . . . . . . . . . . . . . . . . . . 23

Getting Started

Presetting DAB services manually

Resetting the unit. . . . . . . . . . . . . . . . . . . . . . 9

— Preset Edit . . . . . . . . . . . . . . . . . . . . . 23

Detaching the main display window . . . . . . . 9

Tuning in DAB programme through

Setting the clock . . . . . . . . . . . . . . . . . . . . . 10

a list . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Switching multi-channel audio and

CD/MD

DRC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing a disc. . . . . . . . . . . . . . . . . . . . . . . . 11

Locating a DAB service by programme type

Display items. . . . . . . . . . . . . . . . . . . . . . . . 12

(PTY) . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing tracks repeatedly

— Repeat Play . . . . . . . . . . . . . . . . . . . . 12

Tuning up for your best sound

Playing tracks in random order

Setting the equalizer (EQ7). . . . . . . . . . . . . 26

— Shuffle Play . . . . . . . . . . . . . . . . . . . . 12

Setting the soundstage menu

Labelling a CD

— Dynamic Soundstage Organizer

— Disc Memo*. . . . . . . . . . . . . . . . . . . . 13

(DSO). . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Locating a disc by name

Listening to each programme source in its

— List-up* . . . . . . . . . . . . . . . . . . . . . . . 14

registered DSO

Selecting specific tracks for playback

— Source Sound Memory (SSM) . . . . . 28

— Bank*. . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting the sound characteristics . . . . . . 28

* Functions available with optional CD/MD unit

Selecting the listening position

Radio

(CDX-M770 only) . . . . . . . . . . . . . . . . . 29

Adjusting the balance

Storing stations automatically

(BAL). . . . . . . . . . . . . . . . . . . . . . . . . . . 29

— Best Tuning Memory (BTM). . . . . . . 15

Adjusting the bass

Receiving the stored stations. . . . . . . . . . . . 16

(CDX-M670, MDX-M690 only) . . . . . . 29

Storing only the desired stations . . . . . . . . . 16

Adjusting the treble

Tuning in a station through a list

(CDX-M670, MDX-M690 only) . . . . . . 30

— List-up . . . . . . . . . . . . . . . . . . . . . . . . 17

Adjusting the balance (FAD)

RDS

(CDX-M670, MDX-M690 only) . . . . . . 30

Overview of RDS . . . . . . . . . . . . . . . . . . . . 17

Adjusting the front and rear volume

Automatic retuning for best reception results

(CDX-M770 only) . . . . . . . . . . . . . . . . . 30

— AF function . . . . . . . . . . . . . . . . . . . . 18

Adjusting the volume of

Receiving traffic announcements

the subwoofer(s). . . . . . . . . . . . . . . . . . . 31

— TA/TP . . . . . . . . . . . . . . . . . . . . . . . . 19

Other adjustable items

Presetting RDS stations with AF and TA

(CDX-M670, MDX-M690 only) . . . . . . 31

setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Other Functions

Tuning in stations by programme type

Using the rotary commander. . . . . . . . . . . . 32

— PTY . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Quickly attenuating the sound . . . . . . . . . . 33

Setting the clock automatically

Selecting the spectrum analyzer . . . . . . . . . 33

— CT . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Changing the sound and display settings

— Menu . . . . . . . . . . . . . . . . . . . . . . . . . 34

Labelling a Motion Display . . . . . . . . . . . . 35

Connecting auxiliary audio equipment

(CDX-M770 only) . . . . . . . . . . . . . . . . . 35

Additional Information

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 36

Removing the unit. . . . . . . . . . . . . . . . . . . . 37

Specifications . . . . . . . . . . . . . . . . . . . . . . . 38

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 39

3

Error displays/Messages . . . . . . . . . . . . . . . 41

Location of controls

Card remote commander RM-X111

Refer to the pages listed for details.

CD/MD

: During Playback : During radio reception : During menu mode

RADIO MENU

M (DISC)

OPEN/CLOSE

(+): to select upwards

SCRL

PTY

< (SEEK)

DSPL

AF

TA

(–): to select

DISC

+

REP SHUF

leftwards/

1

2

3

.

SOURCE

SEEK

–

SEEK

+

4

5

6

, (SEEK)

DISC

–

EQ7 DSO

MODE

(+): to select

rightwards/

m (DISC)

>

LIST

MENU

DISC

+

(–): to select downwards

In menu mode, the currently selectable button (s) of

SOURCE

these four are indicated with a “ v” in the display.

SEEK

–

SEEK

+

SOUND

DISC

–

ENTER

Note

If the unit is turned off by pressing (OFF) for 2

ATTOFF

+

seconds, the unit cannot be operated with the card

VOL

remote commander unless (SOURCE) on the unit is

pressed, or a disc is inserted to activate the unit first.

–

Tip

Refer to “Replacing the lithium battery” for details on

how to replace the batteries (page 36).

a SCRL (scroll) button 12

i OFF (Stop/Power off) button 11, 35

b DSPL/PTY (display mode change/

j VOL +/– buttons 19

programme type) button 12, 13, 17,

k OPEN/CLOSE button 11, 37

20, 25, 35

l AF button 18, 19

c Number buttons

m TA button 19

CD/MD

n MODE button

(1) REP 12

CD/MD

11, 13

(2) SHUF 12

RADIO

15, 16, 19, 22

RADIO

15, 16, 18, 19, 22, 24

o DSO button 27

d EQ7 button 26

p LIST button

e MENU button 10, 13, 14, 15, 19, 21,

CD/MD

13, 14

23, 25, 26, 27, 28, 30, 31, 33, 34, 35

RADIO

17, 24

f SOURCE (Power on/Radio/CD/MD)

q M/m DISC +/– buttons

button 10, 11, 13, 15, 16, 19, 22, 26,

CD/MD

11, 14

27, 29, 30, 31, 33, 35

RADIO

16, 17, 20, 22, 23, 24, 25

10, 13, 14, 15, 19, 21, 23, 25,

g </, SEEK +/– buttons 10, 28, 29,

MENU

26, 27, 28, 30, 31, 33, 34, 35

30, 31

r ENTER button

CD/MD

11

CD/MD

14

RADIO

16, 18, 22

RADIO

17, 20, 23, 24, 25

MENU

10, 13, 14, 15, 21, 23, 25, 26,

MENU

10, 13, 14, 15, 19, 21, 23, 25,

27, 28, 30, 31, 33, 34, 35

26, 27, 30, 31, 33, 34, 35

h SOUND button 28, 29, 30, 31

4

s ATT button 33

Main display panel

Operation side

RESET

C

R

L

D

S

P

L

P

S

T

Y

DISC

LIST

MENU

DSO

SOURCE

EQ7

REP SHUF

SOUND

F

E

CLOSE

O

F

M

O

D

AF TA

123456

DISC

ENTER

CDX-M770/CDX-M670

/MDX-M690

The corresponding buttons of the unit

j DISC +/– (cursor up/down) buttons

control the same functions as those on

SEEK –/+ (cursor left/right) buttons

the card remote commander.

k MENU button

m LIST button

a OPEN button 9, 11, 37

o

CLOSE (front panel close) button

9, 11

b Main display window

p OFF (Stop/Power off) button*

c qf Receptor for the card remote

q MODE button

commander

r Number buttons

d qs Reset button 9

s SOUND button

e Volume adjust buttons

t EQ7 button

f SCRL (scroll) button

u ENTER button

g SOURCE button

v DSO button

h DSPL/PTY (display mode change/

w Z (eject) button 11

programme type) button

i Sub display window

5

continue to next page t

* Warning when installing in a car without

an ACC (access

ory) position on the ignition

Precautions

switch

After turning off the ignition, be sure to press

the power on/

off button on the unit for 2 seconds to

• If your car was parked in direct sunlight, allow

turn off the clo

ck display.

the unit to cool off before operating it.

Otherwise, the clock display does not turn off

• Power aerials will extend automatically while

and this causes battery drain.

the unit is operating.

If you have any questions or problems

Concerning the front panel positions

concerning your unit that are not covered in this

This unit has 3 front panel open modes.

manual, please consult your nearest Sony dealer.

• Main display position

Moisture condensation

On a rainy day or in a very damp area, moisture

unit

condensation may occur inside the lenses and

display of the unit. Should this occur, the unit

will not operate properly. In such a case, remove

the disc and wait for about an hour until the

• Detaching position

moisture has evaporated.

To maintain high sound quality

unit

Be careful not to splash juice or other soft drinks

onto the unit or discs.

• Sub-display position

unit

To prevent the wireless rotary

commander RM-X5S from falling off

(supplied with CDX-M770 only)

If the wireless commander falls off, it could

cause an accident.

• Be sure to attach the supplied strap when

installing the rotary commander near the

steering wheel.

• Be sure that the strap does not get caught on the

car controls (gear, shifter, etc.).

• Be sure to tighten the stopper of the strap after

hanging the strap on the indicator switch, etc.

6

Notes on CD-R/CD-RW discs

Notes on CDs

• You can play CD-Rs (recordable CDs)

designed for audio use on this unit.

Look for this mark to distinguish CD-Rs for

• To keep the disc clean, do not touch the surface.

audio use.

Handle the disc by its edge.

• Keep your discs in their cases or disc

magazines when not in use.

Do not subject the discs to heat/high

temperature. Avoid leaving them in parked cars

or on dashboards/rear trays.

This mark denotes that a disc is not for audio use.

• Some CD-Rs (depending on the equipment

used for its recording or the condition of the

• Do not attach labels, or use discs with sticky

disc) may not play on this unit.

ink/residue. Such discs may stop spinning

• You cannot play a CD-R that is not finalized*.

when used, causing a malfunction, or may ruin

* A process necessary for a recorded CD-R disc to

the disc.

be played on the audio CD player.

• You cannot play CD-RWs (rewritable CDs) on

this unit.

• Discs with non-standard shapes (e.g., heart,

square, star) cannot be played on this unit.

Attempting to do so may damage the unit. Do

not use such discs.

• You cannot play 8 cm CDs.

• Before playing, clean the discs with a

commercially available cleaning cloth. Wipe

each disc from the centre out. Do not use

solvents such as benzine, thinner, commercially

available cleaners, or antistatic spray intended

for analog discs.

7

Cleaning

Notes on MDs

Wipe the surface of the cartridge from time to

time with a soft, dry cloth.

• Do not open the shutter of the cartridge

to expose the MD. Close immediately if

the shutter opens.

• Never touch the surface of the disc inside.

• Do not subject the discs to heat/high

temperature. Avoid leaving them in parked cars

or on dashboards/rear trays.

Notes on attaching labels

To avoid MDs becoming stuck in the unit:

– Attach the label in a suitable position.

– Remove old labels before putting new ones on.

– Replace labels that are peeling away.

8

Detaching the main display

Getting Started

window

You can detach the main display window of this

Resetting the unit

unit to protect the unit from being stolen.

Before operating the unit for the first time, or

Caution alarm

after replacing the car battery or changing the

If you turn the ignition switch to the OFF

connections, you must reset the unit.

position without removing the front panel, the

Press the reset button on the front panel with a

caution alarm will beep for a few seconds.

pointed object, such as a ballpoint pen.

1 Press (OPEN) on the unit for 2

Reset button

seconds.

CD/MD playback or radio reception stops,

and the front panel automatically tilts at an

angle of 30°.

(OPEN)

Notes

• After resetting the unit in the closed position, be sure

to press (OPEN) once before operating further. If a

disc is in the unit, the disc will be ejected

automatically. Insert the disc again.

• Pressing the reset button will erase the clock setting

and some stored contents.

Resetting the unit during use in sub-

2 Detach the main display window as

illustrated.

display position

After the main display window detaching is

Press the reset button by the disc-slot with a

complete, the front panel closes

pointed object, such as a ballpoint pen.

automatically.

Reset button

Notes

• If you detach the main display window while the unit

is still turned on, the power will turn off automatically

to prevent the speakers from being damaged.

• Do not drop or put excessive pressure on the display

window.

• Do not subject the main display window to heat/high

temperature or moisture. Avoid leaving it in parked

cars or on dashboards/rear trays.

Tips

• If you want to detach the main display window, when

the front panel is in the sub-display position, press

(CLOSE) for 2 seconds. If a disc is partially inserted,

load the disc correcty or remove the disc from the

unit.

• When carrying the main display window with you,

use the supplied front panel case.

continue to next page t

9
