Yamaha KMA-700: SPECIFICATIONS

SPECIFICATIONS

AMPLIFIER

ACCESSORIES

• Maximum output

• Owner’s manual................................................................................1

[KMA-700]

• Remote control .................................................................................1

(1 kHz, 8 Ω, 10%THD)........................................ 120 W+120 W

[KMA-500]

• Power cable (Except U.S.A. model).................................................1

(1 kHz, 8 Ω, 10%THD)........................................ 100 W+100 W

DIMENSIONS

• Total harmonic distortion

[KMA-700]

(1 kHz, 93 W, 8 Ω)..................................................................1%

[KMA-500]

(1 kHz, 76 W, 8 Ω)..................................................................1%

• Audio input (Sensitivity/Impedance)

DVD, TAPE, AUX (KMA-700 only)....................200 mV/42 k Ω

BGM.......................................................................200 mV/42 k Ω

MIC .........................................................................6.0 mV/20 k Ω

• Audio output (Output level/Output impedance)

PRE OUT .................................................................. 1.0 V/1.2 k Ω

SUBWOOFER..........................................................2.0 V/1.2 k Ω

416 (16-3/8”)

429 (16-7/8”)

• Frequency response

MUSIC...........................................20 Hz to 15 kHz, +1.5/–0.5 dB

MIC ................................................40 Hz to 15 kHz, +1.0/–0.5 dB

• Tone control characteristics

MUSIC

BASS.................................................................±12 dB (100 Hz)

TREBLE............................................................±12 dB (10 kHz)

MIC

BASS.................................................................±12 dB (100 Hz)

MID.....................................................................±12 dB (1 kHz)

TREBLE............................................................±10 dB (10 kHz)

• Speaker impedance

[KMA-700]

(1 system only A or B)...........................4 Ω to 8 Ω /8 Ω to 16 Ω

132 (5-3/16”)

150 (5-15/16”)

(2-system operation A and B) ...................................8 Ω to 16 Ω

435 (17-1/8”)

[KMA-500]

(1 system only)..........................................................8 Ω to 16 Ω

18 (11/16”)

• Key control range............................................... ±5 steps, ±2.5 tones

• Video input

Design and specifications are subject to change without notice.

(Sensitivity/Input impedance).....................................1 Vp-p/75 Ω

• Video output

(Output level/Impedance)............................................1 Vp-p/75 Ω

POWER SUPPLY, ETC.

• Supply voltage

Asia and Other models....... AC 110/120/220/230-240 V 50/60 Hz

U.S.A. model........................................................AC 120 V 60 Hz

• Power consumption

[KMA-700]

(IEC 60065)....................................................................... 190 W

(Idling) ................................................................................ 25 W

[KMA-500]

(IEC 60065)....................................................................... 165 W

(Idling) ................................................................................ 25 W

• AC OUTLETS (U.S.A. model only)

SWITCHED (100 W max.)........................................................... 2

• Dimensions (W × H × D)...................435 mm × 150 mm × 416 mm

(17-1/8” × 5-15/16” × 16-3/8”)

• Weight....................................................................................... 10 kg

(22 lbs. 1 oz.)

18 En
