Yamaha KMA-700: instruction

L

KMA-700/KMA-500

Digital Karaoke Mixing Amplifier

OWNER’S MANUAL

MANUAL DE INSTRUCCIONES

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

IMPORTANT SAFETY INSTRUCTIONS

1 Read these instructions.

2 Keep these instructions.

CAUTION

3 Heed all warnings.

RISK OF ELECTRIC SHOCK DO

4 Follow all instructions.

NOT OPEN

5 Do not use this apparatus near water.

6 Clean only with dry cloth.

CAUTION: TO REDUCE THE RISK OF

7 Do not block any ventilation openings. Install in accordance

ELECTRIC SHOCK, DO NOT REMOVE COVER

with the manufacturer’s instructions.

(OR BACK). NO USER-SERVICEABLE PARTS

8 Do not install near any heat sources such as radiators, heat

INSIDE. REFER SERVICING TO QUALIFIED

registers, stoves, or other apparatus (including amplifiers) that

SERVICE PERSONNEL.

produce heat.

9 Do not defeat the safety purpose of the polarized or

• Explanation of Graphical Symbols

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

The lightning flash with arrowhead symbol, within an

blades and a third grounding prong. The wide blade or the

equilateral triangle, is intended to alert you to the

presence of uninsulated “dangerous voltage” within

third prong are provided for your safety. If the provided plug

the product’s enclosure that may be of sufficient

does not fit into your outlet, consult an electrician for

magnitude to constitute a risk of electric shock to

replacement of the obsolete outlet.

persons.

10 Protect the power cord from being walked on or pinched

The exclamation point within an equilateral triangle

particularly at plugs, convenience receptacles, and the point

is intended to alert you to the presence of important

where they exit from the apparatus.

operating and maintenance (servicing) instructions in

11 Only use attachments/accessories specified by the

the literature accompanying the appliance.

manufacturer.

12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold

IMPORTANT

with the apparatus. When a cart is used, use

Please record the serial number of this unit in the space

caution when moving the cart/apparatus

below.

combination to avoid injury from tip-over.

MODEL:

13 Unplug this apparatus during lightning storms or when unused

Serial No.:

for long periods of time.

The serial number is located on the rear of the unit.

14 Refer all servicing to qualified service personnel. Servicing is

Retain this Owner’s Manual in a safe place for future

required when the apparatus has been damaged in any way,

reference.

such as power cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate normally,

or has been dropped.

i En

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1 IMPORTANT NOTICE: DO NOT MODIFY THIS

Compliance with FCC regulations does not guarantee that

UNIT!

interference will not occur in all installations. If this

This product, when installed as indicated in the

product is found to be the source of interference, which can

instructions contained in this manual, meets FCC

be determined by turning the unit “OFF” and “ON”, please

requirements. Modifications not expressly approved by

try to eliminate the problem by using one of the following

Yamaha may void your authority, granted by the FCC, to

measures:

use the product.

Relocate either this product or the device that is being

2IMPORTANT: When connecting this product to

affected by the interference.

accessories and/or another product use only high quality

Utilize power outlets that are on different branch (circuit

shielded cables. Cable/s supplied with this product MUST

breaker or fuse) circuits or install AC line filter/s.

be used. Follow all installation instructions. Failure to

In the case of radio or TV interference, relocate/reorient

follow instructions could void your FCC authorization to

the antenna. If the antenna lead-in is 300 ohm ribbon lead,

use this product in the USA.

change the lead-in to coaxial type cable.

3 NOTE: This product has been tested and found to comply

If these corrective measures do not produce satisfactory

with the requirements listed in FCC Regulations, Part 15

results, please contact the local retailer authorized to

for Class “B” digital devices. Compliance with these

distribute this type of product. If you can not locate the

requirements provides a reasonable level of assurance that

appropriate retailer, please contact Yamaha Electronics

your use of this product in a residential environment will

Corp., U.S.A. 6660 Orangethorpe Ave., Buena Park, CA

not result in harmful interference with other electronic

90620.

devices.

This equipment generates/uses radio frequencies and, if

The above statements apply ONLY to those products

not installed and used according to the instructions found

distributed by Yamaha Corporation of America or its

in the users manual, may cause interference harmful to the

subsidiaries.

operation of other electronic devices.

We Want You Listening For A Lifetime

Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your

equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or

distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is

often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group

recommend you to avoid prolonged exposure from excessive volume levels.

ii En

Caution: Read this before operating your unit

1 To assure the finest performance, please read this manual

19 The batteries shall not be exposed to excessive heat such as

carefully. Keep it in a safe place for future reference.

sunshine, fire or like.

2 Install this sound system in a well ventilated, cool, dry, clean

20 Condensation will form when the surrounding temperature

place – away from direct sunlight, heat sources, vibration,

changes suddenly. Disconnect the power supply cable from

dust, moisture, and/or cold. Allow ventilation space of at least

the outlet, then leave the unit alone.

10 cm (3-15/16”) on the top, left and right of this unit, and

21 When using the unit for a long time, the unit may become

20 cm (7-7/8”) on the back.

warm. Turn the power off, then leave the unit alone for

3 Locate this unit away from other electrical appliances, motors,

cooling.

or transformers to avoid humming sounds.

22 VOLTAGE SELECTOR (Except U.S.A. model)

4 Do not expose this unit to sudden temperature changes from

The VOLTAGE SELECTOR on the rear panel of this unit

cold to hot, and do not locate this unit in an environment with

must be set for your local main voltage BEFORE plugging

high humidity (i.e. a room with a humidifier) to prevent

into the AC wall outlet.

condensation inside this unit, which may cause an electrical

shock, fire, damage to this unit, and/or personal injury.

5 Avoid installing this unit where foreign objects may fall onto

this unit and/or this unit may be exposed to liquid dripping or

splashing. On the top of this unit, do not place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall and liquid

foot foot

may cause electrical shock to the user and/or damage to

rack

this unit.

6 Do not cover this unit with a newspaper, tablecloth, curtain,

The following rack size measurements must be adhered to:

etc. in order not to obstruct heat radiation. If the temperature

inside this unit rises, it may cause fire, damage to this unit,

12 The ventilation space on the top, left and right of this

and/or personal injury.

unit; more than 10 cm (3-15/16”)

7 Do not plug in this unit to an AC wall outlet until all

3 The ventilation space on the back of this unit; more

connections are complete.

than 20 cm (7-7/8”)

8 Do not operate this unit upside-down. It may overheat,

4 Do not remove the feet.

possibly causing damage.

9 Do not use force on switches, knobs and/or cords.

10 When disconnecting the power cord from the AC wall outlet,

WARNING

grasp the plug; do not pull the cord.

TO REDUCE THE RISK OF FIRE OR ELECTRIC

11 Do not clean this unit with chemical solvents; this might

SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN

damage the finish. Use a clean, dry cloth.

OR MOISTURE.

12 Only voltage specified on this unit must be used. Using this

unit with a higher voltage than specified is dangerous and may

As long as this unit is connected to the AC wall outlet,

cause fire, damage to this unit, and/or personal injury.

it is not disconnected from the AC power source even

Yamaha will not be held responsible for any damage resulting

if you turn off this unit by POWER switch.

from use of this unit with a voltage other than specified.

13 To prevent damage by lightning, keep the power cord

disconnected from an AC wall outlet or the unit during a

CAUTION

lightning storm.

Danger of explosion if battery is incorrectly replaced.

14 Do not attempt to modify or fix this unit. Contact qualified

Replace only with the same or equivalent type.

Yamaha service personnel when any service is needed. The

cabinet should never be opened for any reasons.

CAUTION

15 When not planning to use this unit for long periods of time

Use of controls or adjustments or performance of

(i.e. vacation), disconnect the AC power plug from the AC

procedures other than those specified herein may result

wall outlet.

in hazardous radiation exposure.

16 Install this unit near the wall outlet and where the AC power

plug can be reached easily.

17 Be sure to read the “Troubleshooting” section on common

operating errors before concluding that this unit is faulty.

18 Before moving this unit, press POWER switch to turn this

unit off, and disconnect the power cord from the AC wall

outlet.

iii En

CONTENTS

INTRODUCTION

HANDLING PRECAUTIONS .............................. 2

BEFORE CONNECTING ..................................... 2

PREPARATION

NAMES OF PARTS AND THEIR FUNCTIONS

.............................................................................. 3

PREPARATIONINTRODUCTION

OPERATION

SYSTEM CONNECTIONS................................... 6

CONNECTIONS .................................................... 7

CONFIGURATION DIAGRAM ........................ 10

REMOTE CONTROL ......................................... 11

GENERAL OPERATION ................................... 13

SETUP MODE...................................................... 14

OPERATION

ADDITIONAL INFORMATION

TROUBLESHOOTING....................................... 16

MAINTENANCE ................................................. 16

AFTER-SALES SERVICING............................. 17

KARAOKE ETIQUETTE ................................... 17

COPYRIGHT ....................................................... 17

INFORMATION

SPECIFICATIONS .............................................. 18

ADDITIONAL

English

1 En

INTRODUCTION

Thank you for your purchase of the Yamaha KMA-700/KMA-500 Digital Karaoke Mixing Amplifier.

This document is the owner’s manual for both KMA-700 and KMA-500. Model names are given where the details of

functions are unique to each model. Illustrations for KMA-700 are mainly used for explanations.

Before using this unit, be sure to read this manual so that you can take full advantage of the features of this unit.

After you finish reading, keep this manual in a safe place in case you need it in the future. The manual should be very

helpful in understanding the Digital Karaoke Mixing Amplifier and solving any difficulties that may arise during use.

HANDLING PRECAUTIONS

■ Do not install the unit in the following

• In places which may be exposed to rain, such as near a

locations:

window.

• In places exposed to direct sunlight or near heat

• In places which may be exposed to soot, vapor or heat,

sources, such as a radiator.

such as near cooking facilities.

• In places where heat cannot escape due to poor

ventilation, or are very humid or dusty.

• On a sloping surface or exposed to excessive vibration.

BEFORE CONNECTING

■ Connection precautions

■ Power consumption of AC OUTLETS

• Be sure to switch off the power of the relevant

(U.S.A. model only)

equipment before making any connection.

• Be careful that the total power consumption does not

• The white input/output jacks of the amplifier are

exceed the wattage marked on the rear panel. Do not

designed for the left channel, while the red input/output

connect appliances other than system components to

jacks are for the right channels. Be sure to connect the

the AC OUTLETS of this unit.

cords without making a mistake in the color codes for

• Do not connect a TV set to this unit; even if it indicates

the left and right channels.

a power consumption value below the permissible

• Insert the plugs of the connection cords securely into

value when the TV power is turned on.

the jacks. If the connection is incomplete, there may be

no sound produced or noise may be generated.

• When unplugging the power cable from the AC wall

outlet, be sure to hold the plastic molding of the plug

itself and pull.

• For KMA-700, set IMPEDANCE SELECTOR on the

rear panel before turning on the unit. Refer to

“IMPEDANCE SELECTOR” on page 7.

• Except in the case of the U.S.A. model, VOLTAGE

SELECTOR on the rear panel of this unit must be set

for your local main voltage BEFORE plugging the

power cable into the AC wall outlet. Refer to

“VOLTAGE SELECTOR” on page 9.

2 En

PREPARATION

NAMES OF PARTS AND THEIR FUNCTIONS

Front panel

PREPARATION

The shaded part ( ) is provided for KMA-700 only.

1 POWER (ON/OFF)

0 MIC

Turn the power ON/OFF.

Adjust the overall volume of all microphones.

2 MUSIC BALANCE

A Remote sensor

Adjust the volume balance.*

This sensor receives signals from the remote control.

3 MUSIC TONE (BASS/TREBLE)

B ECHO

Adjust the low/high frequency response.*

Adjust the amount of echo.

4 MIC ECHO DELAY

C INPUT/Input source indicators (DVD/AUX**/

Adjust the delay time between echoes.*

TAPE/BGM)

INPUT is not available in the default setting.

5 MIC ECHO REPEAT

To activate INPUT, refer to “Input mode” on page 14.

Adjust the amount of feedback.*

Input source indicators indicate the input source currently

6 ECHO MODE

active.

Select NORMAL, WIDE (stereo) or SPACIOUS** echo.

D MUSIC

SPACIOUS echo is an effect that produces both

Adjust the volume of the music source.

NORMAL and WIDE echo with a time lag. The LED

lights up in amber/green** when WIDE/SPACIOUS**

E KEY CONTROL

echo is selected.

To transpose the key of the played music, rotate this

control. The key can be changed in halftone steps in 5

7 MIC TONE (BASS/MID/TREBLE)

steps; either higher or lower. To reset the key to the

Adjust the low/middle/high frequency response of

natural key, press this control. If over 4 seconds of silence

microphones.*

occurs, the unit assumes the played song has finished and

English

8 MIC jacks (1/2/3**)

resets the key to natural.

Connect microphones to these jacks.

* Use a flathead screwdriver to adjust.

9 MIC VOL (1/2/3**)

** KMA-700 only

Adjust the microphone input level.*

3 En

NAMES OF PARTS AND THEIR FUNCTIONS

Rear panel

(Asia model)

The shaded part ( ) is provided for KMA-700 only.

For details on component connection, refer to “SYSTEM

9 PRE OUT jacks

CONNECTIONS” on page 6.

Connect to the input jacks of the extension power

amplifier.

1 BALANCED MIC INPUT jacks (1/2)

Connect microphones to these jacks.

0 IMPEDANCE SELECTOR*

These are balanced inputs and each connects to the same

Refer to “IMPEDANCE SELECTOR” on page 7.

circuit MIC 1 and 2 on the front panel.

A REMOTE jack

2 DVD audio input jacks

Connect to an external remote control.

Connect to the output jacks of KARAOKE equipment or

Refer to “Connecting an external remote control” on page

DVD player.

8.

3 AUX audio input jacks*

B VIDEO INPUT jacks

Connect to the output jacks of a TAPE player, VCR, etc.

Connect to the input jack of the video output of a DVD,

AUX*, or background video player or video camera, etc.

4 TAPE audio input jacks

Connect to the output jacks of a TAPE player, VCR, etc.

5 TAPE audio output jacks

Connect to the input jacks of a TAPE player, VCR, etc.

* KMA-700 only

6 BGM audio input jacks

Connect to the output jacks of the source component of

background music.

7 SUBWOOFER jack without low-pass filter

Connect to the input jack of the subwoofer with a low-

pass filter. This jack outputs the monaural signal directly.

8 SUBWOOFER jack with low-pass filter

Connect to the input jack of the subwoofer.

4 En

NAMES OF PARTS AND THEIR FUNCTIONS

(Asia model)

PREPARATION

The shaded part ( ) is provided for KMA-700 only.

C DVD INPUT LEVEL

K Signal ground terminal

Adjust the balance of the DVD input level with respect to

Connect this terminal if a humming noise is emitted when

other inputs (AUX*, TAPE, BGM).

connecting this amplifier.

D AUX INPUT LEVEL*

L VIDEO OUTPUT jacks

Adjust the balance of the AUX input level with respect to

Connect to the video input of the monitor.

other inputs (DVD, TAPE, BGM).

E TAPE INPUT LEVEL

Adjust the balance of the TAPE input level with respect to

other inputs (DVD, AUX*, BGM).

* KMA-700 only

F BGM INPUT LEVEL

Adjust the balance of the BGM input level with respect to

other inputs (DVD, AUX*, TAPE).

G SPEAKERS (Speaker system terminal(s))

Connect to the speaker system(s).

For KMA-500, only one speaker system is available.

H AC OUTLETS (Max. total power consumption:

100 W. U.S.A. model only)

Refer to “AC OUTLETS” on page 9.

I AC IN (Except U.S.A. model)

Refer to “AC IN” on page 9.

Power cable (U.S.A. model only)

Plug this cable into an AC wall outlet.

English

J VOLTAGE SELECTOR (Except U.S.A. model)

Refer to “VOLTAGE SELECTOR” on page 9.

5 En

REMOTE CONTROL

Improper use of batteries may cause a risk of battery

Information for Users on Collection and

leakage and explosion.

Disposal of Old Equipment and Used

Adhere to the following guidelines:

• Do not attempt to recharge the old battery.

Batteries

• Insert a battery so that the positive (+) and negative (–)

These symbols on the products,

poles are positioned as shown.

packaging, and/or accompanying

• Even if the shapes are the same, the voltage of batteries

documents mean that used electrical and

may vary depending on the models. Be careful not to

electronic products and batteries should

use different model of battery.

not be mixed with general household

• Dispose of the old battery in accordance with local

waste.

regulations.

For proper treatment, recovery and

recycling of old products and used

batteries, please take them to applicable

collection points, in accordance with your

national legislation and the Directives

2002/96/EC and 2006/66/EC.

By disposing of these products and

batteries correctly, you will help to save

valuable resources and prevent any

potential negative effects on human

health and the environment which could

otherwise arise from inappropriate waste

handling.

For more information about collection

and recycling of old products and

batteries, please contact your local

municipality, your waste disposal service

or the point of sale where you purchased

the items.

[Information on Disposal in other

Countries outside the European

Union]

These symbols are only valid in the

European Union. If you wish to discard

these items, please contact your local

authorities or dealer and ask for the

correct method of disposal.

Note for the battery symbol

(bottom two symbol examples):

This symbol might be used in

combination with a chemical symbol. In

this case it complies with the requirement

set by the Directive for the chemical

involved.

12 En

GENERAL OPERATION

OPERATION

The shaded part ( ) is provided for KMA-700 only.

■ Notes for the proper use of microphones

1 Connect the required number of

• Sing into the microphone by holding it at a distance of 5 to

10 cm (2 to 3-15/16”) from your mouth.

microphones.

• To ensure clear sound, grasp the microphone below the mic

head.

2 Set the POWER switches of this unit and

• Do not block the lower part of the windscreen. This will disturb

other required components to ON.

proper voice reproduction with unclear bass. Howling also

tends to occur in such cases.

3 Play the KARAOKE music source

5 to 10 cm (2 to 3-15/16”)

component, and adjust the volume by

away from your mouth.

rotating MUSIC.

The music source is selected automatically in default

Grasp the microphone below

the head.

setting. To set the conditions for selection, refer to

“Auto input condition” on page 14. To select the

music source manually, refer to “Input mode” on

page 14.

4 Adjust the microphone volume by rotating

MIC.

When different microphone volumes are not

balanced, adjust MIC VOL using a flathead

screwdriver.

5 Adjust the ECHO amount by rotating ECHO.

English

6 Adjust the key by rotating KEY CONTROL.

13 En

SETUP MODE

You can set the following menu in Setup mode:

2. Input mode

• Power ON recall

Set Input mode to Auto or Manual.

• Input mode

Auto*: The input source is set automatically.

• Auto input condition

Manual: The input source is selected by INPUT.

•Enable remote

Source is selected in order of DVD, AUX**, TAPE,

• Remote mode

BGM.

• MIC/MUSIC max level

3. Auto input condition

• MIC/MUSIC volume select

Set the conditions for each source (DVD, AUX** and

• Initializing

TAPE) for Auto Input mode described in 2.

To set each menu above, set the corresponding controls as

Audio*: The source is switched based on audio signal.

shown in the “Setup mode table” on page 15 according to

Video: The source is switched based on video signal.

the following procedure.

Audio/Video: The source is switched based on audio or

video signal.

1 To enter Setup mode, turn off the main unit

For only this menu, select desired source by INPUT

and press POWER while pressing KEY

before selecting the desired item.

CONTROL and ECHO MODE.

4. Enable remote

Enable or disable remote control.

Enable*: The remote control is enabled.

Disable: The remote control is disabled.

5. Remote mode

Set the light receiving device.

Front&Ext.*: Both the front panel and external remote

control satellite receive the signal from the remote control.

2 Set KEY CONTROL and MUSIC according to

Front: Only the front panel receives the signal.

the “Setup mode table” on page 15 to set

Ext.: Only the external remote control satellite receives

desired menus and items.

the signal.

For Auto input condition, select the desired source

6. MIC/MUSIC max level

before selecting the item.

Set the maximum volume of MIC and MUSIC.

Set all settings you want to change before moving to

10*: No setting.

step 3.

9 to 3: The maximum volume is set to the level indicated

(2 to 0 cannot be set).

3 Press KEY CONTROL to enter the settings.

7. MIC/MUSIC volume select

Select how MIC and MUSIC volumes increase/decrease

(i.e., the volume curve) when the controls are turned.

Pattern 1*: Steep curve

Pattern 2: Less steep curve

Pattern 3: Least steep curve, and is most suitable for fine

adjustment.

“ ” blinks once when the settings are entered.

8. Initializing

Reset all the settings set in Setup mode to the defaults.

4 To terminate Setup mode, turn off the main

Cancel: Initializing is not executed.

unit.

Initialize: Initializing is executed.

When pressing KEY CONTROL with MUSIC set to 3,

■ Menus in Setup mode

Initializing is executed.

1. Power ON recall

Select Last memory or Preset, to recall the settings of MIC

volume/ECHO amount/MUSIC volume/ECHO MODE

when the unit is turned on.

* Default setting

Last memory*: The settings when the unit was turned off

** KMA-700 only

last are recalled.

Preset: The settings saved to PRESET 1 are recalled.

14 En

SETUP MODE

■ Setup mode table

Menu KEY CONTROL Items/MUSIC

1. Power ON recall

+1 Last memory: 1 Preset: 2

2. Input mode

+2 Auto: 1 Manual: 2

3. Auto input condition

+3

Select desired source

by INPUT.

Example: DVD

OPERATION

Audio: 1 Video: 2 Audio/Video: 3

4. Enable remote

+4 Enable: 1 Disable: 2

5. Remote mode

+5 Front&Ext.: 1 Front: 2 Ext.: 3

6. MIC/MUSIC max

–1

No setting: 10 Set to the indicated level: 9 to 3

level

Example: 3

7. MIC/MUSIC volume

–2

Pattern 1: 1 Pattern 2: 2 Pattern 3: 3

select

8. Initializing

–5

Cancel: 1 Initialize: 3

English

15 En

ADDITIONAL INFORMATION

TROUBLESHOOTING

If problems should occur, check the following table for simple remedies.

If the problem still cannot be solved, please consult your dealer.

Problems Possible causes Solutions

No speaker sound is

POWER is set to OFF. Set POWER to ON.

output at all.

The power cable is unplugged. Plug the power cable securely into the AC wall outlet.

MUSIC is in the lowest position. Adjust MUSIC.

The wrong music source is selected when

Select the correct music source with INPUT or set Input

Input mode is set to Manual in Setup mode.

mode to Auto in Setup mode. Refer to “Input mode” on

page 14.

The sound is cut off due to a temperature rise

Turn the power off, then leave the unit alone for cooling.

in the unit.

No sound is output from

MUSIC BALANCE is turned fully to one

Set the control to the center position.

one of the speakers.

speaker.

One of the speaker cords is disconnected. Insert the cord securely into the terminals.

No microphone sound is

The microphone plug is not fully inserted. Insert the plug securely into the jack.

output.

The switch on the microphone is set to OFF. Set the switch on the microphone to ON.

The corresponding MIC VOL or MIC controls

Adjust the control.

are in the minimum position.

The microphone is too far from your mouth, or

Refer to the user’s manual supplied with your microphone.

the microphone handling is incorrect.

The remote control does

The remote control is too far away or tilted too

The remote control will function within 6 m (20’) and no

not work, or does not

much.

more than 30 degrees off-center from the front panel.

function properly.

Direct sunlight or lighting is striking the

Reposition this unit.

remote control sensor of this unit.

Enable remote is set to Disable in Setup mode. Set Enable remote to Enable in Setup mode. Refer to

“Enable remote” on page 14.

The wrong Remote mode is set in Setup mode. Set the correct Remote mode in Setup mode. Refer to

“Remote mode” on page 14.

The battery is weak. Replace with a new CR2025 battery. Refer to “Loading a

battery” on page 11.

When INPUT does not work, Input mode is set

Set Input mode to Manual in Setup mode. Refer to “Input

to Auto.

mode” on page 14.

MAINTENANCE

When the set gets dirty, wipe it with a soft, dry cloth.

Never use alcohol, thinner, benzene, insecticide or other volatile agents, for they may damage the surface paint or gloss

of the set.

Also do not wipe the set with a chemical cloth or leave it on the set for a long period, for the surface finish may

deteriorate or the paint may be stripped off.

16 En
