Yamaha DV-C6860: instruction

00cv_DV-C6860_G.fm Page 1 Thursday, March 30, 2006 5:04 PM

G

DVD CHANGER

LECTEUR DE DVD CHANGEUR

DV-C6860

DV-C6860

OWNER’S MANUAL

MODE D’EMPLOI

BEDIENUNGSANLEITUNG

2006

YAMAHA ELECTRONICS CORPORATION, USA

6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.

YAMAHA CANADA MUSIC LTD.

135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA

YAMAHA ELECTRONIK EUROPA G.m.b.H.

SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, GERMANY

YAMAHA ELECTRONIQUE FRANCE S.A.

RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE

YAMAHA ELECTRONICS (UK) LTD.

YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND

YAMAHA SCANDINAVIA A.B.

J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN

YAMAHA MUSIC AUSTRALIA PTY, LTD.

17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA

Printed in China 3139 245 21861

VAROITUS

Important notes for users in the

Muiden kuin tässä esitettyjen toimintojen säädön tai

U.K.

asetusten muutto saattaa altistaa vaaralliselle säteilylle

tai muille vaarallisille toiminnoille.

Mains plug

DK

This apparatus is fitted with an approved 13

Advarsel: Usynlig laserstråling ved åbning når

Amp plug. To change a fuse in this type of plug

sikkerhedsafbrydere er ude af funktion. Undgå

proceed as follows:

utsættelse for stråling.

1 Remove fuse cover and fuse.

Bemærk: Netafbryderen STANDBY/ON er

2 Fix new fuse which should be a BS1362 5 Amp,

sekundært indkoblet og ofbryder ikke strømmen fra

A.S.T.A. or BSI approved type.

nettet. Den indbyggede netdel er derfor tilsluttet til

lysnettet så længe netstikket sidder i stikkontakten.

3 Refit the fuse cover.

N

If the fitted plug is not suitable for your jack

Observer: Nettbryteren STANDBY/ON er sekundert

outlets, it should be cut off and an appropriate

innkoplet. Den innebygdenetdelen er derfor ikke

plug fitted in its place.

frakoplet nettet så lenge apparatet er tilsluttet

If the mains plug contains a fuse, this should

nettkontakten.

have a value of 5 Amp. If a plug without a fuse

S

is used, the fuse at the distribution board should

Klass 1 laseraparat

not be greater than 5 Amp.

Varning! Om apparaten används på annat sätt än i

Note: The severed plug must be disposed to avoid

denna bruksanvisning specificerats, kan användaren

a possible shock hazard should it be inserted into

utsättas för osynlig laserstrålning, som överskrider

a 13 Amp jack elsewhere.

gränsen för laserklass 1.

How to connect a plug

Observera! Strömbrytaren STANDBY/ON är

The wires in the mains lead are coloured with

sekundärt kopplad och inte bryter inte strömmen från

the following code: blue = neutral (N),

nätet. Den inbyggda nätdelen är därför ansluten till

brown = live (L).

elnätet så länge stickproppen sitter i vägguttaget.

● As these colours may not correspond with the

SF

Luokan 1 laserlaite

colour markings identifying the terminals in your

Varoitus! Laitteen käyttäminen muulla kuin tässä

plug, proceed as follows:

käyttöohjeessa mainitulla tavalla saattaa altistaa

– Connect the blue wire to the terminal

käyttäjän turvallisuusluokan 1 ylittävälle

marked N or coloured black.

näkymättömälle lasersäteilylle.

– Connect the brown wire to the terminal

Oikeus muutoksiin varataan. Laite ei saa olla alttiina

marked L or coloured red.

tippu-ja roiskevedelle.

– Do not connect either wire to the earth

Toiminnanvalitsin STANDBY/ON on kytketty

terminal in the plug, marked E (or e) or

toisiopuolelle, eikä se kytke laitetta irti sähköverkosta.

coloured green (or green and yellow).

Sisäänrakennettu verkko-osa on kytkettynä

Before replacing the plug cover, make certain

sähköverkkoon aina silloin, kun pistoke on

that the cord grip is clamped over the sheath of

pistorasiassa.

the lead - not simply over the two wires.

Copyright in the U.K.

VARO!

Recording and playback of material may require

AVATTAESSA JA SUOJALUKITUS

OHITETTAESSA OLET ALTTIINA

consent. See Copyright Act 1956 and The

NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.

Performer’s Protection Acts 1958 to 1972.

ÄLÄ KATSO SÄ TEESEEN.

VARNING!

OSYNLIG LASERSTRÅLNING NÄR DENNA

DEL ÄR ÖPPNAD OCH SPÄRREN ÄR

URKOPPLAD. BETRAKTA EJ STRÅLEN.

i

DANGER

CLASS 1 LASER PRODUCT

This unit emits visible laser radiation when open.

LASER KLASSE 1 PRODUKT

Avoid direct eye exposure to beam.

LUOKAN 1 LASERLAITE

When this unit is plugged into a wall outlet, do not

KLASS 1 LASER APPARAT

PRODUIT LASER DE CLASSE 1

place your eyes close to the opening of the disc

tray and other openings or look inside.

DANGER

Risque d'exposition au laser en cas d'ouverture.

Eviter toute exposition au faisceau.

C

L

A

L

A

S

R

P

R

L

U

O

S

E

P

K

L

A

S

S

1

L

A

L

A

S

S

E

E

1

R

L

A

O

D

R

O

D

I

T

E

A

R

U

C

T

U

K

A

T

T

E

1

Lorsque cet appareil est branché à la prise de

P

R

O

E

R

K

K

A

N

S

S

1

D

U

I

1

L

L

A

S

T

L

A

A

S

E

R

S

E

R

A

P

P

D

E

C

L

A

S

S

courant, ne pas approcher les yeux de l'ouverture

du plateau changeur et des autres ouvertures

pour regarder à l'intérieur.

GEFAHR

CAUTION

VISIBLE AND INVISIBLE LASER RADIATION WHEN

Sichtbare Laserstrahlen bei geöffneter Abdeckung.

OPEN. AVOID EXPOSURE TO BEAM

Achten Sie darauf, nicht direkt in den Laserstrahl zu

ADVARSEL

SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING

blicken.

UNDGÅ UDSÆTTELSE FOR STRÅLING

ADVARSEL

SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL

Wenn das Gerät an die Wandsteckdose angeschlossen

ÅPNES UNNGÅ EKSPONERING FOR STRÅLEN

ist, halten Sie die Augen von der Öffnung des Disc-

VARNING

SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR

Fachs oder anderen Öffnungen fern, und blicken Sie in

DENNA DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN

diesem Fall nicht in das Innere des Geräts.

VA R O !

AVAT TAESSA OLET ALTTIINA NÄKYVÄLLE JA

NÄKYMÄTTÖMÄLLE LASER SÄTEILYLLE, ÄLÄ KATSO SÄTEESEEN

ОПАСНОСТЬ

VORSICHT

SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG

WENN ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETSEN

Данное устройство излучает в открытом

DANGER

VISIBLE AND INVISIBLE LASER RADIATION WHEN

состоянии видимые лазерные лучи. Не

OPEN AVOID DIRECT EXPOSURE TO BEAM

допускайте непосредственного воздействия

ATTENTION

RAYONNEMENT LASER VISIBLE ET INVISIBLE EN

CAS D’OUVERTURE EXPOSITION DANGEREUSE AU FAISCEAU

лазерных лучей на глаза.

Когда данное устройство подключено к

настенной розетке, не приближайте глаза к

ПРЕДУПРЕЖДЕНИЕ

ПРИ ОТКРЫТИИ УСТРОЙСТВА

отверстию лотка для диска и других

ВЫ МОЖЕТЕ ПОДВЕРГНУТЬСЯ ВОЗДЕЙСТВИЮ

отверстий и не смотрите на внутренние части.

ВИДИМОГО И НЕВИДИМОГО ЛАЗЕРНОГО ИЗЛУЧЕНИЯ.

ИЗБЕГАЙТЕ ВОЗДЕЙСТВИЯ ЛУЧА.

CAUTION

Use of controls or adjustments or performance of

LASER SAFETY

procedures other than those specified herein may

This unit employs a laser. Due to possible eye

result in hazardous radiation exposure.

injury, only a qualified service person should

remove the cover or attempt to service this device.

ATTENTION

L’emploi de commandes, de réglages ou un choix

SECURITE LASER

de procédures différents des spécifications de

L’appareil utilise un laser. En raison des risques de

cette brochure peut entraîner une exposition à

blessure des yeux, le retrait du couvercle ou les

d’éventuelles radiations pouvant être dangereses.

réparations de l’appareil devront être confiés

exclusivement à un technicien d’entretien qualifié.

ACHTUNG

Die Verwendung von Bedienungselementen oder

VORSICHT MIT DEM LASER

Einstellungen oder die Durchführung von

Dieses Gerät enthält einen Laser. Um unnötige

Bedienungsvorgängen, die nicht in dieser

Augenverletzungen zu vermeiden, sollten Sie alle

Anleitung aufgeführt sind, kann zu einem Kontakt

Wartungs- und Reparaturarbeiten einem

mit gefährlichen Laserstrahlen führen.

qualifizierten Wartungstechniker überlassen.

ПРЕДУПРЕЖДЕНИЕ

БЕЗОПАСНОЕ ИСПОЛЬЗОВАНИЕ ЛАЗЕРА

Использование органов управления или

Данное устройство содержит лазер. Из-за

настроек или выполнение процедур,

опасности травмирования глаз снимать

отличных от описанных в данном

крышку или обслуживать данное устройство

руководстве, могут привести к опасному

должен только сертифицированный

облучению.

специалист по техническому обслуживанию.

ii

CAUTION: READ THIS BEFORE OPERATING THIS UNIT.

1 To assure the finest performance, please read this

13 Do not attempt to modify or fix this unit. Contact

manual carefully. Keep it in a safe place for future

qualified YAMAHA service personnel when any

reference.

service is needed. The cabinet should never be

2 Install this unit in a well ventilated, cool, dry, clean

opened for any reason.

place — away from direct sunlight, heat sources,

14 When not planning to use this unit for long

vibration, dust, moisture, or cold. In a cabinet,

periods of time (i.e., vacation), disconnect the AC

allow about 2.5cm (1 inch) of free space all

power plug from the wall outlet.

around this unit for adequate ventilation.

15 Be sure to read the “Troubleshooting” section on

3 Locate this unit away from other electrical appliances,

common operating errors before concluding that

motors, or transformers to avoid humming sounds.

this unit is faulty.

4 Do not expose this unit to sudden temperature

16 Before moving this unit, press STANDBY/ON to

changes from cold to hot, nor locate this unit in

set the unit in standby mode, and then disconnect

an environment with high humidity (i.e., a room

the AC power plug from the wall outlet.

with a humidifier) to prevent condensation inside

17 Install this unit near the wall outlet and where the

this unit, which may cause an electrical shock, fire,

AC power plug can be reached easily.

damage to this unit, and/or personal injury.

5 Avoid installing this unit where foreign objects

The unit is not disconnected from the AC power

may fall onto this unit and/or this unit may be

source as long as it is connected to the wall outlet,

exposed to liquid dripping or splashing. On the

even if this unit itself is turned off. This state is called

top of this unit, do not place:

the standby mode. In this state, this unit is designed

– Other components, as they may cause damage

to consume a very small quantity of power.

and/or discoloration on the surface of this unit.

–

Burning objects (i.e., candles), as they may cause

fire, damage to this unit, and/or personal injury.

WARNING

– Containers with liquid in them, as they may fall,

TO REDUCE THE RISK OF FIRE OR ELECTRIC

spilling the liquid and causing an electrical

SHOCK, DO NOT EXPOSE THIS UNIT TO

shock to the user and/or damage to this unit.

RAIN OR MOISTURE.

6 Do not cover this unit with a newspaper, tablecloth,

curtain, etc. in order not to obstruct heat radiation.

Be sure to place this unit on a level surface.

If the temperature inside this unit rises, it may cause

If you do not do so, PLAYXCHANGE operation of

fire, damage to this unit, and/or personal injury.

this unit will not function correctly, and may damage

7 Do not plug in this unit to a wall outlet until all

the disc(s) and/or this unit itself.

connections are complete.

8 Do not operate this unit upside-down. It may

overheat, possibly causing damage.

LASER

9 Do not use excessive force on switches, knobs

Type Semiconductor laser GaAlAs

and/or cords.

Wave length 650 nm (DVD)

10 When disconnecting the power cord from the

780 nm (VCD/CD)

wall outlet, grasp the plug; do not pull the cord.

Output Power 7 mW (DVD)

11 Do not clean this unit with chemical solvents; this

10 mW (VCD/CD)

might damage the finish. Use a clean, dry cloth.

Beam divergence 60 degree

12 Only voltage specified on this unit must be used.

Using this unit with a higher voltage than specified

is dangerous and may cause fire, damage to this

Refer to pages i and ii at the beginning of the

unit, and/or personal injury. YAMAHA will not be

manual for more information.

held responsible for any damage resulting from use

of this unit with a voltage other than as specified.

iii

Contents

Special DVD features .......................................................... 16

Introduction

English

Playing by title.....................................................................................16

Region codes ...........................................................................2

Camera angle......................................................................................16

Supplied accessories...............................................................2

Audio.......................................................................................................17

Notes on discs ........................................................................2

Subtitles..................................................................................................17

Cleaning discs ..........................................................................2

Special VCD & SVCD features ......................................... 17

Patent information.................................................................. 2

Playback control (PBC) .................................................................17

Audio CDs............................................................................. 17

Functional Overview

Playing by discs................................................................................... 17

Front panel...............................................................................3

Playing MP3/JPEG/Kodak picture CDs............................ 17

Rear panel ................................................................................ 4

General operation............................................................................ 17

Remote control.......................................................................5

Selecting a folder and track/file................................................. 18

Special picture disc features .............................................. 18

Preview function (JPEG) ...............................................................18

Connections

Zooming pictures ............................................................................. 18

General notes on connections............................................ 6

Playback with multi-angles...........................................................18

Audio connections .................................................................6

Scan effect............................................................................................. 19

Digital connection................................................................................6

Playing MP3 music and JPEG pictures simultaneously...19

Analog connection..............................................................................6

Video connections..................................................................7

SCART terminal <A>.......................................................................7

Setup Menu

Component video jacks <B>.......................................................7

General setup menu............................................................ 20

Composite video jack <C>...........................................................7

Locking/Unlocking the disc for viewing................................ 20

Dimming the front panel display..............................................20

Programming disc tracks and discs ......................................... 20

Getting Started

OSD language..................................................................................... 22

Inserting batteries into the remote control.....................8

Screen saver......................................................................................... 22

Using the remote control ...............................................................8

Sleep timer ...........................................................................................22

Turning on the power........................................................... 9

Audio setup menu................................................................ 22

About the auto standby function ...............................................9

Setting the analog output............................................................. 23

Setting a TV type and display...............................................9

Setting the digital output.............................................................. 23

Setting a color system for your TV ...........................................9

CD upsampling .................................................................................. 24

Setting an aspect ratio for your TV........................................ 10

Night mode..........................................................................................24

Setting a language preference ............................................11

Video setup menu................................................................ 24

Setting the OSD language ...........................................................11

TV type...................................................................................................24

Setting the audio, subtitle and disc menu languages.....11

Setting the TV display .................................................................... 25

Progressive............................................................................................ 26

Disc Operations

Picture settings ...................................................................................26

Basic playback........................................................................12

Switching the YUV/RGB...............................................................27

General operation................................................................12

Preference setup menu....................................................... 27

Pausing playback................................................................................12

Audio, subtitle and disc menu................................................... 28

Selecting a track/chapter...............................................................13

Restricting playback with parental control ......................... 28

Searching backward/forward......................................................13

PBC (Playback control) .................................................................28

Stopping playback............................................................................. 13

MP3/JPEG menu................................................................................ 28

Selecting the various repeat/shuffle functions................13

Changing the password.................................................................29

Repeat.....................................................................................................13

Resetting the system....................................................................... 29

Repeating a section within a chapter/track........................14

Shuffle (except DVD/VCD/SVCD)........................................14

Language Code .......................... 30

Operations for video playback (DVD/VCD/SVCD).....14

Using the disc menu........................................................................14

Troubleshooting ........................ 32

Slow motion ........................................................................................14

Zooming in...........................................................................................15

Resuming playback from the last stopped point.............15

Glossary ...................................... 34

On-screen display (OSD)............................................................15

Specifications ............................. 35

1 En

Introduction

Thank you for purchasing this unit. This

– Do not use any non-standard shaped

Owner’s Manual explains the basic

discs (heart-shaped, etc.).

operation of this unit.

– Do not use discs with tape, seals, or

paste on their surface. Doing so may

damage this unit.

Region codes

– Do not use discs affixed with labels

printed by a commercially available label

DVD discs must be labeled ALL

regions or Region 2 in order to

ALL

printer.

play on this unit.

You cannot play discs labeled for

2

Cleaning discs

other regions.

• When a disc becomes dirty, clean it

with a cleaning cloth. Wipe the disc

Supplied accessories

from the center out. Do not wipe in a

circular motion.

– Remote control

• Do not use solvents such as benzine,

– Two batteries (AA, R06, UM-3) for the

thinner, commercially available cleaners,

remote control

or antistatic spray intended for analog

– Audio pin cable

records.

– Video pin cable

– Owner’s Manual

Patent information

Notes on discs

Manufactured under license from

Dolby Laboratories. “Dolby”,

– This unit is designed for use with the

“Pro Logic” and the double-D

following discs: DVD-Video, Video CD,

symbol are trademarks of Dolby

Super Video CD, Audio CD, CD-R,

Laboratories.

CD-RW, DVD+RW, DVD+R, DVD-R

“DTS” and “DTS Digital Out” are

and DVD-RW.

trademarks of Digital Theater

– This unit can play:

Systems, Inc.

– MP3 and picture (Kodak, JPEG) files

recorded on CD-R(W).

This product incorporates copyright protection

– JPEG/ISO 9660 format

technology that is protected by method claims

– Maximum 30 characters per display

of certain U.S. patents and other intellectual

property rights owned by Macrovision

– CD-R and CD-RW cannot be played

Corporation and other rights owners. Use of

unless finalized.

this copyright protection technology must be

– Some discs cannot be played depending

authorized by Macrovision Corporation, and is

on the recording conditions, such as the

intended for home and other limited viewing

uses only unless otherwise authorized by

PC environment and application

Macrovision Corporation. Reverse engineering

software. The characteristics and

or disassembly is prohibited.

conditions of some discs (materials,

scratches, curvature, etc.) may result in

playback failure.

– Be sure to use only CD-R and CD-RW

discs made by reliable manufacturers.

2 En

Functional Overview

English

Front panel

1

2

0

9

8

67

5

1 Disc tray

7 S/Q

Loads up to 5 discs in the disc tray.

Searches backward.*

Moves to the previous chapter or track.

2 / (OPEN/CLOSE)

Opens or closes the disc tray.

8 Front panel display

Shows the current status of this unit.

3 PLAYXCHANGE

Reloads or unloads discs without

9 DISC (1, 2, 3, 4, 5) / LEDs

interrupting current disc playback.

Selects and directly plays back the preferred

disc.

4 9 (STOP)

Each LED lights up in orange when this unit

Stops playback.

recognizes that the corresponding disc has

been loaded.

5 B/; (PLAY/PAUSE)

0 STANDBY/ON

Starts or pauses playback.

Turns on this unit or sets it to the standby

mode.

6 R/T

While this unit is in the standby mode, it

Searches forward.*

consumes a small amount of power.

Moves to the next chapter or track.

* Press the button for about two seconds.

3 En

3

Functional Overview

Rear panel

VIDEO

Y

COAXIAL COMPONENT

AUDI O

OUT

DIGITAL

OUT

PR /CR

VIDEO OUT

P

B /CB

1

2

3

4

5

6

1 AUDIO OUT (L, R) jacks

4 AV terminal

Connect to the audio input jacks of your

Connect to SCART input terminal of your

AV receiver or stereo system.

TV.

2 DIGITAL OUT - COAXIAL jack

5 VIDEO OUT - VIDEO jack

Connect to the coaxial input jack of your

Connect to the composite video input jack

AV receiver.

of your AV receiver.

3 VIDEO OUT - COMPONENT

6 AC power cord

(Y, PB/CB, PR/CR) jacks

Connect to a standard AC outlet.

Connect to the component input jacks of

your AV receiver.

Caution: Do not touch the inner pins of the jacks on the rear panel of this unit.

Electrostatic discharge may cause permanent damage to this unit.

4 En

Functional Overview

English

Remote control

6 STOP (9)

Stops playback.

7 SUBTITLE

Selects the subtitle language.

1

8 ANGLE

1

2

3

Selects the DVD camera angle.

4

5

6

q

9 REPEAT

7

8

9

TOP MENU RETURN

ON SCREEN

Repeats the chapter, track, title, disc or

2

0

w

all discs.

MENU SETUP

3

e

0 A-B

ENTER

Repeats a specific segment.

4

r

OK

t

q Numeric buttons (0-9)

5

STOP

PLAY

PAUSE

Selects numbered items in the currently

6

y

displayed menu.

SUBTITLE

ANGLE

ZOOM AUDIO

7

u

REPEAT

A B

SHUFFLE

w ON SCREEN

DISC SKIP

8

i

Accesses or exits from the on-screen

DVD

display (OSD) menu of this unit.

9

o

0

p

e SETUP

Accesses or exits from the setup menu

of this unit.

r T

Searches forward.*

Moves to the next chapter or track.

1

t PLAY (B)

Turns on this unit or sets it to the

Starts playback.

standby mode.

y PAUSE (;)

2 TOP MENU/RETURN

Pauses playback temporarily.

Displays the top-level disc menu (DVD).

Frame-by-frame playback.

Moves back to the previous menu (DVD*/

VCD).

u AUDIO

Selects the audio language or format.

3 MENU

Accesses the menu of a disc (DVD).

i ZOOM

Switches PBC on or off (VCD).

Enlarges the video image.

4 1 / 2/3 / 4

o DISC SKIP

Selects an item in the currently displayed

Selects another disc.

menu. Search or slow playback.

p SHUFFLE

ENTER/OK

Plays tracks in a random order.

Confirms the menu selection.

5 S

* Press and hold the button for about two

Searches backward.*

seconds.

Moves to the previous chapter or track.

5 En

Disc Operations

IMPORTANT!

5 To stop playback, press 9

(STOP) on the

– If the inhibition icon ( or X)

front panel or STOP (9) on the remote

appears on the TV screen when a

control.

button is pressed, the function for

• To play back a specific disc directly,

that button is not available on the

press DISC SKIP repeatedly on the

current disc or at the current time.

remote control or press DISC (1, 2, 3,

– Depending on the DVD or VIDEO

4, 5) on the front panel.

CD disc, some operations may

• Press PLAYXCHANGE on the front

operate differently or be

panel to open the disc tray, and then

restricted.

reload or unload discs without

– Do not push on the disc tray or put

interrupting current disc playback.

any objects other than discs on the

• Playback stops after all discs have been

disc tray. Doing so may cause the

played.

disc player to malfunction.

• When the disc tray is open, press

B/;

(PLAY/PAUSE),

/

(OPEN/CLOSE),

Basic playback

PLAYXCHANGE or

DISC (1, 2, 3, 4, 5) to close the disc

1 Press STANDBY/ON on the front panel

tray automatically.

or on the remote control.

2 Press /

(OPEN/CLOSE) on the front

panel to open the disc tray.

General operation

3 Place discs in the disc tray with the printed

Unless stated otherwise, all operations

side up.

described here are carried out using the

supplied remote control.

Pausing playback

1 During playback, press PAUSE (;).

➜ Playback is paused and the sound is

muted.

2 Press PAUSE (;) again to select the next

4 Press B/;

(PLAY/PAUSE) on the front

picture frame.

panel or PLAY (B) on the remote

control.

3 To resume normal playback, press

➜ The disc tray closes and playback starts

PLAY (B).

automatically for all of the loaded discs

in the tray in sequence.

TIPS: The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the disc.

12 En

Disc Operations

English

Selecting a track/chapter

Selecting the various repeat/

• Press S / T or use the numeric

shuffle functions

buttons (0-9) to select a track/chapter

number.

Repeat

• During repeated playback of a track/

chapter, press S / T to replay the

Repeating chapter/title/disc (DVD)

same track/chapter.

Each time you press REPEAT, the display

changes as follows:

Searching backward/forward

CHAPTER TITLE

1 Press and hold S / T or press 1 / 2.

REPEAT OFF

ALL DISC DISC

2 While searching, press S / T or

1

/ 2 repeatedly to select the desired

CHAPTER*: repeats the current

speed.

chapter

TITLE: repeats the current title

3 To resume normal playback, press

DISC*: repeats the entire disc

PLAY (B).

ALL DISC*: repeats all discs loaded

Notes:

in the tray

– 1

/ 2 key may not be available with some

REPEAT OFF: exits from the repeat mode

discs.

* This feature may not be available with some

– For MP3 and WMA, the search function

discs.

allows you to search the track currently

Repeating track/disc (except DVD)

being played.

Each time you press REPEAT, the display

changes as follows;

Stopping playback

TRACK DISC

• Press STOP (9).

REPEAT OFF ALL DISC

TRACK: repeats the current track

DISC: repeats the entire disc

ALL DISC: repeats all discs loaded in

the tray

REPEAT OFF: exits from the repeat mode

Notes:

– When only one disc is available in the disc

tray, it is continuously played when

ALL DISC is selected.

– For VCD, repeat playback is not available

when the PBC mode is selected.

TIPS: The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the disc.

13 En

Disc Operations

Repeating a section within a

Operations for video playback

chapter/track

(DVD/VCD/SVCD)

1 While playing a disc, press A-B at the

desired starting point.

Using the disc menu

2 Press A-B again at the desired end point.

Depending on the disc, a menu may appear

•A and B can only be set within the same

on the TV screen once you load the disc.

chapter/track.

➜ The selected section repeats

To select a playback feature or item

continuously.

• Use

1 / 2/3 / 4 or the numeric

buttons (0-9) on the remote control,

3 To exit from the sequence, press A-B.

and then press ENTER/OK to start

playback.

Shuffle (except DVD/VCD/SVCD)

To access or exit from the menu

With the shuffle function, you can play

tracks in a random order.

• Press MENU on the remote control.

1 During playback, press SHUFFLE

repeatedly to select between SHUFFLE

Slow motion

DISC, SHUFFLE ALL DISC, and SHUFFLE

You can play back in slow motion.

OFF.

1 Press 3 for reverse slow motion or 4 for

➜ The selected mode appears in the front

forward slow motion.

panel display for several seconds.

2 During slow motion, press 3

/ 4

• In the SHUFFLE DISC mode, all tracks

repeatedly to select the desired speed.

on the disc currently playing are played

3 To resume normal playback, press

in a random order.

PLAY (B).

• In the SHUFFLE ALL DISC mode, tracks

from all discs are played in a random

Note:

order:

– Reverse slow motion is not available for

– If the disc currently playing is a CD, only

VCDs and SVCDs.

tracks from CDs will be played.

– If the disc currently playing is formatted

in MP3 or WMA, tracks on the disc

currently playing are played in a random

order. When all the tracks on that disc

have been played, shuffle playback

continues with the next disc.

TIPS: The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the disc.

14 En

Disc Operations

English

Zooming in

On-screen display (OSD)

This function allows you to enlarge or

The OSD menu shows disc playback

lessen the picture on the TV screen and

information (e.g., the title or chapter

pan through the enlarged picture.

number, elapsed playing time or audio/

subtitle language). A number of operations

1 During playback, press ZOOM repeatedly

are possible without interrupting disc

to display the picture at different scales.

playback.

• Use

1 / 2/3 / 4 to pan through the

enlarged picture.

1 During playback, press ON SCREEN.

➜ Playback continues.

➜ A list of available disc information

appears on the TV screen.

2 Press ZOOM repeatedly to return to the

original size.

DVD

MENU

Resuming playback from the last

TITLE 02/14

stopped point

CHAPTER 02/14

AUDIO 5.1CH

You can resume playback of the last 10

SUBTITLE ENG

discs, even if the discs were ejected or the

BITRATE 16 TITLE ELAPSED 0:02:25

power of this unit was turned off.

1 Load one of the last 10 discs.

VCD/SVCD

➜ “LOADING #” (#: the disc tray number

(1-5)) appears on the TV screen.

MENU

TRACK 02/14

2 Press PLAY (B) while “LOADING #” is

DISC TIME 0:49:17

displayed on the TV screen.

TRACK TIME 0:03:43

➜ “RESUME PLAY” appears on the TV

REPEAT OFF

screen and the disc is played back from

BITRATE 16 TOTAL ELAPSED 0:02:25

the last point.

To cancel the resume mode

2 Press 3 / 4 to view the information, and

then press ENTER/OK to access the

• When playback is stopped, press

selected item.

STOP (9) again.

3 Use the numeric buttons (0-9) to input

the number/time or press 3

/ 4 to make a

selection, and then press ENTER/OK to

confirm the selection.

➜ Playback changes to the selected time

or to the selected title/chapter/track.

TIPS: The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the disc.

15 En

Disc Operations

Title/Chapter/Track selection

Repeat/Time display (DVD/VCD)

(DVD/VCD)

1 Press 3

/ 4 to select [REPEAT] or [TIME

1 Press 3

/ 4 to select [TITLE] or

DISP.].

[CHAPTER] (DVD) or [TRACK] (VCD).

2 Press ENTER/OK to confirm the

2 Press ENTER/OK to confirm the

selection.

selection.

3 Press 3

/ 4 to highlight your selection, and

3 Select a title, chapter or track number

then press ENTER/OK.

using the numeric buttons (0-9).

Time display (CD)

Time search (DVD/VCD)

Each time you press ON SCREEN, the

1 Press 3

/ 4 to select [TT TIME] or [CH

time display changes as follows:

TIME] (DVD) or [TRACK TIME] or [DISC

TOTAL ELAPSED TOTAL REMAIN

TIME] (VCD).

• [TT TIME] refers to the total time of the

SINGLE REMAIN SINGLE ELAPSED

current title, and [CH TIME] refers to

the total time of the current chapter.

2 Press ENTER/OK to confirm the

Special DVD features

selection.

3 Enter hours, minutes and seconds from left

to right using the numeric buttons (0-9)

Playing by title

(e.g. 0:34:27).

1 Press MENU.

➜ The disc title menu appears on the TV

Audio/Subtitle/Angle (DVD)

screen.

You can change [AUDIO], [SUBTITLE] or

[ANGLE] if these functions are available on

2 Use

1 / 2/3 / 4 or the numeric buttons

the disc you are playing.

(0-9) to select a playback option.

1 Press 3

/ 4 to select [AUDIO],

3 Press ENTER/OK to confirm your

[SUBTITLE] or [ANGLE].

selection.

2 Press ENTER/OK to confirm the

selection.

Camera angle

3 For Audio and Subtitle:

• Press ANGLE repeatedly to select the

Press 3

/ 4 to highlight your selection, and

desired angle.

then press ENTER/OK.

OR

For Angle:

Select an angle using the numeric

buttons (0-9).

TIPS: The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the disc.

16 En
