JVC KD-SHX851: ! Select the picture size—“Large”

Graphic displays

Basic procedure

ENGLISH

MENU

Before starting the following procedure,

prepare a CD-R or an SD card including still

! Select the picture size—“Large”

images (pictures) and animations (movies).

or “Small.”

• With Image Converter (Color Ver. 2.0)

Large

included in the supplied CD-ROM, you can

Small

create your own images and animations.

(Samples are included in the CD-ROM.)

• You can store two sizes of picture and

animation—“Large” and “Small” as the

graphic display (see page 5).

⁄

~ Insert a CD-R, an SD card, or the

supplied CD-ROM.

• CD-R/supplied CD-ROM

@ Select the item.

• SD card

Ex.: When “Delete” is selected

• To download the file(s):

\ “Download” (see page 37)

• To delete the file(s):

\ “Delete” (see page 38)

• To delete all files:

\ “AllDelete” (see page 39)

• To activate the file(s):

Ÿ Enter the PICT menu (see page 5).

\ Activating the downloaded files

•

If you press PICT, you can enter the

(see page 40)

PICT menu directly.

36

EN36-40_KD-SHX851[EY]f.indd 36EN36-40_KD-SHX851[EY]f.indd 36 05.4.11 1:58:56 PM05.4.11 1:58:56 PM

2 Select the file type—either “Picture”

IMPORTANT:

or “Movie.”

• Refer also to Image Converter PDF files

included in the “Manual” folder on the

supplied CD-ROM.

ENGLISH

• Still images (pictures) and animations

(movie) should have the following

extension code in their file names:

– jpl: for large size still images

– jpm: for small size still images

– jpa: for large size animations

– jpb: for small size animations

– jpw: for ImageLink (see pages 41 and 58)

• Before you download or delete the files,

observe the following:

The Folder List appears.

– Do not download a file while driving.

– Do not turn off the ignition key of the

3 Select a folder.

car while downloading or deleting a

• You can move to the other lists by

file.*

pressing 4/¢ (

/ ).

– Do not detach the control panel while

downloading or deleting a file.*

* If you do so, the file download or deletion

will not be done correctly.

Downloading the fi les

The File List appears.

• Picture: Graphic screen

To download/delete still images (16 still

images each for large size and for small size)

4 Select a file.

which will be shown while playing a source.

• You can move to the other lists by

• Movie: Graphic screen

pressing 4/¢ (

/ ).

To download/delete animations (60 frames

each for large size and for small size) which

will be shown while playing a source.

Downloading pictures or animations

• It takes a long time to download an animation.

For details, see page 59.

• To activate the downloaded files, see page 40.

1 Follow steps ~ to @ on page 36.

• In step !, select the picture size.

• Then in step @, select “Download.”

To be continued....

37

EN36-40_KD-SHX851[EY]f.indd 37EN36-40_KD-SHX851[EY]f.indd 37 05.4.11 1:58:56 PM05.4.11 1:58:56 PM

5 Download the file.

3 • To delete the stored pictures

1

ENGLISH

• To cancel downloading, press DISP.

• When download is complete, the File List

appears again.

2

Select “Delete.”

6 • To download more pictures from

the same folder, repeat steps 4 and

5.

• To download more pictures from

another folder, press BACK. Then,

repeat steps 3 to 5.

7 Finish the procedure.

DISP

The File List appears.

3

Select a file.

• You can move the other lists by

pressing 4/¢ (

/ ).

Deleting the fi les

Deleting the stored pictures and

animations

1

Follow steps ~ to @ on page 36.

• In step !, select the picture size.

• Then in step @, select “Delete.”

4

2 Select the file type—either “Picture”

or “Movie.”

• When a file is deleted, the File List

appears again.

5

Repeat steps 3 and 4 to delete

more pictures.

Ex.: When “Picture” is selected

38

EN36-40_KD-SHX851[EY]f.indd 38EN36-40_KD-SHX851[EY]f.indd 38 05.4.11 1:58:57 PM05.4.11 1:58:57 PM

• To delete the stored animation

4

1

Ex.: When “Large” is selected

ENGLISH

for the picture size

5

• When all pictures are

Ex.: When “Large” is selected for the

deleted, the PICT menu

picture size

appears again.

2

6 Finish the procedure.

• When the animation

DISP

is deleted, the PICT

menu appears again.

4 Finish the procedure.

DISP

To delete all the stored files

You can delete all stored pictures and

animations of each size (“Large” or “Small”).

1 Follow steps ~ to @ on page 36.

Deleting all the stored pictures and

• In step !, select the picture size.

animations for each size

• Then in step @, select “AllDelete.”

To delete all the stored pictures

You can delete all stored pictures of each size

2

(“Large” or “Small”).

1 Follow steps ~ to @ on page 36.

• In step !, select the picture size.

Ex.: When “Large” is selected

• Then in step @, select “Delete.”

for the picture size

2 Select “Picture.”

3

• When all files are deleted,

the PICT menu appears

again.

3 Select “AllDelete.”

4 Finish the procedure.

DISP

39

EN36-40_KD-SHX851[EY]f.indd 39EN36-40_KD-SHX851[EY]f.indd 39 05.4.11 1:58:57 PM05.4.11 1:58:57 PM

5

Activating the downloaded files

1 Enter the PSM menu (see page

5).

ENGLISH

Picture:

One of your edited still

2 Select “PICT.”

images stored in “Picture”

is activated.

\ Go to step 6.

Slideshow:

All stored still images are

activated and shown in

sequence (UserSlide).

3 Select the picture size you want to

\ Go to step 7.

activate—“Large” or “Small.”

Movie:

Your edited animation

stored in “Movie” is

Large

activated.

Small

\ Go to step 6.

6 Select a file.

4

*

• For “Movie,” select either “Default” or

“UserMovie.” (If no animation is stored,

* If there is no still images or animation

you can only select “Default.”)

downloaded, you can only select

“Default.”

7 Finish the procedure.

• To activate the file for the

other size, repeat steps 1

to 7.

40

EN36-40_KD-SHX851[EY]f.indd 40EN36-40_KD-SHX851[EY]f.indd 40 05.4.11 1:58:58 PM05.4.11 1:58:58 PM

General settings — PSM

3 Adjust the setting.

Basic procedure

You can change PSM (Preferred Setting Mode)

items listed in the table that follows.

ENGLISH

4 Repeat steps 2 and 3 to adjust the

1 Enter the PSM menu (see page

5).

other PSM items if necessary.

2 Select a PSM item.

5 Finish the procedure.

Ex.: When “Scroll” is selected

Indications Selectable settings, [reference page]

Demo/Link

Demo: [Initial]; Display demonstration (animation) appears.

Display

ImageLink: To show a still image while playing back an

demonstration

MP3/WMA track, [17, 19, 58].

Off: Cancels.

• These graphics appear if no operation is done for about 45 seconds.

WallPaper

You can select the background screen of the display window.

Wall paper

Standard 1 [Initial] O Standard 2 O Standard 3

O (back to the beginning)

LevelMeter

You can select the level meter.

Audio level meter

Meter1 [Initial] O Meter2 O Meter3 O (back to the beginning)

• Press DISP repeatedly to show the selected level meter.

PICT

You can activate the graphic screen using either movie or picture, [40].

Pictures

Select the picture size first.

Large: [Initial]; 256 x 64 pixel (full screen size)

Small: 64 x 64 pixel (CD jacket image)

After select the picture size, you can select one of the following items

separately for “Large” and “Small.”

Picture: [Initial]; One of your edited still images stored in

“Picture” is activated.

Slideshow: All stored still images are activated and shown in

sequence (UserSlide).

Movie: Your edited animation stored in “Movie” is activated.

• Press DISP repeatedly to show the selected graphics.

To be continued....
