JVC KD-SHX851: ! Adjust the selected setting item. ~ Enter the SEL menu (see page

Setting the basic sound selection menu—SEL

ENGLISH

MENU

You can adjust the sound characteristics to your

preference.

! Adjust the selected setting item.

~ Enter the SEL menu (see page

5).

Ÿ Select a setting item—“Fad/Bal,”

“Crossover*,” “Subwoofer,” or

• To adjust other SEL settings, press

“VolAdjust.”

BACK. Then repeat steps Ÿ and !.

⁄ Finish the procedure.

Ex.: When “Fad/Bal” is selected

* Appears only when crossover network

is activated (see page 32).

When selecting “Fad/Bal,”

“Crossover,” or “Subwoofer,”

press

to enter the its

submenu.

33

EN32-35_KD-SHX851[EY]f.indd 33EN32-35_KD-SHX851[EY]f.indd 33 05.4.11 1:58:31 PM05.4.11 1:58:31 PM

Select “ON” or “OFF.”

To adjust fader and balance

• If you connect high-range speakers to

—Fad/Bal

Front or Rear output, select “ON” for the

corresponding HPF; otherwise, the speakers

ENGLISH

may be damaged.

• ON / OFF

Adjust the fader*—speaker output balance

between the front and rear speakers.

* When crossover network is activated, speaker

output balance between high-range and mid-

ON:

Activates the filter.

range speakers is adjusted.

\ Press

to adjust

reproduced frequency level and

• F12: Upmost—front only

slope (see below).

• R12: Downmost—rear

only

OFF:

Deactivates the filter.

\ Press

.

Adjust the balance—speaker output balance

“Filter Off OK?” appears, then press

between the left and right speakers.

again.

• L12: Leftmost—left only

To select the cutoff frequency

• R12: Rightmost—right

only

To adjust reproduced frequency

Select an appropriate cutoff frequency level

level—Crossover

according to speakers.

• This setting is available only when crossover

• 1.6 kHz to 16 kHz:

network (see page 32) is activated.

For Front HPF and Rear

To activate the fi lters (HPF/LPF)

LPF

• 31.5 Hz to 200 Hz:

For Rear HPF

To adjust the slope

Select an item.

• Front HPF / Rear LPF /

Rear HPF

Adjust the slope—continuity of sound among

• For Front HPF and Rear HPF: Frequencies

speakers.

lower than the selected level are cut off.

• For Rear LPF: Frequencies higher than the

• –18 / –12 / –6 (dB)

selected level are cut off.

Front HPF:

Adjusts HPF for front speakers.

• As the number becomes higher, the

Rear LPF:

Adjusts LPF for rear speakers.

reproduced band width shared among

speakers becomes wider.

Rear HPF:

Adjusts HPF for rear speakers.

34

EN32-35_KD-SHX851[EY]f.indd 34EN32-35_KD-SHX851[EY]f.indd 34 05.4.11 1:58:31 PM05.4.11 1:58:31 PM

To adjust subwoofer output—

To adjust the input level of each

Subwoofer

source—VolAdjust

To adjust subwoofer level

ENGLISH

This setting is required for each source except

Adjust the subwoofer output level.

FM. Before making an adjustment, select an

appropriate source for which you want to make

• 00 (min.) to 12 (max.)

an adjustment.

Once you have made an adjustment, it

is memorized, and the volume level will

• Press

to adjust reproduced

automatically increase or decrease by adjusted

frequency level and slope.

level whenever you change the source.

To select the cutoff frequency

Adjust to match the input level to the FM sound

level.

• –5 (min.) to +5 (max.)

Select an appropriate cutoff frequency level

according to the subwoofer connected.

• 31.5 Hz to 200 Hz

• Frequencies higher than the selected level are

cut off to the subwoofer.

To adjust the slope

Adjust the slope—continuity of sound among

speakers.

• –18 / –12 / –6 (dB)

• As the number becomes higher, the

reproduced band width shared among

speakers becomes wider.

35
